Lumineux Eyebrook Installation Instructions

Eyebrook
Lens
Downlight
1

READ THESE INSTRUCTIONS

THOROUGHLY BEFORE
INSTALLATION KEEP THESE
INSTRUCTIONS FOR
FUTURE REFERENCE.

IMPORTANT:

This product must be installed
by a qualified electrician or
competent person, and in
accordance with current building
and IET wiring regulations.

BOX CONTENTS

This lighting fixture has been properly
packed to avoid damage during
transit. Before commencing with the
installation carefully inspect the
4
luminaire to confirm there is no
damage. DO NOT INSTALL if any
damage has occurred to the fixture
or any of its components:
• Light Fitting
• Instruction Manual

TOOLS REQUIRED

• Hole Saw
• Screwdriver
• Cable
Manby Business Park, Manby, Lincolnshire, LN11 8UT
Lumineux is a B&T Associates Ltd company.
13W - 4" Downlight, 18W, 25W & 35W - 6" Downlight
INSTALLATION INSTRUCTIONS
2
on
off
L N
LIVE = Brown
NEUTRAL = Blue
5
Technical Helpline: +44 (0)1507 328031
<19
5 YR
IP54
60º
UGR
Warranty
3
1. Cut your required size mounting hole.
2. Using a suitable terminal connector or
3. Connect the LED driver to the downlight using
4. Fit the Downlight into desired location lifting
the fixing levers before installation
5. Re-connect the mains supply
on
DO NOT COVER PRODUCT OR CONTROL GEAR
off
WITH INSULATION OR OTHER MATERIALS
Eyebrook
PLEASE READ THESE INSTRUCTIONS
BEFORE INSTALLATION.
WARNING: Risk of electric shock! Isolate
the mains power before proceeding.
• Turn off the mains power before performing
inspections, installation, or removal
• Verify that the supply voltage is correct by
comparing it with the luminaire label information
• It is the installers responsibility to ensure installation
is suitable for the total load of the luminaire(s). The
supply cable, fuses/circuit brakers must be correctly
rated for the electrical load and considering for any
transient inrush currents that may occur
• Do not perform insulation strength or resistance
tests on installed luminarie(s) connected
(See reverse)
junction box, connect the LED driver to the
mains supply as per wiring diagram
the Twist-N-Lock jack connector
www.lumineux.co.uk
