Carton Inventory

Your garage door opener is packaged in two cartons which
contain the motor unit and all parts illustrated below.
Accessories will depend on the model purchased. If
L O C
K
L I G
H T
Smart Control Panel
2-Conductor Bell Wire
White & White/Red
Safety Sensor
Bracket (2)

INSTALLATION HARDWARE

Hex Bolt 5/16"-18x7/8" (4)
Hex Screw #8 x 3/8" (2)
Lag Screw 5/16"-9x1-5/8" (2)
Lag Screw 5/16"-18x1-7/8" (2)
Clevis Pin 5/16"x2-3/4" (1)
Clevis Pin 5/16"x1-1/4" (1)
Clevis Pin 5/16"x1" (1)
Nut 5/16"-18 (4)
Lock Washer 5/16" (4)
Screw 6ABx1-1/4" (2)
SECURITY✚ ®
3-Button Remote Control
® ®
Motor Unit w/Light Lenses
Trolley
Belt
Pulley Bracket
The Protector System
(2) Safety Reversing Sensors
(1 Sending Eye and 1 Receiving Eye)
with 2-Conductor White & White/Black
Bell Wire attached
anything is missing, carefully check the packing material.
Parts may be stuck in the foam. Hardware for installation
is also listed below.
Optional EverCharge ® Standby
Power System (battery)
Belt
One-Piece
Rail
Header Bracket
®
Self-Threading Screw 1/4"-14x5/8" (2)
Screw 6-32x1" (2)
Insulated Staples (10)
Ring Fastener (3)
Drywall Anchors (2)
Rope
Handle
Rail Grease
Carriage Bolt 1/4"-20x1/2" (2)
Wing Nut 1/4"-20 (2)
5
Remote Control
Visor Clip
Styrofoam
Belt Cap Retainer
Door Bracket
Curved Door
Arm Section
Safety Labels
and
Straight Door
Literature
Arm Section
