Position "II" = hot air stage
The button for increasing temperature (5) and the
button for decreasing temperature (8) allow you to
precisely set the temperature.
Setting the airflow (fig. 1)
The airflow can be adjusted when the two-stage ON/
OFF switch is in position "I" or "II".
The button for increasing airflow (6) and the button
for decreasing airflow (8) allow you to precisely set
the airflow.
Use as a free-standing appliance/cooling (Fig. 2)
Place the appliance upright on a level surface
– to have both hands free to work.
– or to allow the appliance to cool down.
Removing the protective cover (fig. 3)
When working at particularly hard-to-reach locations,
remove the removable protective cover (1) by turning
it and pulling it off the nozzle (2).
m Caution!
Increased risk of burns!
Using the accessory (fig. 1)
Scraper (A): Install the scraper blade between the
two nuts.
The scraper (A) allows you to remove paint, for exa-
mple
Using the nozzles:
Plug the desired nozzle adapter (B-E) onto the nozzle
(2).
Flat nozzle (B) – separating glued joints, softening
paints:
Avoid prolonged exposure to heat as burnt paint can
be very difficult to remove. Many adhesives can be
softened with heat. The glued joints can be separated
and excess glue removed.
Reducer nozzle (C) – welding plastics:
Use the reducer nozzle with heat-shrinkable tubing
and films.
The reflector nozzle (D) is designed for soldering
and shaping tubes, for defrosting water pipes and for
shrinking insulating hoses.
Spatula nozzle (E) – removing paints or varnish:
The spatula shape of the nozzle is designed for tar-
geted hot air delivery. Use it together with a separate
spatula to remove paint and coatings.
14 І GB
 www.scheppach.com  service@scheppach.com  +(49)-08223-4002-99  +(49)-08223-4002-58
Additional usage examples for house, car and
garden
Defrosting water pipes:
Note! Do not use on PVC piping.
Note! Water and gas pipes are often indistinguisha-
ble from the outside. If in doubt, always ask a profes-
sional.
Note! Copper pipes are soldered and may not be
heated to above 200°C.
Releasing screwed joint:
• Heat screwed joints carefully with hot air and the
screws can then usually be removed easily.
Removing weeds:
• The hot air can be used to dry out weeds and seed-
lings.
Cleaning and Servicing
Pull the mains plug before any adjustments,
maintenance or repair.
m Have any work on the device that is not de-
scribed in this instruction guide performed by a
professional. Only use original parts. Allow the
device to cool off before any maintenance or
cleaning is undertaken. There is a risk of burn-
ing!
Always check the device before using it for obvi-
ous defects such as loose, worn or damaged parts,
correct the positioning of screws or other parts. Ex-
change the damaged parts.
Cleaning
Do not use any cleaning agents or solvents. Chemi-
cal substances can etch the plastic parts of the de-
vice. Never clean the device under running water.
• Thoroughly clean the device after every use.
• Clean the ventilation openings and the surface of
the device with a soft brush or cloth.
Service information
Please note that the following parts of this product
are subject to normal or natural wear and that the fol-
lowing parts are therefore also required for use as
consumables.
Wear parts*: Carbon brushes; nozzles, scraper
* Not necessarily included in the scope of delivery!
Storage
Store the device and its accessories in a dark, dry
and frost-proof place that is inaccessible to children.
The optimum storage temperature is between 5 and
30˚C.
Store the electrical tool in its original packaging.
Cover the electrical tool in order to protect it from
dust and moisture.
Store the operating manual with the electrical tool.
