Operating voltage window, typical
Solder-in tips
Browser
SMA adapter
Offset voltage range, typical
Solder-in tips
Browser
SMA adapter
Input range, typical
Solder-in tips
Browser
SMA adapter
Impedance graphs
Figure 27: P77STCABL differential impedance
TDP7700 Series TriMode™ Probes Technical Reference
±5.25 V
±10 V
±4 V
-4 V to +4 V
-10 V to +10 V
-4 V to +4 V
Single-ended
2.5 V
pp
Single-ended
6.0 V
pp
Single-ended
1.2 V
pp
Differential
5.0 V
pp
Differential
12.0 V
pp
Differential
2.0 V
pp
Specifications
25
