Dyna-Glo ANSI Z83.7-2000 Instruction Manual

Propane construction heater.
Hide thumbs

Advertisement

PROPANE CONSTRUCTION HEATER
Dyna-Glo
Delux
RMC-FA40DLX (40,000 BTU/HR, FORCED - AIR)
MODELS:
RMC-FA100DLX (70,000/100,000 BTU/HR, FORCED - AIR)
RMC-FA150DLX (120,000/150,000 BTU/HR, FORCED - AIR)
Dyna-Glo
RMC-FA40A (40,000 BTU/HR, FORCED - AIR)
MODELS:
RMC-FA50A (30,000/50,000 BTU/HR, FORCED - AIR)
RMC-FA100A (70,000/100,000 BTU/HR, FORCED - AIR)
RMC-FA150A (120,000/150,000 BTU/HR, FORCED - AIR)
GENERAL HAZARD WARNING:
FAILURE TO COMPLY WITH THE PRECAUTIONS AND INSTRUCTION PROVIDED
WITH THIS HEATER, CAN RESULT IN DEATH, SERIOUS BODILY INJURY AND
PROPERTY LOSS OR DAMAGE FROM HAZARDS OF FIRE EXPLOSION, BURN,
ASPHYXIATION, CARBON MONOXIDE POISONING, AND/OR ELECTRIC SHOCK.
ONLY PERSONS WHO CAN UNDERSTAND AND FOLLOW THE INSTRUCTIONS
SHOULD USE OR SERVICE THIS HEATER.
IF YOU NEED ASSISTANCE OR HEATER INFORMATION SUCH AS AN
INSTRUCTION MANUAL, LADLES, ETC. CONTACT THE MANUFACTURER.
RETAIN THIS INSTRUCTION MANUAL FOR FUTURE REFERENCE
USER'S INSTRUCTION MANUAL
CSA 2.14-2000, ANSI Z83.7-2000
5/05 Rev.1

Advertisement

Table of Contents

   Related Manuals for Dyna-Glo ANSI Z83.7-2000

   Summary of Contents for Dyna-Glo ANSI Z83.7-2000

  • Page 1 ONLY PERSONS WHO CAN UNDERSTAND AND FOLLOW THE INSTRUCTIONS SHOULD USE OR SERVICE THIS HEATER. IF YOU NEED ASSISTANCE OR HEATER INFORMATION SUCH AS AN INSTRUCTION MANUAL, LADLES, ETC. CONTACT THE MANUFACTURER. RETAIN THIS INSTRUCTION MANUAL FOR FUTURE REFERENCE CSA 2.14-2000, ANSI Z83.7-2000 5/05 Rev.1...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS • Introduction & Specifications ..........•...
  • Page 3: Introduction & Specifications

    Dyna-Glo Propane Forced Air Construction Heaters The heater is designed and approved for use as a construction heater under ANSI Z83.7., CSA2.14 It is hard to anticipate every use which may be made of this heater. FIRE SAFETY AUTHORITY IF YOU HAVE QUESTIONS ABOUT APPLICATIONS. Other standards govern the use of fuel gases and heat producing products in specific applications.
  • Page 4: General Safety Instructions

    GENERAL SAFETY INSTRUCTIONS: Accidents are always tragic especially because so many of them could have been prevented with lit- tle care and judgment. There are some basic good practices, we hope you will follow for safe use of your heater. IMPORTANT SAFETY INFORMATION: •...
  • Page 5: Unpacking Heater

    UNPACKING: 1. Remove heater from carton. 2. Remove all protective packing applied to heater for shipment. 3. Retain cartons and packaging material until unit is operated and found in good condition. 4. Checker heater for any shipping damage. If heater shows any external or internal damage, promptly inform dealer/distributor where you purchased heater.
  • Page 6: Installation To The Propane Gas Tank

    INSTALLATION TO THE PROPANE GAS TANK: IMPORTANT: You must use a propane/LP gas supply cylinder that is compatible with the connec- tion device provided with the hose and regulator. 1. Provide propane/LP supply system (see Propane/LP Supply, page 6). 2. Connect fuel gas fitting hose/regulator assembly to propane LP tank(s). Turn fuel fitting counter- clockwise into threads on tank.
  • Page 7: Leak Checking & Location Heater

    Propane is safe to use when properly handled. Careless handling of the Propane gas tank could result in fire and/or an explosion. Therefore: • Always keep tank/cylinder securely fastened in an upright position. • Avoid tipping tank on its side when connected to a regulator since this may cause damage to diaphragm in regulator.
  • Page 8: Test Firing Heater & Storage

    SHUTDOWN INSTRUCTIONS: Shutoff Heater: WARNING: Motor and fan must be running before lighting, during operation and at shutdown, in order to prevent a flame-out condition which could result in personal injury or property damage. Turn gas valve knob clockwise to OFF position. Turn gas supply OFF by turning Propane tank valve clockwise to close.
  • Page 9: Wiring Diagrams

    PROPANE CONSTRUCTION HEATER ILLUSTRATED 40,000 BTU/Hr - 50,000 BTU/Hr Page 8...
  • Page 10: Troubleshooting

    ILLUSTRATED PARTS BREAKDOWN ITEM DESCRIPTION OUT SHELL HANDELASSEMBLY SCREW MOTOR ASSEMBLY SCREW SUPPORT MOTOR SUPPORT MOTOR SCREW MOTOR BRACKET MOTOR CONDENSER SCREW GUARD FAN POWER CORD PCB ASSEMBLY 13-1 SCREW LEAD WIRE ASSEMBLY CONNECTOR INLET BASE LOWER VALVE 17-1 VALVE KNOB SCREW BASE ASSEMBLY SCREW...
  • Page 11: Replacement Parts List

    PROPANE CONSTRUCTION HEATER ILLUSTRATED 100,000 BTU/Hr - 150,000 BTU/Hr Page 10...
  • Page 12 ILLUSTRATED PARTS BREAKDOWN ITEM DESCRIPTION OUT SHELL HANDELASSEMBLY SCREW MOTOR ASSEMBLY MOTOR FAN MOTOR SUPPORT MOTOR SUPPORT SCREW MOTOR BRACKET MOTOR CONDENSER SCREW GUARD FAN POWER CORD SPARK MODULE CIRCUIT BOARD ASSEMBLY CIRCUIT SCREW LEAD WIRE ASSEMBLY VALVE MPU LEAD WIRE ASSEMBLY CONNECTOR INLET VALVE KNOB SCREW...
  • Page 13 WIRING DIAGRAMS: Page 12...
  • Page 14 WARRANTY SERVICE AND LIMITED WARRANTY CFM Home Products warrants this product to be free from defects in materials and components for two (2) years from the date of first purchase, provided that the product has been properly installed, operated and maintained in accordance with all applicable instructions.
