NOTICE
In Europe, the greenhouse gas emissions of the total
refrigerant charge in the system (expressed as tonnes CO
equivalent) is used to determine the maintenance intervals.
Follow the applicable legislation.
Formula to calculate the greenhouse gas emissions:
GWP value of the refrigerant × Total refrigerant charge [in
kg] / 1000
10.1 Overview: Maintenance and
service
This chapter contains information about:
▪ The yearly maintenance of the outdoor unit
10.2

Maintenance safety precautions

DANGER: RISK OF ELECTROCUTION
DANGER: RISK OF BURNING
NOTICE: Risk of electrostatic discharge
Before performing any maintenance or service work, touch
a metal part of the unit in order to eliminate static electricity
and to protect the PCB.
WARNING
▪ Before carrying out any maintenance or repair activity,
ALWAYS switch off the circuit breaker on the supply
panel, remove the fuses or open the protection devices
of the unit.
▪ Do NOT touch live parts for 10 minutes after the power
supply is turned off because of high voltage risk.
▪ Please note that some sections of the electric
component box are hot.
▪ Make sure you do NOT touch a conductive section.
▪ Do NOT rinse the unit. This may cause electric shocks
or fire.
10.3 Checklist for yearly maintenance
of the outdoor unit
Check the following at least once a year:
▪ Heat exchanger
The heat exchanger of the outdoor unit can get blocked up due to
dust, dirt, leaves, etc. It is recommended to clean the heat
exchanger yearly. A blocked heat exchanger can lead to too low
pressure or too high pressure leading to worse performance.
11

Troubleshooting

11.1

Overview: Troubleshooting

This chapter describes what you have to do in case of problems.
It contains information about solving problems based on symptoms.
Before troubleshooting
Carry out a thorough visual inspection of the unit and look for
obvious defects such as loose connections or defective wiring.
ARXM25~35N2V1B9+RXM20~35N2V1B9
R32 split series
4P518023-5C – 2018.09
11.2

Precautions when troubleshooting

WARNING
2
▪ When carrying out an inspection on the switch box of
the unit, ALWAYS make sure that the unit is
disconnected from the mains. Turn off the respective
circuit breaker.
▪ When a safety device was activated, stop the unit and
find out why the safety device was activated before
resetting it. NEVER shunt safety devices or change
their values to a value other than the factory default
setting. If you are unable to find the cause of the
problem, call your dealer.
DANGER: RISK OF ELECTROCUTION
WARNING
Prevent hazards due to inadvertent resetting of the thermal
cut-out: power to this appliance MUST NOT be supplied
through an external switching device, such as a timer, or
connected to a circuit that is regularly turned ON and OFF
by the utility.
DANGER: RISK OF BURNING
11.3 Solving problems based on
symptoms
11.3.1 Symptom: Indoor units fall, vibrate or
make noise
Possible causes
The indoor units are not installed
securely
11.3.2 Symptom: The unit is NOT heating or
cooling as expected
Possible causes
Wrong connection of the
electrical wires
Gas leakage
11.3.3

Symptom: Water leakage

Possible causes
Incomplete thermal insulation
(gas and liquid piping, indoor
portions of the drain hose
extension)
Improperly connected drainage
11.3.4

Symptom: Electrical leakage

Possible causes
The unit is NOT earthed correctly Check and correct the
11 Troubleshooting
Corrective action
Install the indoor units securely.
Corrective action
Connect the electrical wires
correctly.
Check for gas leakage.
Corrective action
Make sure the thermal insulation
of the piping and the drain hose
is complete.
Secure the drainage.
Corrective action
connection of the earth wiring.
Installer reference guide
21
