Summary of Contents for LG LD-4204T1
- Page 1 DISHWASHER OWNER'S MANUAL MODEL : LD-1420T1 Please read this manual carefully before operating your dishwasher. Retain it for future reference.
-
Page 2: Table Of Contents
ONTENTS SAFETY AND CAUTION INSTALLATION INSTRUCTIONS PARTS NAME FUNCTION OF CONTROL BUTTON BEFORE USING FOR THE FIRST TIME HOW TO USE AND OPERATE OPERATING SEQUENCE PROGRAM USER MAINTENANCE INSTRUCTIONS TROUBLE SHOOTING GUIDE SPECIFICATION... -
Page 3: Safety And Caution
AFETY AND CAUTION IMPORTANT SAFETY INSTRUCTIONS WARNING - When using your dishwasher, follow basic precautions, including the following: • Please read this manual carefully before using • The appliance is to be connected to the water mains using new hose-sets and that old hose- the dishwasher for the first time. - Page 4 AFETY AND CAUTION CAUTION CAUTION concerning the Power Cord Most appliances recommend they be placed upon a dedicated circuit; that is, a single outlet circuit which powers only that appliance and has no additional outlets or branch circuits. Check the specification page of this owner's manual to be certain.
-
Page 5: Installation Instructions
NSTALLATION INSTRUCTIONS WARNING A qualified electrician/plumber or competent person should carry out any electrical/plumbing work required to install this appliance. Step 1 : Step 2 : PREPARE CUPBOARD OPENING PREPARATION FOR ELECTICAL WIRING This dishwasher is designed to fit the size shown as below. - Page 6 NSTALLATION INSTRUCTIONS Step 3 : Step 4 : PREPARING THE DISHWASHER INSTALLING THE FOR INSTALLATION DISHWASHER IN CUPBOARD Lay the dishwasher on its back. Before sliding the dishwasher into the cupboard opening, all necessary height Adjust the legs to the required height and balancing adjustments should be as shown in below figure.
- Page 7 NSTALLATION INSTRUCTIONS Step 5 : When the drain hose is connected to a separate standpipe, it is essential that an DRAIN LINE CONNECTION airtight connection be made. Refer to Fig.B If the end of drain hose does not fit to the drain line, use a rubber connector(not supplied) that is resistant to heat and detergent.
- Page 8 NSTALLATION INSTRUCTIONS Step 8 : Step 6 : HOW TO LEVEL THE DISHWASHER WATER SUPPLY CONNECTION Connect the water supply hose to the After installing the dishwasher, you may water tap as shown.(Some models notice a slight sticking of the door to the consist of an inlet valve and hose.) dishwasher, when you open or close the door.
-
Page 9: Parts Name
ARTS NAME 1. Control Panel 10. Adjustable Leg 2. Door Handle 11. Upper Rack 3. Front Cover 12. Cutlery Rack 4. Lower Cover 13. Detergent And Rinse Aid Dispenser 5. Display Window 14. Vapor Vent Cover 6. Power Button 15. Upper Spray Arm 7. -
Page 10: Function Of Control Button
UNCTION OF CONTROL BUTTON Program Program • To select a program, press this button. • If you want to sterilize the dishes, press UV button. • After drying cycle, the UV lamp will turn on to perform the sterilization function. Indicator •... - Page 11 Indicator Time Left Beep On/Off Rinse Half Load Delay Start Spray Power Child Lock Rinse • Repeated pressing of the Rinse button will select Extra Hot, Rinse+, Extra Hot & Rinse+. • If you select the Extra Hot function, the operationg temperature will be up to 80 . (Dual Wash, Auto, Eco 50) •...
-
Page 12: Before Using For The First Time
EFORE USING FOR THE FIRST TIME 1. Adding Rinse Aid For filling To fill the Rinse Aid chamber, rotate the round cap counter clockwise and remove. Fill the container to the maximum level with a good quality Rinse Aid, then replace and lock the cap. The Rinse Aid is automatically dispensed during the final rinse cycle. -
Page 13: How To Use And Operate
OW TO USE AND OPERATE 1. Loading your Dishwasher Loading examples (Energy test) Dinner plate Dessert plate For better washing performance, always load the dishwasher according to the instructions. Before loading items into the dishwasher clean off large particles of food, in particular insoluble items such as bones, pips, etc. - Page 14 OW TO USE AND OPERATE Loading examples (Energy test) How to use Fold-down dividers at the upper rack can be lowered to improve stacking of dishes. Loading examples (Energy test) Glasses Cups 4. Loading the Upper Rack Knives Saucers It is best to load this with more delicate items such as, small plates, long cutlery, cups, glasses Non Dishwasher Safe Items and dishwasher safe plastic items.
- Page 15 OW TO USE AND OPERATE 5. Adjusting the Upper Rack 6. Adding Detergent Your upper rack can be raised or lowered to • Detergent must be put into the detergent chamber before starting every program except cater for different sized crockery. Before the Pre Wash.
- Page 16 OW TO USE AND OPERATE ATTENTION Push latch to open Using combined detergent products (ex.3 in 1) Some products integrated rinse aid work best specific programs only. Yow will obtain optimum rinsing and drying results by using conventional and separate salt and rinse aid. Place proper Products that replace regeneration salt detergent into this...
- Page 17 OW TO USE AND OPERATE 7. Refilling 8. Drying To assist drying, we recommend that the For refilling Rinse Aid door be partially opened after the cycle. Depending on the dosage setting and the The display will indicate "Cd"(cool dry) for number of washes, the chamber may need to a further 60 minutes after the end of the be topped up, approximately once a month.
-
Page 18: Operating Sequence
PERATING SEQUENCE Before starting, the display window shows Press the “Power” button the running time of the selected program. After starting, the display window shows Check there is rinse aid the remaining time. The time in the display window will start The corresponding indicator lights will to decrease minute by minute. -
Page 19: Program
ROGRAM Running time may vary according to the water temperature, water pressure and voltage. Running time doesn’t include “Cool Dry - 30min”. Wash Rinse Cool Program Heating Pre Wash Pre Wash2 Main Wash Rinse Rinse Dual Wash Auto Eco 50 Gentle Quick Pre Wash... -
Page 20: User Maintenance Instructions
SER MAINTENANCE INSTRUCTIONS To prevent trouble and poor operating, it is important to check filters and spray arms at regular intervals. Filters Lower Spray Arm • Remove the lower rack first. • Check that the water jet holes are not blocked. -
Page 21: Trouble Shooting Guide
ROUBLE SHOOTING GUIDE If a problem occurs check below to see whether this can be solved. In the unlikely event that the problem cannot be rectified, please contact a service engineer. Problem Possible Causes Solution • Plug is not properly inserted into the socket. - Page 22 ROUBLE SHOOTING GUIDE Problem Possible Causes Solution • Straighten hose(s). • The drain hose is kinked. The display shows "OE" • Clean the filter. • The filter is clogged. code. (Water is not • If you can not solve • Motor trouble. pumped away.) the problem, call for (Washing motor or Drain motor)
- Page 24 LD-1420T1 Capacity 14 Place settings Weight See rating label Power Supply See rating label Power Consumption See rating label Water Feed Pressure 0.05 ~ 0.8 MPa The maximum permissible inlet water pressure, in megapascals The minimum permissible inlet water pressure, in megapascals (if this is necessary for the correct operation of the appliance) P/No.: MFL30149772...
