- Page 1 DISHWASHER OWNER'S MANUAL MODEL : LD-4120M Please read this manual carefully before operating your dishwasher. Retain it for future reference.
-
Page 2: Table Of Contents
CONTENTS SAFETY AND CAUTION INSTALLATION INSTRUCTIONS PARTS NAME FUNCTION OF CONTROL BUTTON HOW TO USE AND OPERATE OPERATING SEQUENCE PROGRAM USER MAINTENANCE INSTRUCTIONS TROUBLE SHOOTING GUIDE SPECIFICATION... -
Page 3: Safety And Caution
SAFETY AND CAUTION IMPORTANT SAFETY INSTRUCTIONS WARNING - When using your dishwasher, follow basic precautions, including the following: • Please read this manual carefully before During use using the dishwasher for the first time. • Only suitable household utensils should •... - Page 4 SAFETY AND CAUTION Child Safety • Controls may be locked using “Child Lock” mode to prevent from all the setting from being changed by a child. • Keep children away from detergents and rinse-aids. • Do not allow children to operate the dishwasher. •...
-
Page 5: Installation Instructions
INSTALLATION INSTRUCTIONS If dishwasher is to be installed in a corner, WARNING a minimum 5cm of space is required Any electrical work required to install this between the washer and an adjacent appliance should be carried out by a cabinet or a wall. qualified electrician or competent person. - Page 6 INSTALLATION INSTRUCTIONS Step 3 : Step 4 : PREPARE DISHWASHER FOR INSTALL THE DISHWASHER IN INSTALLATION CUPBOARD Lay the dishwasher on its back. Before sliding the dishwasher into the cupboard opening, all necessary final Adjust the legs to the needed height of height adjustment and balancing adjustment cabinet as shown in below figure.
- Page 7 INSTALLATION INSTRUCTIONS Step 5 : DRAIN LINE CONNECTION ■ When the drain hose is connected to a If the end of drain hose does not fit to the drain line, use a piece of rubber separate stand pipe, it is essential that an connector(not supplied) that must be air tight connection is made.
- Page 8 INSTALLATION INSTRUCTIONS Step 8 : Step 6 : HOW TO LEVEL THE PRODUCT WATER SUPPLY CONNECTION Connect the water supply hose to the After installing the product, if you feel some valve behind dishwasher and the water sticky or hear a frictional sound between the tap as shown in figure.
-
Page 9: Parts Name
PARTS NAME 1. Control Panel 10. Adjust Leg 2. Door Handle 11. Upper Rack 3. Front Cover 12. Cutlery Basket 4. Lower Cover 13. Detergent & Rinse Aid Dispenser 5. Process Monitor 14. Vapor Vent Cover 6. Power Switch 15. Upper Spray Arm 7. -
Page 10: Function Of Control Button
FUNCTION OF CONTROL BUTTON TIME LEFT DELAY START INDICATOR • Before starting, the display window shows the running time of • If you want to delay • Child Lock the selected program. the start of selected • After starting, the display window shows the remaining time. program, press this •... -
Page 11: How To Use And Operate
HOW TO USE AND OPERATE 1. Loading your Dishwasher Be careful large items not to prevent the detergent dispenser lid from opening For the best washing performance, it is important that the dishwasher is loaded according to instructions. 3. Using the Cutlery Basket Before loading items into the dishwasher, you must scrape off large particles in particular non soluble Cutlery should be mixed within each section of... - Page 12 HOW TO USE AND OPERATE 4. Loading the Upper Rack 5. Adjusting the Upper Rack (Not on all models) The upper rack is best loaded with more delicate items, small plates, long cutlery, cups, glasses and dishwasher safe plastic Your upper rack can be raised or lowered to items.
- Page 13 HOW TO USE AND OPERATE 6. Adding Detergent Push latch to open Dispenser • Detergent must be put into the detergent chamber before starting every program except the Pre-Wash. • Please follow the manufacturer’s instructions printed on the manual when determining the correct dosage.
- Page 14 HOW TO USE AND OPERATE 7. Adding Rinse Aid Dispenser � For filling To fill the Rinse Aid chamber, rotate the round cap counter clockwise and remove. Fill the container to the maximum level with a good quality Rinse Aid, then replace and lock the cap.
- Page 15 HOW TO USE AND OPERATE 8. Fold down dividers. 9. Drying (Not on all models) At the end of the program, it is recommended to fully open the door to Fold-down dividers at the lower rack can assist in drying. be lowered to improve stacking of pots and pans.
-
Page 16: Operating Sequence
OPERATING SEQUENCE Press the “Power” button Before starting, the display window shows the running time of the selected program. After starting, the display window shows Check that there is rinse the remaining time. The time in the display window will start to decrease from minute to minute. -
Page 17: Program
PROGRAM ▶According to the water temperature, pressure, voltage, running time may be varied. ▶Running time doesn’t contain “Cool dry - 60 min”. WASH RINSE Cool Program Main Heating Pre Wash Rinse 1 Rinse 2 Rinse 3 Wash Rinse The program sequence is optimized and adapted in accordance Auto with how dirty the dishes are. -
Page 18: User Maintenance Instructions
USER MAINTENANCE INSTRUCTIONS To prevent trouble and poor operating, it is important to check and care for the filters and spray arms at intervals. Filters Upper Spray Arm • Remove the lower rack first. • Pull the upper rack forwards. •... -
Page 19: Trouble Shooting Guide
TROUBLE SHOOTING GUIDE If a problem occurs in your machine, call for service. Before you call for service, check the below instructions to see whether the problem can be solved by yourself first. Problem Possible Causes The lamps do not come •... - Page 20 Capacity 14 Place settings Weight 52 kg Power Supply See rating label Power Consumption See rating label Water Feed Pressure 50 ~ 800 kPa P/No.: 3828DD3002R...
