Full Menu Setup
IP Filter
Provides the IP filtering elements such as On/Off, Priority, Policy and IP Ranges.
The default setting is disabling.
> Enable IP filtering:
Click the Enable IP filtering checkbox to enable the IP address filtering function.
This dialog allows you to add new allowed/denied IP addresses. These can be
added whole ranges (subnets) of IP address can be added directly.
> On/Off: Click the checkbox to active the settings (Priority, Policy, and IP ranges).
> Priority:
The number means a priority if there are duplicated IP address each IP ranges.
> Policy: Determines the filtering attribute of the IP address selected.
> Start IP: Enters the start IP address to ALLOW/ DENY in the IP range selected.
> End IP: Enters the end IP address to ALLOW/ DENY in the IP range selected.
[ NOTE ]
To add a subnet of network addresses, these must be added in CIDR (Classless
Inter-Domain Routing) notation. For example: entering 192.168.1.0/24 will add all
the addresses in the range 192.168.1.1 to 192.168.1.254. Please contact with your
network administrator for more detail.
- If you are accessing the network camera via a proxy server, the IP address for
the proxy server must be added as an allowed address.
ONVIF
ONVIF Authentication: Provides the ONVIF compliance.
56
