Full Menu Setup
> Name: Click in the Name box and type a user favorite event name.
(1 to 31 alphanumeric characters).
Event Trigger : Shows the Event source type to be configured.
> Type: Selects the Event source type.
Event Action : The Event Out provides that the camera will perform certain actions.
> Alarm output: Click the Alarm output port checkbox to enable the Alarm out port.
> E-mail: Click the Email checkbox to enable the emailing below each email address.
To email address, Click the each email addresses checkbox.
[ NOTE ] If you want to additional message when emailing, click in the Subject /
Additional Info box and type a description for the text you are creating.
(0 to 255 alphanumeric characters).
> FTP: Click the FTP checkbox to enable the image uploading to FTP server using
JPEG image.
> Video Boost:
Click to enable to boost the video as set in Event > Actions > Video Boost.
[ NOTE ] Video Boost does not work during SD recording.
> Record: Click the Record checkbox to enable the image recording to SD Card.
> PTZ: Click to enable PTZ preset.
2) Edit Rule
To modify an existing event map list, select it and click the Modify button.
3) Delete Rule
To delete an event map list, select it and click the Delete button.
ONVIF Mapping
●
Enable event mapping via onvif. Click the 'Edit' button to select the event funtions.
1. Send Motion alarm as selected event notification(Motion detection, Tamper,
Alarm In, System Booting, Network Loss, Manual Trigger) through ONVIF.
2. Send Digital Input as selected event notification(Motion detection, Tamper,
Alarm In, System Booting, Network Loss, Manual Trigger) through ONVIF.
