Full Menu Setup
WDR
●
> WDR:
WDR is extended the gain range of the screen that is mostly useful if camera
takes a simultaneous picture of both indoor and outdoor nearby window.
It improves contrast of the picture in outdoor scenery as well as indoor.
Video outputs image processed from two images by dual shutter (long and short
shutter) in a field to provide the best dynamic range.
Highlight area is compensated by the short shutter and dark area is compensated
by the long shutter. Final video may have less contrast compared to the conventional
camera which does not have WDR function.
Set the Mode and Level to enable the backlight compensation function.
> Defog :
Defog detects foggy condition automatically, also provides high contrast picture.
BLC
●
> BLC:
Improves the visibility for the dark object by the bright backlight.
Outside area of BLC window can over saturate.
Set the Mode On to enable the backlight compensation function.
> HLC:
Cuts out the highlight area with black mask and excludes it from compensation.
Set the Mode On/Off and level to enable the highlight compensation function.
