- Page 1 User Manual 1/1.8” Network Camera, 5MP, 2592x1944, Day&Night, D-WDR, C/CS, Indoor IPC-55C0000M0A...
-
Page 2: Table Of Contents
Table of content Parts supplied ......................5 Part names .........................6 Installation instructions ...................7 General Description ....................8 Speci cation ......................9 Quick Network Setup ....................11 Further information ....................11 Full Menu Setup ...................... 12 Web viewer description ..........................12 Setup Menu Table .............................. 13 LIVE VIEW .................................. - Page 3 Safety instructions General safety instructions • • Keep the operating instructions in a safe place for later use. • Installation, commissioning and maintenance of the system may only be carried out by authorised individuals and in accordance with the installation instructions - ensuring that all applicable standards and guidelines are followed.
- Page 4 Class A device note This is a Class A device. This device can cause malfunctions in the living area; in such an event, the operator may need to take appropriate measures to compensate for these. WEEE (Waste Electronical & Electronic Equipment) Correct Disposal of This Product (Applicable in the European Union and other European countries with separate collection systems).
-
Page 5: Parts Supplied
Parts supplied • Box Camera • C-mount adaptor • Dust protection • Torque Wrench: 3mm • CD • Operating Instruction... -
Page 6: Part Names
Part names Mount Holes (Top / Bottom) Rear Case Front Case Dust Protection Cap Torque Wrench PIN 4 PIN 2 DC Iris Damp(-) Damp(+) Back focus adjustment Drive(+) PIN 3 PIN 1 ① IP Reset button ② Alarm input / output terminal ③... -
Page 7: Installation Instructions
Installation instructions CAUTION: The camera’s base should be attached to a structural object, such as concrete, hard wood, wall stud or ceiling rafter that supports the weight of the camera. If necessary use appro- priate mounting material (e.g. anchors) instead of the material enclosed with the camera. -
Page 8: General Description
General Description • 5.04Mega Pixel, NETWORK CAMERA, 2592x1944(15p/12.5p) • ONVIF Conformance • Zero con guration • Cross Web Browsing (IE, Edge, Safari, Firefox, Chrome) • Adaptive web resizing depending on layout & resolution of display device by RESPONSIVE WEB • Increased usability for all PC, tablet and mobile •... -
Page 9: Speci Cation
Speci cation ITEM IPC-55C0000M0A Imaging Sensor 1/1.8" Sony 5.04 Mega pixel RGB Bayer Array CMOS Sensor Effective Pixels 2592(H) x 1944(V) approx. 5Mega pixels Color Mode: 0.07 lux , B/W Mode: 0.005 lux Sensitivity Scanning mode Progressive Scan S/N Ratio 51dB Day &... - Page 10 Speci cation Security Multi User Authority, IP Filtering, HTTPS, Video Stream, Export/Import Network Time Sync. Synchronize Computer/NTP Server, Manual Software Reset Restart, Reset, Factory Default Auto Recovery Backup, Restore Remote Upgrade Using Web Browser Protocol TCP/IP, UDP, IPv4/v6, HTTP, HTTPS, FTP, UPnP, RTP, RTSP, RTCP, DHCP, ARP, Zeroconf, Bonjour Client Software Built-In Web, ONVIF Compatible 3rd Party VMS...
-
Page 11: Quick Network Setup
IP addresses. The network camera‘s default IP address is: 192.168.1.10. 4. Right clicking the device name in the eneo Scan Device tool will bring up the context menu. Use the ‘Open Device Web Site’ option to access the camera. 5. The web viewer login page will open up in your default web browser. -
Page 12: Full Menu Setup
Full Menu Setup Web viewer description XXX-XXXXXXXXXX (A) Menu button : Click the button to show or hide the setup menu bar. (B) Model name : Show a camera model name connected. (C) Select Language : Set the web viewer language English, Deutsch or French. (D) Main setup menu bar : Set the camera or network functions. -
Page 13: Setup Menu Table
Full Menu Setup Setup Menu Table Category Menu Player Control Pause, Snapshot, Speaker, Microphone, Record Display Window Fit, Full Screen, Custom LIVE VIEW Video Stream Stream1, Stream2, Stream3 Protocol HTTP, TCP, UDP PTZ Contol Zoom, Focus, Push AF PLAYBACK Event Search, Timeline Search, Timeline Bar Information General, System Information, Open source Information Source... - Page 14 Full Menu Setup Compression, Sample rate, Bitrate, Input Volume, Output Audio Volume, Audio auto activation on ONVIF access Record Overwrite when storage is full, Continuous record setting Record Schedule Storage Format, Remove, Storage Information Motion, VCA, Tamper, Alarm In, System, Manual, Network, Triggers Timer, Day/Night Actions...
-
Page 15: Live View
Full Menu Setup 1. LIVE VIEW Enter the live view menu on the Web Viewer. ■ Player Control & Display ① Pause : Pauses the live view. ② Snapshot : Captures the image in .jpg format with the current stream resolution. ③... -
Page 16: Ptz Control
Full Menu Setup ■ PTZ Control • ZOOM : Controls the lens optical zoom in/out for WIDE & TELE. • FOCUS : Adjusts the lens focus manually for NEAR & FAR. • PUSH AF : Gets the lens to focus at the push of a button. NOTE ZOOM, FOCUS &... -
Page 17: Playback
Full Menu Setup 2. PLAYBACK 0:00:00 ■ Event Search Playback display using the event list. • Press the input bar to pop up EVENT DATE & TIME window and select the event TYPE. • Click SEARCH button to show up EVENT LIST. •... -
Page 18: Setup
Full Menu Setup 3. SETUP Enter the setup menu on the Web Viewer. 3-1. Information Shows the overall information about the system such as Model name, MAC address, IP address, Zeroconf, IP address, Firmware version, Server time, Running time, CPU usage, Inbound/Outbound Bandwidth and Open source list. - Page 19 Full Menu Setup 3-2-2. Stream 2592x1944 Stream1, 2, 3 ● > COMPRESSION : Video compression codecs are available with H.264 profiles for all streams and additional MJPEG for stream3 only. > RESOLUTION : Each stream can have its individual resolution selected from its list. >...
- Page 20 Full Menu Setup > BITRATE : Indicates the transmission speed through the network and defines the overall picture quality along with the image resolution, frame rate, GOP size and the compression codec for H.264. A high value provides the higher image quality but the total sum of bitrates for the streams has to be considered in calculating the network duty.
- Page 21 Full Menu Setup 3-2-3. Image 2015-10-06 09:50:35 CAM1...
- Page 22 Full Menu Setup Basic ● > BRIGHTNESS: Adjusts the overall brightness of the scene. Increasing the value increases the brightness. > CONTRAST: Adjusts the contrast of the scene. Increasing the value increases the contrast. > SATURATION: Adjusts the color richness of the scene. Increasing the value increases the color richness.
- Page 23 Full Menu Setup ● > MODE : Selects how to control the exposure, AUTOMATIC or MANUAL. > SHUTTER : (Available only in MANUAL mode) Sets the shutter to a fixed value. > MAX. SHUTTER : Sets the maximum exposure time to limit long exposure at night or in low-light scenes.
- Page 24 Full Menu Setup VerticalView ● ( * Built-in Auto Focus Zoom lens or Motor driven V/F lens only ) > MODE : Selects how to control the focus of the built-in Motor driven V/F lens or AF lens. • MANUAL : Focusing works during zoom operation only and stops thereafter. •...
- Page 25 Full Menu Setup [ WARNING ] LENS CALIBRATION is not necessary for regular installations. LENS CALIBRATION would only be necessary should you not be able to focus the lens after a zoom operation due to shock during transportation of the camera. To perform LENS CALIBRATION;...
- Page 26 Full Menu Setup > SWITCHING TIME : Delays switching the day/night filter to prevent from an undesirable transition. > THRESHOLD [D->N] : (Available in AUTOMATIC mode) Sets the threshold level for day->night switching. Decrease the value to switch at low luminance.
- Page 27 Full Menu Setup ● > BLC (Back Light Compensation) : • MODE : ON enhances the visibility of the back-lit object. • LEVEL : Determines the strength of the bright-up. High value gets brighter. > HLC (High Light Compensation) : ON cuts out the highlight area with black mask and excludes it from compensation.
- Page 28 Full Menu Setup > 3DNR : • MODE: ON reduces the noise by cancelling the spatial & temporal components in 3 dimensional a way. • LEVEL: Determines the strength of the noise reduction. Higher values reduce more noise but can also lead to a ghosting effect. ●...
- Page 29 Full Menu Setup VerticalView ● > MODE : ON displays the video in vertical view format, 16:9->9:16 for narrow streets, corridors or hallways. > ROTATION : Determines the orientation to rotate. Mode : On Rotation : 90 degree...
- Page 30 Full Menu Setup 3-2-4. Privacy Mask Mark ENABLE checkbox to activate the privacy masks. > COLOR : Select the color to mask at each privacy area. > NAME : Input the individual name for each privacy mask. To set the privacy mask (up to 8 privacy areas) : 1) Mark ENABLE checkbox.
-
Page 31: Audio
Full Menu Setup 3-2-5. Digital Zoom > Mark ENABLE checkbox to activate the digital zoom. > LEVEL selects the fixed digital zoom ratio. X1.0 is not digital zoomed. 3-3. Audio > Mark ENABLE checkbox to activate the audio. Supports full duplex audio. >... -
Page 32: Record
Full Menu Setup 3-4. Record 3-4-1. Record > Mark OVERWRITE WHEN STORAGE IS FULL checkbox to allow the storage to be overwritten. > CONTINUOUS RECORD SETTING : Mark ENABLE checkbox to activate the continuous recording into the storage. > VIDEO STREAM : Selects the stream to be recorded into the storage. [ NOTE ] SD, SDHC or SDXC memory can be used as a storage device. - Page 33 Full Menu Setup > Mark ENABLE SCHEDULED RECORD checkbox to activate the scheduled recording into the storage. > Mark each box in time and day matrix when to be recorded. It can be selected a time zone or day of the week. 3-4-3.
-
Page 34: Event
Full Menu Setup 3-5. Event 3-5-1. Triggers EVENT TRIGGERS menu defines and sets the parameters for the various event sources. [ Important NOTE ] Once the event is generated, the camera can record the video into the storage, output the alarm signal, email the event, send the video clip to FTP, boost the video frame rate, move to PTZ preset or send the event to the notification server. - Page 35 Full Menu Setup To set the motion detection area (up to 4 include-types and 4 exclude-types) : 1) Mark ENABLE checkbox. 2) In the video window, place the mouse cursor where you would like to make a detection window and click&drag the right button. The following window is then generated. •...
- Page 36 Full Menu Setup > OBJECT SETTING: Click the green rotating icon on the top-right of the video window and OBJECT SETTING menu will appear. To hide it, click the icon again. Mark SHOW OBJECT SIZE checkbox and a black rectangle at the top-left corner of the video window will appear.
- Page 37 Full Menu Setup • SENSITIVITY : Sets the detection sensitivity for the objects. • WIDTH : Sets the minimum/maximum sizes in width of the objects to be detected. • HEIGHT : Sets the minimum/maximum size in height of the objects to be detected. •...
- Page 38 Full Menu Setup Network ● Used to trigger the event when the network connection fails. > Mark ENABLE checkbox to activate the network event. > DWELL TIME : Sets the time for the event once triggered by the network connection event.
- Page 39 Full Menu Setup Timer ● Mark ENABLE checkbox to trigger the event as defined Timer Interval. (Hour/Minute/Second) Day / Night ● Mark ENABLE checkbox to trigger the event when Day/Night is switched. > MODE : Select the mode, Day->Night or Night->Day. >...
- Page 40 Full Menu Setup 3-5-2. Actions EVENT ACTIONS menu defines and sets the parameters for how to treat the various event sources. Record ● > Mark ENABLE checkbox to enable recording into the built-in storage when the event occurs. > VIDEO STREAM : Selects the stream to be recorded when the event occurs. >...
- Page 41 Full Menu Setup • INTERVAL : Sets the interval for emailing after the events occur. • AGGREGATE EVENTS : Sets the number of events which will be sent in an email. > Mark USE MAIL SERVER checkbox to set the mailing server. •...
- Page 42 Full Menu Setup > Mark ENABLE USE(SMTP) AUTHENTICATION checkbox if the mail server requires authentication. • USER NAME : Enter the user name as provided by the network administrator. • PASSWORD : Enter the password as provided by the network administrator. •...
- Page 43 Full Menu Setup • REMOTE DIRECTORY: Specify the path to the directory where the uploaded images will be stored. If this directory doesn’t already exist on the FTP server, an error message shows up when uploading. • USER NAME: Enter the user name provided by the network administrator. •...
- Page 44 Full Menu Setup • PREFIX FILE NAME : Input the prefix for JPEG image file names to be sent to FTP. • ADDITIONAL SUFFIX : Selects the suffix for JPEG image file names to be added after the file name. Selecting NONE will overwrite the previous file and thus DATE &TIME is most preferable.
- Page 45 Full Menu Setup Notification Server ● > Mark ENABLE checkbox to notify the event to the notification server when it occurs. • TYPE : Selects the network protocol to connect the notification server. • SERVER URL : Input the server URL of the notification sever. To enable the audio when the event occurs, copy the URL at SETUP>AUDIO and paste it on the server URL like http://x.x.x.x/setup/audio/audio.php •...
- Page 46 Full Menu Setup 3-5-3. Rules EVENT RULES menu defines and sets the parameters for what to do for the various event sources. Event Processing ● Event process lists have to be generated and can be edited for what to do when the event occurs.
- Page 47 Full Menu Setup > FTP : Mark the checkbox to use FTP as set in SETUP>EVENT>ACTIONS>FTP when the selected event occurs. > VIDEO BOOST : Select the video stream to be boosted up. Video boost is disabled if RECORD is enabled. [ NOTE ] >...
- Page 48 Full Menu Setup ONVIF Mapping ● Onvif mapping is provided to map the various events generated by this camera, but not defined by Onvif, to assign them to Onvif events for the Onvif compatible VMSes or NVRs. Two mappings for Motion and Alarm In are provided to be mapped and can be used by editing them.
-
Page 49: System
Full Menu Setup 3-6. System 3-6-1. Security Users ● Manages the user accounts by names, groups and authorities. > Mark ENABLE ANONYMOUS VIEWR LOGIN if anyone is permitted to login anonymously. Accessing SETUP menu with the anonymous login will exit and require ID/Password login. >... - Page 50 Full Menu Setup HTTPS ● Selects the CONNECTION MODE. Export / Import > HTTP : Transfers data without encryption. Supports a URL that only starts with "HTTP: " > HTTPS : Transfer data with encryption by Hypertext Transfer Protocol over SSL protocol. Supports a URL that only starts with "HTTPS: "...
- Page 51 Full Menu Setup To add a subnet of network addresses, these must be added in CIDR [ NOTE ] (Classless Inter-Domain Routing) notation. For example: entering 192.168.1.0/24 will add all the addresses in the range 192.168.1.1 to 192.168.1.254. Contact your network administrator for more detail.
- Page 52 Full Menu Setup 3-6-2. Date & Time Current Time ● Shows the current date and time. Clicking SAVE tap updates and saves the date and time with the selected time in NEW TIME. New Time ● Select one of the following server times. >...
- Page 53 Full Menu Setup 3-6-3. Network TCP/IP ● > IPv4 ADDRESS : • OBTAIN IP ADRESS VIA DHCP : Gets the IP address assigned by the DHCP (Dynamic Host Configuration Protocol) server. • STATUS : ‘Allocated’ shows that the IP address is obtained from the DHCP. •...
- Page 54 Full Menu Setup > PORT : • HTTP PORT : Use a port number in the range 1024-65535. Default is 80. • HTTPS PORT : Use a port number in the range 1024-65535. Default is 443. • RTSP PORT : Use a port number in the range 1024-65535. Default is 554.
- Page 55 Full Menu Setup DDNS ● (Dynamic Domain Naming Service) > Mark ENABLE checkbox to use DDNS. > DDNS server : Select the DDNS server to use. > Input REGISTERED HOST name, USER NAME, PASSWORD and INTERVAL. [ NOTE ] If the camera has not been registered to the DDNS host previously, the registration is required.
- Page 56 Full Menu Setup ● > START PORT & END PORT : RTP port range defines the range of the ports from which ports of the video/audio are automatically selected. This feature is useful if the camera is connected to a NAT router with manually configured port mapping. Limit the range of the ports permitted for RTP unicast/multicast by entering START PORT and END PORT.
- Page 57 Full Menu Setup UPnP ● UPnP is enabled by default so that the network camera can be automatically detected by operating systems and clients that support this protocol. > FRIENDLY NAME : Enter the name up to 32 alphanumeric characters like Model Name-MAC address.
- Page 58 Full Menu Setup 3-6-4. Language Six languages are available to select from English, Deutsch (German), Français (French), Polski (Polish), Suomi (Finnish), and 한국어 (Korean). 3-6-5. Maintenance Maintain ● > RESTART : Restarts the camera without changing any settings. > RESET : Restarts and loads the factory settings but does not change IP address and PTZ settings.
-
Page 59: User Manual
Full Menu Setup Upgrade ● Bring the firmware file to the drop box or click the drop box to browse for the firmware file, and then click the UPGRADE button. Do not disconnect the power or network cable during firmware UPGRADE. [ CAUTION ] Setup Export ●... -
Page 60: Troubleshooting
Troubleshooting If you suspect a problem is being caused by incorrect configuration or some other minor problem, consult the troubleshooting guide below. Upgrading the Firmware Firmware is software that determines the functionality of the network camera. One of your first actions when troubleshooting a problem should be to check the current firmware. - Page 61 Troubleshooting Poor image quality. Increased lighting can often improve image quality. Check that there is sufficient lighting at the monitored location. Check all image and lighting settings. Rolling dark bands or flickering Try adjusting the Exposure Control setting under AE in image.
