- Page 1 Instruction Manual CM7-DCFP Swing Gate Operator 24V Battery Backup www.calimetco.com 9949 Hayward Way South El Monte, CA, 91733 Tel: (626) 452-9009...
- Page 2 Product Specs PRODUCT SPECS Main AC Supply: 110V AC, System Operating Voltage: 24V DC Maximum Output Current: 30 amp, Fuse: 24V DC 30 amp Remote Control Distance: >150 Feet (50 meters) Maximum Gate Weight: 2500 lbs Maximum Gate Length: 25 Feet LANGUAGES To download this user manual in a different language, visit calimetco.com/manuals Para descargar este manual de usuario en otro idioma, visite calimetco.com/manuals...
- Page 3 UL325 Installation (OPTIONAL) Requirements for UL Compliant Installation UL 325 standard is a safety standard for electric gate openers. If the gate operator installation requires a UL325 installation, follow these instructions. For full instructions, visit the UL325 website. REQUIRED ENTRAPMENT PROTECTION A - Inherent (built-in) Entrapment protection System B1 - Non-contact sensor such as a photo-eye or equivalent B2 - Contact sensor such as edge sensor or equivalent...
- Page 4 UL325 Installation (OPTIONAL) Requirements for UL Compliant Installation Continued Additional UL Requirements • A minimum of two (2) warning signs shall be installed, one on each side of the gate where easily visible. • The gate must have sufficient room when opening and closing. Swinging gates should open inwards and not into public access areas.
-
Page 5: Step 1: Installing The Base
Installation Step 1: Installing the Base The base, also known as a pad is a raised platform. We recommend using a concrete base. Lay out position of 6 wedge anchors by measuring clearance between anchors and inside edge of gate. Figure 1 Install underground conduits in area for conduits. - Page 6 Installation Step 2: Door arm installation Figure 3 After you're satisfied with testing the arm in the full open and closed positions, weld gate bracket and arm. Figure 4 A. Should be at least 1/4 the gate length. NOTE: Uphill or heavy gates should be at least 1/3 gate length.
- Page 7 Installation Figure 5 A. DO NOT allow the arm to touch the gate operator's hood when the gate is in the open position. Too much stress is put on the arm in this position during gate operation. Figure 6 Preferred arm position is 90° from the open gate. NOTE: If dimension between open gate and wall is 20"...
- Page 8 Installation Figure 7 Support bar should be installed at the gate bracket height across the entire gate to keep the gate pickets from bending.
-
Page 9: Step 3: Connecting The Power
Installation Figure 8 Figure 9 Step 3: Connecting the Power MUST use UL approved power wires, power wires MUST have minimum capacity for 15 amp current. 2. All operators MUST be properly grounded in order to prevent an electrical charge. Must use a dedicated circuit for power supply. - Page 10 Installation Step 4: Open Direction See which direction your gate opens when viewed from the inside (exit side). Dip Switch #6 (Figure 10) on the bottom of the gate operator circuit board controls the open direction. = opens to the right, = opens to the left Figure 10 Step 5: Installing the Photo Eye...
- Page 11 Installation Step 6: Gate Travel Limit This controls the position of where the gate stops when it opens and closes. 1. Use a screwdriver to loosen the nails on the top and bottom limit cams 2. Turn left or right on both limit cams to adjust the position of where the gate opens and closes. Figure 9 TIP: Use the OPEN, CLOSE, STOP buttons on the gate operator circuit board for faster testing 3.
- Page 12 Features EMERGENCY RELEASE The emergency release allows you to open the gate manually, such as in cases where there is a power outage and there is no electricity. Opening the gate Disconnect power. Push release pedal downward and move slightly to the right until it is locked in. Hold and push gate to desired direction.
-
Page 13: Entrapment Protection
Features Entrapment Protection Safety and Exit Loop This is an optional step. If you wish to install a exit loop detector, see figure 15 for the position of the safety and exit loops. Figure 15... - Page 14 Features Dual Gates Setup - Master/Slave This setup is for dual swing gates. A single button press of the remote control can open both gates. This requires 2 swing gate operators. One gate operator is the "Master", and the other is the "Slave". 1.
-
Page 15: Control Board Layout
Features Control Board Layout This is a picture of the control board. Use this for reference. Youtube Circuit board Programming Guide: https://youtu.be/_7iBuKr1ZtY Figure 16... - Page 16 Features Connecting Additional Remote Controls By default, the remote controls are already connected to the gate operator. You do not need to do any of the following steps unless you are adding more remote controls. There are two ways to connect your remote control: Study Mode & Numeric Mode. Study Mode Study mode can fit up to 60 different remote controls.
-
Page 17: Dip Switch Features
The second vehicle must get off the loop before the gate closes completely. 5. SLAVE: Secondary operator activation 6. OPEN L/R: Choose gate open direction Left or Right. Installing Non-Calimet Brand Photosensors Figure 19 Follow infrared control instruction to connect power. Common wire is connected to Common... - Page 18 Features Installing an External Receiver External connectors are installed on the rear side of mainboard protector box. Figure 20...
- Page 19 Features Electronic Reversing Device (ERD) The Electronic Reversing Device (ERD) is a feature on the circuit board which detects when the gates comes in contact with an obstruction, causing the gate to reverse. The open and close knobs determine the amount of force required to reverse the gate (figure 22). We generally recommend leaving the knob at 75, or around a 3:00 position.
- Page 20 Features Main Board Light Status Chart Other: 1. BAT: 24V external Battery Connector 2. LOOP DETECTOR: Only compatible with Calimet Loop detector device. 3. RELAY-1: Signal light connector, this light only turns on when door is in motion Name Status/Light...
- Page 21 Features B.L-POWER ON when back up battery is fully charged, blinks when low battery M/S LINK Blinks when master/slave communication is active TIMER Blinks when TIMER is counting down to close automatically OPENING ON when gate is in the open cycle CLOSEING ON when gate is in the close cycle ON when photo eye has malfunctioned...
- Page 22 9949 Hayward Way South El Monte, CA 91733 Tel: 626-452-9009 Alternate: 626-482-3066 Fax: 626-452-9010 Email: info@calimetco.com www.calimetco.com...
