Installation-USA DG68-00108E-01_EN.indd 1
Electric Range
installation manual
imagine
the possibilities
Thank you for purchasing this Samsung product.
To receive more complete service, please register
your product at
www.samsung.com/register
1-800-SAMSUNG(726-7864)
F T Q 3 8 6 * /
F E - R 3 0 0 *
F T Q 3 5 2 * /
F E - R 4 0 0 *
F C Q 3 2 1 * /
F E - R 5 0 0 *
F T Q 3 8 7 * /
F E - R 7 0 0 *
F T Q 3 5 3 * /
F E - N 3 0 0 *
F T Q 3 0 7 * /
F E - N 5 0 0 *
ENGLISH
2011-03-18
4:06:26

Advertisement

   Also See for Samsung FE-N500WX

   Related Manuals for Samsung FE-N500WX

   Summary of Contents for Samsung FE-N500WX

  • Page 1

    This manual is made with 100% recycled paper. Installation-USA DG68-00108E-01_EN.indd 1 imagine the possibilities Thank you for purchasing this Samsung product. To receive more complete service, please register your product at www.samsung.com/register 1-800-SAMSUNG(726-7864) F T Q 3 8 6 * /...

  • Page 2: Before You Begin

    before you begin About this mAnuAl READ THESE INSTRUCTIONS COMPLETELY AND CAREFULLY. Important note to the installer • Read all instructions contained in these installation instructions before installing range. • Remove all packing materials from the oven compartments before connecting the electrical supply to the range.

  • Page 3: Remove Packaging

    preparing to install the range REmoVE PACKAGinG Remove packaging materials. Failure to remove packaging materials could result in damage to the appliance. PREPARE tools & PARts What tools you will need Drill Phillips Screwdriver What’s included with your range Template What’s not included 4-Wire Cord or 3-Wire Cord (UL Approved 40 or 50 AMP)

  • Page 4: Checking The Installation Site

    ChECKinG thE instAllAtion sitE Clearances and dimensions To install the range, refer to the following figure. For installation in CANADA, a Free-standing range is not to be installed closer than 12mm from any adjacent surface. CAUTION CAUTION cabinet temperatures of 194°F. Make sure the wall covering, countertops and cabinets around the range can withstand the heat (up to 194°F) generated by the range.

  • Page 5

    connecting the power stEP 1. mEEtinG ElECtRiCAl ConnECtion REQuiREmEnts CAUTION CAUTION Remove house fuse or open circuit breaker before beginning installation. This appliance must be supplied with the proper voltage and frequency, and connected to an individual properly grounded branch circuit, protected by a circuit breaker or fuse having amperage as specified on the rating plate.

  • Page 6

    stEP 2. ACCEssinG thE PoWER CoRD ConnECtion Remove the rear access cover and loosen the screw with a screwdriver. The terminal block will then be accessible. Terminal block Access cover Specified power-supply-cord kit rating Range rating, watts 120/240 volts 3-wire 8,750 - 16,500 6_ Connecting the power Installation-USA DG68-00108E-01_EN.indd 6...

  • Page 7

    stEP 3. instAllinG thE PoWER CoRD For power cord installations, hook the strain relief over the power cord hole (1 rear of the drawer body. Insert the power cord through the strain relief and tighten the device. Power cord • You must install the power cord with a strain relief. •...

  • Page 8

    Installing a 4-wire power cord WARNING WARNING located in the lower center of the terminal block. The power leads must be connected to the lower left and the lower right terminals of the terminal block. The 4th grounding lead must be connected to the frame of the range with the ground plate and the ground screw.

  • Page 9

    stEP 4. instAllinG thE ConDuit Remove the conduit connection plate from the rear of the drawer body and rotate it as shown below. The conduit hole (1 1. Prepare the conduit cord shown in Figure 1. 2. Install the conduit cord as shown in Figure 2. 1”...

  • Page 10

    Installing a 4-wire conduit • Aluminum building wire may be used but it must be rated for the correct amperage and voltage to make the connection. Connect wires according to this Step 4 depending on the number of wires. • Wire used, location and enclosure of splices, etc., must conform to good wiring practices and local codes.

  • Page 11: Installing The Range

    installing the range instAllinG thE Anti-tiP DEViCE WARNING WARNING installing the Anti-Tip device packed with the appliance. • Refer to the installation instructions supplied with the bracket. • Unless properly installed, the range could be tipped by stepping or sitting on the door. Injury may result from spilled hot liquids or from the range itself.

  • Page 12: Finalizing The Installation

    3. Check your adjustments Use a spirit level to check your adjustments. Place the level diagonally on the oven rack, and check each direction for level. FinAliZinG thE instAllAtion • Move range close enough to the opening to plug into the receptacle. •...
