FMUser FUTV4314A User Manual

4 in 1 mpeg-4 avc/h.264 hd encoder
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司
FUTV4314A 4 in 1 MPEG-4 AVC/H.264 HD Encoder
User Manual
Date: 2015-04-22
Version: 1.0
NMS Version: 2.3.8
SW: 0.02F
HW: 0.8
FMUSER International Group Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FUTV4314A and is the answer not in the manual?

Questions and answers

Related Manuals for FMUser FUTV4314A

Summary of Contents for FMUser FUTV4314A

  • Page 1 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 FUTV4314A 4 in 1 MPEG-4 AVC/H.264 HD Encoder User Manual Date: 2015-04-22 Version: 1.0 NMS Version: 2.3.8 SW: 0.02F HW: 0.8 FMUSER International Group Inc.

  • Page 2: Table Of Contents

    Chapter 4 SNMP Operation ....................... 24 4.1 Installation..........................24 4.2 Software Operation....................... 24 4.3 FUTV4314A 4 in 1 MPEG-4 AVC/ H.264 HD Encoder Operation ........29 4.4 Other Settings........................39 Chapter 5 Troubleshooting ......................42 Chapter 6 Packing list......................... 43...

  • Page 3: Chapter 1 Product Introduction

    Chapter 1 Product Introduction 1.1 Outline The FMUSER FUTV4314A 4 in 1 MPEG-4 AVC/H.264 HD encoder is a professional HD audio & video encoding and multiplexing device with powerful functionality. It has been equipped with 4 HDMI (or SDI) input channels, which allows 4 HD programs can be processed simultaneously.

  • Page 4: Specifications

    FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 1.3 Specifications 4x SDI input FUTV4314A-SDI Input 4x HDMI input FUTV4314A-HDMI 1×ASI input, BNC interface 1920*1080_59.94P, 1920*1080_50P 1920×1080_59.94i, 1920×1080_50i Resolution 1280×720_59.94p, 1280×720_50p 720x576_50i, 720x480_59.94i Encoding MPEG4 AVC/H.264 High Profile Level 4.0 Video Bit-rate 0.8Mbps~19Mbps (each channel)

  • Page 5: Principle Chart

    FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 1.4 Principle Chart 1.5 Appearance and Illustration Front Panel Illustration: Indicate area: All indicators will light on when the device is on the current working state. LCD Screen Power Indicator TS In: Input Lock Indicator CH1 TS out –...
  • Page 6 Lock Key Rear Panel Illustration ( FUTV4314A-HDMI Rear Panel Illustration ( FUTV4314A-SDI 4 * HDMI Input Ports-- FUTV4314A-HDMI 4 * SDI Input Ports-- FUTV4314A-SDI ASI Input Port 2 * ASI Output Ports Data Port (for IP Signal Output) NMS (Network Management Port)

  • Page 7: Chapter 2 Installation Guide

    When users open the package of the device, it is necessary to check items according to packing list. Normally it should include the following items: l FUTV4314A 4 in 1 MPEG-4 AVC/H.264 HD Encoder l User Manual l HDMI Cable for FUTV4314A-HDMI...
  • Page 8 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 2.2.2 Environment Requirement Item Requirement When user installs machine frame array in one machine Machine Hall hall, the distance between 2 rows of machine frames Space should be 1.2~1.5m and the distance against wall should be no less than 0.8m.

  • Page 9: Wire's Connection

    When the device adopts united way, the grounding resistance should be smaller than 1 . FCaution: Before connecting power cord to FUTV4314A 4 in 1 MPEG-4 AVC/H.264 HD 9 / 43...

  • Page 10: Signal Cable Connection

    2.4 Signal Cable Connection The signal connections include the connection of input signal cable and the connection of output signal cable. The details are as follows: 2.4.1 HDMI input cable illustration (FUTV4314A-HDMI): 2.4.2 SDI input cable illustration (FUTV4314A-SDI): 2.4.3 ASI output cable illustration: 2.4.4 Network Cable illustration (CAT5):...
  • Page 11 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 User can firstly find the HDMI or SDI interface on the device according to the connector mark described on the rear panel illustration, and then connect the HDMI or SDI cable (in the accessories). One end is connected to the head-end equipment while the other end to the encoder’s HDMI or SDI input port.
  • Page 12 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 2.4.8 NMS Connection Users can firstly find the NMS interface on the device according to the connector mark described on the rear panel illustration, and then connect the network (CAT5). One end of the network cable is connected to the encoder’s NMS connecter, while the other ends to the computer or the PC.

  • Page 13: Chapter 3 Operation

    FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 Chapter 3 Operation FUTV4314A 4 in 1 MPEG-4 AVC/H.264 HD Encoder’s front panel is user operating interface. Before operating, user can decide whether directly use the default setting or customize the input and output parameters setting. The detail operations go as...

  • Page 14: General Setting

    FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 3.2 General Setting By pressing LOCK key, users can enter in the main menu and set the input and output parameters in the following editing interfaces, the LCD will display the following pages: The option with “ ” is the current selection, users can press the ENTER key to enter the specified submenu to modify the device parameter.
  • Page 15 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 Ø Bitrate By press “Enter” key, user can modify relevant parameter of encoding rate (adjustable range: 0.8M~19M), the specific steps are displayed as follows: 1.1.1.1 Bitrate 8.000Mbps Ø Bitrate Mode User can choose CBR & VBR at this menu. CBR (Constant Bit-rate) means that the bit-rate will be a constant value.
  • Page 16 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 1.1.1.4 Level 03/03 [4.0] 3.2.1.2 Audio Setting 1.1.2.1 Bit Rate 1.1.2.2 Format Ø Audio Bit Rate Setting User can set the input audio bit-rate by pressing the enter key to enter the main editing interface. And there are: 64Kbps, 96Kbps, 112Kbps, 128Kbps, 160Kbps, 192Kbps, 224Kbps, 256 Kbps, 320Kbps, and 384Kbps.
  • Page 17 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 3.2.1.3 System Settings 1.1.3.1 Prog Number 1.1.3.2 Video PID 1.1.3.3 Audio PID 1.1.3.4 PMT PID 1.1.3.5 PCR PID 1.1.3.6 IP Enable 1.1.3.7 Out Address 1.1.3.8 Out Port 1.1.3.9 Null PKT Under this interface, users can set the corresponding system parameters, after the modification, users can press enter key to take the modification into effect.
  • Page 18 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 Ø IP Enable 1.1.3.6 IP Enable 01/01 [NO] Ø Out Address/Out Port Setting User can modify the out address and out port in below interfaces. 1.1.3.7 Out Address 224.002.002.002 1.1.3.8 Out Port 1002 Ø Null Packet 1.1.3.9 Null Packet...
  • Page 19 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 Under this interface, users can decide whether to multiplex the channel encoding stream. YES means that the device multiplexes the encoding stream into the MPTS, while NO means that the output program is SPTS. The LCD will display the following pages after pressing enter key.
  • Page 20 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 This is the new function of this encoder, user can decide whether to open the IP output function by press the ENTER key in this menu, and the operating interface will show the following page: 3.2.3.2 IP Out Address...
  • Page 21 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 3.2.3.6 ASI Output Users can set the ASI output in this interface under this menu, and there are 5 options: MPTS, Channel 1-4. 3.6 ASI Output 01/02 [MPTS] Channel 1 Channel 2 Channel 3 3.2.3.7 UTC Time UTC refers to Universal Time Coordinated.
  • Page 22 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 The MAC address is read-only in the keyboard operation interface, so users can just check the physical address under this interface, and the modification must be done in the network updating tools. 4.5 MAC Address 201012345679 NOTE: The MAC address is unique, and cannot be modified.
  • Page 23 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 defaulted configuration. Users can enter the corresponding menu to select the configuration. The LCD will display the following interfaces: 3.2.7 Version Users can check the device software version and hardware version, and the LCD will display the following interface when users press the ENTER key.

  • Page 24: Chapter 4 Snmp Operation

    FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 Chapter 4 SNMP Operation Network Management System SNMP Network management system is applied to digital TV equipment operation, control and management and parameters setting, etc. It centralizes digital TV equipment through network. 4.1 Installation The software doesn’t need special installation. User can just open the folder SnmpNMS x.xy.z to find the icon...
  • Page 25 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 4.2.2 Main Interface User can create a device node tree in the left column by adding, modifying and deleting the device node. This software provides a powerful node operation function, and the user can edit various parameters in the device tree for management and classification.
  • Page 26 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 The Add Freq Point dialog box popes up when the user clicks the Add Freq Point item in the Edit pull down menu on the menu row. The device will confirm the given frequency while user clicks OK.
  • Page 27 “ ” Or Click “?” to auto search the type of device. NOTE: The default IP of FUTV4314A Encoder is 192.168.002.136, also you can check its IP address in the front panel of device in case the IP changed unexpected.
  • Page 28 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 4.2.6 Delete Equipment User can choose the equipment to be deleted in the left column, and then click the “delete” item in the pull down menu which appears by clicking the right mouse key. 4.2.7 Save Configuration...

  • Page 29: Futv4314A 4 In 1 Mpeg-4 Avc/ H.264 Hd Encoder Operation

    4.3 FUTV4314A 4 in 1 MPEG-4 AVC/ H.264 HD Encoder Operation User can choose the encoder in the device tree; the procedure will display the encoder interface in operating area.
  • Page 30 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 4.3.1 Parameters Setting Users can click Equipment Name on the node tree and enter in the Parameter interface by clicking to configure the parameters. 4.3.1.1 General Parameters User can check version information in this area.
  • Page 31 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 Ø ASI Output Channel This device supports 1 MPTS (Multiple Programs Transport Stream) and 4 SPTS (Single Programs Transport Stream) output. User can click to triger a pull-down list to select the output type. Ø Output Port To set the by modifying the value in this field.
  • Page 32 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 Ø PSI/SI Editor This button will trigger the PSI/SI Editor for some users’ advanced usage. For more detail, please refer to the manual of PSI/SI. 4.3.1.2 Video Parameters (Parameters->Channel->CH0X) Audio Config Area: configure audio manually.
  • Page 33 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 The programs in the left column represent all input programs and which port they come from, while the programs in the right column represent the output programs and from which port they are from. User can parse the programs of each channel and multiplex those programs to the output.
  • Page 34 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 Select the target item and input the new value in the box below, then click to effect the modification. : The parsing overtime value 4.3.3 Tables 4.3.3.1 PID Filter Table 34 / 43...
  • Page 35 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 Users can operate PID filter in this table by checking the check boxes of corresponding items and click CONFIRM to effect. Refresh: getting PID filter table from the device Confirm: submitting the PID filter table to the device...
  • Page 36 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 Input PID and Output PID The Old (Input) PID is the PID number in the TS from given Port. The correspondent New (output) PID number could be same as input PID number while it could be different if a PID remapping is needed.
  • Page 37 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 ：The parameter describes the output TS’s network ID ：The parameter describes the output TS’s network name. Insertion private description ： This checkbox will allow user to insert the private descriptor into the output TS. The private descriptor includes two parts. One is descriptor tag, and the other is descriptor information.
  • Page 38 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 ： Users can add the cable transmission descriptor in this Add button, and it will pop up the following dialogue box, say, the added descriptor is apply for the DVB-C network. The interface will show as below after the NIT parameters being added：...

  • Page 39: Other Settings

    FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 4.4 Other Settings 4.4.1 Difference between Set and Remote Save In many cases during the configuration of parameters in NMS, users save the modified configuration by clicking “Set”, in which way the configuration can only be saved temporarily and will restore the last saved configuration if the device reboots.
  • Page 40 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 Users can click Operate and select Modify IP in the drop-down list, and a dialog box presents itself as shown below. Users input the new NMS IP Address for the device and click OK button to confirm.
  • Page 41 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 After finishing all the parameters setting, user should click button on the toolbar to save the modifications to the device’s flash. 4.4.3 User Add admin When logging in, user will note that the default user name is and no password.

  • Page 42: Chapter 5 Troubleshooting

    FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 Chapter 5 Troubleshooting For guarantee the products’ quality, reliability and stability. All FMUSER products have passed the testing and inspection before shipping out from factory. The testing and inspection scheme already covers all the Optical, Electronic and Mechanical criteria which have been published by FMUSER.

  • Page 43: Chapter 6 Packing List

    FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 Chapter 6 Packing list l FUTV4314A 4 in 1 MPEG-4 AVC/H.264 HD Encoder 1pcs l User manual 1pcs l HDMI cable(FUTV4314A-HDMI) 4pcs l SDI cable(FUTV4314A-SDI) 4pcs l ASI cable 1pcs l Power cord 1pcs 43 / 43...
