- Page 1 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 FUTV4311A MPEG-2/H.264 HD Encoder SW Version: V1.49 HW Version: V1.3.11 Web NMS Version: V1.28 Date: 9 JUNE, 2013...
-
Page 2: About This Manual
The contents of this document are subject to revision without notice due to continued progress in methodology, design and manufacturing. FMUSER shall have no liability for any error or damage of any kind resulting from the use of this document. -
Page 3: Table Of Contents
FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 Directory CHAPTER 1 INTRODUCTION ....................4 1.1 P ......................4 RODUCT VERVIEW 1.2 K ........................4 EATURES 1.3 S ........................5 PECIFICATIONS 1.4 P ........................6 RINCIPLE HART 1.5 A ....................6 PPEARANCE AND ESCRIPTION CHAPTER 2 INSTALLATION GUIDE ..................8 2.1 G ......................8... -
Page 4: Chapter 1 Introduction
FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 Chapter 1 Introduction 1.1 Product Overview FUTV4311A MPEG-2/H.264 HD Encoder is the new broadcasting audio & video encoding and multiplexing device with powerful functionality. It is equipped with multiple video input interfaces (SDI, CVBS, YPbPr and HDMI) and audio input interfaces (AES, RCA and XLR). -
Page 5: Specifications
FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 1.3 Specifications 1×SDI, 1×CVBS, 1×YPbPr and 1×HDMI input Input 2×XLR, 2×RCA and 1×AES inputs 1×ASI input, BNC interface 1920×1080i @59.94Hz, 1920×1080i @50Hz 1280×720p@59.94Hz, 1280×720p @50Hz Resolution 720×480i @59.94Hz, 720×576i @50Hz MPEG-2 HD/SD; MPEG-4 AVC/H.264 HD/SD Encoding 0.25 Mbps~60.5Mbps... -
Page 6: Principle Chart
FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 1.4 Principle Chart 1.5 Appearance and Description Front Panel Illustration ① LCD window ② Indicators ③ Up and down, left and right navigation buttons ④ Enter button: for confirm ⑤ Menu button: for back step ⑥... - Page 7 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 ① SDI input connector ② YPbPr & CVBS input connectors ③ AES, RCA and XLR input connectors ④ HDMI input connector ⑤ ASI input connector ⑥ NMS connector for connecting Web management on PC ⑦ DATA Port (not applicable currently) ⑧...
-
Page 8: Chapter 2 Installation Guide
FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 Chapter 2 Installation Guide This section is to explain the cautions the users must know in some case that possible injure may bring to users when it’s used or installed. For this reason, please read all details here and make in mind before installing or using the product. -
Page 9: Environment Requirement
FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 2.4 Environment Requirement Item Requirement When user installs machine frame array in one machine Machine Hall hall, the distance between 2 rows of machine frames Space should be 1.2~1.5m and the distance against wall should be no less than 0.8m. -
Page 10: Chapter 3 Front Panel Operation
25 mm Chapter 3 Front Panel Operation FUTV4311A’s front panel is user operation interface where users configure the device manually. The LCD is a 2-line * 40-character back-lit dot-matrix user interface with pushbuttons for UP, DOWN, LEFT, RIGHT, ENTER, MENU, and LOCK for front panel control. -
Page 11: Lcd Menus
FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 3.1 LCD Menus An overview of the LCD menus: 11 / 38... -
Page 12: Initial Status
FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 3 Output Setting 3.1 TS Mux Option 3.2 IP Null Packet 3.3 IP Out Mode 3.4 IP Out Address 3.5 IP Out Submask 3.6 IP Out Port 3.7 Service IP 3.8 Source MAC 3.9 Source Gateway 3.10 Output Bit rate... -
Page 13: General Settings For Main Menu
FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 3.3 General Settings for Main Menu Press “LOCK” key on the front panel to enter the main menu. The LCD will display the following pages where user can configure the parameters for the device: 1 Alarm Status... - Page 14 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 Ø Audio Input Press ENTER to enter menu 2.1.1Audio Input. It displays the current mode of audio input. Press ENTER again to enter the setting interface, move the square bracket with LEFT/RIGHT keys to select the target mode and press ENTER to confirm.
- Page 15 If “AC3 Pass” is chosen, user needs to enable the pass-through function at menu “2.1.7 Pass through” Ø Audio Channel FUTV4311A HD Encoder supports both single audio channel and dual audio channels (Audio1 and Audio 2). Audio Channel Multi...
- Page 16 Audio Pass Through [ON] Ø Audio-1/2 PID FUTV4311A HD Encoder supports both single audio channel and dual audio channels (Audio1 and Audio 2). User can edit the audio PID at menus 2.1.8 and 2.1.9. When the audio channel is single, only audio 1 PID is effect, while audio channel is multi, both audio1 and 2 PID are effect.
- Page 17 Make sure the single cables are properly connected. Ø Video Bit Rate FUTV4311A can encode video at range of 0.25 Mbps to 60.50 Mbps (This item is for setting CBR). Video Bit rate 12.00 Mbps...
- Page 18 FUTV4311A supports two Encode Types: H.264 (MPEG4 AVC/H.264) and MPEG2 (see 2.3.2). Modes “4:2:0” is only applicable for H.264 encode type. Ø Rate Control Mode FUTV4311A supports both CBR (Constant Bit Rate) and VBR (Variable Bit Rate) control mode. Rate Control Mode [CBR] Ø...
- Page 19 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 Ø Video/PCR/PMT PID Enter each menu to edit the PIDs. REMARKS: These values are based on decimal system. Video PID 0258 PCR PID 0256 PMT PID 0257 Ø GOP Setting Select GOP structure mode from the options listed.
- Page 20 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 Encode Mode Manual Auto [Manual] Ø Encode Type FUTV4311A supports two Encode Types: H.264 (MPEG4 AVC/H.264) and MPEG2. User can choose to one mode as the video compression type at this menu. Encode Type MPEG 2 H.264 [MPEG 2] Ø...
- Page 21 User can decide whether to filter IP null packet at this menu. Filter IP Null Packet? [No] 3.3.3.3 IP Out Enable FUTV4311A HD encoder supports program stream to output over IP (MPTS or SPTS) through the DATA port. IP Out Mode MPTS...
-
Page 22: Network Setting
FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 3.3.3.4 – 3.3.3.9 User can enter 3.3.3.4 – 3.3.3.9 respectively to check or modify IP Out Address 224.002.002.002 IP Out Mask 255.255.255.000 IP Out Port 1234 Service IP Address 192.168.002.137 Source MAC is read only on the front panel. -
Page 23: Save Configuration
FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 IP Address This is the IP address used for 192.168.000.136 connecting to Web management. Subnet Mask 255.255.255.000 Gateway 192.168.000.001 The MAC is read only on the front MAC Address panel. It is can be modified in the 00:11:22:33:55:11 Web management interface. - Page 24 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 equipment under this submenu. NDS3211A HD Encoder SW: V1.36 HW: V1.3.2 24 / 38...
-
Page 25: Chapter 4 Web Nms Operation
PC (Personal Computer) by connecting the device to web NMS Port. User should ensure that the computer’s IP address is different from the FUTV4311A’s IP address; otherwise, it would cause IP conflict. 4.1 login The default IP address of this device is 192.168.0.136. -
Page 26: Operation
FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 Figure-1 4.2 Operation Ø System Information When we confirm the login, it displays the SYSTEM INFORMATION interface as Figure-2 where user can view the system information. The system automatically reads and displays the current encoding state. - Page 27 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 Red boxes and arrows in Figure 3 and Figure 4 display the hidden menus under different settings. Figure-3 27 / 38...
- Page 28 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 Figure-4 28 / 38...
- Page 29 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 Important Function Remarks: Be careful to apply this function: If the output video has problems, like there is ghost on the screen, users can apply this function to adjust lines or fields to debug. “Help” Function In “Encode Setting”...
- Page 30 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 Figure-5 Figure-6 Ø Output Setting Click “Output Setting” on the left column and it displays interface as Figure-7. User can set the output parameters by inputting a value or selecting a mode in the pull-down list.
- Page 31 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 Figure-7 Ø TS Mux Setting Click “TS Mux Setting” on the left column and it displays interface as Figure-8. This section is for filter programs which are from both the ASI IN and Encoder interfaces (HDMI/SDI/CVBS/YPbPr).
- Page 32 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 Click “Refresh” button to refresh the input/output program list. Select one program in the left box and click this button to transfer the selected program to the right box to output. Similarly, user can click this button to cancel the multiplexed programs from the right box.
- Page 33 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 FUTV4311A HD encoder supports 1 MPTS IP or 8 SPTS IP output. Click “SPTS Setting” on the left column and it displays interface as Figure-10 where user can configure the SPTS output. Figure-10 Select one program and click to add its SPTS information.
- Page 34 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 Figure-12 Click to confirm. Ø Save/Load Config Click “Save/Load Config” on the left column and it displays interface as Figure-13 where user can save new configuration or load existing configuration as per prompts. Figure-13 Ø Network Setting Click “Network Setting”...
- Page 35 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 Figure-14 Ø Update Software Click “Update Software” on the left column and it displays interface as Figure-15 where user can update the software for the device. Click browse button to find the update file and click “Update” button to start updating.
- Page 36 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 Figure-16 Ø Modify Password Click “Modify Password” on the left column and it displays interface as Figure-12 where user can reset the account information as needed. Figure-12 36 / 38...
-
Page 37: Chapter 5 Troubleshooting
FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 Chapter 5 Troubleshooting To guarantee the products’ quality, reliability and stability, all FMUSER’s products have been passed the testing and inspection before ship out factory. The testing and inspection scheme already covers all the Optical, Electronic and Mechanical criteria which have been published by FMUSER. -
Page 38: Chapter 6 Packing List
FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 Ø Maintenance needed Chapter 6 Packing List FUTV4311A MPEG2/H.264HD Encoder User Manual HDMI Cable SDI Cable YPbPr Cable CVBS Cable Audio Cables 2PCs Power Cord 38 / 38...
