- Page 1 广州市汉婷生物技术开发有限公司 FMUSER INTERNATIONAL GROUP INC. FUTV466X SD IRD User’s Manual Web-NMS Version: 1.05 Software: 2.01 Hardware: 1.0 FMUSER International Group Inc...
-
Page 2: About This Manual
The contents of this document are subject to revision without notice due to continued progress in methodology, design and manufacturing. FMUSER shall have no liability for any error or damage of any kind resulting from the use of this document. -
Page 3: Table Of Contents
广州市汉婷生物技术开发有限公司 FMUSER INTERNATIONAL GROUP INC. DIRECTORY Chapter 1 Product Outline .................. 3 1.1 Outline ........................3 1.2 Features ........................3 1.3 Specifications ......................4 1.4 Principle Chart ......................5 1.5 Appearance and description ..................5 Chapter 2 Installation Guide ................7 2.1 Acquisition Check .................... -
Page 4: Chapter 1 Product Outline
Its pluggable structure design greatly facilitates the change of modules (demodulator or decoder) as needed. To meet customers’ various requirements, FUTV466X is also equipped with ASI and IP input, and output with 2 ASI ports and IP port. 1.2 Features... -
Page 5: Specifications
广州市汉婷生物技术开发有限公司 FMUSER INTERNATIONAL GROUP INC. Constellation QPSK, 8PSK 1.3 Specifications Output 1*MPTS & 8*SPTS over UDP, Input RTP/RTSP. 2 x RF (DVB-C, T/T2, S/S2 optional), F type Output 100Base-T Ethernet interface 1×ASI input for re-mux, BNC interface (unicast / multicast) 1xIP input for re-mux (UDP) 2×ASI... -
Page 6: Principle Chart
广州市汉婷生物技术开发有限公司 FMUSER INTERNATIONAL GROUP INC. 1.4 Principle Chart IP Output Tuner 1 ASI Output 1,2 Tuner 2 A/V 1 Decoder Module A/V 2 CAM/CI 1 CAM/CI 2 1.5 Appearance and description Front Panel Illustration: 5 / 43... - Page 7 广州市汉婷生物技术开发有限公司 FMUSER INTERNATIONAL GROUP INC. Rear Panel Illustration 6 / 43...
-
Page 8: Chapter 2 Installation Guide
Chapter 2 Installation Guide 2.1 Acquisition Check When user opens the package of the device, it is necessary to check items according to packing list. Normally it should include the following items: l FUTV466X SD IRD 1pcs l User’s Manual 1pcs... - Page 9 广州市汉婷生物技术开发有限公司 FMUSER INTERNATIONAL GROUP INC. 2.2.2 Environment Requirement Item Requirement When user installs machine frame array in one machine hall, the distance between 2 rows of machine frames should be Machine Hall Space 1.2~1.5m and the distance against wall should be no less than 0.8m.
-
Page 10: Wire's Connection
When the device adopts united way, the grounding resistance should be smaller than 1 . FCaution: Before connecting power cord to FUTV466X SD IRD, user should set the power switch to “OFF”. 9 / 43... -
Page 11: Signal Cable Connection
2.4 Signal Cable Connection The signal connections include the connection of input signal cable and the connection of output signal cable. The details are as follows: 2.4.1 FUTV466X SD IRD Cables Illustration: l IP Input/output Cable Illustration: l Tuner Cable Illustration:... - Page 12 广州市汉婷生物技术开发有限公司 FMUSER INTERNATIONAL GROUP INC. l CVBS & Audio output Cable Illustration: (for connection between the IRD and TV set) 11 / 43...
-
Page 13: Chapter 3 Operation
FMUSER INTERNATIONAL GROUP INC. Chapter 3 Operation The front panel of FUTV466X SD IRD is the user-operating interface and the equipment can be conveniently operated and managed by user according to the procedures displayed on the LCD: Keyboard Function Description: MENU: Cancel current entered value, resume previous setting;... - Page 14 广州市汉婷生物技术开发有限公司 FMUSER INTERNATIONAL GROUP INC. 13 / 43...
- Page 15 广州市汉婷生物技术开发有限公司 FMUSER INTERNATIONAL GROUP INC. 14 / 43...
-
Page 16: General Setting
广州市汉婷生物技术开发有限公司 FMUSER INTERNATIONAL GROUP INC. 3.2 General Setting Switch on the device and after a few seconds’ initialization, it presents start-up pictures as below: SD IRD Start up… Start OK… Bitrate: xx.xxx Mbps l SD IRD: Device’s name l Bitrate: xx.xxx MHz indicates the current ASI output bitrate. - Page 17 FMUSER INTERNATIONAL GROUP INC. 3.2.2 Input Sets FUTV466X supports 2 tuners input, 1 ASI input and 1 IP stream input. Users can enter ‘Input Sets’ to configure the tuner/IP parameters to receive the transport streams and select programs to mux out.
- Page 18 广州市汉婷生物技术开发有限公司 FMUSER INTERNATIONAL GROUP INC. For reading the input TS Locked Mux Program bitrate TS Lock For reading the number Searching Program of programs from Tuner Parse Program Get 7 Programs 1 (or 2) Mux Program (0/7) Process of selecting programs to...
- Page 19 Parse Program 3.2.3 CI Card FUTV466X SD IRD supports 2 CI cards (Card A & Card B) to descramble programs from either encrypted RF, ASI or IP. Users can press ENTER key to enter ‘CI Card’ to configure the 2 cards respectively.
- Page 20 Ø Input TS Mode FUTV466X has 4 signal sources: Tuner 1, Tuner 2, ASI, and IP. One CI card can applied to descramble one channel input signal from the 4 signal sources. ‘Skip CI card’ means to skip the card which is used for FTA stream.
- Page 21 广州市汉婷生物技术开发有限公司 FMUSER INTERNATIONAL GROUP INC. Users can select program(s) from the searched out programs to descramble. The quantity to be descrambled will depend on the CAM/CI performance you apply to. √ 1 CETV 1 2 CCTV 4A Ø Rom Version/Card Status/Descramble Error Users can read the other info about the CI card in the following menus.
- Page 22 广州市汉婷生物技术开发有限公司 FMUSER INTERNATIONAL GROUP INC. TS output mode: Enter this menu to select a TS output mode. Under this mode, users can randomly select programs from any input channel to mux out. TS output mode To transfer programs from Tuner 1/2...
- Page 23 广州市汉婷生物技术开发有限公司 FMUSER INTERNATIONAL GROUP INC. 3.2.5 Decoder Users can press ENTER key to enter ‘Decoder’ to set the video to be decoded. FUTV466X IRD supports 2 separate decoded videos/audios output at the same time. Decoder Decoder 1 Ø Decoder 1/2 Decoder 1 and 2 are for setting the two decoded programs respectively.
- Page 24 广州市汉婷生物技术开发有限公司 FMUSER INTERNATIONAL GROUP INC. NMS IP The IP address for connecting 192.168.000.136 the device to PC Subnet Mask 255.255.255.000 Gateway 192.168.000.001 MAC Address 201012345678 Web NMS Port 00080 Reset Password? 3.2.8 System Users can set the system parameters in this menu. Enter ‘System’ submenus to separately set corresponding parameters.
- Page 25 广州市汉婷生物技术开发有限公司 FMUSER INTERNATIONAL GROUP INC. Save Configuration? Choose yes to save settings. and press ENTER to confirm Load Saved CFG? Choose yes to restore the device into the last saved configuration. Reset All Sets? Choose yes to restore the device into factory’s default configuration.
-
Page 26: Chapter 4 Web-Based Nms Management
广州市汉婷生物技术开发有限公司 FMUSER INTERNATIONAL GROUP INC. Chapter 4 Web-based NMS Management In addition to using front buttons to control the device, users can also control and set the configuration with the web Brower in the PC. 4.1 login The default IP address of this device is 192.168.0.136. (We can modify the IP through the front panel.) -
Page 27: Operation
广州市汉婷生物技术开发有限公司 FMUSER INTERNATIONAL GROUP INC. 4.2 Operation Summary: When we confirm the login, it displays the WELCOME interface as Figure-2 where users can have an overview of the device’s system information and working status. Language shift area System information Input information of... - Page 28 广州市汉婷生物技术开发有限公司 FMUSER INTERNATIONAL GROUP INC. Configure tuner parameters in this area according to your signal source receive programs. Click “Apply” button to apply the input data to start receive signals. Figure-3 Parameters → Input 3 (ASI Input): “Input 3” refers to the ASI source, this page is not applicable as it does not need to configure ASI signal.
- Page 29 Figure-5 Parameters → CI Card: FUTV466X SD IRD supports 2 CI cards (Card A & Card B) to descramble programs from either encrypted RF, ASI or IP. Users can click and enter ‘CI Card’ to configure the 2 cards respectively.
- Page 30 Ø Input TS Mode FUTV466X has 4 signal sources: Tuner 1, Tuner 2, ASI, and IP. One CI card can applied to descramble one channel input signal from the 4 signal sources. ‘Skip CI card’ means to skip the card...
- Page 31 广州市汉婷生物技术开发有限公司 FMUSER INTERNATIONAL GROUP INC. which is used for FTA stream. Ø Card Error Check Users can decide whether to enable or disable the card error check function by checking the box. After configuring the above CI card parameters, click...
- Page 32 广州市汉婷生物技术开发有限公司 FMUSER INTERNATIONAL GROUP INC. Check the program(s) to be descrambled and click button to start descrambling the checked program(s). The program quantity to be descrambled will depend on the CAM/CI performance you apply to. Number before slash indicates the programs which have been descrambled.
- Page 33 广州市汉婷生物技术开发有限公司 FMUSER INTERNATIONAL GROUP INC. Output TS Mode: Under this mode, users can randomly select programs from any input channel to mux out. To transfer programs from Tuner 1/2 out without mux To transfer programs from ASI out without mux...
- Page 34 广州市汉婷生物技术开发有限公司 FMUSER INTERNATIONAL GROUP INC. To refresh the input program information To refresh the output program information Select one input program first and click this button to transfer the selected program to the right box to output. Similarly, user can cancel the multiplexed programs from the right box.
- Page 35 广州市汉婷生物技术开发有限公司 FMUSER INTERNATIONAL GROUP INC. Parameters → PID Pass: Click this button to add new columns. Operation Area Figure-11 After finishing the configuration, click to confirm. Parameters → Decoder: This unit supports to decode two programs to output simultaneously through the CVBS ports. From the menu on left side of the webpage, clicking “Decoder”, it displays the interface where users can...
- Page 36 广州市汉婷生物技术开发有限公司 FMUSER INTERNATIONAL GROUP INC. After finishing the configuration, click to confirm. Parameters → IP Stream: This unit supports TS output in IP (1 MPTS & 8 SPTS). Click “IP Stream” and it displays the interface where users can configure the MPTS & SPTS out parameters. (Figure-13) Figure-13 Parameters →...
- Page 37 广州市汉婷生物技术开发有限公司 FMUSER INTERNATIONAL GROUP INC. Figure-14 System → LCD/Keyboard: From the menu on left side of the webpage, clicking “LCD/Keyboard”, it will display the screen as Figure-15 where to control the device’s front panel. Figure-15 36 / 43...
- Page 38 广州市汉婷生物技术开发有限公司 FMUSER INTERNATIONAL GROUP INC. System → Password: From the menu on left side of the webpage, clicking “Password”, it will display the screen as Figure-16 where to set the login account and password for the web NMS. Figure-16 System → Save/Restore: From the menu on left side of the webpage, clicking “Save/Restore”, it will display the screen as...
- Page 39 广州市汉婷生物技术开发有限公司 FMUSER INTERNATIONAL GROUP INC. Figure-17 System → Backup/Load: From the menu on left side of the webpage, clicking “Backup/Load”, it will display the screen as Figure-18 where to backup or load your configurations. Figure-18 38 / 43...
- Page 40 广州市汉婷生物技术开发有限公司 FMUSER INTERNATIONAL GROUP INC. System → Firmware: From the menu on left side of the webpage, clicking “Firmware”, it will display the screen as Figure-19 where to update firmware for the device. Figure-19 System → Reboot: From the menu on left side of the webpage, clicking “Reboot”, it will display the screen as Figure-20 where to restart the device manually.
- Page 41 广州市汉婷生物技术开发有限公司 FMUSER INTERNATIONAL GROUP INC. Figure-20 40 / 43...
-
Page 42: Chapter 5 Troubleshooting
FMUSER’s ISO9001 quality assurance system has been approved by CQC organization. For guarantee the products’ quality, reliability and stability. All FMUSER products have been passed the testing and inspection before ship out factory. The testing and inspection scheme already covers all the Optical, Electronic and Mechanical criteria which have been published by FMUSER. -
Page 43: Chapter 6 Packing List
CVBS Cable set 2 sets ASI Cable 1pcs Power Cord 1pcs Ordering Guide FUTV466X, ‘X’ should be interpreted as different digits which indicate tuners of different standard. ü FUTV4661 DVB-C SD IRD ü FUTV4664 DVB-T/T2 SD IRD 42 / 43...
