FMUser FUTV4318A User Manual

8 in 1 mpeg4 avc/h.264 hd encoder
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司
FUTV4318A 8 in 1 MPEG4 AVC/H.264 HD Encoder
User's Manual
Date: 2015-04-29
Version: 1.0
NMS Version: 2.2.5
SW: 0.17F
HW: 0.8
FMUSER International Group Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FUTV4318A and is the answer not in the manual?

Questions and answers

Related Manuals for FMUser FUTV4318A

Summary of Contents for FMUser FUTV4318A

  • Page 1 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 FUTV4318A 8 in 1 MPEG4 AVC/H.264 HD Encoder User’s Manual Date: 2015-04-29 Version: 1.0 NMS Version: 2.2.5 SW: 0.17F HW: 0.8 FMUSER International Group Inc.

  • Page 2: Table Of Contents

    CHAPTER 4 SNMP OPERATION ................... 23 4.1 INSTALLATION ........................ 23 4.2 SOFTWARE OPERATION ....................23 4.3 FUTV4318A 8 IN 1 MPEG-4 AVC/ H.264 HD ENCODER OPERATION ......28 4.4 OTHER SETTINGS ......................38 CHAPTER 5 TROUBLESHOOTING ..................42 CHAPTER 6 PACKING LIST ....................43...

  • Page 3: Chapter 1 Product Introduction

    Chapter 1 Product Introduction 1.1 Outline The FMUSER FUTV4318A 8-in-1 MPEG-4 AVC/H.264 HD encoder is our newest professional HD audio & video encoding and multiplexing device with powerful functionality. It is equipped with 8 HDMI channels input supporting MPEG-4 AVC/H.264 High Profile code format &...

  • Page 4: Specifications

    FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 1.3 Specifications 8 HDMI inputs Input 1 ASI input, BNC interface 1920×1080_60P, 1920×1080_50P 1920×1080_60i, 1920×1080_50i Resolution 1280×720_60P, 1280×720 _50P 720x576_50i, 720x480_59.95i Encoding MPEG-4 AVC/H.264 high profile level 4.0 Video Bit-rate 0.8Mbps~19Mbps (each channel) Rate Control...

  • Page 5: Principle Chart

    FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 1.4 Principle Chart 1.5 Appearance and Illustration Front Panel Illustration: Indicate area: All indicators will light on when the device is on the current working state. LCD Screen Power Indicator TS In: Input Lock Indicator...
  • Page 6 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 Rear Panel Illustration: 8 * HDMI Input Ports ASI Input Port 2 * ASI Output Ports Data Port (for IP Signal Output) NMS (Network Management Port) Power Switch and socket Grounding Pole 6 / 43...

  • Page 7: Chapter 2 Installation Guide

    When users open the package of the device, it is necessary to check items according to packing list. Normally it should include the following items: Ø FUTV4318A 8 in 1 MPEG-4 AVC/H.264 HD Encoder Ø User’s Manual Ø HDMI Cable Ø...
  • Page 8 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 2.2.2 Environment Requirement Item Requirement When user installs machine frame array in one Machine Hall machine hall, the distance between 2 rows of machine Space frames should be 1.2~1.5m and the distance against wall should be no less than 0.8m.

  • Page 9: Wire's Connection

    When the device adopts united way, the grounding resistance should be smaller than 1 . FCaution: Before connecting power cord to FUTV4318A 8 in 1 MPEG-4 AVC/H.264 HD Encoder, user should set the power switch to “OFF”. 2.4 Signal Cable Connection...
  • Page 10 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 The signal connections include the connection of input signal cable and the connection of output signal cable. The details are as follows: 2.4.1 HDMI input cable illustration: 2.4.2 ASI output cable illustration: 2.4.3 Network Cable illustration (CAT5): 2.4.4 HDMI input interface connection...
  • Page 11 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 2.4.5 ASI output interface connection User can firstly find the ASI output interface on the device according to the connector mark described on the rear panel illustration, and then connect the ASI cable (in the accessories).

  • Page 12: Chapter 3 Operation

    FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 Chapter 3 Operation FUTV4318A 8 in 1 MPEG-4 AVC/H.264 HD Encoder’s front panel is user operating interface. Before operating, user can decide whether directly use the default setting or customize the input and output parameters setting. The detail operations go as follows:...

  • Page 13: Video Setting

    FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 By pressing LOCK key, users can enter in the main menu and set the input and output parameters in the following editing interfaces, the LCD will display the following pages: The option with “ ” is the current selection, users can press the ENTER key to enter the specified submenu to modify the device parameter.
  • Page 14 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 Ø Bitrate By press “Enter” key, user can modify relevant parameter of encoding rate (adjustable range: 0.8M~19M), the specific steps are displayed as follows: 1.1.1.1 Bitrate 8.000Mbps Ø Bitrate Mode User can choose CBR & VBR at this menu. CBR (Constant Bit-rate) means that the bit-rate will be a constant value.
  • Page 15 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 1.1.1.4 Level 03/03 [4.0] 3.2.1.2 Audio Setting 1.1.2.1 Bit Rate 1.1.2.2 Format Ø Audio Bit Rate Setting User can set the input audio bit-rate by pressing the enter key to enter the main editing interface. And there are: 64Kbps, 96Kbps, 112Kbps, 128Kbps, 160Kbps, 192Kbps, 224Kbps, 256 Kbps, 320Kbps, and 384Kbps.

  • Page 16: System Settings

    FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 3.2.1.3 System Settings 1.1.3.1 Prog Number 1.1.3.2 Video PID 1.1.3.3 Audio PID 1.1.3.4 PMT PID 1.1.3.5 PCR PID 1.1.3.6 IP Enable 1.1.3.7 Out Address 1.1.3.8 Out Port 1.1.3.9 Null PKT Under this interface, users can set the corresponding system parameters, after the modification, users can press enter key to take the modification into effect.
  • Page 17 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 Ø IP Enable 1.1.3.6 IP Enable 01/01 [NO] Ø Out Address/Out Port Setting User can modify the out address and out port in below interfaces. 1.1.3.7 Out Address 224.002.002.002 1.1.3.8 Out Port 1002 Ø Null Packet 1.1.3.9 Null Packet...
  • Page 18 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 enter key. 3.2.2 ASI Setting Users can check the ASI input program amount in this interface, and the LCD will display the following page. Prog: 006 represents the input program is 6 and Out:003 represents 3 of the 6 programs have been multiplexed.

  • Page 19: Asi Output

    FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 3.2.3.2 IP Out Address If users enable the IP output function, then users can set the device IP output address in this interface. After users press the ENTER key, the operating interface will display the following page: 3.2.3.3 IP Out Port...

  • Page 20: Network Setting

    FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 Users can set the ASI output in this interface under this menu, and there are 9 options: MPTS, Channel 1-8. 3.6 ASI Output 01/03 [MPTS] Channel 1 Channel 2 Channel 3 3.2.3.7 UTC Time UTC refers to Universal Time Coordinated. User can enter this menu to set the time as needed and it will then generate the TDT table and show in the user’s STB.
  • Page 21 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 The MAC address is read-only in the keyboard operation interface, so users can just check the physical address under this interface, and the modification must be done in the network updating tools. 4.5 MAC Address 201012345679 NOTE: The MAC address is unique, and cannot be modified.
  • Page 22 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 3.2.7 Version Users can check the device software version and hardware version, and the LCD will display the following interface when users press the ENTER key. 8 in 1 Encoder SW 0.17F HW 08 3.2.8 Language...

  • Page 23: Chapter 4 Snmp Operation

    FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 Chapter 4 SNMP Operation Network Management System SNMP Network management system is applied to digital TV equipment operation, control and management and parameters setting, etc. It centralizes digital TV equipment through network. 4.1 Installation The software doesn’t need special installation. User can just open the folder SnmpNMS x.xy.z to find the icon...
  • Page 24 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 User can create a device node tree in the left column by adding, modifying and deleting the device node. This software provides a powerful node operation function, and the user can edit various parameters in the device tree for management and classification.
  • Page 25 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 The Add Freq Point dialog box popes up when the user clicks the Add Freq Point item in the Edit pull down menu on the menu row. The device will confirm the given frequency while user clicks OK.
  • Page 26 “ ” Or Click “?” to auto search the type of device. NOTE: The default IP of FUTV4318A Encoder is 192.168.0.136, also you can check its IP address in the front panel of device in case the IP changed unexpected.
  • Page 27 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 4.2.6 Delete Equipment User can choose the equipment to be deleted in the left column, and then click the “delete” item in the pull down menu which appears by clicking the right mouse key. 27 / 43...

  • Page 28: Futv4318A 8 In 1 Mpeg-4 Avc/ H.264 Hd Encoder Operation

    4.3 FUTV4318A 8 in 1 MPEG-4 AVC/ H.264 HD Encoder Operation 28 / 43...
  • Page 29 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 User can choose the encoder in the device tree; the procedure will display the encoder interface in operating area. The interface is mainly composed of encoding video parameters, audio parameters and the encoding system parameters, output parameters and etc.
  • Page 30 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 Set: to make the current parameters shown in the SNMP software activate. Get: to read the current device’s activating parameters and show them on SNMP software. Ø IP Out Enable Check the checkbox with “√”, then the IP output is enabled, otherwise it is not. Users can decide whether to open the IP output function or not.Users can modify the IP address here...
  • Page 31 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 In this field, users can decide whether to effect the NIT (Network Information Table) insertion function. Ø SDT Insertion In this field, users can decide whether to effect the SDT insertion function. Ø MPTS Filter Null Packet If this function is effected, then the null packets in IP output stream will be filtered.
  • Page 32 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 activating parameters. 4.3.2 Multiplexing CH01-CH08: The 8 HDMI Encoding Channels CH09: The 1 ASI Input Channel The programs in the left column represent all input programs and which port they come from, while the programs in the right column represent the output programs and from which port they are from.
  • Page 33 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 : To modify the output programs’ Program Name, PMT, PCR, video, or audio PID as needed. To modify program information, user can select the target program in output part first and click this button to pop up a dialog box as below: Select the target item and input the new value in the box below, then click to effect the modification.
  • Page 34 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 Users can operate PID filter in this table by checking the check boxes of corresponding items and click CONFIRM to effect. Refresh: getting PID filter table from the device Setting: submitting the PID filter table to the device...
  • Page 35 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 Input PID and Output PID The Old (Input) PID is the PID number in the TS from given Port. The correspondent New (output) PID number could be same as input PID number while it could be different if a PID remapping is needed.
  • Page 36 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 ：The parameter describes the output TS’s network ID ：The parameter describes the output TS’s network name. Insertion private description ：This checkbox will allow user to insert the private descriptor into the output TS. The private descriptor includes two parts. One is descriptor tag, and the other is descriptor information.
  • Page 37 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 ：Users can add the cable transmission descriptor in this Add button, and it will pop up the following dialogue box, say, the added descriptor is apply for the DVB-C network. The interface will show as below after the NIT parameters being added：...

  • Page 38: Other Settings

    FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 4.4 Other Settings 4.4.1 Difference between Set and Remote Save In many cases during the configuration of parameters in NMS, users save the modified configuration by clicking “Set”, in which way the configuration can only be saved temporarily and will restore the last saved configuration if the device reboots.
  • Page 39 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 Users can click Operate and select Modify IP in the drop-down list, and a dialog box presents itself as shown below. Users input the new NMS IP Address for the device and click OK button to confirm.
  • Page 40 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 Input the new IP Address in the box and click OK button, then the device will be connected again. After finishing all the parameters setting, user should click button on the toolbar to save the modifications to the device’s flash.
  • Page 41 FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 41 / 43...

  • Page 42: Chapter 5 Troubleshooting

    Chapter 5 Troubleshooting FMUSER’s ISO9001 quality assurance system has been approved by CQC organization. For guarantee the products’ quality, reliability and stability. All FMUSER products have been passed the testing and inspection before ship out factory. The testing and inspection scheme already covers all the Optical, Electronic and Mechanical criteria which have been published by FMUSER.

  • Page 43: Chapter 6 Packing List

    FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物科技开发有限公司 Chapter 6 Packing list Ø FUTV4318A 8 in 1 MPEG-4 AVC/H.264 HD Encoder 1pcs Ø User’s manual 1pcs Ø HDMI cable 8pcs Ø ASI cable 1pcs Ø Power cord 1pcs 43 / 43...
