4.STORAGE CAPACITY CALCULATION

1) Image Quality & Streams
Resolution Image
quality
720P
WD1
WHD1
Stream
WCIF
Kbps
D1
HD1
CIF
2) Record File Size Calculation
Rec. file size for each channel is:
Recording time (s) x Stream (Kbps) / 8 / 1024 = File Size (MB)
e.g. The file size of the Image 1 with D1 resolution within 1 hour:
3600 x 2048 Kbps / 8 / 1024 = 900 MB
3) Image Quality & Resolution
Resolution
quality
720P
WD1
WHD1
Record
WCIF
(MB)
D1
HD1
CIF
1 2
6144 4800
2662 1997
1664 1248
1040 780
2048 1536
1280 960
800 600
1 2 3
2700 2109 1814
1170 878 702
731 549 438
456 343 274
900 675 540
562 422 337
351 264 211
3 4 5
4128 3456 2784
1599 1331 1170
998 832 728
624 520 455
1230 1024 900
768 640 560
480 400 350
4 5
1518 1223
585 514
365 320
229 199
450 395
281 246
176 153
71-73
User manual for XMR401HDS
6 7 8
2112 1440 768
1040 936 832
650 585 520
405 364 325
800 720 640
500 450 400
312 280 250
6 7
928 632
456 411
285 257
178 160
351 316
219 198
137 123
8
337
365
229
143
281
176
110
