1. PRODUCT CHARACTERISTICS

1.1. OVERVIEW

Streamax X1-H0401 is a functional Mobile Digital Video Recorder specially designed for vehicle
video surveillance and remote monitoring. It has a high-speed processor and embedded operating
system, combining with the most advanced H.264 video compression / decompression technology,
3G/4G network, GPS positioning technology, as well as WIFI. It supports not only video recording in
720P, WD1, WHD1, WCIF, D1, HD1 and CIF formats, but also vehicle travel information recording and
wireless data upload. With center software it also achieves alarm linkage central monitoring, remote
management and playback analysis. It is easy to use with simple design, multi-functions, superior
anti-vibration, flexible installation and high reliability.

1.2. SPECIFICATIONS

Function Overview
OS
System
Control Mode
Input
Output
Video Total Resource
Video Signal Standard
Input
Audio Output
Audio Signal Standard
Display Split
Display OSD
Operation Interface
Video/Audio Compression
Recording
Image Resolution
Preview, Recording, Playback, Network, Locating
Linux 3.0.8
Easy Check, network, CP4, mouse (3G/4G/WIFI)
4 channels WD1+1 channel 720P
1 channel
(4x25)FPS WD1 @ PAL / (4x30)FPS WD1 @ NTSC
+30FPS 720P
Electrical level: 1Vpp Impedance: 75Ω NTSC/PAL
Optional
5channels (1 channel IPC audio input)
1channel
Electrical level: 2Vpp Input impedance: 4.7kΩ
1/4
GPS information, alarm, vehicle No., speed,
date/time
Semi-transparent GUI
Video: H.264
Audio: ADPCM, G.711A , G.711U
Analog:
PAL:WD1(928X576),WHD1(928X288),
WCIF(464X288),D1(704X576),HD1(704x288),
CIF(352x288);
NTSC:WD1(928X480),WHD1(928X240),
WCIF(464X240),D1(704x480),HD1(704x240),
CIF(352x240);
Digital:
720P(1280X720);
