Summary of Contents for Body Solid POWERLINE PAB-21 X
- Page 1 PAB-21X AB-BENCH Owner’s Manual WWW.BODYSOLID.COM ✁ ✂ ✂ ✄ ✂ ✂ ☎ ✆...
- Page 2 THERE IS A RISK ASSUMED BY INDIVIDUALS WHO USE THIS TYPE OF EQUIPMENT. TO MINIMIZE RISK, YOU MUST FOLLOW THESE RULES: Inspect equipment before each workout. Check that all nuts, bolts, screws and pop pins are in place and fully tightened. Also, before use, check cables for sign of wear. Replace all worn parts immediately.
-
Page 3: Table Of Contents
PAB-21X TABLE OF CONTENTS • SAFETY INSTRUCTIONS....... PAGE 4 • PREPARATION........PAGE 5 • HARDWARE LIST........PAGE 6 • HARDWARE ILLUSTRATION....PAGE 7 • PART LIST / ILLUSTRATION....PAGE 10 • ASSEMBLY INSTRUCTIONS....PAGE 12 • EXPLODED VIEW........PAGE 16 •... -
Page 4: Safety Instructions
Keep hands, limbs, loose clothing, and long hair well description from this Owner’s Manual. Use only out of the way of all moving parts Powerline by Body Solid replacement parts when • Use care when getting on or off the unit. -
Page 5: Preparation
PAB-21X PREPARATION Required tools Assembly Tips The basic tools that you must obtain before assembling Read all “Notes” on each page before beginning each step. the PAB-21X include but are not limit to: While you may be able to assemble the PAB-21X using the •... -
Page 6: Hardware List
PAB-21X HARDWARE LIST PART # SIZE DESCRIPTION QUANTITY... -
Page 7: Hardware Illustration
PAB-21X HARDWARE ILLUSTRATION Part #1 M10x65 Hex Head Bolt Qty. 4 Part #2 M10x70 Hex Head Bolt Qty. 4 Part #3 M10x70 THUMB SCREW Qty. 1 Part #4 M10x20 Hex Head Bolt Qty. 2... - Page 8 PAB-21X HARDWARE ILLUSTRATION CONT. Part #5 3/8”X2 1/4” Hex Head Bolt Qty. 1 Part #6 M10 Nylon Lock Nut QTY. 6 Part #7 3/8” Nylon Lock Nut QTY. 1 Part #8 M10 Washer QTY. 7 Part #9 M10 Spring Washer QTY.
- Page 9 PAB-21X HARDWARE ILLUSTRATION CONT. Part #10 2”X2” end cap Qty. 3 Part #11 51.5mm dia. pulley Qty. 1 Part #12 6mm dia. spring snap link Qty. 2 Part #13 820mm steel cable Qty. 1 ✷ ✸ ✹ ✺ ✺ ✸ ✻...
-
Page 10: Part List / Illustration
PAB-21X PART LIST Part A Part B Part C lower mainframe seat frame mainframe support [1pcs] [1pcs] [1pcs] Part D Part E Part F bottom mainframe seat pad upper mainframe [1pcs] [1pcs] [1pcs] Part G Part H Part I back pad holder back pad weight holder [1pcs]... - Page 11 PAB-21X NOTES...
-
Page 12: Assembly Instructions
PAB-21X STEP 1 BE CAREFUL TO ASSEMBLE ALL COMPONENTS IN THE SEQUENCE THAT THEY ARE PRESENTED. NOTE: finger tighten all hardware in this step. DO NOT wrench tighten until the last step. some components may be pre-assembled. nylon lock nuts will not fully screw onto bolts, must wrench tighten. 1A. - Page 13 PAB-21X STEP 1 Above shows STEP 1 assembled and completed Step 1A, 1B, 1D Step 1C, 1D...
- Page 14 PAB-21X STEP 2 BE CAREFUL TO ASSEMBLE ALL COMPONENTS IN THE SEQUENCE THAT THEY ARE PRESENTED. NOTE: finger tighten all hardware in this step. DO NOT wrench tighten until the last step. some components may be pre-assembled. nylon lock nuts will not fully screw onto bolts, must wrench tighten. 2A.
- Page 15 PAB-21X STEP 2 Above shows STEP 2 assembled and completed...
-
Page 16: Exploded View
PAB-21X EXPLODED VIEW... -
Page 18: Contact Page
PAB-21X please write your serial number in the boxes below S/N # Body-Solid Built for Life 1900 S. Des Plaines Ave. Forest Park, IL 60130 Phone:(708)427-3555 Fax:(708)427-3556 Hours: M-F 8:30 - 5:00 CST www.bodysolid.com Copyright 2011. Body-Solid. All rights reserved. Body-Solid reserves the right to change design and specifications when we feel it will improve the product. Body-Solid machines maintain several patented and patent pending features and designs.
