- Page 1 E200 User Manual E200 GNSS Receiver User Manual V1.0_202105 Web: www.esurvey-gnss.com Email: support@esurvey-gnss.com...
-
Page 2: Table Of Contents
E200 User Manual Contents Introduction ......................3 Appearance ....................3 Indicator ......................3 Interface ......................4 Pin definition ....................4 Power button ....................5 Web User Interface ....................5 Position ......................5 Satellites ......................6 Information ....................6 Working Mode ....................6 Satellite Setting ..................... -
Page 3: Introduction
E200 User Manual 1. Introduction This is the user manual for survey E200 GNSS receiver. It gives basic description and operation guide which may help user to operate device properly. 1.1 Appearance The E200 main body is designed with magnesium alloy material to provide durable usage and better heat dispersion as well as light weight 915g. -
Page 4: Interface
Flash red: battery level below 10% 1.3 Interface E200 GNSS receive bottom interface is shown as below. The 5-pin port is used to connect external radio and external power, or output NMEA messages. Type-C port can be used for data download (internal storage access) or charging. -
Page 5: Power Button
Signal ground Device in Front View 1.5 Power button There is a power button on E200 control panel, the main function as below: Long press button for two seconds to power on Power On receiver. Long press button for two seconds then release, Power Off will hear the voice “Power off?”... -
Page 6: Satellites
E200 User Manual 2.2 Satellites View satellite list and satellite map, set cut-off angle. 2.3 Information View receiver information: firmware version, GNSS board, and network module. 2.4 Working Mode Configurate working mode: base, rover or static. Web: www.esurvey-gnss.com Email: support@esurvey-gnss.com... -
Page 7: Satellite Setting
E200 User Manual 2.5 Satellite Setting Configurate the satellites to be used. “RTK Timeout” setting is for aRTK service (With Hemisphere L-Band service, user cans still keep high accuracy for a period when correction data loses). “Surefix” is hemisphere technology to increase the reliability of the fixed solution. -
Page 8: Nmea Message
E200 User Manual 2.7 NMEA Message Configurate NMEA data output through Bluetooth or 5-pin port. 2.8 View Logs The log files can be used to diagnose issues. Click “download” to download the files. Web: www.esurvey-gnss.com Email: support@esurvey-gnss.com... -
Page 9: Raw Data
E200 User Manual 2.9 Raw Data Download raw data or convert data to RINEX format. User can use check box, then click “Package” to download multiple files. 2.10 Backup Data The points collected in SurPad4.2 will be backup in receiver storage automatically to avoid data loss. -
Page 10: Management
E200 supports network working mode. Open the cover and insert SIM card. 3.2 Charge the battery E200 is equipped with Type-C charger which support maximum 45w PD quick charge. Fully charge the battery will take 4 hours typically. The battery indicator is red when charging, will turn green when fully charged. -
Page 11: Measure Antenna Height
E-bubble code, you can update to MEMS later by contacting with salesman. 3.4.1 E-bubble Calibration When e-bubble is activated on E200. To calibrate the e-bubble, put the device on flat table or pole (ensure the bubble on the pole is normal before calibration, then centering the pole bubble). -
Page 12: Mems Tilt Survey
E200 User Manual 3.4.2 MEMS Tilt Survey When MEMS sensor is activated on E200. To calibrate the MEMS sensor, receiver must be in Fixed solution. In SurPad4.2 software, connect device and click “Device” -> “Device Settings”, enable “Pole Tilt Correction” function. Then, go to “Survey” ->... - Page 13 E200 User Manual Web: www.esurvey-gnss.com Email: support@esurvey-gnss.com...
-
Page 14: Standard Accessories
E200 User Manual 4. Standard Accessories E200 base and rover are using the same accessories. We provide easy carrying soft bag or hard carrying case. Soft Bag: Carrying Case: Web: www.esurvey-gnss.com Email: support@esurvey-gnss.com... -
Page 15: Technical Specifications
E200 User Manual 5. Technical Specifications Web: www.esurvey-gnss.com Email: support@esurvey-gnss.com... -
Page 16: Warranty Policy
If it is a non-warranty product, and the repair center will handle the maintenance of the extra- fee. After the device is repaired, the same fault is con- firmed by the repair center and e-survey will provide a 3-month free warranty service. - Page 17 E200 User Manual Damage to the product is caused by external, including but not limited to, abnormal and unpredictable factors such as satellite systems, geomagnetism, static electricity, physical pressure, etc. Damage caused by force majeure such as earth- quakes, floods, wars, etc.
