- Page 1 Instructions for Use and Installation 90cm Black Freestanding Cooker TEG95TBK...
-
Page 2: Table Of Contents
Contents For your safety Safety of children and the infirm ......3 Cleaning and maintenance ......3 During use . -
Page 3: For Your Safety
To maintain the efficiency and safety of this appliance, we recommend that you do the following: · Always call the Technika service department if there are any faults with your appliance. · Always use original spare parts available from Technika. -
Page 4: During Use
For Your Safety During use · The appliance becomes hot. Care should be taken to avoid touching heating elements inside the oven. · WARNING: Accessible parts will become hot when in use. To avoid burns and scalds, children should be kept away. ·... -
Page 5: Installation
· Use oven gloves to place cookware in the oven or when removing it. Always grip the oven door handle in the centre. · Technika will not accept any liability as a result of any damage due to incorrect installation or improper use Installation ·... -
Page 6: Service And Spare Parts
Only use the temperature sensing probe recommended for this oven. Technika Service Department must be contacted... · If in doubt about the operation of the appliance. · If in doubt about the soundness of the appliance after removing it from its packaging. -
Page 7: Use And Care
Use and Care Description of the appliance 1. Three Key Touch Timer 5. Wok burner 2. Control knob (cooktop burners) 6. Semi-rapid burner 3. Cooking temperature selection knob 7. Pan supports 4. Cooking mode selection knob Note: Material, colours, pan supports and burner configuration may vary. -
Page 8: Oven & Accessories
Use and Care Oven & accessories The oven is supplied with chrome wire shelf supports and one telescopic shelf support. There are a range of shelf options as shown below. There are four shelf positions on the oven. Grill Tray with removable insert Oven Shelf Shelf... -
Page 9: Instructions For Use
Use and Care Instructions for use (cooktop burners) The symbols on the control knobs mean the following: No gas flow or 'Off' Maximum gas flow or 'high' flame and lighting position Minimum gas flow or 'low' flame All operating positions must be set between the maximum and minimum flow settings, and never between the maximum setting and the closed position. - Page 10 Use and Care To light the cooktop burners To light the burner, press the control knob fully down and hold the knob down before rotating anti-clockwise to the High Flame position. The ignition device is integrated into the control knob and is automatically activated by pushing down on the control knob.
-
Page 11: How To Use Your Oven
Use and Care How to use your oven This multi-function oven combines the advantages of traditional conventional ovens with modern fan forced ovens in a single appliance. It is an extremely versatile appliance that allows you to choose easily and safely between different cooking modes. The various cooking modes are selected by means of a cooking mode selection knob, located on the control panel. -
Page 12: Positioning The Oven Trays & Shelves
Use and Care Positioning the oven trays & shelves The Baking Tray, Grill Tray or Oven Shelf can be located in any of the five height positions. Refer to the ‘Cooking mode table’ for the recommended shelf position. When fitting the trays or shelves, ensure they are fitted between the two wires that are closest together as shown below. - Page 13 Use and Care COOKING MODES Conventional mode When set to Conventional mode, the top and bottom heating elements operate together like a ‘normal’ conventional oven that you have probably used before. Conventional mode is best suited for traditional baking and roasting and you should only use one shelf at a time, otherwise the heat distribution will be uneven.
- Page 14 Use and Care Fan assisted Top heat mode Select ‘Fan Assisted Top’ mode with cooking mode selection knob and turn cooking temperature selection knob to the desired temperature setting. When set to Fan Assisted Top mode, the top inner element and the fan operate. This mode increases the circulation of air throughout the oven, which helps prevent food from burning on the surface, allowing the heat to penetrate right into the food.
- Page 15 Use and Care Cooling ventilation In order to keep the appliance cool, this model is equipped with a cooling fan, which switches on automatically. When the cooling fan is on, you will notice a flow of air exiting between the oven door and the control panel.
- Page 16 Use and Care Control Elements 8888 h:min min:sec Auto Set ‘-’ Select Set ‘+’ SELECT Function Browse through sequence of functions to select desired function using ‘SELECT’ on the touchpad. Minute Minder Cook Time End Time Time of Day Volume SET Time or Volume •...
- Page 17 Use and Care End Time Setting of End Time • Upon selection of end time function, next end time (time of day plus cook time) is displayed. Set desired end time (max time of day + 23:59 h:min) in increment/decrement steps of 1min. •...
- Page 18 Use and Care Time of Day Set the time of day • Select time of day and set actual time of day between 0:00 and 23:59 h:min in increment /decrement steps of 1min. • Time of day is displayed in 24 hour mode, max. 23:59 h:min; 12:00p.m.
-
Page 19: Practical Cooking Advice
Use and Care This appliance will allow you to cook any type of food in the best possible way. With time you will learn to make the best use of this versatile cooking appliance. The following directions are only a guideline which may be varied according to your own personal experience. - Page 20 Use and Care Baking cakes When baking cakes ,always place them in a preheated oven. Make sure you wait until the oven has been preheated thoroughly (the indicator light will turn off). To prevent heat loss and the cake from dropping, do not open the oven door during baking.
- Page 21 Use and Care Cooking pizza For best results when cooking pizza: · Preheat the oven for at least 10 minutes. · Use a light aluminum pizza pan, placing it on the shelf supplied with the oven. Don’t use the dripping pan since this will extend the cooking time, making it difficult to get a crispy crust.
-
Page 22: Cleaning & Maintenance
Use and Care Cooktop cleaning and maintenance Before cleaning, make sure all burners are 'off' and allow the appliance to cool down. The enamelled or stainless steel parts should be washed with lukewarm water without using any abrasive powders or corrosive substances. - Page 23 If necessary, clean it but avoid using abrasive products or objects to do so. Should it become damaged, please contact Technika Service Department. We recommend you avoid using the oven until it has been repaired.
- Page 24 Proceed as follows: Remove and assemble procedure · Open door fully · Lift up and turn the small levers situated on the two hinges fully back · Grip the door on the two external sides; shut it slowly until door contacts the clips. Then continue closing door until it is about 10cm from closing fully.
- Page 25 · Burners failing to remain alight. · Burners extinguished by cupboard doors. · Gas valves, which are difficult to turn. In case the appliance fails to operate correctly, contact Technika. Service and parts Before leaving the factory, this appliance was tested and adjusted by specialist skilled staff to give the best operating results.
-
Page 26: Disposal
- Voltage: 220-240V - Wattage: 25W - Type: E 14 Replacement lamps are available from Technika. Replace the glass cover and reconnect the oven to the mains power supply. Disposal By ensuring this product is disposed of correctly, you will help... -
Page 27: Technical Data
220-240V AC (50-60Hz) 220-240V ~ 50-60Hz Maximum Rating: 2880W - 3428W... -
Page 28: Installation
Installation Instructions for installation This appliance shall be installed only by authorised persons and in accordance with the manufacturer's installation instructions, local gas fitting regulations, municipal building codes, electrical wiring regulations, AS 5601 - Gas Installations and any other statutory regulations. -
Page 29: Dimensions
Install Range Hoods in accordance with manufacturer's instructions, no closer than 600mm above the maintop for Range Hoods and 750mm for Exhaust Fans. -
Page 30: Anti-Tilting Chains/Hose Restraining Chain
Installation Anti-tilting chains/hose restraining chain A chain should be fitted by the installer within 50mm of the hose connection point to prevent strain on the hose when the cooker is pulled forward. The chain should restrict the appliance movement to no more than 80% of the hose length. After the chain is installed, check that there is no strain on the hose or gas connections when the cooker is pulled as far forward as the chain allows. -
Page 31: Anti-Tilting Chain - Incorrect Installation
Installation Anti-tilting chains - INCORRECT Installation Accidental Tipping Chains are provided as a preventative measure against accidental tipping. These chains must be fitted as part of the installers compliance. Failure for your installer to fit chains in accordance with the relevant installation code will make the installation of your upright cooker non-compliant and class as an illegal installation. -
Page 32: Anti-Tilting Chain - Correct Installation
Installation Anti-tilting chains - CORRECT Installation In order to prevent the oven from tipping forward as shown on the previous page, we need to make sure both chains provided with the oven are used. LEFT SIDE RIGHT SIDE Hole and chain level On the left side of the oven, The right side has been... - Page 33 Installation Anti-tilting chains - CORRECT Installation Once the holes have been drilled, the chains can be fed through and the upright can be fitted into position. The chains then need to be pulled as tight as possible from inside the cabinet while at the same time being fixed to the rear of the cabinet using a self drilling wood screw.
-
Page 34: Connection To The Gas Supply
Ensure that the available gas supply is the same A - Manifold Nut as the gas type label affixed near the gas B - Gasket connection point. If not, contact Technika for a Gas Conversion Kit. C - Elbow Natural Gas The natural gas regulator supplied must be fitted for natural gas. -
Page 35: Electrical Connection
When satisfied with the hotplate, please instruct the user on the correct method of operation. In case the appliance fails to operate correctly after all checks have been carried out, please call the Technika Service Centre. -
Page 36: Gas Conversion
Gas Conversion (NG to U-LPG) Hob Burners Parts needed... - Test Point Assembly LPG Gas Type label - Auxiliary Jet Ø0.53mm - Semi-Rapid Jet Ø0.68mm - Rapid Jet Ø0.88mm - Wok Jet Ø1.00mm Converting to a different gas type When converting from Natural Gas to Universal LPG ensure that the NG regulator is removed and replaced with the Test Point Assembly supplied in the conversion kit. -
Page 37: U-Lpg To Ng
Gas Conversion (U-LPG to NG) Hob Burners Parts needed... - NG Regulator - NG Gas Type label - Auxiliary Jet Ø0.88mm - Semi-Rapid Jet Ø1.16mm - Rapid Jet Ø1.50mm - Wok Jet Ø1.75mm Converting to a different gas type When converting from Universal LPG to Natural Gas ensure that the ULPG test point is removed and replaced with the AGA Approved NG Regulator supplied in the conversion kit. - Page 38 Actual product only should be used to derive cut out sizes. All Technika Appliances must be installed by a qualified person/s with adherence to the relevant electrical, plumbing and gas codes, with compliance being issued as required by state or national legislation.
