10-1/2 LIGNE, 3 EYES CHRONOGRAPH WITH
1.BASIC SPECIFICATIONS
(1) CaL. No.
CALIBRE
PUSHER
Ligne
Size*mm
Date
Total height
Figure
(push button
placed angle)
Battery & Life
(2) Time standard
Type of quartz : Tuning fork type quartz crystal
Frequency
: 32,768Hz
Accuracy
: +/-20 s/month worn under normal circumstances
(3) Balanceable weight of hand
Minute hand Max. 0.4 μN.m
Second hand Max. 0.035 μN.m
Other small hands Max. 0.02 μN.m
(4) Function
Chronograph 1/1 sec. Basis (Up to 59 min. 59 sec.)
Powercell Saving Reset Mechanism(PSRM)
Over-loading Compensation Device(OLCD)
Digital Frequency Control(DFC) for time adjustment
Small Hands
Height
FS00/01
MOVEMENT SPECIFICATIONS
CAL.FS03/04
ANALOGUE QUARTZ, 0 JEWEL
MANUFACTURED IN JAPAN
FS03
SLANTED
4.15mm
FS03
*Eye position is the same as FS00
HIGH HAND
*TO CONFIRM WITH MOV'T DRAWING ATTACHED
10-1/2
Φ 23.7X22mm (3H-9H)
O
Slanted
*Eye position is the same as FS01
SR626SW 2YEARS*
* based on 1 hour/day chronograph use
FS00/01
Center Hands
Height
FS04
PARALLEL
4.28mm
Parallel
FS04
