1. Basic Specification
CAL.
Push Buttons
Total height
Ligne
Overall diameter
Case fitting diameter
Date
Function
Bateery & Life
<TIME STANDARD>
Type of quartz:
Frequency :
Accuracy :
< Balanceable weight of hand >
Minute hand Max. 0.4 μN・m
Second hand Max. 0.035 μN・m
Other small hands Max. 0.02 μN・m
< Function >
Chronograph 1/1 sec. Basis (Up to 59 min. 59 sec.)
Dual Time Function
Powercell Saving Reset Mechanism(PSRM)
Over-loading Compensation Device(OLCD)
Digital Frequency Control(DFC) for time adjustment
Cal. FS16/17 FS26/27
DUAL TIME CHRONOGRAPH
FS16
SLANTED
5.10mm
Dual Time , Chronograph 1/1sec. Basis (Up to 59min. 59sec.)
Tuning fork type quartz crystal
32,768Hz
±20 second / month
FS17
FS26
PARALLEL
SLANTED
5.25mm
5.10mm
10 1/2'''
Φ23.7mm×22.0mm (3H-9H)
Φ23.3mm×22.0mm (3H-9H)
○
SR626SW 2YEARS *
*based on 1 hour/day chronograph use
worn under normal circumstances
FS27
PARALLEL
5.25mm
Advertisement
Table of Contents
Related Manuals for Citizen FS16
Summary of Contents for Citizen FS16
- Page 1 Cal. FS16/17 FS26/27 DUAL TIME CHRONOGRAPH 1. Basic Specification FS16 FS17 FS26 FS27 CAL. Push Buttons SLANTED PARALLEL SLANTED PARALLEL Total height 5.10mm 5.25mm 5.10mm 5.25mm Ligne 10 1/2''' Φ23.7mm×22.0mm (3H-9H) Overall diameter Φ23.3mm×22.0mm (3H-9H) Case fitting diameter ○ Date Dual Time , Chronograph 1/1sec.
- Page 2 2. Separated Parts ×1 065- 549 Setting stem Length from movement 20.00mm center to far end of setting stem Ф0.9mm×9.06mm Thread 3. Others * Measurement of time rate The unit(gate) time of measurement must be set at "10 sec." or integer fold value of 10 sec.
- Page 3 A) SETTING THE TIME 1. Pull the crown out to the 2nd Click Position. 2. Turn the crown to set the hour and minute hands. * * home time hand, local time hand , 24hour hand are linked. B) SETTING THE DATE * If the date is set between the hours of around 9:00 PM and 1:00 AM, the date may not change on the following day.
