MODEL:BL2500
BLOWER WITH VACUUM KIT
WARNING
Always wear eye and hearing protection when operating this
machine. Minimize the risk of injury : Read this manual and
familiarize yourself with its contents. This product is intended for
outdoor use only and should be used only in well ventilated area.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BL2500 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Nakayama BL2500

  • Page 1 MODEL:BL2500 BLOWER WITH VACUUM KIT WARNING Always wear eye and hearing protection when operating this machine. Minimize the risk of injury : Read this manual and familiarize yourself with its contents. This product is intended for outdoor use only and should be used only in well ventilated area.
  • Page 2 INTRODUCTION EBV260 engine blower has been designed and built to deliver superior performance and reliability without compromise to quality, compromise to quality, comfort, safety, or durability EBV260 high performance engines represent the leading edge of 2-cycle engine technology, delivering exceptionally high power at remarkably low displacement and weight .
  • Page 3: Table Of Contents

    CAUTION! This EBV260 engine machine is equipped with a speak-arresting muffler. Never operate this machine without both the muffler and spark arrestor installed and properly functioning! CONTENTS ……………………… Attention Statements ……………………… Product Description ……………………………… Specifications Assembling the Machine …………………… Mixing Fuel ………………………………… Filling the Fuel Tank …………………………...
  • Page 4: Attention Statements

    ATTENTION STAEMENTS This manual contains special “attention statements” surrounded by boxes and preceded by the triangular Attention Symbol CAUTION! WARNING! A statement preceded by A statement preceded by WARNING contains word “CAUTION” Information that should be contains information that acted upon to prevent should be acted upon to serious bodily injury.
  • Page 5 · Never operate this machine when you are fatigued,ill or under the influence of alcohol. · Never smoke when working with this machine ·Never allow children or anyone unable to fully understand the manual to use this machine ·Clothing must be sturdy and snug-fitting, but allow complete freedom of movement—...
  • Page 6: Product Description

    or in poorly ventilated locations. ·Danger form rotating impeller! Stop the engine before installing or removing the machine tubes! Never perform any maintenance or assembly procedures on this machine while the engine is running. ·Never direct the machine stream toward people or animals! ·Operate the machince only at reasonable hours-not early in the morning or late at night when people might be disturbed.
  • Page 7: Specifications

    not understand something in this manual, your dealer will be glad to assist you. WARNING! Do not make unauthorized Modifications to this machine SPECIFICATIONS Model………………………………………EBV260 Dimensions(L×W×H)………………570×290×410 Engine Type……………………………BF26FB Cylinder Diameter………………………34mm Displacement……………………………26cc Fuel…………………………Gasoline/oil mixture 40:1 Carburetor…………Membrane type primer pump Way of ignition……………………………CDI Spark plug…………………………………L7RTC Starting……………………………………Recoil starter Fuel Tank Capacity………………………0.5L...
  • Page 8: Assembling The Machine

    ASSEMBLING THE MACHINE 1. Assembling the vacuum (1) Nomenclature Inhale pipe NO.1 Handle Tank Inhale pipe NO.2 Lower handle Dust bag (2)Assembly Open Insert discharging pipe into cover, connect dust bag from the jaws of the inhale pipe No.1 slide fastener according to the and No.2 picture discharging pipe.
  • Page 9 discharging pipe Put the discharging pipe to the machine. Herein, use screw M5×10 to reinforce. 2. Install blower machine (1) Terms Stop switch Throttler lever handle Starter handle Cleaner cover Fuel tank Lower handle...
  • Page 10: Mixing Fuel

    Blow pipe B (2)Install Blow pipe A Put blow pipe B to the machine Put blow A to B by by rotating rotating Use screw M5×10 to reinforce IMPORTANT! Mix only enough fuel for your immediate needs! If fuel must be stored longer than 30-days,it should first be treated with a stabilizer or equivalent product! MIXING FUEL...
  • Page 11 CAUTION! Never attempt to mix fuel in the machine fuel tank! Always mix all fuels in a clean. approved container! Some gasoline contain alcohol as an oxy genated! Oxy genated fuels may cause increased engine operating temperatures! Under certain conditions, alcohol-based fuels may also reduce the lubricating qualities of some mixing oils! Never use any fuel containing more than 10% alcohol by volume! When an oxygenated fuel must be used fuel containing...
  • Page 12: Filling The Fuel Tank

    IMPORTANT! Mix only enough fuel for your immediate needs! If fuel must be stored longer than 30-days, it should first be treated with a stabilizer or equivalent product! FILLING THE FUEL TANK Remove the fuel cup WARNING! Danger of fire and burn injury! □...
  • Page 13: Starting The Machine

    1. Place the machine on the ground or on a sturdy work surface, and wipe any debris from around the fuel cap. 2. Remove the fuel cap. 3. Fill the tank with clean, fresh fuel. 4. Replace the cap, and wide away any spilled fuel before starting the machine.
  • Page 14 1. Run the engine at idle speed until operating temperature is reached(2 to 3 minutes) 2. As the engine warms, open the choke gradually by slowly pushing the choke control in to the fully retracted position. 3. The machine should now be ready for use. If the engine dose not start Repeat the appropriate starting procedures for “hot”...
  • Page 15: Adjusting Engine Speed

    WARNING! Incorrect spark plug installation Can result in serious engine damage! Choke rod Starting a flooded engine 1. Disconnect the spark plug lead, and use the spark plug wrench to remove the plug in a counterclockwise direction. 2. If the spark plug is fouled or is soaked with fuel, clean or replace the plug as required.
  • Page 16 1. Start the engine by following the procedures described on the preceding pages. 2. Run the engine at idle speed until operating temperature is reached (2-3 minutes) 3. Use a screwdriver to adjust the engine idle speed to 3000±200r/min □ Turn the idle screw clockwise to increase engine idle speed. □...
  • Page 17: Routine Maintenances

    1 Using the vacuum When using the blower vac.,examine the collection bag timely.When it is full, pleade open the zip on the collection bag and clear it. 2 Using the blower Always be aware of the strength and direction of stream. Never direct the blower discharge stream toward people or animals.
  • Page 18 Inspect the element. If the element is distorted or damaged, replace it with a new one. Wash the element in clean fuel, and squeeze or blow dry. Wash the air cleaner cover in clean fuel, and wipe or blow dry. Install the element and cover, and the tighten the cover retaining screw.
  • Page 19: Storage

    CAUTION! Never allow dirt or debris to enter the cylinder bore! Before removing the speak plug. Thoroughly clean the the spark plug and cylinder head area! Allow the engine to cool before servicing the spark plug! Cylinder tightening or loosening the spark plug while the engine is hot! Incorrect spark plug installation can result in serious engine damage!
