- Page 1 RFID Reader/ Writer TWN4 MultiTech M User Manual...
-
Page 2: Getting Started
Elatec GmbH 1. Introduction The transponder reader module TWN4 MultiTech M is a device for reading and writing RFID transponders. There are different versions of TWN4 devices available, which cover a large range of transponder types both in the frequency range of 125kHz and 13.56MHz. -
Page 3: Normal Operation
Elatec GmbH this step. After successful initialization, the device sounds a short sequence, which consists of a lower tone followed by a higher tone. 2.4 Normal Operation As soon as the device has completed the initialization, it is entering normal operation. -
Page 4: Suspend Mode
Elatec GmbH Suspend Mode The transponder reader supports the USB suspend mode. If the USB host is signaling suspend via the USB bus, the transponder reader is turning off most of its power consuming peripherals. During this operation mode, no detection of transponders is possible and all LEDs are turned off. - Page 5 Elatec GmbH 3. List of Antennas HF antenna LF antenna Page 5 of 13...
-
Page 6: Compliance Statements
Elatec GmbH 4. Compliance statements (RF module) Compliance statement: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. - Page 7 Elatec GmbH Host devices FCC notes for a host subject to verification or SDoC: For a host device assembled with the certified module and subject to 47 CFR Part 15 verification of class A digital devices, the following statements have to be included in the user manual and the host device has to be labelled as noted below.
- Page 8 Elatec GmbH Example for SDoC: The compliance information statement shall be included in the user's manual or as a separate sheet. In cases where the manual is provided only in a form other than paper, such as on a computer disk or over the Internet,...
- Page 9 Elatec GmbH NOTE: The Commission does not have a required SDoC format. This is an example only and is provided to illustrate the type of information that may be supplied with the product at the time of marketing or importation for meeting the FCC SDoC requirement.
- Page 10 Elatec GmbH For class A devices: FCC §15.105 (b): NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
- Page 11 If additional filing is required please contact the person at ELATEC GmbH responsible for certification of the RF module. Page 11 of 13...
-
Page 12: Service Address
Elatec GmbH 5. Service Address In case of any technical questions, please contact: Elatec GmbH Zeppelinstr. 1 82178 Puchheim Germany Phone: +49 (0) 89 5529961 0 Fax: +49 (0) 89 5529961 29 Email: info-rfid@elatec.com Page 12 of 13... - Page 13 Elatec GmbH 6. Trademarks All referenced brands, product names, service names and trademarks mentioned in this document are the property of their respective owners. Page 13 of 13...
