Setting Twain Driver - Kyocera TASKalfa 307ci Operation Manual

Installing and Setting up the Machine > Installing Software

Setting TWAIN Driver

Register this machine to the TWAIN Driver. Instructions are based on interface elements as they appear in Windows 8.1.
1
2
Display the screen.
1
Click [Search] in charms, and enter "TWAIN Driver Setting" in the search box. Select
[TWAIN Driver Setting] in the search list.
NOTE
In Windows 7, select [Start] button on the Windows, [All Programs], [Kyocera] and then
[TWAIN Driver Setting]. TWAIN Driver screen appears.
2
Click [Add].
Configure TWAIN Driver.
(Network)
1
4
2
3
5
6
(USB)
3
1
2
4
5
1 Enter the machine name.
2 Select this machine from the list.
3 Enter the machine's IP address or host name.
4 Set units of measurement.
5 When using SSL, select the checkbox beside SSL.
6 Click [OK].
1 Enter the machine name.
2 Select this machine from the list.
3 Set units of measurement.
4 Set the Compression Level.
5 Click [OK].
2-41
