- Page 1 TECHNICAL DATA & SERVICE MANUAL OUTDOOR UNIT: GRV72R5TA- GRV92R5TA- GRV122R5TA- SPLIT SYSTEM AIR CONDITIONER Model No. Product Code No. GRV72R5TA- 387107056 GRV92R5TA- 387107057 GRV122R5TA- 387107058 0.8180.262.0 05/2002...
- Page 2 • Ground the unit following local electrical codes. IMPORTANT! • The Yellow/Green wire cannot be used for any connection Please read before installation different from the ground connection. • Connect all wiring tightly. Loose wiring may cause overheating This air conditioning system meets strict safety and operating at connection points and a possible fire hazard.
-
Page 3: Table Of Contents
Table of Contents Page 1. OPERATING RANGE 2. SPECIFICATIONS 2-1 Unit specifications 2-2 Major Component specifications 2-3 Other Component specifications 3. DIMENSIONAL DATA 4. REFRIGERANT FLOW DIAGRAM 5. PERFORMANCE DATA 5-1 Performance Charts 5-2 Cooling Capacity 5-3 Heating Capacity 6. ELECTRICAL DATA 6-1 Electrical characteristics 6-2 Electric Wiring Diagram 6-3 System Wiring Diagram... -
Page 4: Operating Range
1. OPERATING RANGE Temperature Indoor Air Intake Temp. Outdoor Air Intake Temp. Maximum 32°C D.B. / 23°C W.B. 43°C D.B. Cooling Minimum 19°C D.B. / 14°C W.B. 19°C D.B. Maximum 27°C D.B. 24°C D.B. / 18°C W.B. Heating Minimum -8°C D.B. / -9°C W.B. -
Page 5: Specifications
2. SPECIFICATIONS 2-1 Unit Specifications GRV72R5TA- 220 - 240V ~ 50Hz Power source 230V Voltage rating Cooling Heating Performance * MCAV72R5TA- Capacity 2,30 2.65 7843 9045 BTU/h Air circulation (High) m³/h Moisture removal (High) Liters/h Cooling Heating Electrical Rating 198 ~ 264 Available voltage range Running amperes Power input... - Page 6 GRV92R5TA- 220 - 240V ~ 50Hz Power source 230V Voltage rating Cooling Heating Performance * MCAV92R5TA- 2,50 3.40 Capacity BTU/h 8532 11604 Air circulation (High) m³/h Moisture removal (High) Liters/h Cooling Heating Electrical Rating Available voltage range 198 ~ 264 Running amperes 1040 1050...
- Page 7 GRV122R5TA- 220 - 240V ~ 50Hz Power source 230V Voltage rating Cooling Heating Performance * MCAV122R5TA- 3,10 4.10 Capacity BTU/h 10580 13993 Air circulation (High) m³/h Moisture removal (High) Liters/h Cooling Heating Electrical Rating Available voltage range 198 ~ 264 Running amperes 1300 1400...
-
Page 8: Major Component Specifications
2-2 Major Component Specifications Outdoor Unit: GRV72R5TA- Compressor Rotary (Hermetic) Type 80225245F C-RN75H5A Compressor model Nominal output FV68S…470 Compressor oil…Amount C-R: 3.38 Coil resistance (Ambient temp. 25°C) Ω C-S: 7.49 External (OLR T) Overload relay CS-7C115 Safety devices Type 115 ± 3 Operating Temp. - Page 9 Outdoor Unit: GRV92R5TA- Compressor Rotary (Hermetic) Type Compressor model 80228345 C-RN90H5B Nominal output FV68S…470 Compressor oil…Amount C-R: 3.07 Coil resistance (Ambient temp. 25°C) Ω C-S: 6.69 External (OLR T) Overload relay CS-7C115 Safety devices Type 115 ± 3 Operating Temp. Open °C 95 ±...
- Page 10 Outdoor Unit: GRV122R5TA- Compressor Rotary (Hermetic) Type Compressor model 80235645B C-RN110H5B Nominal output 1100 FV68S…520 Compressor oil…Amount C-R: 1.962 Coil resistance (Ambient temp. 25°C) Ω C-S: 5.38 External (OLR T) Overload relay CS-7C115 Safety devices Type 115 ± 3 Operating Temp. Open °C 95 ±...
-
Page 11: Other Component Specifications
2-3 Other Component Specifications GRV72R5TA- SRF-01AJ504D1 (Coil) STF-0101Z (Valve) 4-way Valve (20S) AC 220/240 V, 50 Hz, 6W Coil rating 1402 ± 7% Coil resistance Ω (at 20°C) GRV92R5TA- SRF-01AJ504D1 (Coil) STF-0101Z (Valve) 4-way Valve (20S) AC 220/240 V, 50 Hz, 6W Coil rating 1402 ±... -
Page 12: Dimensional Data
3. DIMENSIONAL DATA 4 – ø12 holes Air intake Wide tube service valve ø9.52 (3/8") 7000/9000 BTU/h ø12.7 (1/2") 12000 BTU/h Narrow tube service valve Air discharge ø6.35 (1/4") Unit : mm... -
Page 13: Refrigerant Flow Diagram
4. REFRIGERANT FLOW DIAGRAM Indoor Unit: Outdoor Unit: GRV72R5TA- Indoor unit Outdoor unit Accumulator Wide tube service Wide tube valve 4-way Muffler valve O.D. ø9.52 mm (3/8 ") Narrow tube service Capillary tube Narrow tube valve Capillary tube Cooling cycle Strainer Strainer O.D. - Page 14 Indoor Unit: Outdoor Unit: GRV122R5TA- Indoor unit Outdoor unit Accumulator Wide tube service Wide tube valve 4-way Muffler valve O.D. ø12.7 mm (1/2 ") Narrow Accumulator tube Capillary service tube Narrow tube valve Cooling cycle Strainer O.D. Check Capillary Strainer ø6.35 mm valve Heating cycle...
-
Page 15: Performance Data
5. PERFORMANCE DATA 5-1 Performance charts GRV72R5TA- n Cooling Characteristics n Heating Characteristics Indoor inlet air Indoor inlet air D.B. (°C) D.B. (°C) Outdoor inlet D.B. temp. (°C) Outdoor inlet air D.B. temp. (°C) 0,70 2,60 Indoor inlet air Indoor inlet air D.B. - Page 16 GRV92R5TA- n Cooling Characteristics n Heating Characteristics Indoor inlet air Indoor inlet air D.B. (°C) D.B. (°C) Outdoor inlet D.B. temp. (°C) Outdoor inlet air D.B. temp. (°C) 0,60 2,40 Indoor inlet air Indoor inlet air D.B. (°C) D.B. (°C) 2,20 0,50 2,00...
- Page 17 GRV122R5TA- n Cooling Characteristics n Heating Characteristics Indoor inlet air Indoor inlet air D.B. (°C) D.B. (°C) Outdoor inlet D.B. temp. (°C) Outdoor inlet air D.B. temp. (°C) 0,60 2,80 Indoor inlet air Indoor inlet air D.B. (°C) D.B. (°C) 2,60 0,50 2,40...
-
Page 18: Cooling Capacity
5-2 Cooling Capacity GRV72R5TA- OUTDOOR UNIT: MCAV72R5TA- INDOOR UNIT: 220 - 240V ~ 50Hz RATING CAPACITY 2,30 kW moisture removal 0,9 l/h COMP. POWER INPUT 0,802 kW max comp input 0,902 kW AIR FLOW RATE 430 m³/h EVAPORATOR CONDENSER ENT.TEMP. °C OUTDOOR AMBIENT TEMP. - Page 19 GRV92R5TA- OUTDOOR UNIT: MCAV92R5TA- INDOOR UNIT: 220 - 240V ~ 50Hz RATING CAPACITY 2,50 kW moisture removal 1,1 l/h COMP. POWER INPUT 0,963 kW max comp input 1,14 kW AIR FLOW RATE 450 m³/h EVAPORATOR CONDENSER ENT.TEMP. °C OUTDOOR AMBIENT TEMP. °C W.B.
- Page 20 GRV122R5TA- OUTDOOR UNIT: MCAV122R5TA- INDOOR UNIT: 220 - 240V ~ 50Hz RATING CAPACITY 3,10 kW moisture removal 1,5 l/h COMP. POWER INPUT 1,206 kW max comp input 1,426 kW AIR FLOW RATE 470 m³/h EVAPORATOR CONDENSER ENT.TEMP. °C OUTDOOR AMBIENT TEMP. °C W.B.
-
Page 21: Heating Capacity
5-3 Heating Capacity –5 –8 Outdoor temperature (°C D.B.) NOTE … Point of Rating condition Black dot in the chart indicate the following rating condition. Indoor : 20°C D.B. Outdoor : 7°C D.B. / 6°C W.B. 2) Above characteristics indicate instantaneous operation, which does not take into consideration defrost operation. -
Page 22: Electrical Data
6. ELECTRICAL DATA 6-1 Electrical characteristics OUTDOOR UNIT: GRV72R5TA- COOLING Indoor Unit Outdoor unit Complete Unit Fan Motor Fan Motor Compressor performance at 230V 1-Phase 50 Hz Rating conditions Running Amps. 0,11 0,28 3,61 Power input 0,025 0,063 0,802 0,890 Full load conditions Running Amps. - Page 23 OUTDOOR UNIT: GRV92R5TA- COOLING Indoor Unit Outdoor unit Complete Unit Fan Motor Fan Motor Compressor performance at 230V 1-Phase 50 Hz Rating conditions Running Amps. 0,12 0,28 Power input 0,027 0,063 0,963 1,040 Full load conditions Running Amps. 0,12 0,28 Power input 0,027 0,063...
- Page 24 OUTDOOR UNIT: GRV122R5TA- COOLING Indoor Unit Outdoor unit Complete Unit Fan Motor Fan Motor Compressor performance at 230V 1-Phase 50 Hz Rating conditions Running Amps. 0,13 0,28 5,79 Power input 0,031 0,063 1,206 1,300 Full load conditions Running Amps. 0,13 0,28 6,79 Power input...
-
Page 25: Electric Wiring Diagram
6-2 Electric Wiring Diagram 6-3 System Wiring Diagram... - Page 26 R.D. 28 Reyrieux BP 131 - 01601 Trévoux CEDEX France Tél. 04.74.00.92.92 - Fax 04.74.00.42.00 R.C.S. Bourg-en-Bresse B 759 200 728...
