TECHNICAL DATA
& SERVICE MANUAL
OUTDOOR UNIT: GRV72R5TA-
SPLIT SYSTEM AIR CONDITIONER
Model No.
GRV72R5TA-
GRV92R5TA-
GRV122R5TA-
All manuals and user guides at all-guides.com
GRV92R5TA-
GRV122R5TA-
Product Code No.
387107056
387107057
387107058
0.8180.262.0
05/2002

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GRV92R5TA Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Technibel Climatisation GRV92R5TA Series

Summary of Contents for Technibel Climatisation GRV92R5TA Series

  • Page 1 All manuals and user guides at all-guides.com TECHNICAL DATA & SERVICE MANUAL OUTDOOR UNIT: GRV72R5TA- GRV92R5TA- GRV122R5TA- SPLIT SYSTEM AIR CONDITIONER Model No. Product Code No. GRV72R5TA- 387107056 GRV92R5TA- 387107057 GRV122R5TA- 387107058 0.8180.262.0 05/2002...
  • Page 2 All manuals and user guides at all-guides.com IMPORTANT! • Ground the unit following local electrical codes. • The Yellow/Green wire cannot be used for any connection Please read before installation different from the ground connection. • Connect all wiring tightly. Loose wiring may cause overheating This air conditioning system meets strict safety and operating at connection points and a possible fire hazard.

  • Page 3: Table Of Contents

    All manuals and user guides at all-guides.com Table of Contents Page 1. OPERATING RANGE 2. SPECIFICATIONS 2-1 Unit specifications 2-2 Major Component specifications 2-3 Other Component specifications 3. DIMENSIONAL DATA 4. REFRIGERANT FLOW DIAGRAM 5. PERFORMANCE DATA 5-1 Performance Charts 5-2 Cooling Capacity 5-3 Heating Capacity 6.

  • Page 4: Operating Range

    All manuals and user guides at all-guides.com 1. OPERATING RANGE Temperature Indoor Air Intake Temp. Outdoor Air Intake Temp. Maximum 32°C D.B. / 23°C W.B. 43°C D.B. Cooling Minimum 19°C D.B. / 14°C W.B. 19°C D.B. Maximum 27°C D.B. 24°C D.B. / 18°C W.B. Heating Minimum -8°C D.B.

  • Page 5: Specifications

    All manuals and user guides at all-guides.com 2. SPECIFICATIONS 2-1 Unit Specifications GRV72R5TA- 220 - 240V ~ 50Hz Power source 230V Voltage rating Cooling Heating Performance * MCAV72R5TA- 2,30 2.65 Capacity 7843 9045 BTU/h Air circulation (High) m³/h Moisture removal (High) Liters/h Cooling Heating...
  • Page 6 All manuals and user guides at all-guides.com GRV92R5TA- 220 - 240V ~ 50Hz Power source 230V Voltage rating Cooling Heating Performance * MCAV92R5TA- 2,50 3.40 Capacity BTU/h 8532 11604 Air circulation (High) m³/h Moisture removal (High) Liters/h Cooling Heating Electrical Rating 198 ~ 264 Available voltage range Running amperes...
  • Page 7 All manuals and user guides at all-guides.com GRV122R5TA- 220 - 240V ~ 50Hz Power source 230V Voltage rating Cooling Heating Performance * MCAV122R5TA- 3,10 4.10 Capacity BTU/h 10580 13993 Air circulation (High) m³/h Moisture removal (High) Liters/h Cooling Heating Electrical Rating 198 ~ 264 Available voltage range Running amperes...

  • Page 8: Major Component Specifications

    All manuals and user guides at all-guides.com 2-2 Major Component Specifications Outdoor Unit: GRV72R5TA- Compressor Rotary (Hermetic) Type 80225245F C-RN75H5A Compressor model Nominal output FV68S…470 Compressor oil…Amount C-R: 3.38 Coil resistance (Ambient temp. 25°C) Ω C-S: 7.49 Overload relay External (OLR T) CS-7C115 Safety devices Type...
  • Page 9 All manuals and user guides at all-guides.com Outdoor Unit: GRV92R5TA- Compressor Rotary (Hermetic) Type 80228345 C-RN90H5B Compressor model Nominal output FV68S…470 Compressor oil…Amount C-R: 3.07 Coil resistance (Ambient temp. 25°C) Ω C-S: 6.69 Overload relay External (OLR T) CS-7C115 Safety devices Type 115 ±...
  • Page 10 All manuals and user guides at all-guides.com Outdoor Unit: GRV122R5TA- Compressor Rotary (Hermetic) Type 80235645B C-RN110H5B Compressor model Nominal output 1100 FV68S…520 Compressor oil…Amount C-R: 1.962 Coil resistance (Ambient temp. 25°C) Ω C-S: 5.38 Overload relay External (OLR T) CS-7C115 Safety devices Type 115 ±...

  • Page 11: Other Component Specifications

    All manuals and user guides at all-guides.com 2-3 Other Component Specifications GRV72R5TA- SRF-01AJ504D1 (Coil) STF-0101Z (Valve) 4-way Valve (20S) AC 220/240 V, 50 Hz, 6W Coil rating 1402 ± 7% Coil resistance Ω (at 20°C) GRV92R5TA- SRF-01AJ504D1 (Coil) STF-0101Z (Valve) 4-way Valve (20S) Coil rating AC 220/240 V, 50 Hz, 6W...

  • Page 12: Dimensional Data

    All manuals and user guides at all-guides.com 3. DIMENSIONAL DATA 4 – ø12 holes Air intake Wide tube service valve ø9.52 (3/8") 7000/9000 BTU/h ø12.7 (1/2") 12000 BTU/h Narrow tube service valve Air discharge ø6.35 (1/4") Unit : mm...

  • Page 13: Refrigerant Flow Diagram

    All manuals and user guides at all-guides.com 4. REFRIGERANT FLOW DIAGRAM Indoor Unit: Outdoor Unit: GRV72R5TA- Indoor unit Outdoor unit Accumulator Wide tube service Wide tube valve 4-way Muffler valve O.D. ø9.52 mm (3/8 ") Narrow tube service Capillary tube Narrow tube valve Capillary tube...
  • Page 14 All manuals and user guides at all-guides.com Indoor Unit: Outdoor Unit: GRV122R5TA- Indoor unit Outdoor unit Accumulator Wide tube service Wide tube valve 4-way Muffler valve O.D. ø12.7 mm (1/2 ") Narrow Accumulator tube Capillary service tube Narrow tube valve Cooling cycle Strainer O.D.

  • Page 15: Performance Data

    All manuals and user guides at all-guides.com 5. PERFORMANCE DATA 5-1 Performance charts GRV72R5TA- n Cooling Characteristics n Heating Characteristics Indoor inlet air Indoor inlet air D.B. (°C) D.B. (°C) Outdoor inlet D.B. temp. (°C) Outdoor inlet air D.B. temp. (°C) 0,70 2,60 Indoor inlet air...
  • Page 16 All manuals and user guides at all-guides.com GRV92R5TA- n Cooling Characteristics n Heating Characteristics Indoor inlet air Indoor inlet air D.B. (°C) D.B. (°C) Outdoor inlet D.B. temp. (°C) Outdoor inlet air D.B. temp. (°C) 0,60 2,40 Indoor inlet air Indoor inlet air D.B.
  • Page 17 All manuals and user guides at all-guides.com GRV122R5TA- n Cooling Characteristics n Heating Characteristics Indoor inlet air Indoor inlet air D.B. (°C) D.B. (°C) Outdoor inlet D.B. temp. (°C) Outdoor inlet air D.B. temp. (°C) 0,60 2,80 Indoor inlet air Indoor inlet air D.B.

  • Page 18: Cooling Capacity

    All manuals and user guides at all-guides.com 5-2 Cooling Capacity GRV72R5TA- OUTDOOR UNIT: MCAV72R5TA- INDOOR UNIT: 220 - 240V ~ 50Hz RATING CAPACITY 2,30 kW moisture removal 0,9 l/h COMP. POWER INPUT 0,802 kW max comp input 0,902 kW AIR FLOW RATE 430 m³/h EVAPORATOR CONDENSER...
  • Page 19 All manuals and user guides at all-guides.com GRV92R5TA- OUTDOOR UNIT: MCAV92R5TA- INDOOR UNIT: 220 - 240V ~ 50Hz RATING CAPACITY 2,50 kW moisture removal 1,1 l/h COMP. POWER INPUT 0,963 kW max comp input 1,14 kW AIR FLOW RATE 450 m³/h EVAPORATOR CONDENSER ENT.TEMP.
  • Page 20 All manuals and user guides at all-guides.com GRV122R5TA- OUTDOOR UNIT: MCAV122R5TA- INDOOR UNIT: 220 - 240V ~ 50Hz RATING CAPACITY 3,10 kW moisture removal 1,5 l/h COMP. POWER INPUT 1,206 kW max comp input 1,426 kW AIR FLOW RATE 470 m³/h EVAPORATOR CONDENSER ENT.TEMP.

  • Page 21: Heating Capacity

    All manuals and user guides at all-guides.com 5-3 Heating Capacity –8 –5 Outdoor temperature (°C D.B.) NOTE … Point of Rating condition Black dot in the chart indicate the following rating condition. Indoor : 20°C D.B. Outdoor : 7°C D.B. / 6°C W.B. 2) Above characteristics indicate instantaneous operation, which does not take into consideration defrost operation.

  • Page 22: Electrical Data

    All manuals and user guides at all-guides.com 6. ELECTRICAL DATA 6-1 Electrical characteristics OUTDOOR UNIT: GRV72R5TA- COOLING Indoor Unit Outdoor unit Complete Unit Fan Motor Fan Motor Compressor performance at 230V 1-Phase 50 Hz Rating conditions Running Amps. 0,11 0,28 3,61 Power input 0,025...
  • Page 23 All manuals and user guides at all-guides.com OUTDOOR UNIT: GRV92R5TA- COOLING Indoor Unit Outdoor unit Complete Unit Fan Motor Fan Motor Compressor performance at 230V 1-Phase 50 Hz Rating conditions Running Amps. 0,12 0,28 Power input 0,027 0,063 0,963 1,040 Full load conditions Running Amps.
  • Page 24 All manuals and user guides at all-guides.com OUTDOOR UNIT: GRV122R5TA- COOLING Indoor Unit Outdoor unit Complete Unit Fan Motor Fan Motor Compressor performance at 230V 1-Phase 50 Hz Rating conditions Running Amps. 0,13 0,28 5,79 Power input 0,031 0,063 1,206 1,300 Full load conditions Running Amps.

  • Page 25: Electric Wiring Diagram

    All manuals and user guides at all-guides.com 6-2 Electric Wiring Diagram 6-3 System Wiring Diagram...
  • Page 26 All manuals and user guides at all-guides.com R.D. 28 Reyrieux BP 131 - 01601 Trévoux CEDEX France Tél. 04.74.00.92.92 - Fax 04.74.00.42.00 R.C.S. Bourg-en-Bresse B 759 200 728...
