- Page 1 TECHNICAL DATA & SERVICE MANUAL OUTDOOR UNIT: GRF99R5IAA GRF129R5IAA SPLIT SYSTEM AIR CONDITIONER Model No. Product Code No. GRF99R5IAA 387107101 GRF129R5IAA 387107099 0.8180.580.00 05/2009...
- Page 2 IMPORTANT! • Ground the unit following local electrical codes. • The Yellow/Green wire cannot be used for any connection Please read before installation different from the ground connection. • Connect all wiring tightly. Loose wiring may cause overheating This air conditioning system meets strict safety and operating at connection points and a possible fire hazard.
-
Page 3: Table Of Contents
Table of Contents Page 1. OPERATING RANGE 2. SPECIFICATIONS 2-1 Unit specifications 2-2 Major Component specifications 2-3 Other Component specifications 3. DIMENSIONAL DATA 4. REFRIGERANT FLOW DIAGRAM 5. PERFORMANCE DATA 5-1 Performance Charts 6. ELECTRICAL DATA 6-1 Electrical characteristics 6-2 Electric Wiring Diagram 6-3 System Wiring Diagram... -
Page 4: Operating Range
1. OPERATING RANGE GRF98R5IAA - GRF128R5IAA Temperature Indoor Air Intake Temp. Outdoor Air Intake Temp. Maximum 32°C D.B. / 23°C W.B. 43°C D.B. Cooling Minimum 10°C D.B. / 6°C W.B. -15°C D.B. Maximum 27°C D.B. 24°C D.B. / 18°C W.B. Heating Minimum 5°C D.B. -
Page 5: Specifications
2. SPECIFICATIONS 2-1 Unit Specifications GRF99R5IAA 220 - 240V ~ 50Hz Power source 230V Voltage rating Performance * MRAF99R5IAA Cooling Heating 2,85 3,24 Capacity BTU/h 9720 11050 Air circulation (High) m³/h Moisture removal (High) Liters/h Cooling Heating Electrical Rating 198 ~ 264... - Page 6 GRF129R5IAA 220 - 240V ~ 50Hz Power source 230V Voltage rating Performance * MRAF129R5IAA Cooling Heating 3,25 3,40 Capacity 11083 11594 BTU/h Air circulation (High) m³/h Moisture removal (High) Liters/h Cooling Heating Electrical Rating 198 ~ 264 Available voltage range 4,50 Running amperes Power input...
-
Page 7: Major Component Specifications
2-2 Major Component Specifications Outdoor Unit: GRF99R5IAA Compressor Rotary (Hermetic) DC inverter Type G4C090LUCJR Compressor model Nominal input (compressor rating condition) RB68EP …… 320 Compressor oil…Amount Ω 0,77 Coil resistance (Ambient temp. 20°C) Overload relay software protection Safety devices Type Operating Temp. - Page 8 Outdoor Unit: GRF129R5IAA Compressor Rotary (Hermetic) DC inverter Type G4A110LUBJR Compressor model 1018 Nominal input FV50S Compressor oil…Amount Ω 0,48 Coil resistance (Ambient temp. 20°C) Overload relay software protection Safety devices Type Operating Temp. Open °C Close °C Fan & Fan Motor Propeller Type 1….
-
Page 9: Other Component Specifications
2-3 Other Component Specifications GRF99R5IAA GRF129R5IAA 4-way Valve (20S) SQ-136 (Coil) SHF-4H-23U (Valve) Coil rating AC 220/240 V, 50 Hz, 6W Ω (at 20°C) Coil resistance 1440 ± 7% ZCAM-MD12EX(Coil) ZCAM-BD15EX (Valve) Electr. Expansion Valve DC 12V Coil rating Ω (at 20°C) 46 ±... -
Page 10: Dimensional Data
3. DIMENSIONAL DATA 4 – ø12 holes Air intake Wide tube service valve ø9.52 (3/8") 7000/9000 BTU/h ø12.7 (1/2") 12000 BTU/h Narrow tube service valve Air discharge ø6.35 (1/4") Unit : mm... -
Page 11: Refrigerant Flow Diagram
4. REFRIGERANT FLOW DIAGRAM Indoor Unit: MRAF99R5IAA Outdoor Unit: GRF99R5IAA MRAF129R5IAA GRF129R5IAA... - Page 12 Insulation of Refrigerant Tubing IMPORTANT Because capillary tubing is used in the outdoor unit, both the wide and narrow tubes of this air conditioner become cold. To prevent heat loss and wet floors due to dripping of condensation, both tubes must be well insulated with a proper insulation material.
-
Page 13: Performance Data
5. PERFORMANCE DATA 5-1 Performance charts GRF99R5IAA Cooling Characteristics Heating Characteristics Indoor inlet air D.B. (°C) Indoor inlet air D.B. (°C) Outdoor inlet air D.B. temp. (°C) Outdoor inlet D.B. temp. (°C) 34,0 Indoor inlet air Indoor inlet air 32,0 D.B. - Page 14 GRF129R5IAA Cooling Characteristics Heating Characteristics Indoor inlet air D.B. (°C) Indoor inlet air D.B. (°C) Outdoor inlet air D.B. temp. (°C) Outdoor inlet D.B. temp. (°C) 34,5 Indoor inlet air 34,0 D.B. (°C) 33,5 33,0 32,5 Indoor inlet air D.B. (°C) 32,0 Outdoor inlet air D.B.
-
Page 15: Electrical Data
6-1 Electrical characteristics OUTDOOR UNIT: GRF99R5IAA COOLING Indoor Unit Outdoor unit Complete Unit Fan Motor Fan Motor + compressor performance at 230V 1-Phase 50 Hz Rating conditions Running Amps. 0,12 3,48 Power input 0,027 0,753 0,780 Rating Conditions: Indoor Air Temperature 27°C D.B. / 19°C W.B. - Page 16 OUTDOOR UNIT: GRF129R5IAA COOLING Indoor Unit Outdoor unit Complete Unit Fan Motor Fan Motor + compressor performance at 230V 1-Phase 50 Hz Rating conditions Running Amps. 0,13 4,37 Power input 0,031 0,949 0,980 Rating Conditions: Indoor Air Temperature 27°C D.B. / 19°C W.B. Outdoor Air Temperature 35°C D.B.
-
Page 17: Electric Wiring Diagram
6-2 Electric Wiring Diagram 6-3 System Wiring Diagram... - Page 18 0.8180.580.00 05/2009 R.D. 28 Reyrieux BP 131 - 01601 Trévoux CEDEX France Tél. 04.74.00.92.92 - Fax 04.74.00.42.00 R.C.S. Bourg-en-Bresse B 759 200 728...
