Page 1 RFID System V680S Series User’s Manual (EtherNet/IP Reader/Writer V680S-HMD63-EIP V680S-HMD64-EIP V680S-HMD66-EIP Man. No. Z353-E1-12...
Page 2 If you find any problems in this manual, please contact your OMRON representative. If you do so, please provide the Cat. No. that is given at the back of this manual.
Page 3: Introduction
Installation and Connections Section 4 Preparations for Communications Section 5 Functions Section 6 Host Communications Specifications Section 7 Web Browser Interface Section8 Troubleshooting Section9 Maintenance and Inspection Section10 Appendices Section11 RFID System V680S-HMD63-EIP Reader/Writer V680S-HMD64-EIP Reader/Writer V680S-HMD66-EIP Reader/Writer User's Manual...
Page 4: Terms And Conditions Agreement
Omron’s exclusive warranty is that the Products will be free from defects in materials and workmanship for a period of twelve months from the date of sale by Omron (or such other period expressed in writing by Omron). Omron disclaims all other warranties, express or implied.
Page 5 Disclaimers 1. Performance Data Data presented in Omron Company websites, catalogs and other materials is provided as a guide for the user in determining suitability and does not constitute a warranty. It may represent the result of Omron’s test conditions, and the user must correlate it to actual application requirements. Actual performance is subject to the Omron’s Warranty and Limitations of Liability.
Page 6: Precautions For Safe Use
• Do not bend the Cable to a bending radius of 40 mm or less. Doing so may break the wires. • If an error is detected in the Product, immediately stop operation and turn OFF the power supply. Consult with an OMRON representative. 4. Cleaning •...
Page 7: Precautions For Correct Use
Introduction Precautions for Correct Use Always observe the following precautions to prevent operation failures, malfunctions, and adverse effects on performance and equipment. 1. Installation and Storage Environment Do not use or store the Product in the following locations. • Locations subject to combustible gases, explosive gases, corrosive gases, dust, dirt, metal powder, or salt •...
Page 8: Meanings Of Symbols
Introduction Meanings of Symbols Indicates particularly important points related to a function, including precautions and application advice. Indicates page numbers containing relevant information. Indicates reference to helpful information and explanations for difficult terminology. RFID System User's Manual (EtherNet/IP...
Page 9: Table Of Contents
Introduction Table of Contents Introduction Terms and Conditions Agreement Precautions for Safe Use Precautions for Correct Use Meanings of Symbols Table of Contents Section 1 Product Overview Features Application Flowchart Product Specifications Reader/Writer Connector Cover (Slim Type) RF Tag Data Characteristics Communications Range Specifications Section 2 System Configuration System Configuration...
Page 10 Introduction Connections and Wiring Connecting and Removing the Reader/Writer Power Cable and Ethernet Cable Section 5 Preparations for Communications Starting the Reader/Writer Reader/Writer Starting Procedure Setting Communications Conditions Preparations for Work Setting the IP Address of the Reader/Writer from a Web Browser Setting the IP Address of the Reader/Writer on the Network Configurator Setting Tag Data Links Section 6 Functions...
Page 11 Introduction RFID System Maintenance Communication Diagnostic RF Analyzer Multi-Reader/Writer Operation Field Extension Mode High-speed Traveling Mode Using Communication Diagnostic and the RF Analyzer Using the Web Server Using Multi-Reader/Writer Operation Using Field Extension Mode Using High-speed Traveling Mode Section 7 Host Communications Specifications EtherNet/IP Communications Protocol Data Exchange with Ethernet/IP EtherNet/IP Communications with the Reader/Writer...
Page 12 Introduction GET COMMAND ERROR LOG GET RESTORE INFORMATION GET MULTI-READER/WRITER STATUS RESET Time Charts Time Charts 182 Section 8 Web Browser Interface Web Browser Operation Window Operation Interface Password Entry View Status View Network Settings View Communications Settings View SET MULTI-READER/WRITER OPERATION RF Tag Communications View Log View Noise Monitor View...
Page 13 Introduction Troubleshooting Flowcharts Main Check Flowchart System Connections Check Flowchart Operating Conditions and External Environment Check Flowchart Host Device Communications Check Flowchart RF Tag Communications Check Flow About The Ethernet Communication Abnormality When the Web browser screen is not displayed or the screen layout is strange Google Chrome Internet explorer11 Microsoft Edge...
Page 14 Introduction IV680S-D2KF68M V680S-D8KF68 V680S-D8KF68M RF Tag Memory Capacities and Memory Types RF Tag Memory Map Chemical Resistance of the Reader/Writers and RF Tags Degree of Protection Differences in Address and Size Specifications between V680 and V680S Reader/Writers Index Revision History Firmware Version Update History RFID System User's Manual...
Page 15: Section 1 Product Overview
Section 1 Product Overview Features Application Flowchart Product Specifications Reader/Writer Connector Cover (Slim Type) RF Tag Data Characteristics Communications Range Specifications RFID System User's Manual (EtherNet/IP...
Page 16: Features
The integrated V680S-series Reader/Writers (V680S-HMD6-EIP) perform communications with RF Tags according to commands from a host device.  Integrated Structure The controller, amplifier, and antenna are integrated into the Reader/Writer for a simple structure. Previous OMRON models V680S Integrated Reader/Writer Reader/Writer Antennas...
Page 17 You can check the communications leeway to appropriately install the Reader/Writer and RF Tags to achieve stable operation of your OMRON RFID System. For details, refer to Using Communication Diagnostic and the RF Analyzer in Section 6 Functions .
Page 18 Section 1 Product Overview  Simple Connection with EtherNet/IP The Reader/Writer communicates with the host device through EtherNet/IP. EtherNet/IP is an industrial multi-vendor network that uses Ethernet. The EtherNet/IP specifications are open standards managed by the ODVA (Open DeviceNet Vendor Association). EtherNet/IP is used by a wide range of industrial devices.
Page 19 Section 1 Product Overview  Easy Operation A Web server is provided so that you can easily perform setup and status monitoring by connecting to a computer, without the need for any special software. Computer Reader/Writer Switching Hub 24-VDC power supply You can connect a computer to the Switching Hub to easily set up the Reader/Writers and check the status of the Reader/Writers.
Page 20: Application Flowchart
Installation p.66 Install the Reader/Writer with four M4 screws. V680S-HMD63-EIP: Use two screws. M4 screw V680S-HMD64-EIP/-HMD66-EIP: Use four screws. Spring washer Flat washer Connections and Wiring p.78 Insert the Power Cable into the power supply connector on the Reader/Writer (M12 A-Coding, female) and turn the cable connector on the Reader/Writer end clockwise to lock it in place.
Page 21 Section 1 Product Overview Setting Reader/Writer Communications Conditions p.83 he default network settings for the Reader/Writer are listed in the following table. IP address 192.168.1.200 (fixed settings) Subnet mask 255.255.255.0 Default gateway 192.168.1.254 Port number for Web browser 7090 Change the network settings of the host device to match those of the Reader/Writer. Host Device Setting Example IP address: 192.168.1.100 Subnet mask: 255.255.255.0...
Page 22 Section 1 Product Overview Using Communication Diagnostic to Check Communications Leeway p.118 Connect the Ethernet cable, turn ON the power supply to the Reader/Writer, and then start a Web browser on a computer. Specify the IP address of the Reader/Writer in the address field of the Web browser. Enter http://192.168.1.200/ if you are using the default IP address.
Page 23 Section 1 Product Overview Using the RF Analyzer to Check the Results of Communication Diagnostic p.122 Display the RF Analyzer View. Click the Display Button in the Details column and follow the guidance to check the assumed causes and corrections. RFID System User's Manual (EtherNet/IP...
Page 24 Section 1 Product Overview In this example, the position of the Tag is corrected according to the guidance. You can check the graph display to check quantitative information on the degree of instability. When you are finished, perform the step to communicate with the RF Tag again and check to see if stable communications have been achieved.
Page 25 Section 1 Product Overview Communications with RF Tags for Commands from the Host Device Using Tag Data Links p.152 The Reader/Writer can perform various types of communications with RF Tags. Communications Description Page command name READ DATA Reads data from an RF Tag in the communications field. p.157 WRITE DATA Writes data to an RF Tag in the communications field.
Page 26 Section 1 Product Overview If you Encounter a Problem... Troubleshooting p.153 Error Codes p.60 Operation Indicators p.224 Troubleshooting Flowcharts RFID System User's Manual (EtherNet/IP...
Page 27: Product Specifications
Host device EtherNet/IP communications protocol Accessories Instruction Sheet Copy of EC Self Declaration IP address label Note 1. Oil resistance has been tested using a specific oil as defined in the OMRON test method. RFID System User's Manual (EtherNet/IP...
Page 28 Section 1 Product Overview  Dimensions  V680S-HMD63-EIP (Unit: mm) Seven operation indicators Two, 4.5 dia. mounting holes Standards label Two, M4 holes 42±0.2 Mounting Hole Dimensions 18 dia. Cable bracket (20.5) 8-dia. round vinyl-insulated cable 8 dia. 4.6 dia. mounting hole View from Arrow A 6.5-dia.
Page 29 Section 1 Product Overview  V680S-HMD64-EIP (Unit: mm) Seven operation indicators Four, 4.5 dia. mounting holes Standards label Four, M4 holes 65±0.2 18 dia. Cable bracket Mounting Hole Dimensions (20.5) 8-dia. round vinyl-insulated cable 17.5 8 dia. 4.6 dia. mounting hole View from Arrow A 6.5-dia.
Page 30 Section 1 Product Overview  V680S-HMD66-EIP (Unit: mm) Seven operation indicators Four, 4.5 dia. mounting holes Standards label Four, M4 holes 110±0.2 18 dia. Mounting Hole Dimensions Cable bracket (20.5) 8-dia. round vinyl-insulated cable 17.5 8 dia. 4.6 dia. mounting hole View from Arrow A 6.5-dia.
Page 31: Connector Cover (Slim Type)
Mounting hole Connector Cover Mounting hole 27±0.2  V680S-A64 (Unit: mm) Mounting Hole Dimensions (V680S-HMD66-EIP) 110 ±0.2 6-M4 Mounting Hole Dimensions (V680S-HMD64-EIP) 65 ±0.2 6-M4 Reader/Writer Mounting hole Reader/Writer Mounting hole Connector Cover Connector Cover Mounting hole Mounting hole 27 ±0.2 27 ±0.2...
Page 32: Rf Tag
Note 1. After storing RF Tags at high temperatures, rewrite the data even if changes are not required. High temperatures are those between 125 and 180°C. 2. Oil resistance has been tested using a specific oil as defined in the OMRON test method.  Dimensions (Unit: mm) 1.1 2.7±0.1...
Page 33 Section 1 Product Overview V700-A80 Attachment (Unit: mm) Mounting Hole Dimensions Two, M3 holes 31±0.2 31±0.2 Materials PPS resin  RF Tag Heat Resistance •Storing RF Tags under high temperatures or under heat cycles will adversely affect the performance of the internal parts and the service life of the RF Tags. An LTPD of 10% was used for evaluation of RF Tags that reached the end of their service life after testing under the following test conditions.
Page 34 Note 1. After storing RF Tags at high temperatures, rewrite the data even if changes are not required. High temperatures are those between 125 and 180°C. 2. Oil resistance has been tested using a specific oil as defined in the OMRON test method. The V680-D1KP66MT must be mounted on a metallic surface. The markings on the V680-D1KP66T and V680-D1KP66MT are shown below.
Page 35 Section 1 Product Overview  Dimensions V680-D1KP66T/-D1KP66MT (Unit: mm) Four, 4-mm corners Mounting Hole Dimensions Four, 3-mm corners +0.2 Two, M3 holes +0.2 +0.2 Two, 3.5 dia. Two, 6 dia. +0.2 +0.1 Case material PPS resin V600-A86 Attachment (Unit: mm) Four, 5.5-mm corners Two, 4 dia.
Page 36 Section 1 Product Overview  V680-D1KP66T-SP  General Specifications Item Specification Compliance standards ISO/IEC 18000-3 (15693) Memory capacity 1,000 bytes Memory type EEPROM Data retention 10 years (85°C or less) Write endurance 100,000 writes for each block (25°C) Ambient operating -25 to 70°C (with no icing) temperature Ambient operating...
Page 37 Note 1. After storing RF Tags at high temperatures, rewrite the data even if changes are not required. High temperatures are those between 125 and 250°C. 2. Oil resistance has been tested using a specific oil as defined in the OMRON test method.  Dimensions V680-D1KP58HTN 10±0.2...
Page 38 Section 1 Product Overview V680-A80 Attachment This Attachment is used to hold V680-D1KP58HTN ID Tags. Applicable model: V680-D1KP58HTN (Unit: mm) 20 dia. 3.2 dia. 12 dia. 11.5 Mounting Hole Dimensions Accessories: 2 nuts (M12) 1 split pin (nominal dimensions: 3.2-mm dia. × 20-mm length) ...
Page 39 Section 1 Product Overview  Data Retention Time Reset Procedure Always use the following procedure to reset the data holding time before a total of 10 hours is reached. When Using RF Tag Memory Addresses 0010 to 0015 hex 1. Read the data from RF Tag addresses 0010 to 0015 hex. RF Tag Memory 0010 Read the memory addresses...
Page 40 Note 1. The number of accesses is the total number of reads and writes. 2. Oil resistance has been tested using a specific oil as defined in the OMRON test method. The V680S-D2KF67M/-D8KF67M must be mounted on a metallic surface. The markings on the V680- D2KF67/-D8KF67 and V680-D2KF67M/-D8KF67M are shown below.
Page 41 Section 1 Product Overview  Dimensions V680S-D2KF67/-D2KF67M/-D8KF67/-D8KF67M (Unit: mm) Two, 3.5-dia. mounting holes Mounting Hole Dimensions Two, M3 holes 32±0.2 32±0.2 Case material PPS resin RFID System User's Manual (EtherNet/IP...
Page 42 Note 1. The number of accesses is the total number of reads and writes. 2. Oil resistance has been tested using a specific oil as defined in the OMRON test method. The V680S-D2KF68M/-D8KF68M must be mounted on a metallic surface. The markings on the V680- D2KF68/-D8KF68 and V680-D2KF68M/-D8KF68M are shown below.
Page 43 Section 1 Product Overview You can use the V680S-D8KF68 with Reader/Writers with firmware version 2.00 or higher.  Dimensions V680S-D2KF68/-D2KF68M/-D8KF68/-D8KF68M (Unit: mm) Two, 4.5-dia. mounting holes Mounting Hole Dimensions Two, M4 holes 76±0.2 76±0.2 Case material PPS resin RFID System User's Manual (EtherNet/IP...
Page 44: Data Characteristics
Section 1 Product Overview Data Characteristics Communications Range Specifications  V680S-HMD63-EIP Reader/Writer RF Tag Communications range specification V680S-HMD63-EIP V680-D1KP54T Read 0.0 to 24.0 mm (axis offset: ±10 mm) (mounted to metallic (mounted to non-metallic material) Write 0.0 to 20.0 mm (axis offset: ±10 mm) material) V680-D1KP66T Read...
Page 45 Section 1 Product Overview  Installation Conditions V680-D1KP54T V680-D1KP66T V680S-HMD63-EIP V680S-HMD63-EIP Metallic material Metallic material V680-D1KP66T V680-D1KP54T Communications range Communications range Non-metallic material Non-metallic material Non-metallic material Non-metallic material (Examples: Resin, plastic, wood, etc.) (Examples: Resin, plastic, wood, etc.) (Examples: Resin, plastic, wood, etc.) (Examples: Resin, plastic, wood, etc.) V680-D1KP66MT V680-D1KP66T-SP...
Page 46 Section 1 Product Overview  V680S-HMD64-EIP Reader/Writer RF Tag Communications Range Specification Read 0.0 to 33.0 mm (axis offset: ±10 mm) V680S-HMD64-EIP V680-D1KP54T (mounted to metallic material) (mounted to non-metallic material) Write 0.0 to 28.0 mm (axis offset: ±10 mm) Read 0.0 to 47.0 mm (axis offset: ±10 mm)
Page 47 Section 1 Product Overview  Installation Conditions V680S-D2KF67/-D8KF67 V680S-D2KF67/-D8KF67M Metallic material V680S-HMD64-EIP V680S-HMD64-EIP V680S-D2KF67M/-D8KF67M V680S-D2KF67/-D8KF67 Communications Communications range range Non-metallic material Non-metallic material Non-metallic material Non-metallic material (Examples: Resin, plastic, wood, etc.) (Examples: Resin, plastic, wood, etc.) (Examples: Resin, plastic, wood, etc.) (Examples: Resin, plastic, wood, etc.)
Page 48 Section 1 Product Overview V680-D1KP54T V680-D1KP66T Metallic material Metallic material V680S-HMD64-EIP V680S-HMD64-EIP V680-D1KP66T V680-D1KP54T Communications Communications range range Non-metallic material Non-metallic material Non-metallic material Non-metallic material (Examples: Resin, plastic, wood, etc.) (Examples: Resin, plastic, wood, etc.) (Examples: Resin, plastic, wood, etc.) (Examples: Resin, plastic, wood, etc.)
Page 49 Section 1 Product Overview  V680S-HMD66-EIP Reader/Writer RF Tag Communications Range Specification Read 7.5 to 75.0 mm (axis offset: ±10 mm) V680S-HMD66-EIP V680-D1KP54T (mounted to metallic material) (mounted to non-metallic material) Write 7.5 to 75.0 mm (axis offset: ±10 mm) Read 0.0 to 45.0 mm (axis offset: ±10 mm) V680-D1KP66T (mounted to non-metallic material)
Page 50 Section 1 Product Overview  Installation Conditions V680S-D2KF67/-D8KF67 V680S-D2KF67M/-D8KF67M V680S-HMD66-EIP Metallic material Metallic material V680S-HMD66-EIP V680S-D2KF67/-D8KF67 V680S-D2KF67M/-D8KF67M Communications Communications range range Non-metallic material Metallic material Non-metallic material Non-metallic material (Examples: Resin, plastic, wood, etc.) (Examples: Resin, plastic, wood, etc.) (Examples: Resin, plastic, wood, etc.) V680S-D2KF68/-D8KF68 V680S-D2KF68M/-D8KF68M V680S-HMD66-EIP...
Page 51 Section 1 Product Overview V680-D1KP54T V680-D1KP66T Metallic material Metallic material V680S-HMD66-EIP V680S-HMD66-EIP V680-D1KP66T V680-D1KP54T Communications Communications range range Non-metallic material Non-metallic material Non-metallic material Non-metallic material (Examples: Resin, plastic, wood, etc.) (Examples: Resin, plastic, wood, etc.) (Examples: Resin, plastic, wood, etc.) (Examples: Resin, plastic, wood, etc.) V680-D1KP66MT V680-D1KP66T-SP...
Page 52 Section 1 Product Overview MEMO RFID System User's Manual (EtherNet/IP...
Page 53: Section 2 System Configuration
Section 2 System Configuration System Configuration RFID System User's Manual (EtherNet/IP...
Page 54: System Configuration
(e.g., PLC) RF Tag (V680 Series and V680S Series) Ethernet Cable (Max. length: 100 m) (Recommended: XS5W-T42 - MC-K from OMRON) 24-VDC power supply Power Cable (Recommended: XS5F-D42 - 80-F from OMRON) Connect the Ethernet Cable to a host device (e.g., Switching Hub or PLC) that supports STP and ground the host device to 100 Ω...
Page 55 RF Tag RF Tag (V680 Series and V680S Series) (V680 Series and V680S Series) Ethernet Cable (Max. length: 100 m) (Recommended: XS5W-T42 - MC-K from OMRON) Ethernet Cable 24-VDC power supply Power Cable (Recommended: XS5F-D42 - 80-F from OMRON) Ethernet Cable (Max. length: 100 m)
Page 56 (Recommended: W4S1-05C Switching Hub from OMRON) Ethernet Cable Ethernet Cable (Max. length: 100 m) (Recommended: XS5W-T42 - MC-K from OMRON) 24-VDC power supply Power Cable (Recommended: XS5F-D42 - 80-F from OMRON) Connect the Ethernet Cable to a host device (e.g., Switching Hub or PLC) that supports STP and ground the host device to 100 Ω...
Page 57 Section 2 System Configuration  About the Ethernet communication abnormality If an Ethernet network is configured into a loop as shown below, broadcast packets are accumulated in the band, and the communication is disabled. Therefore, do not configure the Ethernet network into a loop. Sending broadcast storm Reader/Writer Broadcast storm...
Page 58 Section 2 System Configuration MEMO RFID System User's Manual (EtherNet/IP...
Page 59: Section 3 Names And Functions Of Components
Section 3 Names and Functions of Components Component Names Reader/Writer RF Tag RFID System User's Manual (EtherNet/IP...
Page 60: Component Names
Section 3 Names and Functions of Components Component Names Reader/Writer V680S-HMD63-EIP V680S-HMD64-EIP LINK/ACT LINK/ACT NORM/ERR NORM/ERR NORM/ERR NORM/ERR NORM/ERR NORM/ERR NORM/ERR NORM/ERR Ethernet connector Power supply connector Ethernet connector Power supply connector RFID System User's Manual (EtherNet/IP...
Page 61 Section 3 Names and Functions of Components V680S-HMD66-EIP LINK/ACT NORM/ERR NORM/ERR NORM/ERR NORM/ERR Ethernet Connector Power supply connector RFID System User's Manual (EtherNet/IP...
Page 62 Section 3 Names and Functions of Components  Operation Indicators  Status Meaning Lit green Lighting while the Reader/Writer is operating normally. Flashing Flashes during operation in Safe Mode. (Flashes at 1-s intervals.) green Flashing The indicator will flash quickly in the following cases. (Flashes at 200-ms intervals.) green •...
Page 63 Section 3 Names and Functions of Components  Connector  Power Supply Connector (M12 A-Coding) Power Supply Connector (M12 A-Coding, male) Pin No. Name Description +24 V Control signal (operating mode signal) CONT * Run Mode: Connect to +24 V and then start the Reader/Writer. Safe Mode: Connect to 0 V and then start the Reader/Writer.
Page 64: Rf Tag
Section 3 Names and Functions of Components RF Tag The model numbers of the RF Tags that can communicate with the Reader/Writer are given in this section. For the communications range specifications, refer to Communications Range Specifications in Section 1 Product Overview. p.42 (Unit: mm) ...
Page 65 Section 3 Names and Functions of Components (Unit: mm)  V680S-D2KF67/-D2KF67M/-D8KF67/-D8KF67M Shape: 40 × 40 × 5 (W × H × D)  V680S-D2KF68/-D2KF68M/-D8KF68/-D8KF68M Shape: 86 × 54 × 10 (W × H × D) You can use the V680S-D8KF6 with Reader/Writers with firmware version 2.00 or higher. RFID System User's Manual (EtherNet/IP...
Page 66 Section 3 Names and Functions of Components MEMO RFID System User's Manual (EtherNet/IP...
Page 67: Section 4 Installation And Connections
Section 4 Installation and Connections Installation Reader/Writer Connector Cover RF Tag Connections and Wiring Connecting and Removing the Reader/Writer Power Cable and Ethernet Cable RFID System User's Manual (EtherNet/IP...
Page 68: Installation
Section 4 Installation and Connections Installation Reader/Writer  V680S-HMD63-EIP Install the Reader/Writer with two M4 screws. Use both spring washers and flat washer. M4 screw Spring washer Mounting Hole Dimensions Flat washer Two, M4 holes 42±0.2 (Unit: mm) When you install the Reader/Writer, prepare the metal plate shown in the following figure. When the metal plates size is larger than the below illustration, communication range will change.
Page 69 Section 4 Installation and Connections  V680S-HMD64-EIP Install the Reader/Writer with four M4 screws. Use both spring washers and flat washers. M4 screw Spring washer Flat washer Mounting Hole Dimensions Four, M4 holes 65±0.2 (Unit: mm) When you install the Reader/Writer, prepare the metal plate shown in the following figure.
Page 70 Section 4 Installation and Connections  V680S-HMD66-EIP Install the Reader/Writer with four M4 screws. Use both spring washers and flat washers. Bracket Spring washer Mounting Hole Dimensions Flat washer Four, M4 holes 110±0.2 (Unit: mm) When you install the Reader/Writer, prepare the metal plate shown in the following figure. When the metal plates size is larger than the below illustration, communication range will change.
Page 71: Connector Cover
Section 4 Installation and Connections Connector Cover  V680S-A63-S Either use the V680S-A63-S Attachment to mount the Connector Cover with screws or permanently attach the RF Tags with adhesive. Through a cord into a connector cover. Press a connector cover up until it clicks. Install the connector cover with two M4 screws.
Page 72 Section 4 Installation and Connections  V680S-A64-S Either use the V680S-A64-S Attachment to mount the Connector Cover with screws or permanently attach the RF Tags with adhesive. Through a cord into a connector cover. Press a connector cover up until it clicks. Install the connector cover with two M4 screws.
Page 73: Rf Tag
Section 4 Installation and Connections RF Tag  V680-D1KP54T Either use the V700-A80 Attachment to mount the RF Tags with screws or permanently attach the RF Tags with adhesive. Installation with the V700-A80 Attachment Place the V680-D1KP54T RF Tag in the Attachment. The V680-D1KP54T RF Tag can be placed in the Attachment in either direction.
Page 74 Section 4 Installation and Connections  V680-D1KP66T  Mounting on Non-metallic Material Mount the RF Tag using M3 flat-head screws Mounting Hole Dimensions from the marked side. Two, M3 holes Tighten the screws to a torque of 0.3 to 0.5 N·m. M3 flat-head screw ±0.2 Marked side...
Page 75 Section 4 Installation and Connections  V680-D1KP66MT Mount the RF Tag using M3 flat-head screws Mounting Hole Dimensions from the marked side. Two, M3 holes Tighten the screws to a torque of 0.3 to 0.5 N·m. M3 flat-head screw ±0.2 Marked side ±0.2 When you install the RF tag, prepare the metal plate as shown in the figure below.
Page 76 Section 4 Installation and Connections  V680-D1KP66T-SP Mount the RF Tag using M5 screws and washers. The tightening torque is 1.2 N·m. There are no restrictions on the mounting direction for the RF Tag or the direction of RF Tag travel in respect to the Reader/Writer.
Page 77 Section 4 Installation and Connections  V680-D1KP58HTN Use the following procedure to install an RF Tag with the V680-A80 Attachment. Attach the Attachment to the workpiece. Mounting Hole Dimensions Tighten the lock nut. · Use a tightening torque of 21 to 42 N Place the RF Tag in the Attachment.
Page 78 Section 4 Installation and Connections  V680S-D2KF67/-D8KF67 Mount the RF Tag with M3 screws. Mounting Hole Dimensions Two, M3 holes Tighten the screws to a torque of 0.6 N·m. M3 screw ±0.2 Marked side ±0.2 Refer to RF Tag Installation Precautions in Section 11 Appendices for information on the effect of metal at the back surface, Mutual Interference of RF Tags and Influence of Inclination of the V680S-D2KF67.
Page 79 Section 4 Installation and Connections  V680S-D2KF68/-D8KF68 Mount the RF Tag with M4 screws. Tighten the screws to a torque of 0.7 to 1.2 N·m. Two, M4 holes M4 screw Spring washer Flat washer Marked side (Unit: mm) Refer to RF Tag Installation Precautions in Section 11 Appendices for information on the effect of metal at the back surface, Mutual Interference of RF Tags and Influence of Inclination of the V680S-D2KF68.
Page 80: Connections And Wiring
Section 4 Installation and Connections Connections and Wiring Connecting and Removing the Reader/Writer Power Cable and Ethernet Cable  Connecting Method Hold onto the connector on the Power Cable and insert it into the power connector on the Reader/ Reader/Writer power Writer.
Page 81 Section 4 Installation and Connections Hold onto the connector on the Ethernet Cable and insert it into the Ethernet connector on the Ethernet connector Reader/Writer. on Reader/Writer (M12 D-Coding, female) Do not apply more than 30 N·m of force to the connector on the Reader/Writer.
Page 82 Section 4 Installation and Connections  Removal Method Turn the connector on the Power Cable counterclockwise to unlock it. Power supply connector on cable Hold onto the connector on the Power Cable and pull it straight out to remove it. Reader/Writer power supply connector (M12 A-Coding, male)
Page 83: Section 5 Preparations For Communications
Section 5 Preparations for Communications Starting the Reader/Writer Reader/Writer Starting Procedure Setting Communications Conditions Preparations for Work Setting the IP Address of the Reader/Writer from a Web Browser Setting the IP Address of the Reader/Writer on the Network Configurator Setting Tag Data Links RFID System User's Manual (EtherNet/IP...
Page 84: Starting The Reader/Writer
Section 5 Preparations for Communications Starting the Reader/Writer Reader/Writer Starting Procedure Connect the Cable to the Reader/Writer. Refer to Connecting and Removing the Reader/Writer Power Cable and Ethernet Cable in Section 4 Installation and Connections for the connector method. p.78 Connect the power supply lines and the operation mode signal line in the Cable to the power source and connect the RJ45 connector to an Ethernet port on the host device.
Page 85: Setting Communications Conditions
Section 5 Preparations for Communications Setting Communications Conditions Preparations for Work Network Configuration The network configuration that is described in this manual is shown in the following figure. Connect the Reader/Writer and the computer with an Ethernet Cable. Computer Reader/Writer Switching Hub Ethernet Cable Ethernet Cable...
Page 86 Section 5 Preparations for Communications  Setting the IP Address on the Computer with Windows 7 or Windows 10 Open the Control Panel, and select Network and Internet and then Network and Sharing Center. Select Change adapter settings and then right-click Local Area Connection. Right-click Local Area Connection and select Properties.
Page 87: Setting The Ip Address Of The Reader/Writer From A Web Browser
Section 5 Preparations for Communications Setting the IP Address of the Reader/Writer from a Web Browser Start the Web browser. Enter the IP address of the Reader/Writer in the address field of the Web browser to display the Web Browser Operation Window.
Page 88 Section 5 Preparations for Communications  Getting an IP Address from a BOOTP Server On the Network Settings View, select the Obtain from BOOTP server Option or the Fix at the IP address which is obtained from BOOTP server Option, and then click the Set Button. If you use the BOOTP client, the IP addresses that are used for the following Reader/Writer functions will change dynamically and may result in unexpected operation.
Page 89: Setting The Ip Address Of The Reader/Writer On The Network Configurator
− − − − To start the Network Configurator, select All Programs OMRON Sysmac Studio Network Configurator for EtherNetIP NetworkConfigurator from the Windows Start Menu. The following window will be displayed when the Network Configurator starts. Go online with the network.
Page 90 Section 5 Preparations for Communications Enter the default IP address of the Reader/Writer (192.168.1.200) in the Target IP Address Box.  Setting a Fixed IP Address 1. Enter the IP address, subnet mask, and default gateway. 2. Click the Set to the Device Button. 3.
Page 91 Section 5 Preparations for Communications  Getting an IP Address from a BOOTP Server 1. Select the Get the IP Address via BOOTP server Option. 2. Click the Set to the Device Button. 3. Click the Reset the Device Button to apply the IP address setting in the Reader/Writer. RFID System User's Manual (EtherNet/IP...
Page 92: Setting Tag Data Links
Section 5 Preparations for Communications Setting Tag Data Links Refer to Section 7 Tag Data Link Setting Methods. p.148 RFID System User's Manual (EtherNet/IP...
Page 93: Section 6 Functions
Section 6 Functions Operation Mode Run Mode Safe Mode RF Tag Communications Communications Options Normal RF Tag Communications Tag Memory Management Reader/Writer Controls RESET Maintenance Reading Device Information Noise Measurement Setting Functions Initialization Setting Communications Conditions Network Settings Error Logs System Error Log Command Error Log Web Server...
Page 94: Operation Mode
Section 6 Functions Operation Mode The Reader/Writer has two operation modes: Run Mode and Safe Mode. You can use the control signal to the Reader/Writer connector to change between these modes. Run Mode When you connect the control signal to the 24-VDC side of the power supply and turn ON the power supply, the Reader/Writer will start in Run Mode.
Page 95: Rf Tag Communications
Section 6 Functions RF Tag Communications Communications Options Communications with the RF Tag are performed according to one of the communications options that are listed in the following table. The setting of the communications option is effective immediately after it is changed. It is saved in internal memory in the Reader/Writer even after the power supply is turned OFF.
Page 96 Section 6 Functions  Once The Reader/Writer communicates with RF Tags for command execution requests from the host device. When the Reader/Writer is finished communicating with an RF Tag, it returns the communications results to the host device and waits for another command. If there is no RF Tag in the communications field when the Reader/Writer receives the command from the host device, an RF Tag missing error will occur.
Page 97 Section 6 Functions  Repeat When the Reader/Writer receives a command execution request from the host device, it automatically detects RF Tags in the communications field and communicates with them. This process is repeated until the execution request is cleared. Communications are not performed for RF Tags that have returned communications results to the host device until the Reader/Writer has to communicate with another RF Tags.
Page 98 Section 6 Functions  FIFO Repeat When the Reader/Writer receives a command execution request from the host device, it automatically detects RF Tags in the communications field and communicates with them. After successfully communicating with an RF Tag once, operation for that RF Tag is stopped. This process is repeated until the execution request is cleared.
Page 99 Section 6 Functions The FIFO Repeat detects the RF tag in the sequence of “1. RF tag detection processing” and executes read/write with the RF tag detected in the sequence of “2. communication processing”. <Without ID code check> When using FIFO Repeat (Without ID code check), please do not put the next RF tag B in the communication area until communication with the detected RF tag is completed.
Page 100: Normal Rf Tag Communications
Section 6 Functions Normal RF Tag Communications The commands in the following table perform communications with RF Tags. Name Description Page READ DATA Reads data from an RF Tag. p.157 WRITE DATA Writes data to the memory of the RF Tag. p.158 READ ID Reads the RF Tag’s ID code.
Page 101 Section 6 Functions RF TAG OVERWRITE COUNT CONTROL Command with a Addition Specification The overwrite count control area consists of 4 bytes from the specified start address. The increment value is added to the overwrite count and then written to this area. When the value reaches 100,000 (i.e., 0186A0 hex), a warning code is returned.
Page 102: Reader/Writer Controls
Section 6 Functions Reader/Writer Controls RESET You can restart the Reader/Writer. You can restart the Reader/Writer by using a RESET command or by using a CIP message (specifically, by issuing the Reset service to the Identity object) from a Web browser. The Reader/ Writer will return the execution results and reset itself.
Page 103: Maintenance
Section 6 Functions Maintenance Reading Device Information You can read the device information given in the following table from the Reader/Writer. You can send a command from the host device or access the information from a Web browser to read the device information.
Page 104: Setting Functions
Section 6 Functions Setting Functions You can use a setting command or a Web browser to set the operating conditions of the Reader/Writer according to the application environment. You can save the settings so that they are stored in internal memory in the Reader/Writer even after the power supply is turned OFF.
Page 105: Setting Communications Conditions
Section 6 Functions Setting Communications Conditions This command sets parameters that are related to the operation of communications with RF Tags. Any changes to the settings that are made with this command are effective immediately. (There is no need to reset the Reader/Writer to save the settings.) ...
Page 106 Section 6 Functions  RF Tag Communications Speed Setting You can set the speed for communications between the Reader/Writer and RF Tags. High speed (default) This setting reduces the communications time by reading more than one block at the same time with an air interface.
Page 107: Network Settings
Section 6 Functions Network Settings You can set the parameters for communications between the Reader/Writer and the host device. If you change the settings, you must reset the Reader/Writer to enable the new settings.  IP Address, Subnet Mask, and Default Gateway You can use any of the following methods to set the IP address, subnet mask, and default gateway for the Reader/Writer.
Page 108: Error Logs
Section 6 Functions Error Logs The Reader/Writer manages errors that occur during operation in logs. The error logs are saved until the power supply to the Reader/Writer is turned OFF. You can read the error logs by sending commands from the host device or by using a Web browser.
Page 109: Web Server
Section 6 Functions Web Server The following functions are provided in the Web server interface. Status Monitoring, Setting, and Confirmation  Status Monitoring You can monitor the status of the Reader/Writer. The Reader/Writer status includes the firmware versions, MAC address, network settings, operating status, and other status information. ...
Page 110: Rfid System Maintenance
Section 6 Functions RFID System Maintenance Communications performance can be affected by environmental factors around the RFID System (including metal objects, the positional relationship between the Reader/Writer and RF Tags, and noise). You can use the RFID System maintenance functions to check the leeway in communications and achieve more stable device operation.
Page 111 Section 6 Functions Communication diagnostic is disabled in the default settings. To use communication diagnostic, you must enable it in advance. Refer to RF Tag Communications View in Section 8 Web Browser Interface for the setting procedure for communication diagnostic. p.196 Use the results of communication diagnostic as a guideline.
Page 112 Section 6 Functions You can use communication diagnostic to detect and diagnoses deterioration of performance for the following conditions. Communications performance reduced by inclination of Communications performance reduced by positional RF Tags offset of RF Tags Communications performance reduced by metal objects Communications performance reduced by an excessively long communications ranges Metal...
Page 113: Rf Analyzer
Section 6 Functions RF Analyzer The RF Analyzer displays detailed information from communication diagnostic on a Web browser. You can easily check to see how stable communications are and troubleshoot problems. You can browse a list of diagnostic information and periodically confirm the leeway quantitatively on graphs. You can download a log file that contains the diagnostic information stored in the Reader/Writer to a computer for your usage.
Page 114 Section 6 Functions An application example of the RFID System maintenance functions is given below. Enable communication diagnostic. p.20 Communicate with an RF Tag. p.19 If the operation indicator lights in yellow, check the RF Analyzer on a Web browser. p.20 Check the assumed causes and corrections with the RF Analyzer and implement suitable measures.
Page 115: Multi-Reader/Writer Operation
Section 6 Functions Multi-Reader/Writer Operation There are two modes that you can use for multi-Reader/Writer operation: Field Extension Mode and High- speed Traveling Mode. You can link up to eight Reader/Writers to perform communications operations with RF Tags. One of the Reader/Writers operates as the master and the other Reader/Writers operate as slaves.
Page 116 Section 6 Functions Field Extension Mode High-speed Traveling Mode LOCK Not supported Not supported The commands that can be acknowledged by a Slave Reader/Writer are shown in the following table. If an unsupported command is received by a Slave Reader/Writer, a multi-Reader/Writer execution error will occur.
Page 117: Field Extension Mode
Section 6 Functions Field Extension Mode You can use this mode to link Reader/Writers in order to extend the effective communications field. Even if the workpieces are not all the same height or not oriented in the same direction, the placement of more than one Reader/Writer enables communicating with the RF Tags without worrying about the positions or orientation of the RF Tags.
Page 118: High-Speed Traveling Mode
Section 6 Functions High-speed Traveling Mode You can read large data sizes from RF Tags because the data is split up and read by more than one Reader/Writer on a time-sharing basis while the workpiece is moving. We recommend that you use this mode when reading data from RF Tags that are moving on a production line.
Page 119 Section 6 Functions In High-speed Traveling Mode, you can use only the READ DATA RF Tag communications command. Also, you can specify only the Auto or Repeat communications option. If you use any communications option other than Repeat in the High-speed Traveling Mode, an execution status error will be indicated in the response.
Page 120: Using Communication Diagnostic And The Rf Analyzer
Section 6 Functions Using Communication Diagnostic and the RF Analyzer You can use communications diagnostics from a Web server. Use either of the following procedures. Use the Web server to use the RF Analyzer. Using the Web Server  Enabling Communication Diagnostic Connect the Ethernet cable, turn ON the power supply to the Reader/Writer, and then start a Web browser on a computer.
Page 121 Section 6 Functions Select the Enable Option for Communication Diagnostics and click the Set Button. Refer to Communications Settings View in Section 8 Web Browser Interface for the setting procedure for the Web browser interface. p.194 When you enable communication diagnostic, the setting will be retained after the Reader/Writer is restarted and communication diagnostic will remain enabled.
Page 122 Section 6 Functions  Communicating with an RF Tag The RF Tag Communications View will be displayed. Place a RF Tag in front of the Reader/Writer. To increase the accuracy of communication diagnostic, we recommend installation in an environment that is as close as possible to the actual application environment.
Page 123 Section 6 Functions Set the communications parameters (data address, data size, etc.), click the Send Button, and check the diagnostic results. RFID System User's Manual (EtherNet/IP...
Page 124 Section 6 Functions  Checking with the RF Analyzer and Implementing Corrections Display the RF Analyzer View. You cannot use the RF Tag Analyzer if you are using the FIFO Repeat communications option. Use the Once, Auto or Repeat communications option. Click the Display Button in the Details column and follow the guidance to check the assumed causes and corrections.
Page 125 Section 6 Functions In this example, the position of the Tag is corrected according to the guidance. You can check the graph display to check quantitative information on the degree of instability. When you are finished, perform the step to communicate with the RF Tag again and check to see if stable communications have been achieved.
Page 126: Using Multi-Reader/Writer Operation
Section 6 Functions Using Multi-Reader/Writer Operation Using Field Extension Mode Use the following procedure for operation in Field Extension Mode. The following figure shows an example in which four Reader/Writers are installed. Slave Reader/Writer No. 1 IP:192.168.1.201 Master Reader/Writer IP:192.168.1.200 Switching Hub IP:192.168.1.203 Slave...
Page 127 Section 6 Functions  Enabling Field Extension Mode Connect all of the Reader/Writers with Ethernet Cables and turn ON the power supplies. Set a unique IP address for each Reader/Writer in advance. Refer to Section 5 Preparations for Communications. Start a Web browser on your computer. In the address field on the Web browser operation window, enter the IP address of the master Reader/ Writer (here, 192.168.1.200).
Page 128 Section 6 Functions Display the Multi-Reader/Writer Settings View. Select the Field Extension Mode Check Box. Set the IP addresses of the three slave Reader/Writers and click the Set Button. RFID System User's Manual (EtherNet/IP...
Page 129 Section 6 Functions A confirmation message will be displayed. Click the OK Button. Click the Reboot Button. A Confirm Reboot Dialog Box will be displayed. Click the OK Button. Click this button to reboot Click this button to cancel the Reader Writer. rebooting the Reader Writer.
Page 130 Section 6 Functions The following dialog box is displayed after reconnecting to the Reader/Writer. Click the OK Button. When re-connection goes wrong and an error message is displayed, check connection with the Reader/Writer and reboot a Web browser. After re-connection, displays the “Status” window. When the Master Reader/Writer is restarted, group registration processing is automatically performed for the registered Slave Reader/Writers.
Page 131 Section 6 Functions  Executing a READ DATA Command in Field Extension Mode.  When the RF Tag Communications Option of the Master Reader/Writer Is Set to Once Send a READ DATA command from the host device to the Master Reader/Writer. Slave Reader/Writer No.
Page 132 Section 6 Functions Slave Reader/Writer No. 1 will communicate with the RF Tag using the Once communications option. Here, communications will end normally or an RF Tag communications error will occur, the Reader/ Writer will return a response to the host device, and processing will end. If an RF Tag tag missing error is detected, processing will be continued in order by Slave No.
Page 133 Section 6 Functions  When the RF Tag Communications Option of the Master Reader/Writer Is Set to Auto Send a READ DATA command from the host device to the Master Reader/Writer. Slave Reader/Writer No. 1 IP:192.168.1.201 READ DATA Master Reader/Writer IP:192.168.1.200 IP:192.168.1.203 Slave...
Page 134 Section 6 Functions Slave Reader/Writer No. 1 will communicate with the RF Tag using the Once communications option. Here, communications will end normally or an RF Tag communications error will occur, the Reader/ Writer will return a response to the host device, and processing will end. If an RF Tag tag missing error is detected, processing will be continued in order by Slave No.
Page 135 Section 6 Functions  When the RF Tag Communications Option of the Master Reader/Writer Is Set to Repeat Send a READ DATA command from the host device to the Master Reader/Writer. Slave Reader/Writer No. 1 IP:192.168.1.201 READ DATA Master Reader/Writer IP:192.168.1.200 IP:192.168.1.203 Slave...
Page 136 Section 6 Functions Slave Reader/Writer No. 1 will communicate with the RF Tag using the Once communications option. Here, if RF Tag communications end normally, the Reader/Writer will return a response to the host device and processing is repeated from step 2. If an RF Tag tag missing error is detected, processing will be continued in order by Slave No.
Page 137: Using High-Speed Traveling Mode
Section 6 Functions Using High-speed Traveling Mode Use the following procedure for operation in High-speed Traveling Mode. The following figure shows an example in which four Reader/Writers are installed. Master Reader/Writer IP:192.168.1.200 Direction of line movement IP:192.168.1.201 Switching Hub Slave Reader/Writer No.
Page 138 Section 6 Functions  Enabling High-speed Traveling Mode Connect all of the Reader/Writers with Ethernet Cable and turn ON the power supplies. Set a unique IP address for each Reader/Writer in advance. Refer to Section 5 Preparations for Communications. Start a Web browser on your computer. In the address field on the Web browser operation window, enter the IP address of the master Reader/ Writer (here, 192.168.1.200).
Page 139 Section 6 Functions Display the Multi-Reader/Writer Settings View. Select the High-speed travelling mode Check Box. Set the IP addresses of the three slave Reader/Writers and click the Set Button. RFID System User's Manual (EtherNet/IP...
Page 140 Section 6 Functions A confirmation message will be displayed. Click the OK Button. Click the Reboot Button. A Confirm Reboot Dialog Box will be displayed. Click the OK Button. Click this button to reboot Click this button to cancel the Reader Writer. rebooting the Reader Writer.
Page 141 Section 6 Functions The following dialog box is displayed after reconnecting to the Reader/Writer. Click the OK Button. When re-connection goes wrong and an error message is displayed, check connection with the Reader/Writer and reboot a Web browser. After re-connection, display the “Status” window. When the Master Reader/Writer is restarted, group registration processing is automatically performed for the registered Slave Reader/Writers.
Page 142 Section 6 Functions  Executing a READ DATA Command in High-speed Traveling Mode. Send a READ DATA command from the host device to the Master Reader/Writer. READ DATA Master Reader/Writer IP:192.168.1.200 Direction of line movement IP:192.168.1.201 Slave Switching Hub Reader/Writer No.
Page 143 Section 6 Functions Slave No. 1 will wait for an RF Tag to enter the communications field and then communicate with the RF Tag. If communicating with the RF Tag ends normally, processing will be continued in order by Slave No. 2 and then by Slave No. 3. Master Reader/Writer IP:192.168.1.200 Direction of line...
Page 144 Section 6 Functions  Disabling Multi-Reader/Writer Operation The following example procedure shows how to disable the multi-Reader/Writer operation. You can use the same procedure from either Field Extension Mode or High-speed Traveling Mode. Start the Web browser on your computer and enter the IP address of the master Reader/Writer (here, 192.168.1.200) in the address field.
Page 145 Section 6 Functions A confirmation message will be displayed. Click the OK Button. Click the Reboot Button. A Confirm Reboot Dialog Box will be displayed. Click the OK Button. Click this button to reboot Click this button to cancel the Reader Writer. rebooting the Reader Writer.
Page 146 Section 6 Functions The following dialog box is displayed after reconnecting to the Reader/Writer. Click the OK Button. When re-connection goes wrong and an error message is displayed, check connection with the Reader/Writer and reboot a Web browser. After re-connection, display the “Status” window. The Slave Reader/Writers will also be restarted automatically.
Page 147: Section 7 Host Communications Specifications
Section 7 Host Communications Specifications EtherNet/IP Communications Protocol Data Exchange with Ethernet/IP EtherNet/IP Communications with the Reader/Writer 147 Tag Data Link Setting Methods Memory Assignments V680S Commands V680S Command Details READ ID READ DATA WRITE DATA LOCK DATA FILL RF TAG OVERWRITE COUNT CONTROL RESTORE DATA COPY DATA INITIALIZE...
Page 148: Ethernet/Ip Communications Protocol
Section 7 Host Communications Specifications EtherNet/IP Communications Protocol Data Exchange with Ethernet/IP Data is exchanged cyclically between Ethernet devices on the EtherNet/IP network using tag data links as shown below. Originator Target Reader/Writer Output tag set name: Input tag set name: Output_10 Tag: D100 Tag: Output_10...
Page 149: Ethernet/Ip Communications With The Reader/Writer
Section 7 Host Communications Specifications EtherNet/IP Communications with the Reader/Writer You can use EtherNet/IP tag data links to communicate between the PLC and the Reader/Writer to perform control via command/response communications or to perform RF Tag communications. The following communications areas are prepared in the PLC to perform communications. Area name Description Command Area...
Page 150: Tag Data Link Setting Methods
To connect to OMRON PLCs or Controllers, you use the Network Configurator to set up tag data links (i.e., tags, tag sets, and connection settings).
Page 151 Input connection (1,032-byte tag set and tags) If you connect to an OMRON master, the maximum data size for one tag data link connection depends on the model of the master. Use the sizes in the following table for reference.
Page 152: Memory Assignments
Section 7 Host Communications Specifications Memory Assignments This section describes the memory assignments for the Command Area and Response Area in the PLC. Memory is aligned in 16-bit units. The bit order for each field is little endian.  Command Area (from PLC Originator to Reader/Writer Target) memory offset Resv Resv Resv Resv Resv Resv Resv Resv Resv Resv Resv Resv Resv Resv Resv...
Page 153 Section 7 Host Communications Specifications  Response Area (from Reader/Writer Target to PLC Originator) memory offset Resv Resv Resv Resv Resv Resv Resv FRIC ERR Error code Response Information 1 Response Information 2 Response Data (The format depends on the command.) * Reserved (resv) bits are for future expansion.
Page 154: V680S Commands
Section 7 Host Communications Specifications V680S Commands  Command Codes The following table lists the command codes that you can specify for execution by the Reader/Writer. Set these codes in the Command Code field in the command area. Classification Command code Command name Reference RF Tag communications...
Page 155 Section 7 Host Communications Specifications  Error Codes The following tables list the error codes that indicate the response results from the Reader/Writer. These codes are set in the Error Code field in the response area. If an error response is returned (i.e., an error code other than 0000 hex), a record is stored in the command error log in the Reader/Writer.
Page 156 Section 7 Host Communications Specifications  Reader/Writer Operation Errors Error code name Error code Description Unfixed operation mode error The control signal was not stable when the Reader/Writer was started. A 8001 hex record is stored only in the system error log. User setting error An error was detected in user configuration memory when the Reader/ Writer was started.
Page 157 Section 7 Host Communications Specifications  Communications Diagnostics Results The following table lists the communications diagnostic results that are obtained when the Reader/ Writer communicates with an RF Tag. If communications diagnostics are enabled, these codes are provided to indicate the cause when diagnostics indicate that communications are unstable.
Page 158: V680S Command Details
Section 7 Host Communications Specifications V680S Command Details READ ID This command reads the ID code of the RF Tag in the communications field.  Command Area Signal/data Data type Size Description CmdCode/Command Code WORD 2 bytes 0001 hex CmdParam1/Command Parameter 1 WORD 2 bytes 0000 hex (Not used.)
Page 159: Read Data
Section 7 Host Communications Specifications READ DATA This command reads data from the RF Tag in the communications field.  Command Area Signal/data Data type Size Function CmdCode/Command Code WORD 2 bytes 0002 hex CmdParam1/Command Parameter 1 First word address of the data read from the RF Tag WORD 2 bytes 0000 to FFFF hex...
Page 160: Write Data
Section 7 Host Communications Specifications WRITE DATA This command writes data to the RF Tag in the communications field.  Command Area Signal/data Data type Size Function CmdCode/Command Code WORD 16 bits WRITE DATA (0003 hex) CmdParam1/Command Parameter 1 First word address of the data to write to the RF Tag WORD 16 bits 0000 to FFFF hex...
Page 161: Lock
Section 7 Host Communications Specifications LOCK This command locks the memory of the RF Tag in the communications field. Memory cannot be written again after it is locked. There is also no way to unlock memory.  Command Area Signal/data Data type Size Function...
Page 162: Data Fill
Section 7 Host Communications Specifications DATA FILL This command fills the specified number of words in the RF Tag in the communications field with the specified data.  Command Area Signal/data Data type Size Function CmdCode/Command Code WORD 2 bytes 0005 hex CmdParam1/Command Parameter 1 First word address of the data to write to the RF Tag...
Page 163: Rf Tag Overwrite Count Control
Section 7 Host Communications Specifications RF TAG OVERWRITE COUNT CONTROL This command is used to control the number of times RF Tags are overwritten. You can use it for RF Tags that have EEPROM.  Command Area Signal/data Data type Size Function CmdCode/Command Code...
Page 164: Restore Data
Section 7 Host Communications Specifications RESTORE DATA This command restores the RF Tag data that is held in the Reader/Writer. You can use it for RF Tags that have EEPROM. You can restore RF Tag data only when the RF Tag in the communications field matches the held RF Tag ID.
Page 165: Copy Data
Section 7 Host Communications Specifications COPY DATA This command uses two Reader/Writers to copy data from an RF Tag in the communications field of one Reader/Writer (A) to the RF Tag in the communications field of another Reader/Writer (B). Switching Hub Copy Source Copy Destination Reader/Writer...
Page 166 Section 7 Host Communications Specifications  Execution Example Copying Four Words of Data Starting from Word Address 1234 Hex in the RF Tag to an RF Tag in the Communications Field of the Reader/Writer with IP Address 192.168.1.201 (C0A801C9 Hex) Command Area Response Area Memory offset...
Page 167: Initialize
Section 7 Host Communications Specifications INITIALIZE This command restores the Reader/Writer settings to their default values.  Command Area Signal/data Data type Size Function CmdCode/Command Code WORD 2 bytes 1000 hex CmdParam1/Command Parameter 1 WORD 2 bytes 0000 hex (Not used.) CmdParam2/Command Parameter 2 WORD 2 bytes...
Page 168: Set Rf Tag Communications
Section 7 Host Communications Specifications SET RF TAG COMMUNICATIONS This command sets the RF Tag communications conditions in the Reader/Writer (communications option, communications speed, and write verification).  Command Area Signal/data Data type Size Function CmdCode/Command Code WORD 2 bytes 1001 hex CmdParam1/Command Parameter 1 WORD...
Page 169: Get Rf Tag Communications Settings
Section 7 Host Communications Specifications GET RF TAG COMMUNICATIONS SETTINGS This command reads the RF Tags communications conditions from the Reader/Writer (communications option, communications speed, and write verification).  Command Area Signal/data Data type Size Function CmdCode/Command Code WORD 2 bytes 1002 hex CmdParam1/Command Parameter 1 WORD...
Page 170: Set Multi-Reader/Writer Operation
Section 7 Host Communications Specifications SET MULTI-READER/WRITER OPERATION This command sets multi-Reader/Writer operation.  Command Area Signal/data Data type Size Function CmdCode/Command Code WORD 2 bytes 1003 hex CmdParam1/Command Parameter 1 WORD 2 bytes 0000 hex (Not used.) CmdParam2/Command Parameter 2 WORD 2 bytes 0000 hex (Not used.)
Page 171 Section 7 Host Communications Specifications  Execution Example Setting the Multi-Reader/Writer Mode to Field Extension Mode, the Number of Slave Reader/Writers to 3, and the IP Addresses of Slaves No. 1, No. 2, and No. 3 to 192.168.1.201, 192.168.1.202, and 192.168.1.203, Respectively Command Area Response Area...
Page 172: Get Multi-Reader/Writer Settings
Section 7 Host Communications Specifications GET MULTI-READER/WRITER SETTINGS You can use this command to check the multi-Reader/Writer settings in a Reader/Writer.  Command Area Signal/data Data type Size Function CmdCode/Command Code WORD 2 bytes 1004 hex CmdParam1/Command Parameter 1 WORD 2 bytes 0000 hex (Not used.) CmdParam2/Command Parameter 2...
Page 173 Section 7 Host Communications Specifications  Execution Example Reading the Multi-Reader/Writer Settings When the Multi-Reader/Writer Mode Is Set to Field Extension Mode, the Number of Slave Reader/Writers Is Set to 3, and the IP Addresses of Slaves No. 1, No. 2, and No. 3 Are Set to 192.168.1.201, 192.168.1.202, and 192.168.1.203, Respectively Command Area Memory offset Data name...
Page 174: Get Model Information
Section 7 Host Communications Specifications GET MODEL INFORMATION This command reads the model of the Reader/Writer.  Command Area Signal/data Data type Size Function CmdCode/Command Code WORD 2 bytes 2000 hex CmdParam1/Command Parameter 1 WORD 2 bytes 0000 hex (Not used.) CmdParam2/Command Parameter 2 WORD 2 bytes...
Page 175: Get Firmware Version
Section 7 Host Communications Specifications GET FIRMWARE VERSION This command reads the firmware version of the Reader/Writer.  Command Area Signal/data Data type Size Function CmdCode/Command Code WORD 2 bytes 2001 hex CmdParam1/Command Parameter 1 WORD 2 bytes 0000 hex (Not used.) CmdParam2/Command Parameter 2 WORD 2 bytes...
Page 176: Get Operating Time
Section 7 Host Communications Specifications GET OPERATING TIME This command reads the operating time since the Reader/Writer was started. The operating time is reset when the Reader/Writer is reset.  Command Area Signal/data Data type Size Function CmdCode/Command Code WORD 2 bytes 2002 hex CmdParam1/Command Parameter 1...
Page 177: Measure Noise
Section 7 Host Communications Specifications MEASURE NOISE This command measures the noise level around the Reader/Writer.  Command Area Signal/data Data type Size Function CmdCode/Command Code WORD 2 bytes 2003 hex CmdParam1/Command Parameter 1 WORD 2 bytes 0000 hex (Not used.) CmdParam2/Command Parameter 2 WORD 2 bytes...
Page 178: Get Command Error Log
Section 7 Host Communications Specifications GET COMMAND ERROR LOG This command reads the log of command errors that have occurred in the Reader/Writer. The command error log is reset when the Reader/Writer is restarted.  Command Area Signal/data Data type Size Description CmdCode/Command Code...
Page 179 Section 7 Host Communications Specifications  Execution Example Reading the Two Newest Records from the Command Error Log When Command Errors Occur * This example assumes that there are the following two valid records in the command error log. ″Error code 2001 hex occurred for command code 0001 hex at the host device (IP address 192.168.1.10) at an operating time of 11,223,344 (00AB 4130 hex).
Page 180: Get Restore Information
Section 7 Host Communications Specifications GET RESTORE INFORMATION This command reads the restore information from memory in the Reader/Writer. The restore information is reset when the Reader/Writer is reset.  Command Area Signal/data Data type Size Function CmdCode/Command Code WORD 2 bytes 2005 hex CmdParam1/Command Parameter 1...
Page 181 Section 7 Host Communications Specifications  Execution Example Reading the Newest Restore Information Record When Writing to an RF Tag Fails and an RF Tag Data Lost Error Occurs * This example assumes that there is the following one valid record of restore information. ″...
Page 182: Get Multi-Reader/Writer Status
Section 7 Host Communications Specifications GET MULTI-READER/WRITER STATUS This command reads the Master Reader/Writer and Slave Reader/Writer status when multi-Reader/ Writer operation is being used.  Command Area Signal/data Data type Size Description CmdCode/Command Code WORD 2 bytes 2006 hex CmdParam1/Command Parameter 1 WORD 2 bytes...
Page 183: Reset
Section 7 Host Communications Specifications RESET This command resets the Reader/Writer.  Command Area Signal/data Data type Size Function CmdCode/Command Code WORD 2 bytes 3000 hex CmdParam1/Command Parameter 1 WORD 2 bytes 0000 hex (Not used.) CmdParam2/Command Parameter 2 WORD 2 bytes 0000 hex (Not used.) ...
Page 184: Time Charts
Section 7 Host Communications Specifications Time Charts Time Charts  Executing RF Tag Communications Commands  Using the Once Communications Option Command code Command Area Command parameters Command data READY BUSY NORM Response Area Response code Response information Response data RF Tag Communications field RF Tag...
Page 185 Section 7 Host Communications Specifications  Using the Auto Communications Option Command code Command Area Command parameters Command data READY BUSY NORM Response Area Response code Response information Response data Communications field RF Tag 1. The command code, command parameters, and command data are set from the PLC while the READY signal is ON.
Page 186 Section 7 Host Communications Specifications  Using the Repeat or FIFO Repeat Communications Option Command code Command Area Command parameters Command data READY BUSY FRIC NORM Response Area Response code Response information Response data Communications field RF Tag A RF Tag B 8 9 9 1.
Page 187 Section 7 Host Communications Specifications  Executing Other Commands  Executing Reader/Writer Setting, Reader/Writer Information Acquisition, or Reader/Writer Operation Control Commands Command code Command Area Command parameters Command data READY BUSY NORM Response Area Response code Response information Response data 1.
Page 188 Section 7 Host Communications Specifications  Executing the RESET Command Command Area Command code READY BUSY NORM Response Area Response code Response information 1. Set the command code of the RESET command in the PLC while the READY signal is ON. 2.
Page 189: Section 8 Web Browser Interface
Section 8 Web Browser Interface Web Browser Operation Window Operation Interface Password Entry View Status View Network Settings View Communications Settings View SET MULTI-READER/WRITER OPERATION RF Tag Communications View Log View Noise Monitor View RF Analyzer Reboot Configuration Configuration File RFID System User's Manual (EtherNet/IP...
Page 190: Web Browser Operation Window
Section 8 Web Browser Interface Web Browser Operation Window Connect the Ethernet cable and start a Web browser on the computer. Enter the IP address of the Reader/Writer in the address field of the Web browser to display the Web browser operation window.
Page 191 Section 8 Web Browser Interface * Windows is a registered trademark of Microsoft Corporation in the USA and other countries. Screen shots are used with permission from Microsoft. If the characters on the Web browser screen are difficult to see, use the zoom function provided by the Web browser. The operating indicator (Green) may flash because the Web browser communicates with the Reader/Writer at fixed interval.
Page 192: Operation Interface
Section 8 Web Browser Interface Operation Interface Password Entry View If a Web password is set in the Reader/Writer, the Password Entry View will be displayed first. Item name Description Password If a Web password is set in the Reader/Writer, enter the password. If an error message appears after pressing the OK button, confirm the password.
Page 193: Status View
Section 8 Web Browser Interface Status View Item name Description Device type Displays the product model number. Firmware version Run mode program Displays the Run Mode program versions. Displays only “Major version” and “Minor version”. Safe mode program Displays the Safe Mode program versions. Displays only “Major version”...
Page 194: Network Settings View
Section 8 Web Browser Interface Network Settings View  TCP/IP Setting Click this button to set the displayed values. Item name Description Setting range Default IP address IP address 192.168.1.200 Subnet mask Subnet mask address 255.255.255.0 Gateway address Gateway address 192.168.1.254 BOOTP Options Fixed setting, Obtain from BOOTP...
Page 195 Section 8 Web Browser Interface  Web Password Item name Description Setting range Default Web password 15 ASCII characters max. 15 ASCII characters max. None Web password (confirmation) 15 ASCII characters max. 15 ASCII characters max. None If you change the network settings, restart the Reader/Writer. The new settings will be effective after a restart of the Reader/Writer.
Page 196: Communications Settings View
Section 8 Web Browser Interface Communications Settings View Click this button to set the displayed values. Item name Description Setting range Default RF Tag Communications Select the RF Tag communications Once, Auto, Repeat, FIFO Once option option. Repeat (Without ID code check) or FIFO Repeat (With ID code check) RF Tag Communications...
Page 197: Set Multi-Reader/Writer Operation
Section 8 Web Browser Interface SET MULTI-READER/WRITER OPERATION Click this button to set the displayed values. Item name Description Setting range Default setting Multi Reader/Writer mode Sets the Multi-Reader/Writer Mode. Disable, Field extension Disable mode, or High-speed traveling mode Group setting You can check the IP address of Reader/Writers registered as Slave Reader/Writers and the connection...
Page 198: Rf Tag Communications View
Section 8 Web Browser Interface RF Tag Communications View Click this button to send the command. Select this check box to repeatedly send the command. 1. Command Area Item name Description Setting range Command select Select the command to send. ID READ / DATA READ / DATA WRITE Data address...
Page 199: Log View
Section 8 Web Browser Interface Log View  Command error log Click this button to refresh the display. Item name Description Command error log Displays the following command error log information. Operating time, error name, IP address, command code, error code, response information 1, and response information 2 Refer to Command Error Log in Section 6 Functions for details on the command error log.
Page 200: Noise Monitor View
Section 8 Web Browser Interface Noise Monitor View You can check the graphed noise level (one second intervals) around the Reader/Writer. Select from the screen, the type of the RF tag you want to use, because the communication performance will be changed by the combination of the type of the RF tag to be used. The “Normal area”, “Precaution area”...
Page 201: Rf Analyzer
Section 8 Web Browser Interface RF Analyzer You can use the RF Analyzer to check the diagnostic information from communication diagnostic. You can easily see whether communications are stable, unstable (warning), or in error when communication diagnostic is used. If communications are unstable (warning), you can display assumed causes and display guidance that provides detailed cause confirmation and corrections.
Page 202 Section 8 Web Browser Interface  Guidance display Click the Display Button in the Details column on the RF Analyzer View to display guidance. Respond yes or no to the questions to display advice on the assumed causes and corrections. If you follow the advice to make corrections, you can increase the communications leeway and achieve more stable RFID System operation.
Page 203 Section 8 Web Browser Interface  RF Analyzer Graphs You can display time-based graphs of diagnostic log information. This allows you to visually understand the data from communication diagnostic and quantitatively confirm the degree of leeway in communications. Two parameters are displayed for the graph. 1.
Page 204 Section 8 Web Browser Interface  RF Analyzer Diagnostic Log File You can click the Export Button on the RF Analyzer View to download the diagnostic log stored in the Reader/Writer to a computer and save it as a CSV file. The following information is included in the diagnostic log file.
Page 205: Reboot
Section 8 Web Browser Interface Reboot If you click the Reboot Button on any of the operation views, a Confirm Reboot Dialog Box is displayed. Click this button to reboot Click this button to cancel the Reader Writer. rebooting the Reader Writer. The following dialog box is displayed after the Reader/Writer has finished rebooting.
Page 206: Configuration
Section 8 Web Browser Interface Configuration You can save a configuration file (INI file) that contains the configuration information from the Reader/ Writer in the computer. You can also send a configuration file to the Reader/Writer to change all of the configuration information in the Reader/Writer.
Page 207 Section 8 Web Browser Interface  Saving a Configuration File on the Computer You can click the Export Button in the Export Configuration File to PC Area to save a configuration file (file name: conf.ini) that contains the configuration information from the Reader/Writer on the computer. The configuration file uses a normal INI file format.
Page 208 Section 8 Web Browser Interface  Sending a Configuration File to the Reader/Writer You can change all of the configuration information in the Reader/Writer with the following procedure: Click the Browse Button in the Import Configuration File to R/W Area, select the configuration file to use to set up the Reader/Writer, and then click the Import Button.
Page 209 Section 8 Web Browser Interface The following information is displayed after setting is completed. RFID System User's Manual (EtherNet/IP...
Page 210 Section 8 Web Browser Interface  Initializing the Settings Click the Default Button in the Initialize Configuration Area to return all of the settings in the Reader/ Writer to the default settings. After you initialize the settings, cycle the power supply to the Reader/ Writer to enable the new settings.
Page 211: Configuration File
Section 8 Web Browser Interface Configuration File This section describes the format of the configuration file. The configuration file uses a normal INI file format. • Any line that starts with a semicolon (;) is treated as a comment. • Any line that starts with an opening bracket ([) is treated as a section declaration row. The row must also end in a closing bracket (]).
Page 212 Section 8 Web Browser Interface Section name Entry name Description Default MultiReaderWriterSetting MultiReaderWriterM Gives the Reader/Writer Extended Mode settings. Specify a decimal value. 0: Disabled 1: Field Extension Mode 2: High-speed Traveling Mode SlaveNum Gives the number of slaves in Field Extension Mode.
Page 213 Section 8 Web Browser Interface MEMO RFID System User's Manual (EtherNet/IP...
Page 214 Section 8 Web Browser Interface RFID System User's Manual (EtherNet/IP...
Page 215: Section 9 Troubleshooting
Section 9 Troubleshooting Error Descriptions Fatal Errors Nonfatal Errors Errors and Indicator Status Fatal Errors Nonfatal Errors Tag Data Link Error Errors and Countermeasures Reader/Writer Operation Errors IP Address Duplication Error System Errors V680S Command Errors RF Tag Communications Errors Troubleshooting Flowcharts Main Check Flowchart System Connections Check Flowchart...
Page 216: Error Descriptions
Section 9 Troubleshooting Error Descriptions Information on up to eight errors that occur are recorded until the power supply to the Reader/Writer is turned OFF. You can access this information from the host device or the Web server. Fatal Errors ...
Page 217: Nonfatal Errors
Section 9 Troubleshooting Nonfatal Errors The NORM/ERR indicator in the operation indicators flashes red once if an error occurs in communications between the Reader/Writer and host device or in communications with an RF Tag. V680S-HMD63-EIP V680S-HMD64-EIP NORM/ERR NORM/ERR NORM/ERR NORM/ERR NORM/ERR...
Page 218: Errors And Indicator Status
Section 9 Troubleshooting Errors and Indicator Status Fatal Errors  Reader/Writer Operation Errors  User Configuration Memory Error NORM/ERR Processing when error occurs There is an error in user configuration memory. • Initialize the settings to restore normal operation. Refer to User Configuration Memory Error in this Section for information for lnitialize the setting.
Page 219 Section 9 Troubleshooting  System Errors  CPU Error or Hardware Fault NORM/ERR Processing when error occurs Take the appropriate action referring System Errors in this Section Replace the Reader/Writer if the condition does not change. p.220 Lit green or fast Lit red flashing green ...
Page 220: Nonfatal Errors
Section 9 Troubleshooting Nonfatal Errors The NORM/ERR indicator flashes once if an error occurs in communications between the Reader/ Writer and host device or in communications with an RF Tag. NORM/ERR Lit green or fast Flashes red once flashing green Tag Data Link Error NORM/ERR Lit green...
Page 221: Errors And Countermeasures
Section 9 Troubleshooting Errors and Countermeasures Reader/Writer Operation Errors  User Configuration Memory Error Initialize the settings to restore normal operation. There are the following two ways to initialize the Reader/Writer.  Initializing with a Command Message from the Host Device You can send the INITIALIZE SETTINGS command to the Reader/Writer to return the settings to the default values.
Page 222: Ip Address Duplication Error
Section 9 Troubleshooting IP Address Duplication Error Turn OFF the power supply to the Reader/Writer, remove the Reader/Writer from the network, correct the IP addresses, add the Reader/Writer to the network, and turn the power supply back ON. System Errors Turn OFF the power supply, check the wiring, and then turn ON the power supply.
Page 223 Section 9 Troubleshooting  Commands That Can Be Acknowledged by a Slave Reader/Writer The following table shows the commands that a Reader/Writer that is operating as a slave can acknowledge. If an unsupported command is received by a Slave Reader/Writer, an execution status error will be indicated in the response.
Page 224: V680S Command Errors
Section 9 Troubleshooting V680S Command Errors You can check errors detected by the Reader/Writer in the Response Area where the Reader/Writer returns the response after command execution. You can also check error information by sending the GET COMMAND ERROR LOG command to the Reader/Writer or by using the Error Log View on a Web browser.
Page 225: Rf Tag Communications Errors
Section 9 Troubleshooting RF Tag Communications Errors You can check errors detected by the Reader/Writer in the Response Area where the Reader/Writer returns the response after command execution. You can also check error information by sending the GET COMMAND ERROR LOG command to the Reader/Writer or by using the Error Log View on a Web browser.
Page 226: Troubleshooting Flowcharts
Section 9 Troubleshooting Troubleshooting Flowcharts If an error occurs, fully check the whole situation, determine the relationship between the system and any other devices, and refer to the following flowcharts for the troubleshooting procedures. Main Check Flowchart Use the following Main Check Flowchart Main Check Flowchart to determine the cause of the error.
Page 227: System Connections Check Flowchart
Section 9 Troubleshooting System Connections Check Flowchart START Are the connector and Cable connections OK? Power ON Connect them correctly. RUN LED? Flashing green Not lit Lit green NORM/ERR LED? Flashing red Lit red Not lit Check the control Check the control signal line connection.
Page 228: Operating Conditions And External Environment Check Flowchart
Section 9 Troubleshooting Operating Conditions and External Environment Check Flowchart START Refer to Maintenance and Inspection. Are the operating conditions OK? p.238 Refer to Maintenance. Is the ambient p.101 noise OK? RFID System User's Manual (EtherNet/IP...
Page 229: Host Device Communications Check Flowchart
Section 9 Troubleshooting Host Device Communications Check Flowchart START Are the network Is the connector Is there a response? settings OK? wiring OK? Correct the connector Correct the settings. wiring. Are the Error code command contents = 1003 hex? correct? Send the correct command.
Page 230: Rf Tag Communications Check Flow
RF Tag to restore is communications field. correct. RF Tag made by Error code another company? = 2008? Replace the RF Tag with an OMRON RF Tag. Is the copy destination Is there a mistake Error code Reader/Writer operating in the network = 200A?
Page 231: About The Ethernet Communication Abnormality
Section 9 Troubleshooting About The Ethernet Communication Abnormality If an Ethernet network is configured into a loop as shown below, broadcast packets are accumulated in the band, and the communication is disabled. Therefore, do not configure the Ethernet network into a loop. Sending broadcast storm Reader/Writer Broadcast storm...
Page 232: When The Web Browser Screen Is Not Displayed Or The Screen Layout Is Strange
Section 9 Troubleshooting When the Web browser screen is not displayed or the screen layout is strange When the Web browser screen is not displayed or the screen layout is strange. Please reload. If the problem persists even after reloading, follow the procedure below to delete the temporary Internet file and then display it again.
Page 233 Section 9 Troubleshooting (3)Time range selects all time. Check cached images and files and select clear data. RFID System User's Manual (EtherNet/IP...
Page 234: Internet Explorer11
Section 9 Troubleshooting Internet explorer11 (1)Click the Tools menu and select Internet Options. Click the delete… button in the Browsing History section of the General tab. (2)Check "Temporary Internet files and website files" and click Delete. RFID System User's Manual (EtherNet/IP...
Page 235: Microsoft Edge
Section 9 Troubleshooting Microsoft Edge (1)Click the three points in the upper right and click “Settings”. (2)Click “choose what to clear” in the “Privacy & Security” tab. RFID System User's Manual (EtherNet/IP...
Page 236 Section 9 Troubleshooting (3)Check “Cached data and files” and click Clear. RFID System User's Manual (EtherNet/IP...
Page 237: Safe Mode
Section 9 Troubleshooting Safe Mode In addition to the Run Mode that is used for normal operation, the Reader/Writer supports a Safe Mode operation mode. The Safe Mode is used when you do not remember the IP address that is set in the Reader/ Writer.
Page 238 Section 9 Troubleshooting MEMO RFID System User's Manual (EtherNet/IP...
Page 239: Section 10 Maintenance And Inspection
Section 10 Maintenance and Inspection Maintenance and Inspection RFID System User's Manual (EtherNet/IP...
Page 240: Maintenance And Inspection
Section 10 Maintenance and Inspection Maintenance and Inspection The Reader/Writer must be inspected on a daily or periodic basis so that the functions remain in good condition. The Reader/Writer consists of semiconductors that last almost indefinitely. The following malfunctions, however, may result due to the operating environment and conditions. (1) Element deterioration due to overvoltage or overcurrent.
Page 241: Isection 11 Appendices
Section 11 Appendices Data Characteristics RF Tag Communications Range (for Reference Only) RF Tag Communications Time (for Reference Only) Reader/Writer Installation Precautions V680S-HMD63-EIP V680S-HMD64-EIP V680S-HMD66-EIP RF Tag Installation Precautions V680-D1KP54T V680-D1KP66T V680-D1KP66MT V680-D1KP66T-SP V680-D1KP58HTN V680S-D2KF67 V680S-D2KF67M V680S-D8KF67 V680S-D8KF67M V680S-D2KF68 V680S-D2KF68M...
Page 242: Data Characteristics
Section 11 Appendices Data Characteristics RF Tag Communications Range (for Reference Only)  V680S-HMD63-EIP (Unit: mm) V680S-HMD63-EIP and V680-D1KP54MT V680S-HMD63-EIP and V680-D1KP66T (Back Surface: Metal) (Back Surface: Metal) Read Read Write Write -100 -80 -100 -80 V680S-HMD63-EIP and V680-D1KP66MT V680S-HMD63-EIP and V680-D1KP66T-SP (Back Surface: Metal) (Back Surface: Metal) (Back Surface: Metal) Read...
Page 243 Section 11 Appendices (Unit: mm) V680S-HMD63-EIP and V680S-D2KF67M V680S-HMD63-EIP and V680S-D2KF67 (Back Surface: Metal) (Back Surface: Metal) Read Read Write Write -100 -80 -100 -80 V680S-HMD63-EIP and V680S-D8KF67 V680S-HMD63-EIP and V680S-D8KF67M (Back Surface: Metal) (Back Surface: Metal) (Back Surface: Metal) Read Read Write...
Page 244 Section 11 Appendices  V680S-HMD64-EIP (Unit: mm) V680S-HMD64-EIP and V680-D1KP54T V680S-HMD64-EIP and V680-D1KP66T (Back Surface: Metal) (Back Surface: Metal) Read Read Write Write -100 -80 -100 -80 V680S-HMD64-EIP and V680-D1KP66MT V680S-HMD64-EIP and V680-D1KP66T-SP (Back Surface: Metal) (Back Surface: Metal) (Back Surface: Metal)
Page 245 Section 11 Appendices (Unit: mm) V680S-HMD64-EIP and V680S-D2KF67 V680S-HMD64-EIP and V680S-D2KF67M (Back Surface: Metal) (Back Surface: Metal) (Back Surface: Metal) Read Read Write Write -100 -80 -100 -80 V680S-HMD64-EIP and V680S-D8KF67 V680S-HMD64-EIP and V680S-D8KF67M (Back Surface: Metal) (Back Surface: Metal)
Page 246 Section 11 Appendices (Unit: mm) V680S-HMD64-EIP and V680S-D2KF68 V680S-HMD64-EIP and V680S-D2KF68 (Back Surface: Metal) (Horizontal-facing RF Tag) (Back Surface: Metal) (Vertical-facing RF Tag) Read Read Write Write -250 -200 -150 -100 -250 -200 -150 -100 V680S-HMD64-EIP and V680S-D2KF68M V680S-HMD64-EIP and V680S-D2KF68M...
Page 247 Section 11 Appendices  V680S-HMD66-EIP (Unit: mm) V680S-HMD66-EIP and V680-D1KP66T V680S-HMD66-EIP and V680-D1KP54T (Back Surface: Metal) (Back Surface: Metal) Read Read Write Write -100 -80 -250 -200 -150 -100 V680S-HMD66-EIP and V680-D1KP66MT V680S-HMD66-EIP and V680-D1KP66T-SP (Back Surface: Metal) (Back Surface: Metal) (Back Surface: Metal) Read Read...
Page 248 Section 11 Appendices (Unit: mm) V680S-HMD66-EIP and V680S-D2KF67 V680S-HMD66-EIP and V680S-D2KF67M (Back Surface: Metal) (Back Surface: Metal) (Back Surface: Metal) Read Read Write Write -250 -200 -150 -100 -100 -80 V680S-HMD66-EIP and V680S-D8KF67 V680S-HMD66-EIP and V680S-D8KF67M (Back Surface: Metal) (Back Surface: Metal) (Back Surface: Metal) Read Read...
Page 249 Section 11 Appendices (Unit: mm) V680S-HMD66-EIP and V680S-D2KF68 V680S-HMD66-EIP and V680S-D2KF68 (Back Surface: Metal) (Horizontal-facing RF Tag) (Back Surface: Metal) (Vertical-facing RF Tag) Read Read Write Write -250 -200 -150 -100 -250 -200 -150 -100 V680S-HMD66-EIP and V680S-D2KF68M V680S-HMD66-EIP and V680S-D2KF68M (Back Surface: Metal) (Back Surface: Metal) (Back Surface: Metal)
Page 250: Rf Tag Communications Time (For Reference Only)
Section 11 Appendices RF Tag Communications Time (for Reference Only)  Communications Time Communications time is from the rise of the RF signal to the last bit of the response from the RF tag. Command Response RF signal Communications time RF signal : The radio wave that the Reader/Writer turns ON the RF Tag.
Page 251 Section 11 Appendices V680S-HMD6-EIP and V680S-D2KF6 (Communications speed setting: High speed) • Communication Option: Other than FIFO Repeat (With ID code check) Command Communications time (ms) N: No. of bytes processed Read T= 0.4N + 17.4 Write (with verification) T= 1.0N + 51.9 Write (with verification) Write (without verification) T= 0.7N + 35.2...
Page 252 Section 11 Appendices V680S-HMD6-EIP and V680S-D2KF6 (Communications speed setting: Normal speed) • Communication Option: Other than FIFO Repeat (With ID code check) Command Communications time (ms) N: No. of bytes processed Read T= 0.9N + 18.7 Write (with verification) Write (with verification) T= 1.7N + 42.1 Write (without verification) Write (without verification)
Page 253 Section 11 Appendices  Travel Speed Calculations Set the communications option to Repeat to communicate with a moving RF Tag. The maximum speed for communicating with the RF Tag can be calculated simply using the following formula. D (Distance traveled in communications field) Maximum speed = T (Communications time) D (Distance traveled in communications field) is calculated from the actual measurement or the...
Page 254: Reader/Writer Installation Precautions
Section 11 Appendices Reader/Writer Installation Precautions V680S-HMD63-EIP  Influence of Surrounding Metal on Reader/Writer The Reader/Writer can be surface-mounted or it can be embedded in metal to protect it from collisions. If you embed the Reader/Writer in metal, separate it at least 80 mm from any metallic surface to prevent malfunctions.
Page 255: Iv680S-Hmd64-Eip
Section 11 Appendices V680S-HMD64-EIP  Influence of Surrounding Metal on Reader/Writer The Reader/Writer can be surface-mounted or it can be embedded in metal to protect it from collisions. If you embed the Reader/Writer in metal, separate it at least 100 mm from any metallic surface to prevent malfunctions.
Page 256 Section 11 Appendices • Installing the Reader/Writer Facing Each Other • Installing the Reader/Writer in Parallel Mounting distance Mounting distance RFID System User's Manual (EtherNet/IP...
Page 257: V680S-Hmd66-Eip
Section 11 Appendices V680S-HMD66-EIP  Influence of Surrounding Metal on Reader/Writer The Reader/Writer can be surface-mounted or it can be embedded in metal to protect it from collisions. If you embed the Reader/Writer in metal, separate it at least 160 mm from any metallic surface to prevent malfunctions.
Page 258 Section 11 Appendices • Reader/Writers Installed Facing Each Other • Reader/Writers Installed in Parallel Mounting distance Mounting distance RFID System User's Manual (EtherNet/IP...
Page 259: Rf Tag Installation Precautions
(e.g., plastic or resin). The following graphs show the relationship between the distance from the RF Tag to the metallic surface and the communications range. The V700-A80 Attachment is 8 mm thick. V680S-HMD63-EIP and V680-D1KP54T V680S-HMD64-EIP and V680-D1KP54T (mm) (mm) Distance (x) to the metal plate in back of RF Tag...
Page 260 If the distance between the RF tags is too short, read / write distance will be reduced.  V680S-HMD63-EIP Reader/Writer 45 mm min. 45 mm min.  V680S-HMD64-EIP Reader/Writer 60 mm min. 60 mm min.  V680S-HMD66-EIP Reader/Writer 90 mm min.
Page 261 -19% -29% -43% V680S-HMD66-EIP and V680-D1KP54T -11% -18% -27% -42%  Measurement Conditions ″ V680S-HMD63-EIP and V680-D1KP54T ″ V680S-HMD64-EIP and V680-D1KP54T Metallic material Metallic material RF Tag RF Tag Non-metallic material Reader/Writer Non-metallic material Reader/Writer ″ V680S-HMD66-EIP and V680-D1KP54T Metallic material...
Page 262: V680-D1Kp66T
You can also use more than one Attachment (10 mm). Installation with the V600-A86 Attachment M3 flat-head screw Note: Orient the RF Tag so that the mounting holes are aligned. V680S-HMD64-EIP and V680-D1KP66T V680S-HMD63-EIP and V680-D1KP66T (mm) (mm) Distance (x) to the metal plate in back of RF Tag...
Page 263 If the distance between the RF tags is too short, read / write distance will be reduced.  V680S-HMD63-EIP Reader/Writer 54 mm min. 54 mm min.  V680S-HMD64-EIP Reader/Writer 80 mm min. 80 mm min.  V680S-HMD66-EIP Reader/Writer 110 mm min.
Page 264 -14% -21% -32% V680S-HMD66-EIP and V680-D1KP66T -10% -17% -27% -41%  Measurement Conditions ″ V680S-HMD63-EIP and V680-D1KP66T ″ V680S-HMD64-EIP and V680-D1KP66T Metallic material Metallic material RF Tag RF Tag Non-metallic material Reader/Writer Non-metallic material Reader/Writer ″ V680S-HMD66-EIP and V680-D1KP66T Metallic material...
Page 265: V680-D1Kp66Mt
RF Tag RF Tag Embedded Surface-mounted 3.5mm max. Metallic material Metallic material V680S-HMD63-EIP and V680-D1KP66MT V680S-HMD64-EIP and V680-D1KP66MT (mm) (mm) Distance (x) from surrounding metal Distance (x) from surrounding metal V680S-HMD66-EIP and V680-D1KP66MT (mm) Distance (x) from surrounding metal RF Tag...
Page 266 If the distance between the RF tags is too short, read / write distance will be reduced.  V680S-HMD63-EIP Reader/Writer 44 mm min. 44 mm min.  V680S-HMD64-EIP Reader/Writer 70 mm min. 70 mm min.  V680S-HMD66-EIP Reader/Writer 90 mm min.
Page 267 V680S-HMD66-EIP and V680-D1KP66MT -16% -28% -49% (Metal at back surface: Steel)  Measurement Conditions ″ V680S-HMD63-EIP and V680-D1KP66MT ″ V680S-HMD64-EIP and V680-D1KP66MT (Metal at Back Surface: Steel) (Metal at Back Surface: Steel) Metallic material Metallic material RF Tag RF Tag...
Page 268: V680-D1Kp66T-Sp
The following graphs show the relationship between the distance from the RF Tag to the metallic surface and the communications range. V680S-HMD63-EIP and V680-D1KP66T-SP V680S-HMD64-EIP and V680-D1KP66T-SP (mm) (mm) Distance (x) to the metal plate in back of RF Tag...
Page 269  V680S-HMD63-EIP Reader/Writer 54 mm min. 54 mm min. 95 mm min.* 95 mm min.*  V680S-HMD64-EIP Reader/Writer 90 mm min. 90 mm min. 95 mm min.* 95 mm min.* * This is required for the V680-D1KP66T-SP exterior dimension (Length: 95 mm).
Page 270 Section 11 Appendices V680S-HMD66-EIP Reader/Writer 110 mm min. 110 mm min. 110 mm min. 110 mm min. RFID System User's Manual (EtherNet/IP...
Page 271 -32% -48% V680S-HMD66-EIP and V680-D1KP66T-SP -10% -17% -27% -41% -62%  Measurement Conditions ″ V680S-HMD63-EIP and V680-D1KP66T-SP ″ V680S-HMD64-EIP and V680-D1KP66T-SP Metallic material Metallic material RF Tag RF Tag Non-metallic material Non-metallic material Reader/Writer Reader/Writer ″ V680S-HMD66-EIP and V680-D1KP66T-SP Metallic material...
Page 272: V680-D1Kp58Htn
The X axis gives the distance between the RF Tag and a metal plate. The Y axis shows the relative communications range taking the communications range with no metal plate as 100% (i.e., it shows the percentage of decrease in the communications range). V680S-HMD64-EIP and V680-D1KP58HTN Reader/Writer RF Tag...
Page 273 V680S-HMD64-EIP and V680-D1KP58HTN -14% -22% -32% -35% V680S-HMD66-EIP and V680-D1KP58HTN -11% -17% -27% -44%  Measurement Conditions ″ V680S-HMD64-EIP and V680-D1KP58HTN ″ V680S-HMD66-EIP and V680-D1KP58HTN Metallic material Metallic material RF Tag RF Tag Non-metallic material Non-metallic material Reader/Writer Reader/Writer RFID System...
Page 274: V680S-D2Kf67
RF Tag is mounted on metallic material, use a non-metallic spacer (e.g., plastic or resin). The following graphs show the relationship between the distance from the RF Tag to the metallic surface and the communications range. V680S-HMD63-EIP and V680S-D2KF67 V680S-HMD64-EIP and V680S-D2KF67 (mm) (mm) Distance (x) to the metal plate in back of RF Tag...
Page 275 If the distance between the RF tags is too short, read / write distance will be reduced.  V680S-HMD63-EIP Reader/Writer 60 mm min. 60 mm min.  V680S-HMD64-EIP Reader/Writer 90 mm min. 90 mm min.  V680S-HMD66-EIP Reader/Writer 120 mm min.
Page 276 -19% -27% -38% V680S-HMD66-EIP and V680S-D2KF67 -13% -19% -29% -43%  Measurement Conditions ″ V680S-HMD63-EIP and V680S-D2KF67 ″ V680S-HMD64-EIP and V680S-D2KF67 Metallic material Metallic material RF Tag RF Tag Non-metallic material Reader/Writer Non-metallic material Reader/Writer ″ V680S-HMD66-EIP and V680S-D2KF67 Metallic material...
Page 277: V680S-D2Kf67M
V680S-D2KF67M. RF Tag RF Tag Embedded Surface-mounted 5 mm max. Metallic material Metallic material V680S-HMD64-EIP and V680S-D2KF67M V680S-HMD63-EIP and V680S-D2KF67M (mm) (mm) Distance (x) from surrounding metal Distance (x) from surrounding metal V680S-HMD66-EIP and V680S-D2KF67M (mm)
Page 278 If the distance between the RF tags is too short, read / write distance will be reduced.  V680S-HMD63-EIP Reader/Writer 55 mm min. 55 mm min.  V680S-HMD64-EIP Reader/Writer 70 mm min. 70 mm min.  V680S-HMD66-EIP Reader/Writer 90 mm min.
Page 279 (Metal at back surface: Steel) V680S-HMD66-EIP and V680S-D2KF67M -18% -33% (Metal at back surface: Steel)  Measurement Conditions ″ V680S-HMD63-EIP and V680S-D2KF67M ″ V680S-HMD64-EIP and V680S-D2KF67M (Metal at Back Surface: Steel) (Metal at Back Surface: Steel) Metallic material Metallic material RF Tag RF Tag...
Page 280: V680S-D8Kf67
RF Tag is mounted on metallic material, use a non-metallic spacer (e.g., plastic or resin). The following graphs show the relationship between the distance from the RF Tag to the metallic surface and the communications range. V680S-HMD63-EIP and V680S-D8KF67 V680S-HMD64-EIP and V680S-D8KF67 (mm) (mm) Distance (x) to the metal plate in back of RF Tag...
Page 281 If the distance between the RF tags is too short, read / write distance will be reduced.  V680S-HMD63-EIP Reader/Writer 60 mm min. 60 mm min.  V680S-HMD64-EIP Reader/Writer 80 mm min. 80 mm min.  V680S-HMD66-EIP Reader/Writer 120 mm min.
Page 282 -17% -24% -36% V680S-HMD66-EIP and V680S-D8KF67 -12% -19% -28% -42%  Measurement Conditions ″ V680S-HMD63-EIP and V680S-D8KF67 ″ V680S-HMD64-EIP and V680S-D8KF67 Metallic material Metallic material RF Tag RF Tag Non-metallic material Reader/Writer Non-metallic material Reader/Writer ″ V680S-HMD66-EIP and V680S-D8KF67 Metallic material...
Page 283: V680S-D8Kf67M
V680S-D8KF67M. RF Tag RF Tag Embedded Surface-mounted 5 mm max. Metallic material Metallic material V680S-HMD64-EIP and V680S-D8KF67M V680S-HMD63-EIP and V680S-D8KF67M (mm) (mm) Distance (x) from surrounding metal Distance (x) from surrounding metal V680S-HMD66-EIP and V680S-D8KF67M (mm)
Page 284 If the distance between the RF tags is too short, read / write distance will be reduced.  V680S-HMD63-EIP Reader/Writer 50 mm min. 50 mm min.  V680S-HMD64-EIP Reader/Writer 70 mm min. 70 mm min.  V680S-HMD66-EIP Reader/Writer 90 mm min.
Page 285 V680S-HMD66-EIP and V680S-D8KF67M -10% -20% -39% (Metal at back surface: Steel)  Measurement Conditions ″ V680S-HMD63-EIP and V680S-D8KF67M ″ V680S-HMD64-EIP and V680S-D8KF67M (Metal at Back Surface: Steel) (Metal at Back Surface: Steel) Metallic material Metallic material RF Tag RF Tag...
Page 286: V680S-D2Kf68
RF Tag is mounted on metallic material, use a non-metallic spacer (e.g., plastic or resin). The following graphs show the relationship between the distance from the RF Tag to the metallic surface and the communications range. V680S-HMD64-EIP and V680S-D2KF68 V680S-HMD66-EIP and V680S-D2KF68 (mm)
Page 287 If you use more than one RF Tag, separate them by at least the interval shown below to prevent malfunctions due to mutual interference. If the distance between the RF tags is too short, read / write distance will be reduced.  V680S-HMD64-EIP Reader/Writer 130 mm min. 130 mm min.
Page 288 -25% -39% -65% horizontally V680S-HMD66-EIP and V680S-D2KF68 -13% -20% -29% -42% -68% vertically  Measurement Conditions ″ V680S-HMD64-EIP and V680S-D2KF68 ″ V680S-HMD64-EIP and V680S-D2KF68 Horizontally Vertically Metallic material Metallic material RF Tag RF Tag Non-metallic material Non-metallic material Reader/Writer Reader/Writer ″...
Page 289: V680S-D2Kf68M
V680S-D2KF68M. RF Tag RF Tag Embedded Surface-mounted 10 mm max. Metallic material Metallic material V680S-HMD64-EIP and V680S-D2KF68M V680S-HMD66-EIP and V680S-D2KF68M (mm) (mm) Distance (x) from surrounding metal Distance (x) from surrounding metal RF Tag Metallic material...
Page 290 If you use more than one RF Tag, separate them by at least the interval shown below to prevent malfunctions due to mutual interference. If the distance between the RF tags is too short, read / write distance will be reduced.  V680S-HMD64-EIP Reader/Writer 100 mm min. 100 mm min.
Page 291 V680S-HMD66-EIP and V680S-D2KF68M -13% -23% -43% horizontally V680S-HMD66-EIP and V680S-D2KF68M -12% -21% -33% -58% vertically  Measurement Conditions ″ V680S-HMD64-EIP and V680S-D2KF68M ″ V680S-HMD64-EIP and V680S-D2KF68M Horizontally Vertically Metallic material Metallic material RF Tag RF Tag Non-metallic material Non-metallic material Reader/Writer Reader/Writer ″...
Page 292: V680S-D8Kf68
RF Tag is mounted on metallic material, use a non-metallic spacer (e.g., plastic or resin). The following graphs show the relationship between the distance from the RF Tag to the metallic surface and the communications range. V680S-HMD64-EIP and V680S-D8KF68 V680S-HMD66-EIP and V680S-D8KF68 (mm)
Page 293 If you use more than one RF Tag, separate them by at least the interval shown below to prevent malfunctions due to mutual interference. If the distance between the RF tags is too short, read / write distance will be reduced.  V680S-HMD64-EIP Reader/Writer 130 mm min. 130 mm min.
Page 294 -16% -25% -39% horizontally V680S-HMD66-EIP and V680S-D8KF68 -14% -20% -29% -43% -69% vertically  Measurement Conditions ″ V680S-HMD64-EIP and V680S-D8KF68 ″ V680S-HMD64-EIP and V680S-D8KF68 Horizontally Vertically Metallic material Metallic material RF Tag RF Tag Non-metallic material Non-metallic material Reader/Writer Reader/Writer ″...
Page 295: V680S-D8Kf68M
V680S-D8KF68M. RF Tag RF Tag Embedded Surface-mounted 10 mm max. Metallic material Metallic material V680S-HMD64-EIP and V680S-D8KF68M V680S-HMD66-EIP and V680S-D8KF68M (mm) (mm) Distance (x) from surrounding metal Distance (x) from surrounding metal RF Tag Metallic material...
Page 296 If you use more than one RF Tag, separate them by at least the interval shown below to prevent malfunctions due to mutual interference. If the distance between the RF tags is too short, read / write distance will be reduced.  V680S-HMD64-EIP Reader/Writer 100 mm min. 100 mm min.
Page 297 V680S-HMD66-EIP and V680S-D8KF68M -13% -24% -50% horizontally V680S-HMD66-EIP and V680S-D8KF68M -13% -22% -35% -67% vertically Measurement Conditions ″ V680S-HMD64-EIP and V680S-D8KF68M ″ V680S-HMD64-EIP and V680S-D8KF68M Horizontally Vertically Metallic material Metallic material RF Tag RF Tag Non-metallic material Non-metallic material Reader/Writer Reader/Writer ″...
Page 298: Rf Tag Memory Capacities And Memory Types
Section 11 Appendices RF Tag Memory Capacities and Memory Types (As of July 2019) Memory capacity (user Model Memory type Life expectancy memory) • Write endurance: 100,000 times per block V680-D1KP54T (25°C) V680-D1KP66T • Data retention: 10 years after writing (85°C V680-D1KP66MT V680-D1KP66T-SP or less)
Page 299: Rf Tag Memory Map
Section 11 Appendices RF Tag Memory Map V680-D1KP RF Tags Block Address(W) Data 0000 hex 0001 hex 0002 hex 0003 hex 0004 hex 0005 hex 0006 hex EEPROM is used as the memory in the RF Tag. 0007 hex The user-accessible capacity is 1,000 bytes. User area 01EC hex 01ED hex...
Page 300 Section 11 Appendices V680S-D2KF6 RF Tags Block Address(W) Data 0000 hex 0001 hex 0002 hex 0003 hex 0004 hex 0005 hex 0006 hex FRAM is used as the memory in the RF Tag. 0007 hex The user-accessible capacity is 2,000 bytes. User area 03E0 hex 03E1 hex...
Page 301 Section 11 Appendices V680S-D8KF6 RF Tags Block Address(W) Data 0000 hex 0001 hex 0002 hex 0003 hex 000C hex 000D hex 000E hex 000F hex 0010 hex 0011 hex 0012 hex 0013 hex 001C hex 001D hex 001E hex FRAM is used as the memory in the RF Tag. 001F hex The user-accessible capacity is 8,192 bytes.
Page 302: Chemical Resistance Of The Reader/Writers And Rf Tags
Section 11 Appendices Chemical Resistance of the Reader/Writers and RF Tags Chemical Resistance of the Reader/Writers  Applicable Models V680S-HMD63-EIP/-HMD64-EIP/-HMD66-EIP The chemicals that affect the Reader/Writer are listed below. PBT (polybutylene terephthalate) is used as the case material and a urethane resin is used as the filling.
Page 303 Section 11 Appendices Chemical Resistance of RF Tags  Applicable Models V680-D1KP54T/-D1KP66T/-D1KP66MT/-D1KP58HTN/V680S-DKF6 PPS resin is used for case material. Refer to the following lists and do not use chemicals that affect PPS and epoxy resin. RF Tags cannot be used in applications with explosion-proof specifications. At room At room Chemical...
Page 304 Section 11 Appendices  Applicable Models V680-D1KP66T-SP PFA resin is used for exterior case material. Refer to the following lists and do not use chemicals that affect PFA resin. RF Tags cannot be used in applications with explosion-proof specifications.  Chemical Resistance of Fluoroplastic PFA (Reference) PFA: Tetrafluorethylene-Perfluoroalkylvinyletheir Copolymer Fluoroplastic PFA does not react with most chemicals except molten alkali metal, hot pressurized fluorine (F2), and some halogen derivatives.
Page 305 Section 11 Appendices  Organic Chemicals Resulting characteristics Test Weight Chemical name temperature increase Tensile rate (%) (°C) Elongation strength Glacial acetic acid Acetic anhydride Trichloroacetic acid Isooctane Naphtha Mineral oil Toluene o-creosol Nitrobenzene Benzyl alcohol Aniline n-butylamine Ethylenediamine Tetrahydrofuran Benzaldehyde Cyclohexane Methyl ethyl ketone...
Page 306: Degree Of Protection
Section 11 Appendices Degree of Protection Ingress protection degrees (IP-) are determined by the following tests. Be sure to check the sealing capability under the actual operating environment and conditions before actual use.  IEC (International Electrotechnical Commission) IEC 60529:2001 (A) First Digit: Degree of Protection from Solid Materials Degree Protection...
Page 307 Oil-proof Protects against penetration of oil drops or oil spray approaching from any direction. Note. Oil resistance has been tested using a specific oil as defined in the OMRON test method. (JIS C 0920:2003, Appendix 1) RFID System User's Manual...
Page 308: Differences In Address And Size Specifications Between V680 And V680S Reader/Writers
Section 11 Appendices Differences in Address and Size Specifications between V680 and V680S Reader/Writers RF Tag access for V680S-series Reader/Writers is performed in words (1 word = 2 bytes). RF Tag access for V680-series Controllers is performed in bytes. Be sure to access data in the correct units. The word and byte addresses for the memory map of a V680-D1KP...
Page 309 Index RFID System User's Manual (Modbus TCP)
Page 310 Index Index IP Address Duplication Error IP Address, Subnet Mask, and Default Gateway Auto LOCK Log View Command Error Log Communication Diagnostic Communications Diagnostic Maintenance Communications Option Setting Maintenance and Inspection Communications Options MEASURE NOISE Communications Range Specifications Multi-Reader/Writer Operation Communications Settings View Component Names Configuration...
Page 311 Index Safe Mode 92, 235 SET MULTI-READER/WRITER OPERATION 168, 195 SET RF TAG COMMUNICATIONS Setting Communications Conditions Setting Functions Setting the Web Password Status View System Configuration System Error Log System Errors Tag Data Link Error Tag Memory Management Time Charts Troubleshooting Flowcharts V680S Command Details V680S Command Errors...
Page 312 Added the information for “Firmware Version Update History”. October 2016 Changed the information for “Mutual Interference of Reader/Writers (for Reference Only)” of the V680S-HMD63-EIP and V680S-HMD64-EIP. February 2017 Changed the information for “FIFO Repeat”. Addition of description of communication function “Auto”, “FIFO Repeat (Without ID April 2017 code check)”...
Page 313 Firmware Version Update History V680S Reader/Writers: The following table gives an update history of the firmware version of the V680S- HMD6@-EIP Series. Firmware version Revised contents 3.00 Original production 3.01 Web browser interface can be used in the Java8 update74 or later. Addition of communication option “Auto”...
Page 314 MEMO RFID System User's Manual (EtherNet/IP...
Page 316 The Netherlands Hoffman Estates, IL 60169 U.S.A Tel: (31)2356-81-300/Fax: (31)2356-81-388 Tel: (1) 847-843-7900/Fax: (1) 847-843-7787 © OMRON Corporation 2015-2020 All Rights Reserved. OMRON (CHINA) CO., LTD. OMRON ASIA PACIFIC PTE. LTD. In the interest of product improvement, Room 2211, Bank of China Tower, No.

This manual is also suitable for:

V680s series V680s-hmd63-eip V680 series V680s-hmd66-eip

Omron V680S-HMD64-EIP User Manual
