Omron V680 series User Manual

Hand-held reader writer. rf tags
Hide thumbs Also See for V680 series:
Table of Contents

Advertisement

Quick Links

RFID System
V680 Series
Hand-held Reader Writer
User's Manual
Hand-held Reader Writer
V680-CHUD
V680-CH1D
V680-CH1D-PSI
ID Tags
V680/V680S Series
Man. No.: Z272-E1-07

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V680 series and is the answer not in the manual?

Questions and answers

Related Manuals for Omron V680 series

Summary of Contents for Omron V680 series

  • Page 1 RFID System V680 Series Hand-held Reader Writer User's Manual Hand-held Reader Writer V680-CHUD V680-CH1D V680-CH1D-PSI ID Tags V680/V680S Series Man. No.: Z272-E1-07...
  • Page 2 Introduction Thank you for purchasing a V680/V680S-series RFID System. This manual describes the functions, performance, and application methods needed for optimum use of the V680/V680S-series RFID System. Please observe the following items when using the V680-series RFID System. • Allow the V680/V680S-series RFID System to be installed and operated only by qualified specialist with a sufficient knowledge of electrical systems.
  • Page 3 Product Overview Section 1 Communications Preparations Section 2 Commands Section 3 Functions Section 4 Troubleshooting Section 5 Appendices Section 6 RFID System V680-CHUD Hand-held Reader/Writer V680-CH1D Hand-held Reader/Writer V680-CH1D-PSI Hand-held Reader/Writer V680 Series RF Tags V680S Series RF Tags User’s Manual...
  • Page 4 Please read and understand this document before using the products. Please consult your OMRON representative if you have any questions or comments. WARRANTY OMRON’s exclusive warranty is that the products are free from defects in materials and workmanship for a period of one year (or other period if specified) from date of sale by OMRON.

  • Page 5: Safety Precautions

    Introduction Safety Precautions  Signal Words Used in This Manual The following symbols are used in this manual to indicate precautions that must be observed to ensure safe use of the V680/V680S-series RFID System. The precautions provided here contain important safety information.

  • Page 6: Precautions For Safe Use

    Introduction Precautions for Safe Use Observe the following precautions to ensure safe use of the Product. 1. Do not use the Product in environments with flammable, explosive, or corrosive gasses. 2. Do not attempt to disassemble, repair, or modify the Product. 3.

  • Page 7: Precautions For Correct Use

    Introduction Precautions for Correct Use Always observe the following precautions to prevent operation failures, malfunctions, and adverse effects on performance and equipment. 1. Installation and Storage Environment Do not use or store the Product in the following locations. • Locations exposed to corrosive gases, dust, metallic powder, or salts •...
  • Page 8 Introduction •If the central axis of an antenna and RF tag shifts, a communications range will fall. •Do not touch the product immediately after usage at high temperatures. Doing so may occasionally result in burning. 3. Host Communications Always confirm that the Product has been started before attempting to communicate with it from the host.

  • Page 9: How To Read This Manual

    Introduction How to Read this Manual Meanings of Symbols Indicates particularly important points related to a function, including precautions and application advice. Indicates page numbers containing relevant information. Indicates reference to helpful information and explanations for difficult terminology. RFID System User's Manual...
  • Page 10 Introduction MEMO RFID System User's Manual...

  • Page 11: Table Of Contents

    Introduction Table of Contents Introduction Safety Precautions Precautions for Safe Use Precautions for Correct Use How to Read this Manual Section 1 Product Overview Features Using Heat-resistive Tags (V680-D1KP58HTN and V680-D1KP58HT) Names and Functions of Components System Configuration Operation Flowchart Section 2 Communications Preparations V680-CHUD Communications Preparations V680-CH1D Communications Preparations...
  • Page 12 Introduction Section 5 Troubleshooting Error Tables Troubleshooting Flowchart Section 6 Appendices Specifications and Dimensions RF Tag Memory Map RF Tag Memory Capacities and Memory Types (V680 Series) List of ASCII Characters Degree of Protection Revision History RFID System User's Manual...

  • Page 13: Section 1 Product Overview

    Section 1 Product Overview Features Using Heat-resistive Tags (V680-D1KP58HTN and V680-D1KP58HT) Names and Functions of Components System Configuration Operation Flowchart RFID System User's Manual...

  • Page 14: Features

    Section 1 Product Overview Features The V680-series Hand-held Reader/Writer incorporates a V680-series Antenna and Controller into a compact design. Data can be read from or written to the RF Tag simply by approaching or touching the RF Tag with the Hand-held Reader/Writer.
  • Page 15 The Tag memory setting is made in the Hand-held Reader/Writer. A different memory map may be used when reading or writing Heat-resistant Tags that were written by the V680-CA1D/-CA2D from a Reader/Writer that is manufactured by a company other than OMRON. Refer to Operation When Tag Memory Setting Is Set to Standard Mode in this section. p.17 ...

  • Page 16: Using Heat-Resistive Tags (V680-D1Kp58Htn And V680-D1Kp58Ht)

    Section 1 Product Overview Using Heat-resistive Tags (V680-D1KP58HTN and V680-D1KP58HT) This section provides information for using Heat-resistive Tags (V680-D1KP58HTN or V680-D1KP58HT). If you are not using a Heat-resistive Tag, set the Tag memory setting to Standard Mode. Precautions for Saving Data at High Temperatures If you are using a Heat-resistive Tag, write the data again after saving the data at a high temperature even if it is not necessary to change the data.
  • Page 17 Section 1 Product Overview  Introduction The address maps in the RF Tags for the V680-D1KP@@ (except for the V680-D1KP58HT) are reversed between the V680-CA1D/-CA2D ID Controllers and V680-CH@D Hand-held Reader/Writer (with Tag memory setting set to CA1D Mode for version 1.1 or newer), and the V680-CH@D (version 1.0) and V680-CH@D (with Tag memory setting set to Standard Mode for version 1.1 or newer) Hand- held Reader/Writers.
  • Page 18 Section 1 Product Overview  Applicable RF Tags Only the V680-D1KP@@ RF Tags can be used when the Tag memory setting is set to CA1D Mode. V680-D@KF@@ RF Tags cannot be used.  RF Tags That Can Be Used  RF Tags That Cannot Be Used Models Models V680-D1KP58HT...
  • Page 19 Section 1 Product Overview  Operation When Tag Memory Setting Is Set to Standard Mode When data that was written to a V680-D1KP58HTN RF Tag with the V680-CA1D/-CA2D ID Controller is read from a V680-CH@D Hand-held Reader/Writer, the data from addresses that are reversed in one-block (eight-byte) units is read.
  • Page 20 Section 1 Product Overview  Operation When Tag Memory Setting Is Set to CA1D Mode If the Tag memory setting for the V680-CH@D (version 1.1 or newer) is set to CA1D Mode, data is read from or written to addresses that are reversed in block units for the V680-D1KP@@ (except for the V680-D1KP58HT) in the same way as for the V680-CA1D/-CA2D.

  • Page 21: Names And Functions Of Components

    Section 1 Product Overview Names and Functions of Components V680-CHUD  Operation Indicator (LED) Antenna Display Meaning Operation indicator (LED) A command has been received from the host device. Communications with the RF Tag have completed normally. Lit green Activate switch When the power is turned ON, after initialization of the Hand-held Reader/Writer is completed.
  • Page 22 Section 1 Product Overview  Operation Indicator (LED) Antenna Display Meaning A command has been received from the host device. Operation indicator (LED) Communications with the RF Tag have completed normally. Lit green •When the power is turned ON, after initialization of the Hand-held Activate switch Reader/Writer is completed •When the power is turned ON and the reset button is pressed for...
  • Page 23 Section 1 Product Overview  Operation Indicator (LED) Antenna Display Meaning A command has been received from the host device. Operation indicator (LED) Communications with the RF Tag have completed normally. Lit green •When the power is turned ON, after initialization of the Hand-held Activate switch Reader/Writer is completed.

  • Page 24: System Configuration

    Section 1 Product Overview System Configuration V680-CHUD The V680-CHUD Hand-held Reader/Writer can communicate with host devices that have a USB interface, such as personal computers. Host Devices Personal computer Hand-held Reader/Writer RF Tags The V680-CHUD Hand-held Reader/Writer can be used with any RF Tag in the V680/V680S Series. For details on Hand-held Reader/Writer and RF Tag models, refer to Section 6 Appendices.
  • Page 25 Section 1 Product Overview V680-CH1D A built-in RS-232C serial interface in the V680-CH1D Hand-held Reader/Writer allows communication with personal computers and programmable controllers that are equipped with an RS-232C interface. Host Devices Programmable controller Personal computer (Some models require a conversion connector.) Hand-held Reader/Writer V600-A22 (option) V680-CH1D...
  • Page 26 Section 1 Product Overview V680-CH1D-PSI A built-in RS-232C serial interface in the V680-CH1D-PSI Hand-held Reader/Writer allows communications with personal computers and programmable controllers that are equipped with an RS-232C interface Host Devices Recommended Hand-held Terminal: Work About Pro manufactured by Zebra Technologies Inc. Hand-held Reader/Writer V680-CH1D-PSI RF Tags...

  • Page 27: Operation Flowchart

    Section 1 Product Overview Operation Flowchart V680-CHUD Connect the V680-CHUD to the host device. When connecting for the first time, the USB driver must be installed. p.31 to p.34 Perform the communications test between the host device and Hand-held Reader/Writer. p.54 Perform the communications test between the RF Tag and Hand-held Reader/Writer.
  • Page 28 Section 1 Product Overview V680-CH1D Connect the V680-CH1D to the host device. p.46 Set the communications parameters between the host device and Hand-held Reader/Writer. p.49 Perform the communications test between the host device and Hand-held Reader/Writer. p.54 Perform the communications test between the RF Tag and Hand-held Reader/Writer.
  • Page 29 Section 1 Product Overview V680-CH1D-PSI Connect the V680-CH1D-PSI to the host device. p.48 Set the communications parameters between the host device and Hand-held Reader/Writer. p.49 Perform the communications test between the host device and Hand-held Reader/Writer. p.54 Perform the communications test between the RF Tag and Hand-held Reader/Writer.
  • Page 30 Section 1 Product Overview MEMO RFID System User's Manual...

  • Page 31: Section 2 Communications Preparations

    Section 2 Communications Preparations V680-CHUD Communications Preparations V680-CH1D Communications Preparations V680-CH1D-PSI Communications Preparations Setting the Hand-held Reader/Writer Communications Test RFID System User's Manual...

  • Page 32: V680-Chud Communications Preparations

    Section 2 Communications Preparations V680-CHUD Communications Preparations Connections  Connecting the Cable Connect the cable connector to the USB connector on the host device, making sure that the connector is oriented correctly and not inserted at an angle.  Removing the Cable Remove the cable.
  • Page 33  Downloading the USB Driver Download the USB Driver for the V680-CHUD from the web site. For details, ask your OMRON sales representative.  Installing the USB Driver The V680-CHUD supports the Windows XP, Windows 7 or Windows 10 operating system. Install the driver in the host personal computer using the following procedure.
  • Page 34 Section 2 Communications Preparations Click the Browse Button when the Found New Hardware Wizard Dialog Box appears, select the folder in which the downloaded file V680-CHUD_100.inf was saved, and click the Next button. Click the Continue Anyway Button. RFID System User's Manual...
  • Page 35 Section 2 Communications Preparations The USB Driver installation will begin. When the following window is displayed, installation has been completed. Click the Finish Button. RFID System User's Manual...
  • Page 36 On the Start Menu, select Control Panel - System. Click the Device Manager Button in the Hardware Tab Page. Select Ports (COM & LPT), and check that OMRON RFID USB COM is displayed. The driver is correctly installed if this port is displayed.
  • Page 37 Section 2 Communications Preparations Windows 7 Turn ON the power to the personal computer and start Windows 7. Connect the ID Controller to the computer via USB. Refer to Connections for information on the connection method. p.30 Select Settings - Control Panel - System and Security from the Windows Start Menu. Click the Device Manager Button.
  • Page 38 Section 2 Communications Preparations Right-click the Other devices - V680-CHUD and click the Properties. Click the Update Driver Button. Once the following dialog box has been displayed, click the Browse my computer for driver software Button. RFID System User's Manual...
  • Page 39 Section 2 Communications Preparations Click the Browse Button and select the folder where the downloaded V680-CHUD_100_win7_@@.inf is to be saved. Then click the Next Button. Click the Install this driver software anyway Button. The following dialog box will be displayed when the software installation has been completed. Click the Close Button.
  • Page 40 Section 2 Communications Preparations  Checking Installation Use the following procedure to confirm that the driver has been correctly installed. Turn ON the power to the personal computer and start Windows 7. Connect the ID Controller to the computer via USB. Refer to Connections for information on the connection method.
  • Page 41 Select Ports (COM & LPT), and check that OMRON RFID USB COM is displayed. If the driver is correctly installed, the property window for the V680-CHUD will be displayed as follows: Communications with the ID Controller can be performed with the COM number displayed in parentheses after OMRON RFID USB COM.
  • Page 42 Section 2 Communications Preparations Windows 10 Turn ON the power to the personal computer and start Windows 10. Connect the ID Controller to the computer via USB. Refer to Connections for information on the connection method. p.30 Select Settings - Windows System - Control Panel - System and Security from the Windows Start Menu.
  • Page 43 Section 2 Communications Preparations Click the Device Manager Button. Right-click the Ports - USB Serial Device (COM) and click the Update driver. Once the following dialog box has been displayed, click the Browse my computer for driver software Button. RFID System User's Manual...
  • Page 44 Section 2 Communications Preparations Click the Browse Button and select the folder where the downloaded V680-CHUD_100_win10_@@.bat is to be saved. Then click the Next Button. The USB Driver installation will begin. The following dialog box will be displayed when the software installation has been completed. Click the Close Button.
  • Page 45 Section 2 Communications Preparations  Checking Installation Use the following procedure to confirm that the driver has been correctly installed. Turn ON the power to the personal computer and start Windows 10. Connect the ID Controller to the computer via USB. Refer to Connections for information on the connection method.
  • Page 46 Right-click the Ports - OMRON RFID USB (COM), and check the Update driver. If the driver is correctly installed, the property window for the V680-CHUD will be displayed as follows: Communications with the ID Controller can be performed with the COM number displayed in parentheses after OMRON RFID USB COM.

  • Page 47: V680-Ch1D Communications Preparations

    Section 2 Communications Preparations V680-CH1D Communications Preparations Pin Arrangement of the Host Device Interface Connector V680-CH1D Signal Code Pin No. Signal direction (See note.) (See note.) Hand-held Reader/Writer to host Receive data device Host device to Hand-held Reader/ Send data Writer Signal ground (Reserved)
  • Page 48 Section 2 Communications Preparations  Connection with the Host Device Use the following procedure to connect the V680-CH1D to the host device. Connect the V680-CH1D to the RS-232C interface of the host device. • When connecting to an IBM PC/AT or compatible: •...
  • Page 49 Section 2 Communications Preparations  When connecting to a CQM1, CJ1, CS1, etc. Prepare a connection cable as shown in the connection examples below. Note: Because both the V680-CH1D interface connector and the interface connector of the CQM1, CJ1, and CS1 are sockets, a conversion connector is necessary to connect them. Also, the pin arrangement of the CQM1, CJ1, and CS1 interface connector is different from the RS-232C pin arrangement of a personal computer.

  • Page 50: V680-Ch1D-Psi Communications Preparations

    Section 2 Communications Preparations V680-CH1D-PSI Communications Preparations Pin Arrangement of the Host Device Interface Connector V680-CH1D-PSI Signal Code Pin No. Signal direction (See note.) (See note.) Hand-held Reader/Writer to host Receive data device Host device to Hand-held Reader/ Send data Writer Signal ground Reserved...

  • Page 51: Setting The Hand-Held Reader/Writer

    Section 2 Communications Preparations Setting the Hand-held Reader/Writer Settings The following settings are used to operate the Hand-held Reader/Writer. • Serial communications parameters (baud rate, transmission code, parity check, stop bits) • Basic function settings (Auto Command OFF) These settings can be changed by sending a setting command from the host device. To operate the Hand-held Reader/Writer with the new setting, the power must be turned OFF then ON again, or the ABORT command must be used.
  • Page 52 Section 2 Communications Preparations Setting the Operating Parameters To optimize Hand-held Reader/Writer performance and reliability, operating parameters can be set to match the application. The following parameters can be set: the inter-character monitoring time, response delay time, auto command cancel time, write protection setting, and protocol. Usually there will be no problem if the default settings are used, but the system can be optimized by setting following parameters.
  • Page 53 Section 2 Communications Preparations  Auto Command Cancel Time The auto command cancel time is used to set the amount of time from after an auto command is sent until the command processing will be aborted. After waiting for the tag for a fixed period of time, an " RF Tag non-existent" error (error code: 72) will be returned to the host device.
  • Page 54 Section 2 Communications Preparations Initializing the Settings A setting command is used to set the Hand-held Reader/Writer but if the communications parameters are not known or if the setting contents are damaged, it is possible that communications will no longer be possible with the host device.

  • Page 55: Communications Test

    Section 2 Communications Preparations Communications Test Test Run Procedure Connect the Hand-held Reader/Writer to the host device. Visually check the indicator display. Execute the online test from the host Check communications between the host device and Hand-held device. Reader/Writer using the test command. Test run the system.
  • Page 56 Section 2 Communications Preparations Communications Test between Host Device and Hand-held Reader/Writer Use the test command to test communications between the Hand-held Reader/Writer and host device. Before performing communications with the RF Tag, check the Hand-held Reader/Writer connections and communications. Send the test command from the host device.

  • Page 57: Section 3 Commands

    Section 3 Commands Communicating with RF Tags V600 and V680 Command Comparison V680 Commands V600 Commands RFID System User's Manual...

  • Page 58: Communicating With Rf Tags

    Section 3 Commands Communicating with RF Tags Specifying Data Code Whether the read or write data is treated as an ASCII (or JIS 8) or hexadecimal is specified in each command.  ASCII (JIS 8 Code) • One character of ASCII or JIS 8 code data occupies 1 byte •...

  • Page 59: V600 And V680 Command Comparison

    Section 3 Commands V600 and V680 Command Comparison The V680-series Hand-held Reader/Writer can use commands in either the V600 command format or the V680 command format. By using V600 commands, production lines that previously used a V600-series Reader/Writer can use the same application with the V680-series Hand-held Reader/Writer. New functionality can be used by using V680 commands.
  • Page 60 Section 3 Commands Host Commands V680 commands V600 commands Com- Com- Command name mand Command name mand code code TEST TEST VERSION READ VERSION READ RFID System User's Manual...

  • Page 61: V680 Commands

    Section 3 Commands V680 Commands Communications with the RF Tag There are four types of communications specifications for communicating with RF Tags using the Hand-held Reader/Writer. Communications Name Description specification When the Hand-held Reader/Writer receives a command, it communicates with an RF Tag and then Single trigger returns a response.
  • Page 62 Section 3 Commands Single Auto (SA) Communications Specifications A single auto (SA) communications specification is used to communicate with an RF Tag when the antenna end of the Hand-held Reader/Writer is moved close to an RF Tag after the command has been sent from the host device.
  • Page 63 Section 3 Commands Button Trigger (BT) Communications Specifications A button trigger (BT) communications specification is used to communicate with an RF Tag when the antenna is moved close to an RF Tag and the activate switch is pressed after the command has been sent from the host device.
  • Page 64 Section 3 Commands Button Auto (BA) Communications Specifications A button auto (BA) communication specification is used to execute auto commands after the command is sent from the host device and the activate switch of the Hand-held Reader/Writer is pressed. Host device RF Tag Hand-held Reader/Writer B Press...
  • Page 65 Section 3 Commands Command and Response Formats The formats of commands sent from the host device to the Hand-held Reader/Writer and responses returned from the Hand-held Reader/Writer to the host device are described below. The command and response both consist of a single frame. Each frame (including the terminator) consists of up to 2,114 characters.
  • Page 66 Section 3 Commands Command List Commands can be classified into four major types.  Communications Commands The following commands are used for communications with the RF Tag. Command Processing Command name Function Page code specification READ Reads memory data from the RF Tag. p.65 WRITE Writes data to the memory of the RF Tag.
  • Page 67 Section 3 Commands Communications Commands Details of communications commands used to communicate with the RF Tag are provided here.  READ (RD) This command reads up to 2 Kbytes of data from the RF Tag. Command Communica- Data Read area Command tions Fixed...
  • Page 68 Section 3 Commands  WRITE (WT) The WRITE command writes up to 2 Kbytes of data to the memory of an RF Tag. Command Communica- Command Write area Data Fixed tions code start address Terminator specification setting value Write data ×...
  • Page 69 Section 3 Commands  DATA FILL (DF) The DATA FILL command writes the designated data for the specified number of bytes beginning from the specified start address. This command can be used to write data regardless of the write protection setting. Confirm that there is no important data in the area being written before executing this command.
  • Page 70 Section 3 Commands Example This examples shows how to write 00101 hex to the memory area with addresses 0030 to 0006 (hex) for an RF Tag in which the same data and address is written. The communications specification is ST. Command Communica- Write area...
  • Page 71 Section 3 Commands  OVERWRITE COUNT CONTROL (MD S/L) The OVERWRITE COUNT CONTROL command is used to manage overwrite counts for EEPROM RF Tags. The specified overwrite count control area data is updated to enable determining when the EEPROM's write life has expired. Command Communica- Pro-...
  • Page 72 Section 3 Commands  DATA CHECK (MD C/K) This command writes or compares the CRC code using the specified check block unit. The CRC code is calculated from the generated polynomial expression X + 1. Command Pro- Communi- cessing Number of check Check block Command Fixed...
  • Page 73 Section 3 Commands  ID CODE READ (ID) Reads the ID code from the RF Tag. Command Communica- Data tions Fixed Command specification setting value Terminator code × × Communications specifi- Specifies the method for communicating with the RF Tag. cation For details on communications specifications, refer to Communications with the RF Tag.
  • Page 74 Section 3 Commands  READ WITH ERROR CORRECTION (QR) Reads the data in the area written by the WRITE WITH ERROR CORRECTION (QW) command from the RF Tag. Be sure to read data from the same area written by the WRITE WITH ERROR CORREC- TION (QW) command.
  • Page 75 Section 3 Commands  WRITE WITH ERROR CORRECTION (QW) The WRITE WITH ERROR CORRECTION (QW) command writes data to the RF Tag. The command also writes the RF Tag memory check and error correction codes as 5 bytes of write data. Do not change this code, it is required by the READ WITH ERROR CORRECTION (QR) command.
  • Page 76 Section 3 Commands Communications Subcommands Communications subcommands are used together with communications commands. Communications with the RF Tag cannot be performed using only these subcommands.  COMMAND PROCESSING TERMINATE (AA) Terminates the processing of the communications commands and restores the command wait status. Command Pro- cessing...
  • Page 77 Section 3 Commands  COMMUNICATIONS CONDITIONS SETTING (TR) This command is used to set serial communications parameters. The Hand-held Reader/Writer must be restarted to make the changes take effect. The COMMUNICATIONS CONDITIONS SETTING (TR) command can be used only with the V680-CH1D. Do not use it with the V680-CHUD.
  • Page 78 Section 3 Commands  BASIC FUNCTIONS SETTING (FN) This command is used to set the Auto Commands OFF function. The Hand-held Reader/Writer must be restarted to make the changes take effect. A memory error will occur if the power supply is interrupted while parameters are being changed. Command Auto Command...
  • Page 79 Section 3 Commands  SET INFORMATION READ (UL) This command is used to read the settings of the Hand-held Reader/Writer. Only the Auto Command OFF function is supported by the V680-CHUD. The settings made with the COMMUNICATIONS CONDITIONS SETTING (TR) command are not valid for the V600- CHUD.
  • Page 80 Section 3 Commands  PARAMETER SET (SP) The PARAMETER SET command is used to set conditions for communicating with RF Tags. The various parameters are set in the Hand-held Reader/Writer. The Hand-held Reader/Writer does not need to be reset when internal settings are changed. The new settings are effective immediately.
  • Page 81 Section 3 Commands Host Commands  TEST (TS) This command returns test messages sent from the host device without changing anything. The TEST command is used for communications tests between the host device and the Hand-held Reader/Writer. Command Command code Message data Terminator ×...
  • Page 82 Section 3 Commands  VERSION READ (VS) The VERSION READ command reads the Hand-held Reader/Writer's software model, software ver- sion, and software creation date. Command Command code Terminator Response Resend Fixed Command code End code flag Terminator value Software model Software version Creation date Software model...
  • Page 83 Section 3 Commands Other Commands  UNDEFINED COMMAND RESPONSE (IC) This command is returned as the response when the Hand-held Reader/Writer cannot read the com- mand header. Response Fixed Command Resend code End code value flag Terminator × ×  Error Response If an error occurs during communications with the host device, or the RF Tag, error notification is pro- vided in the end code.
  • Page 84 Section 3 Commands End Codes End codes are given in 2-digit hexadecimal. Status End code Meaning Normal Normal completion Host communications error 10 (See note.) Vertical parity error 11 (See note.) Framing error 12 (See note.) Overrun error Format error Execution status error Frame length error Lower communications error...

  • Page 85: V600 Commands

    Section 3 Commands V600 Commands There are 4 types of commands for communicating with the RF Tag using the Hand-held Reader/Writer. • Normal commands • Button commands • Auto commands • Button auto commands Normal Commands Normal commands are sent from the host device for communications with the RF Tag, after the antenna end of the Hand-held Reader/Writer has been moved close to the RF Tag.
  • Page 86 Section 3 Commands Button Commands Button commands used to perform communications with the RF Tag are activated when the activate switch is pressed after commands are sent from the host device, and the antenna end of the Hand-held Reader/Writer has been moved close to the RF Tag. Host device RF Tag Hand-held Reader/Writer...
  • Page 87 Section 3 Commands Auto Commands Auto commands can execute communications with the RF Tag when the antenna end of the Hand-held Reader/Writer has been moved close to the RF Tag after the command is sent from the host device. Host device RF Tag Hand-held Reader/Writer Communications...
  • Page 88 Section 3 Commands Button Auto Commands Button auto commands execute auto commands after a command is sent from the host device and the activate switch of the Hand-held Reader/Writer is pressed. Host device RF Tag Hand-held Reader/Writer B Press Communications with RF Tag Command Response...
  • Page 89 Section 3 Commands Command and Response Formats The formats of commands sent from the host device to the Hand-held Reader/Writer and responses returned from the Hand-held Reader/Writer to the host device are described below. The command and response both consist of a single frame. The frame (including the terminator) consists of up to, 2,114 characters.
  • Page 90 Section 3 Commands Command List Commands can be classified into four major types.  Communications Commands The following commands are used for communications with the RF Tag. Command code Command name Function Page READ Reads memory data from the RF Tag. p.89 WRITE Writes data to the memory of the RF Tag.
  • Page 91 Section 3 Commands Communications Commands Details of communications commands used to communicate with the RF Tag are provided here.  READ (RD) This command reads data from the RF Tag. If the RF Tag is not in the interrogation zone, an error response (end code: 72 = RF Tag non-existent) will be returned.
  • Page 92 Section 3 Commands Response Processing Area Number: 1 Command End code Read data Terminator code × × … × × Processing Area Number: 2 Read data Read data Command Area (1) Area (2) Terminator End code code × × … ×...
  • Page 93 Section 3 Commands  WRITE (WT) This command writes data to the RF Tag. If the RF Tag is not in the interrogation zone, an error response (end code: 72 = RF Tag non-existent) will be returned. Command Processing Area Number: 1 Processing area Command...
  • Page 94 Section 3 Commands  AUTO READ (AR) This command reads data from the RF Tag when the RF Tag enters the interrogation zone. The Hand- held Reader/Writer responds when the communications between the Hand-held Reader/Writer and RF Tag have ended. Command Processing Area Number: 1 Processing...
  • Page 95 Section 3 Commands Response Processing Area Number: 1 Command End code Read data Terminator code × × … × × Processing Area Number: 2 Command Read data Read data code End code area (1) area (2) Terminator × × … ×...
  • Page 96 Section 3 Commands  AUTO WRITE (AW) This command writes data to the RF Tag when the RF Tag enters the interrogation zone. The Hand- held Reader/Writer responds when communications between the Hand-held Reader/Writer and RF Tag have ended. Command Processing Area Number: 1 Processing area...
  • Page 97 Section 3 Commands Response Command code End code Terminator End code Indicates the execution result for the command. The end code 00 indicates normal completion. For details on end codes, refer to End code List. p.118 RFID System User's Manual...
  • Page 98 Section 3 Commands  BUTTON READ (BR) After this command is received by the Hand-held Reader/Writer, data is read from the RF Tag by pressing the activate switch. If the activate switch is pressed and the RF Tag is not in the interrogation zone, an error response (end code: 72 = RF Tag non-existent) will be returned.
  • Page 99 Section 3 Commands Response Processing Area Number: 1 Command Read data Terminator code End code × × … × × Processing Area Number: 2 Read data Read data Command area (1) Terminator End code area (2) code × × … ×...
  • Page 100 Section 3 Commands  BUTTON WRITE (BW) After this command is received by the Hand-held Reader/Writer, data is written to the RF Tag by press- ing the activate switch. If the activate switch is pressed and the RF Tag is not in the interrogation zone, an error response (end code: 72 = RF Tag non-existent) will be returned.
  • Page 101 Section 3 Commands  BUTTON AUTO READ (UR) After this command is received by the Hand-held Reader/Writer, data will be read from the RF Tag after the activate switch is pressed and the Hand-held Reader/Writer is close to the RF Tag. The Hand-held Reader/Writer responds when communications between the Hand-held Reader/Writer and RF Tag have ended.
  • Page 102 Section 3 Commands Response Processing Area Number: 1 Command code Read data Terminator End code × × … × × Processing Area Number: 2 Read data Read data Command End code area (1) area (2) Terminator code × × × …...
  • Page 103 Section 3 Commands  BUTTON AUTO WRITE (UW) After this command is received by the Hand-held Reader/Writer, data will be written to the RF Tag after the activate switch is pressed and the Hand-held Reader/Writer is close to the RF Tag. The Hand-held Reader/Writer responds when communications between the Hand-held Reader/Writer and RF Tag have ended.
  • Page 104 Section 3 Commands  Calculation Write (CW) The RF Tag's memory data and calculation data is calculated in hexadecimal and the result is written to the RF Tag. If an overflow during addition or underflow during subtraction occurs, the data will not be written and an error response (end code: 76 = Data check error) will be returned.
  • Page 105 Section 3 Commands  DATA FILL (FL) Writes fill data for the specified number of bytes beginning from the start address specified in the RF Tag. The write data is specified in hexadecimal. If there is no Tag in the interrogation zone when the Hand-held Reader/Writer receives the command from the host device, the Hand-held Reader/Writer will return an error response (end code: 72 = RF Tag non-existent).
  • Page 106 Section 3 Commands  AUTO DATA FILL (AF) Writes the fill data to the specified number of bytes beginning from the start address specified in the RF Tag when the RF Tag approaches. The write data is specified in hexadecimal. A response will be returned when communications with the RF Tag have been completed.
  • Page 107 Section 3 Commands  Example Writing 01 hex to the 6 bytes in memory starting from address Before Writing (hex) 0030 (hex) for an RF Tag in which the data at each address is the 002F 0030 same as the address. 0031 0032 0033...
  • Page 108 Section 3 Commands  DATA CHECK (MDC/K) This command writes or compares the CRC code using the specified check block unit. The CRC code is calculated from the generated polynomial expression X + 1. Command Processing area Check block Number of check Command Process number...
  • Page 109 Section 3 Commands  OVERWRITE COUNT CONTROL (MDS) This command is used to control the number of overwrite operations performed by EEPROM RF Tags. This command determines whether the EEPROM overwrite count has been exceeded when the speci- fied number of overwrites is subtracted from the specified overwrite count control area data. Command Processing area...
  • Page 110 Section 3 Commands  ID CODE READ (ID) Reads the ID code in the RF Tag. Command Data Command setting Terminator code Data setting Always H. Response Command End code Terminator code U I D × × … × × 0 or 16 End code Indicates the execution result for the command.
  • Page 111 Section 3 Commands Communications Subcommands Communications subcommands are used together with communications commands. Communications with the RF Tag cannot be performed using only these subcommands.  COMMAND PROCESSING TERMINATE (AA) Terminates the processing of the communications commands and restores the command wait status. Command Command code...
  • Page 112 Section 3 Commands Host Commands  TEST (TS) This command returns test messages sent from the host device without changing anything. The TEST command is used for communications tests between the host device and the Hand-held Reader/Writer. Command Command code Message data Terminator ×...
  • Page 113 Section 3 Commands  VERSION READ (VS) Command Terminator Command code Response Terminator Command code End code Software model Software version Creation date Software model The software creation date. For the V680-CHUD: V680-CHUD$000000 For the V680-CH1D: V680-CH1D$000000 For the V680-CH1D-PSI: V680-CH1D$000000 Software version The software version.
  • Page 114 Section 3 Commands Controller Control Commands These commands are used to reset the Controller or set serial communications.  ABORT (XZ) This command is used to restore the Hand-held Reader/Writer to command wait status when there is no response from the Hand-held Reader/Writer due to some problem during communications with the host device or with an RF Tag.
  • Page 115 Section 3 Commands  COMMUNICATIONS CONDITIONS SETTING (TR) This command is used to set serial communications parameters. The Hand-held Reader/Writer must be restarted to make the changes take effect. The COMMUNICATIONS CONDITIONS SETTING (TR) command can be used only with the V680-CH1D. Do not use it with the V680-CHUD.
  • Page 116 Section 3 Commands  BASIC FUNCTIONS SETTING (FN) This command is used to set the Auto Commands OFF function. The Hand-held Reader/Writer must be restarted to make the changes take effect. A memory error will occur if the power supply is interrupted while parameters are being changed. Command Auto Command specification...
  • Page 117 Section 3 Commands  SET INFORMATION READ (UL) This command is used to read the settings of the Hand-held Reader/Writer. Only the Auto Command OFF function is supported by the V680-CHUD. The settings made with the COMMUNICATIONS CONDITIONS SETTING (TR) command are not valid for the V600- CHUD.
  • Page 118 Section 3 Commands  PARAMETER SET (SP) The PARAMETER SET command is used to set conditions for communicating with RF Tags. The various parameters are set in the Hand-held Reader/Writer. The Hand-held Reader/Writer does not need to be reset when internal settings are changed. The new settings are effective immediately.
  • Page 119 Section 3 Commands Other Commands  UNDEFINED COMMAND RESPONSE (IC) This command is returned as the response when the Hand-held Reader/Writer cannot read the com- mand header. Response Command End code Terminator code × ×  Error Response If an error occurs during communications with the host device, or the RF Tag, error notification is pro- vided in the end code.
  • Page 120 Section 3 Commands End code List End codes are indicated in 2-digit hexadecimal. Status End code Meaning Normal Normal completion Host communications error 10 *1 Vertical parity error 11 *1 Framing error 12 *1 Overrun error Format error Execution status error Frame length error Lower communications error RF Tag communications error...

  • Page 121: Section 4 Functions

    Section 4 Functions Hand-held Reader/Writer Functions Multiple Area Control Auto Command OFF Function Write Protection Function RF Tag Service Life Detection Memory Check Function in RF Tag RF Tag Memory Error Correction RFID System User’s Manual...

  • Page 122: Hand-Held Reader/Writer Functions

    Section 4 Functions Hand-held Reader/Writer Functions Multiple Area Control The Hand-held Reader/Writer can read and write across (hex) several non-consecutive RF Tag memory areas (10 areas 0010 “O” max.) at one time. To use this feature, the number of control 0011 “M”...

  • Page 123: Write Protection Function

    Section 4 Functions Write Protection Function The write protection function prevents important data stored in the RF Tag, such as the product type and model, from being overwritten by other data and lost. Use the following method to set write protection after writing important data.
  • Page 124 Section 4 Functions  Write Protection Setting Examples (1) Settings to Write-protect Addresses 0015 to 0120 (hex) (Start address < End address) Address (hex) Address 0000 (hex) 0015 Write-protected area 0000 (Hexadeci- 0120 mal) 0001 03E7 0002 0003 (2) Settings to Write-protect 1 Byte Write-protected area 1 byte (Start address = End address)

  • Page 125: Rf Tag Service Life Detection

    Section 4 Functions RF Tag Service Life Detection The OVERWRITE COUNT CONTROL command (MDS/MDL) can be used to determine whether the Tag overwrite limit has been exceeded. With the MDS command, the overwrite count is subtracted from the data in the user-specified overwrite count control area to determine whether the number of overwrites has been exceeded.
  • Page 126 Section 4 Functions MDL Command The overwrite count control area consists of 3 bytes from the start address. The decrement value from the Area start address Upper digit overwrite count is written in this area, and if this value 3 bytes Middle digit is 100,000 (0186A0 hex) or higher, an end code 76 will Lower digit...

  • Page 127: Memory Check Function In Rf Tag

    Section 4 Functions Memory Check Function in RF Tag A memory check can be made using the DATA CHECK command (MD C/K). A CRC (Cyclic Redundancy Check) code calculation, overwrite, and comparison are made, using the check block units specified by the user.

  • Page 128: Rf Tag Memory Error Correction

    Section 4 Functions RF Tag Memory Error Correction The WRITE WITH ERROR CORRECTION command (QW) can be used to write an RF Tag memory check code and error correction code to the five bytes of memory after the write data. The READ WITH ERROR CORRECTION command (QR) performs a tag memory check and makes 1-bit memory error corrections.

  • Page 129: Section 5 Troubleshooting

    Section 5 Troubleshooting Error Tables Fatal Errors (Operation Stops) Non-fatal Errors (Operation Continues) Troubleshooting Flowchart RFID System User’s Manual...

  • Page 130: Error Tables

    Section 5 Troubleshooting Error Tables If an error occurs in the Hand-held Reader/Writer, the operation indicator will light or flash red to indicate the type of error. Fatal Errors (Operation Stops) If a fatal error occurs, the operation indicator will be lit red and all operations of the Hand-held Reader/ Writer will stop until the power is turned OFF and then ON again.

  • Page 131: Troubleshooting Flowchart

    Section 5 Troubleshooting Troubleshooting Flowchart If an error occurs, be sure to understand the conditions thoroughly, then accurately determine the likelihood of the error re-occurring, whether the problem is related to another device, and other factors causing the error, and refer to the following flowcharts for troubleshooting. S T A R T Connect to the host device.
  • Page 132 Section 5 Troubleshooting MEMO RFID System User's Manual...

  • Page 133: Section 6 Appendices

    Section 6 Appendices Specifications and Dimensions RF Tag Memory Map RF Tag Memory Capacities and Memory Types (V680 Series) List of ASCII Characters Degree of Protection RFID System User's Manual...

  • Page 134: Specifications And Dimensions

    Section 6 Appendices Specifications and Dimensions General Specifications Specification Item V680-CHUD V680-CH1D V680-CH1D-PSI 0.8 m 1.9 m Supply voltage 5.0 VDC ±5% (at Reader/Writer connector) Ambient operating 0 to 40°C temperature Ambient operating humidity 35% to 85% (with no condensation) −25 to 65°C Ambient storage temperature...
  • Page 135 Section 6 Appendices Communications Specifications  Host Communications Interface Specifications V680-CHUD Item Specification Connectors (connector Series A plug connection status) USB specifications Ver 1.1 Baud rate Full speed (12 Mbps) Device class COM class Vendor ID Hexadecimal format [0590] Product ID Hexadecimal format [0048] Use the host communications interface as the COM port for the host device.
  • Page 136 Section 6 Appendices Dimensions V680-CHUD Operation indicator Activate switch Dimension L 800±60 1900±60 160.5 Antenna 10.5 Ferrite core Vinyl-insulated round cable, 3.8 mm dia. Standard length: 0.8 or 1.9 m (Unit: mm) V680-CH1D Operation indicator Activate switch Reset button Vinyl-insulated round cable, 3.8 mm dia.
  • Page 137 Section 6 Appendices V680-CH1D-PSI Activate switch Operation indicator Reset button Vinyl-insulated round cable, 3.8 mm dia. Standard length: 2.5 m 160.5 44.9 −110 Antenna Ferrite core 10.5 Connector (Unit: mm) V600-A22 25.4±1 54±1 48±1 (Unit: mm) 9.5±0.3 RFID System User’s Manual...
  • Page 138 Section 6 Appendices Communication Specifications Communication with the currently available V680/V680S-series RF Tags is possible.  Communications Ranges RF Tag Communications range RF Tag Communications range V680-D1KP52MT Read 0 to 9.0 mm V680-D2KF52M Read 0 to 7.0 mm Write 0 to 7.5 mm Write 0 to 7.0 mm V680-D1KP52MT...
  • Page 139 Section 6 Appendices Note 1: RF Tag Installation Conditions • V680-D1KP52MT Embedded in resin/Embedded in metal (iron) • V680-D1KP53M Embedded in resin/Embedded in metal (iron) • V680-D1KP66MT Metal (iron) on the back surface of the RF Tag. • V680-D1KP66T Resin on the back surface of the RF Tag. RF Tag (no metal on back surface) •...
  • Page 140 Section 6 Appendices  Interrogation Zone (Reference) V680-D1KP52MT V680-D1KP52MT Embedded in metal (iron) Read Read Write Write V680-D1KP53M V680-D1KP53M Embedded in metal (iron) Read Read Write Write V680-D1KP66T-SP V680-D1KP66T Read Read Write Write V680-D1KP66MT V680-D1KP58HT Read Read Write Write RFID System User's Manual...
  • Page 141 Section 6 Appendices V680-D2KF52M V680-D2KF52M Embedded in metal (iron) Read / Write Read / Write V680-D8KF67 V680-D8KF67M Read / Write Read / Write V680-D8KF68/V680-D32KF68 Read / Write RFID System User’s Manual...
  • Page 142 Section 6 Appendices V680S-D2KF67 V680S-D2KF67M Read / Write Read / Write V680S-D2KF68 V680S-D2KF68M Read / Write Read / Write V680S-D8KF67 V680S-D8KF67M Read / Write Read / Write V680S-D8KF68 V680S-D8KF68M Read / Write Read / Write RFID System User's Manual...
  • Page 143 Section 6 Appendices Communications Time TAT represents the total time from when a command is first sent from the host device until a response is received. The communication time represents the time required for communications between the Hand-held Reader/Writer and the RF Tag, not including communications with the host device. Example Communication time Response...
  • Page 144 Section 6 Appendices  Communication Time Write Read 1,024 Number of processing data bytes Calculation Method Operation Communication time (ms) Read T=1.2N+27.3 Write T=2.0N+414.4 N: Number of processing data bytes RFID System User's Manual...
  • Page 145 Section 6 Appendices  V680-D2KF52M/V680S-D2KF6@  V680-CH1D TAT Write Read 1,024 1,280 1,536 1,792 2,048 Number of processing data bytes Note 1) In V680 mode, communications specifications for TAT data with the host device represent values with a baud rate of 9,600 bps, a bit length of 8 bits, 1 stop bit, and even parity.
  • Page 146 Section 6 Appendices  Communication Time Write Read 1,024 1,280 1,536 1,792 2,048 Number of processing data bytes Calculation Method Operation Communication time (ms) Read T=1.1N+26.1 Write T=1.9N+40.3 N: Number of processing data bytes RFID System User's Manual...
  • Page 147 Section 6 Appendices  V680-D8KF68/V680-D32KF68  V680-CH1D TAT Write Read 1,024 1,280 1,536 1,792 2,048 Number of processing data bytes Note 1) In V680 mode, communications specifications for TAT data with the host device represent values with a baud rate of 9,600 bps, a bit length of 8 bits, 1 stop bit, and even parity.
  • Page 148 Section 6 Appendices  Communication Time Write Read 1,024 1,280 1,536 1,792 2,048 Number of processing data bytes Calculation Method Operation Communication time (ms) Read T=1.2N+27.7 Write T=1.5N+41.4 N: Number of processing data bytes RFID System User's Manual...
  • Page 149 Section 6 Appendices  V680S-D8KF6@  V680-CH1D TAT Write Read 1,024 1,280 1,536 1,792 2,048 Number of processing data bytes Note 1) In V680 mode, communications specifications for TAT data with the host device represent values with a baud rate of 9,600 bps, a bit length of 8 bits, 1 stop bit, and even parity.
  • Page 150 Section 6 Appendices  Communication Time Write Read 1,024 1,280 1,536 1,792 2,048 Number of processing data bytes Calculation Method Operation Communication time (ms) Read T=0.8N+45 Write T=1.3N+167 N: Number of processing data bytes RFID System User's Manual...

  • Page 151: Rf Tag Memory Map

    Address (hex) Data 0000 0001 0002 0003 User area 7FE6 7FE7 1 byte For more information on RF Tag memory capacity and memory type, refer to RF Tag Memory Capaci- ties and Memory Types (V680 Series). RFID System User’s Manual...

  • Page 152: Rf Tag Memory Capacities And Memory Types (V680 Series)

    Section 6 Appendices RF Tag Memory Capacities and Memory Types (V680 Series) (As of October 2014) Memory capacity Model Memory type Life expectancy (user memory) V680-D1KP52MT Write endurance: 100,000 times per block (25°C) V680-D1KP66T Data retention: 10 years after writing (85°C or less)

  • Page 153: List Of Ascii Characters

    Section 6 Appendices List of ASCII Characters Left digit b8 to 0000 1001 0010 0011 0100 0101 0110 0111 1000 1101 1010 1011 1100 1101 1110 1111 Right digit Col- b4 to b1 0000 (DLE) (SP) 0001 (SOH) DC 0010 (STX) "...

  • Page 154: Degree Of Protection

    Section 6 Appendices Degree of Protection International protection degrees (IP-@@) are determined by the following tests. Be sure to check the sealing capability under the actual operating environment and conditions before actual use.  IEC (International Electrotechnical Commission) Standards (IEC60529 November 2001) Degree of Protection from Solid Materials Degree...
  • Page 155 Oil-proof Protects against penetration of oil drops or oil spray approaching from any direction. Note. Oil resistance has been tested using a specific oil as defined in the OMRON test method. (JIS C 0920:2003, Appendix 1) RFID System User’s Manual...

  • Page 156: Revision History
