- Page 1 SMR2006/2010 Smart Megapixel Video Recorder Hardware Manual Release 1.0 August, 2011...
-
Page 2: Copyright Statement
Product specifications are also subject to change without notice. Trademarks Surveon and Surveon logo are trademarks of Surveon Technology Inc. Other names prefixed with “SMR” are trademarks of Surveon Technology Inc. Microsoft Windows and Windows are registered trademarks of Microsoft Corporation. -
Page 3: Table Of Contents
Table of Contents Copyright Statement .................2 Safety Precautions ................5 Device Site Recommendations..............5 Regulatory Compliance Information ............6 Revision History ................8 Chapter 1. Product Overview...............9 1.1. Specifications for the SMR Series ..........9 Hardware Specifications ..............9 VMS Specifications ............... 9 Chapter 2. Hardware Overview ............12 2.1. - Page 4 3.6. Storage Management .............. 22 3.7. Configuring an IP Address for NVR Server ........24 3.8. Adding Network Cameras to the Server........25 Auto Scanning for Camera ............25 Manually Adding Cameras ............. 26 3.9. Initializing the Camera ............27 3.10.
-
Page 5: Safety Precautions
Safety Precautions Electric Shock Warning This equipment may cause electric shocks if not handled properly. Access to this equipment should only be granted to trained operators and maintenance personnel who have been instructed of, and fully understand the possible hazardous conditions and the consequences of accessing non-field-serviceable units such as the power supplies. -
Page 6: Regulatory Compliance Information
Regulatory Compliance Information Regulatory Compliance Information FCC/CE Class A IEC 60950 Shown below is the location of the compliance statement label. (applies in the U.S. and Canada) FCC Class A Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules (47 CFR, Part 2, Part 15 and CISPR PUB. - Page 7 Surveon is committed to being properly prepared and taking all the necessary steps that will result in our compliance with the new European directive, RoHS (2002/95/EC), on or before the specific dates set forth in those applicable laws and regulations.
-
Page 8: Revision History
Revision History Version Description Date Initial release August 2011... -
Page 9: Chapter 1. Product Overview
Chapter 1. Product Overview The Surveon SMR series is a state-of-the-art network video recorder features hardware RAID, low power and hot swappable hard disks. With 2/5/8-bay hard disk trays, the SMR series is the best in class NVR that supports megapixel quality video of 6 to 32 channels for video retention periods from 7 to 30 days or more. - Page 10 Surveon SMR2006/2010 eMAP • Drag-n-drop camera manipulation • Directional camera display • Hierarchical map structure • Real time event alert • Instant live video of camera • Multiple maps supported • Pan, tilt, zoom operations (dependent of the camera) • Built-in, floating PTZ control panel •...
- Page 11 • Language supported: English, French, German, Portuguese, Spanish, Simple Chinese, Traditional Chinese Surveon Smart Megapixel Video Recorder Hardware Manual...
-
Page 12: Chapter 2. Hardware Overview
Surveon SMR2006/2010 Chapter 2. Hardware Overview 2.1. Overview Front View LED Indicators Power Switch Hard Drives (Inside the Cabinet) V i d e o B a c k U p B u t t o n BACKUP Front USB Connector... -
Page 13: Panel Introduction
Indicates one of the followings: (1)Disk volume creation is in progress. (2)Online RAID level migration is in progress. (3)RAID rebuilding is in progress. System Indicates the system fan is malfunctioning. Blink Indicates that system is starting Surveon Smart Megapixel Video Recorder Hardware Manual... -
Page 14: Front Panel (Bottom)
Surveon SMR2006/2010 Front Panel (Bottom) Video Back Up Button BACKUP Front USB Connector Name Function Back Up Button Reserved Front USB Connector Connects external accessories such as mouse, keyboard or other external devices Rear Panel Components E SATA Port USB Port... -
Page 15: Chapter 3. Installation Guide
Common Topology Reference Product Existing LAN LAN Switch with DHCP Server Office LAN Router LAN Switch with built-in DHCP Server D-Link DIR-130 Switch/Hub No DHCP Server(refer to the Note below) D-Link DES-1108 Surveon Smart Megapixel Video Recorder Hardware Manual... -
Page 16: Hard Drive Installation
Surveon SMR2006/2010 Note: For devices without DHCP Server function, please refer to section 3.7. 3.2. Hard Drive Installation Hard Drive Installation Prerequisites When purchasing hard drives, the following factors should be considered: Capacity (MB/GB): Use drives with the same capacity. (The maximum is 2TB.) - Page 17 Note: While replacing hard drives, users can only extract one drive tray at a time. WARNING All drive bays must be populated even if it does not contain a hard drive. With one or several empty bays, ventilation will be disrupted and the SMR will overheat. Surveon Smart Megapixel Video Recorder Hardware Manual...
-
Page 18: Cabling
Surveon SMR2006/2010 4. Close the front flap of the front panel. Make sure the front flap is closed properly to ensure that the connector at the back of the hard drive is firmly connected to the corresponding connector on the backplane board. -
Page 19: Powering Up Smr
3. See if the Network LED has turned green, which indicates power is on and network is connected. 4. See if the HDD LED is on, which means the hard drive can be accessed. Surveon Smart Megapixel Video Recorder Hardware Manual... -
Page 20: Resolution Setting
Surveon SMR2006/2010 3.5. Resolution Setting The default monitor resolution for the SMR is 1280x1024, and if the resolution of your monitor is lower than this value, the following warning message will prompt out. To change the resolution setting, please follow the steps below: 1. - Page 21 5. Choose Single Display as the operating mode and Monitor as the display selection in Display Devices. Change the screen resolution in Display Settings. Click OK to finish. Surveon Smart Megapixel Video Recorder Hardware Manual...
-
Page 22: Storage Management
Surveon SMR2006/2010 3.6. Storage Management Follow these steps to make sure the RAID configuration and initialization are complete before the recording starts. 1. When the SMR is starting up, the VMS Client will start automatically. Use the following default account to login to the VMS. - Page 23 5. RAID initialization will begin when all the hard drives are installed. A warning message will jump out when the initialization is in progress. Click OK. 6. Go back to the Storage Manager to check if the RAID is configured successfully. Surveon Smart Megapixel Video Recorder Hardware Manual...
-
Page 24: Configuring An Ip Address For Nvr Server
Surveon SMR2006/2010 3.7. Configuring an IP Address for NVR Server Before NVR Server can run successfully, an IP address must be properly bundled with it. Note: (1) You may skip these steps if your routing devices have DHCP capabilities. (2) If you don’t set the fixed IP in the VMS Console first, a warning massage will prompt out. -
Page 25: Adding Network Cameras To The Server
Select All box at the bottom of the window to select all the cameras found. Enter the username and password, and press Apply Selected. Click OK to add the selected cameras to the Server. Surveon Smart Megapixel Video Recorder Hardware Manual... -
Page 26: Manually Adding Cameras
Surveon SMR2006/2010 Manually Adding Cameras 1. Right-click the Server entry and select Add Camera. 2. In the Add Camera window, please fill in the following information, and then click OK to add the camera. IP Address Camera Port – This value will automatically populate with the default value for the Vendor and Model selected. -
Page 27: Initializing The Camera
3.9. Initializing the Camera Right click the camera under the NVR Server and then click Initialize. Click Yes. These are settings before and after camera initialization. Surveon Smart Megapixel Video Recorder Hardware Manual... -
Page 28: Setting Up Live View
Surveon SMR2006/2010 3.10. Setting up Live View An important part of monitoring your surveillance network is to have the right views so that you will have the optimum viewing angle to discern a situation. The default view setting is 3x3.
