Surveon EMR2000 Quick Installation Manual

QUICK INSTALLATION GUIDE
Installation
Warning!
Only qualified service personnel should install and service this product in order to avoid risk of injury from
electrical shock and energy hazard.
Observe all ESD (Electro-static Discharge) procedures during installation to avoid damage to the recorder
and its components.
Accessories
HDD Screw x20 (EMR2000 series)
Quick Installation Guide x1 ●
●
HDD Screw x40 (EMR5000/8000 series)
Product DVD x1 (including manuals) ●
●
Power Cord x1
●
User-provide Items
LAN Cable
● Flat blade ● Philips
●
Screwdriver Screwdriver
USB compatible Keyboard and Mouse
●
Monitor
●
(Optional) Hard Drives for extra storage space
●
PC(s) with Windows XP (or above) Used as Remote
●
Milestone Smart Client Management Center
USB Drive Used for Installing Milestone Smart Client on
●
remote PC(s)
1

Hardware Overview

Front View
EMR8000 Series
1 2 3
EMR5000 Series
EMR2000 Series
1 2 3 4 5
4 5
6
7
6
1 LCD Display 4 LED Indicators
2 Enter Switch 5 Power Switch
3 Select Switch 6 Front USB Connector
Note: The function of Video Back Up Button is reserved.
Rear View
EMR8000 Series
EMR5000 Series
EMR2000 Series
1
2
8
2 3
3
4
4
5
5
6
8
8
6
7
1 Power Socket 4 LAN Port x2
7 12V DC Power Port
e-SATA Port x1
2 5 8
Restore Button Kensington Lock-hole
3 USB Port x4 6
VGA Port 9 COM Port
Q M E 2 5 8 0 A U R 1 0
© by Surveon Technology, Inc. All rights reserved.
EMR Desktop Series 2

Adding Hard Drives (Optional)

Hard drives are pre-installed in the EMR series. Users can also add supplementary hard drives and do RAID
configurations themselves. Please refer to the following table for more details.
Numbers of Pre-installed
Model
Hard Drives
EMR2000
EMR5000
EMR8000
Note: (1) You should go to Windows Disk Management to allocate and format the logical drives
.
(set the block size as 64K). You can choose to do this before or after the RAID configration
is done. (2) Please refer to Advanced RAID Configuration section in the EMR Series User
Manual for more details.
Hard Drive Installation Prerequisites
Purchase hard drives having the same capacity and using same interface with the pre-installed ones.
Inserting Hard Drive into Drive Tray
4 5
1. Open the front panel of the EMR system.
2. Press the release button (indicated by the blue arrow)
on the bezel, the bezel panel should open automatically
and gently pull out the hard drive tray.
6
3. Place the hard drive into the drive tray.
7 Video Back Up Button
Make sure the hard drive's interface
connector is the open side of the drive
tray and its label side facing up. Adjust
the drive's location until the mounting
holes in the drive tray are aligned with
those on the hard drive. Secure the drive
with four supplied flat head screws
13
3
4. With the tray bezel open, insert the hard drive and
4
tray into the system enclosure.
6
9
10
5. Close the tray bezel.
5
11
1
12
10 HDMI Port
11 USB Port x2
12 Safety Switch
13 Audio Ports
Default RAID Space for Additional RAID Options for
Hard Drives
Configuration Additional Hard Drives
1 HDD
1 HDD N/A
N/A 0 HDD
2 HDD
N/A 4 HDD RAID0, 1 or above
1 HDD
2 HDD RAID0, 1
3 HDD RAID5
6 HDD
2 HDD RAID1 RAID0, 1 or above
.
Password:
6. Use the small flat blade screw driver to turn the bezel lock
from the unlock to lock position.
N/A
N/A
7. Repeat above steps to install other hard drives.
8. Close the system front panel when you are done installing hard drives.

System Connections

3
Remote Milestone XProtect Smart
Client Management Center
Ethernet Connection
USB Connection
Video/Monitor Connection
Note: Shaded areas are optional devices.
Connect cables to the rear panel ports as follows:
Insert mouse, keyboard to the USB for installing Milestone XProtect Server on the EMR system.
●
Insert the LAN Cable to the LAN Port to a local network where your IP Camera reside.
●
(Connection to analog cameras is also available via an IP encoder).
Connect an external monitor capable of 32 bit or higher color quality to the VGA port to view the
●
Milestone XProtect interface.
4 Powering up E MR
1. Attach the power cable to the power socket on the rear panel.
2. (EMR8000 Series) Make sure the safety switch on the rear panel
LED Indicators
is switched to the "-" side, which means that it is turned on.
3. Press the power switch.
4. See if the system LED
is starting up.
5. See if the network LED
the power is on and network is connected.
LCD Display Power Switch
6. See if the HDD LED
be accessed.
7. (EMR5000/8000 series)
be shown on the LCD screen.
IP Camera(s)
Analog Camera(s)
Internet
IP Encoder
Monitor
SMR Pro
SELECT
ENTER
is blinking, which means that the system
has turned green, which indicates that
is on, which means that the hard drive can
The Server name and the IP address will
/4
1/4
