- Page 1 MACH Installation Series In-Fill Speaker user manual M42i M62i M68i MIW62 MIW62-100 M208i...
- Page 2 The M68i is a full-range speaker with usable bass-output down to 60 Hz; it can be used as a stand-alone box without subwoofer support. All Mach in-fill top-boxes have wide, even dispersion that ensures good coverage in low- ceiling applications.
- Page 3 NSTALLATION A N G I N G B R A C K E T S Custom brackets with horizontal and vertical tilt are available for all top-boxes. • Black hanging bracket for M42i/M62i ............P/N 93943001 • White hanging bracket for M42i/M62i............P/N 93943002 •...
- Page 4 O N N E C T I O N S Always use high quality speaker cable for the best sound quality and system performance. All in-fill models are easily connected using push terminals. For correct polarity, connect the red (+) terminal on the amplifier to the red terminal on the speaker. Likewise, connect the black (-) terminal on the amplifier to the black terminal on the speaker.
- Page 5 PERATION W E E T E R P R O T E C T I O N The tweeters are protected by a thermal protection circuit that increases impedance when the current exceeds a safe level. The increased impedance reduces current to the tweeter, thus protecting it against damage.
- Page 6 ECHNICAL DATA M42i M62i M68i M208i MIW62 Woofer 4" 6 1/2" 8" 2x8" 6 1/2" Tweeter 1" 1" 3/4" none 1" Power handling (IEC) 40 W 55 W 90 W 2x100 W 50 W Power handling (Program) 100 W 160 W 250 W 2x200 W 140 W...
- Page 8 Martin Professional A/S • Olof Palmes Allé 18 • 8200 Aarhus N • Denmark www.martin.dk...
