- Page 1 Touring series User Manual M12T M15T M30T M181T M182T M1201T M1502T...
- Page 2 © 2000 - 2001 Martin Professional A/S, Denmark. All rights reserved. No part of this manual may be reproduced, in any form or by any means, without permission in writing from Martin Professional A/S, Denmark. Revision C Printed in Denmark.
- Page 3 SlingShot top-box as front of house speaker. The M12T and M15T are full range boxes that work well without support from subwoofers. The M30T is a dedicated top-box with a roll-off at around 70 Hz, but with extremely high...
- Page 4 O N N E C T I O N S P A S S I V E M O D E All models in the T-series are connected through the 1+/1-pins on the Speakon® plug in passive mode. Figure 1: Default pin configuration (Passive Mode) The crossover is located directly behind the Speakon®...
- Page 5 A C T I V E M O D E In active mode, the woofers are connected through the 1+/1- pins and the compression drivers through the 2+/2- pins. Figure 2: Active mode pin configuration A C T I V E M O D E W I R I N G ( A L L M O D E L S ) •...
- Page 6 Table 1: Active mode specifications Power handling IEC Crossover Model Driver Impedance point Polarity 2" 125 watt 16 ohm 1.3 kHz Inverted M12T 12" 400 watt 8 ohm 1.3 kHz Normal 2" 125 watt 16 ohm 1.3 kHz Normal M15T 15" 500 watt 8 ohm 1.3 kHz...
- Page 7 R E A K I N P E R I O D As with all quality drivers, the drivers in the Mach T series need approximately 20 hours of operation at 70% output before they will perform fully to specifications.
- Page 8 E R V I C E T O O L S The following tools are required for servicing the speakers. T O P - B O X E S & S T A G E M O N I T O R S •...
