Generac Power Systems 005191-1 Owner's Manual page 39

1 0F3137
2 0F7655
3 0F7656
4 023484N
5 0F4677
6 022152
7 023897
8 0C3990
9 * 043365 REF.
10 036943
11 0C2428
12 029289
13 0A9457
14 057073
15 ** 0D5466 REF.
16 ** 0A7822 REF.
17 022237
18 022241
19 0E9764
20 0C2266
21 0C2454
22 042568
23 022473
24 022097
25 049813
26 0F0699
27 0F7475
28 025433
29 024469
30 067210A
31 022158
32 0E9049B
33 081008
34 077043J
35 0F6156
36 0F7038
37 0F4475
1) UL CIRCUIT BREAKER (FD)
A 0F4811
B 065469
C 0D5573
D 0F0199
E 065960
F 022473
G 022097
H 022127
J 0C2454
2)
A 0D5466
B 039287
C 022145
D 022129
E 045771
F 022473
G 022097
H 0A8261
J 0A7822
* ITEM INCLUDED WITH HARNESS
** ITEM INCLUDED WITH 0D5464B
1 PAN CB CONN BOX
1 STAND, R/H CONRTOL
1 STAND, L/H CONTROL
1 BUSHING SNAP SB-2.5-31
1 ASSY PCB INTERFACE 1PH 240V
2 WASHER LOCK #10
2 WASHER FLAT #10 ZINC
6 SCREW PHTT M4-0.7 X 10 ZYC
BLOCK TERM 20A 8 X 6 X 1100V
2 SCREW PPHM #10/32 X 2
2 SCREW PHTT #6-32 X 1/2 ZYC
1 TAPE ELEC 1/2 FOAM (65.5" LG)
1 DECAL NEUTRAL
2 JUNCTION BLOCK 3/8-16
BUS BAR NEUTRAL BLOCK 390
LUG SLDLSS 600/250-1/0 X 1/4-28
2 WASHER LOCK 3/8
2 NUT HEX 3/8-16 STEEL
1 RAIL SNAPTRACK PCB HOLDER BULK (6"LG)
6 SCREW PHTT M5-0.8 X 16 ZYC
15 SCREW THF M6-1 X 16 N WA Z/JS
2 SCREW HHC M6-1.0 X 20 G8.8
4 WASHER FLAT 1/4-M6 ZINC
2 WASHER LOCK M6-1/4
2 NUT HEX M6 X 1.0 G8 YEL CHR
1 DECAL, SPARE OUTPUT
1 DECAL, T-BLOCK H-100 CUST I/O
1 LUG SLDLSS #6-14 X 13/64 CU
1 SCREW HHTT #10-32 X 3/8 CZ
1 DECAL GROUND LUG
2 NUT HEX #10-32 STEEL
1 ASSY PCB G-PANEL RELAY 12VDC
1 GROMMET 1.25 X .25 X .75
1 CONDUIT FLEX 2.0" ID (36" LG)
1 PLATE WIRE SNGL GALV
1 HARNESS, CONNECTION BOX (NOT SHOWN)
1 ASSY PCB IGN MOD 3.9/3.0/2.5L
1 COVER FD CB STAND C3
1 DECAL DANGER HIGH VOLTAGE
1 CB 0175A 3P 600V S FD6 LL
1 INSULATOR CB FD FRAME 30MIL
4 SCREW SHC 1/4-20 X 4 G8.8 NZ
4 WASHER FLAT 1/4-M6 ZINC
4 WASHER LOCK M6-1/4
4 NUT HEX 1/4-20 STEEL
7 SCREW THF M6-1 X 16 N WA Z/JS
1 BUS BAR NEUTRAL BLOCK 390
1 SCREW HHC M8-1.25 X 45 G8.8 FT
1 WASHER FLAT 5/16-M8 ZINC
1 WASHER LOCK M8-5/16
1 NUT HEX M8-1.25 G8 YEL CHR
2 WASHER FLAT 1/4-M6 ZINC
2 WASHER LOCK M6-1/4
2 SCREW HHC 1/4-28 X 5/8 .625TH
1 LUG SLDLSS 600/250-1/0 X 1/4-28
