Hardware Setup - Congatec conga-SMX8-X Quick Start Manual

1.4

Hardware Setup

Follow the steps below to assemble the hardware:
1. Ensure the hardware is protected from the effects of electrostatic
discharge (ESD).
2. On the carrier board, select the boot source via the DIP switches
M18
#1 #2
ON ON
OFF ON
4. On the carrier board, set
5. Insert the included SD card into the SD card slot of the carrier board.
6. Connect the RS232 adapter cable to the connector on the module.
7. Connect the USB 2.0 to Serial Adapter to the RS232 adapter cable port
labeled "CONSOLE".
8. Mount the cooling solution onto the module. (Final torque: 0.4 Nm)
9. Mount the module onto the carrier board. (Final torque: 0.4 Nm)
10. Connect the conga-LDVI/EPI as shown in the image on the right.
11. Connect a Power Supply Unit (PSU)
12. To start the system, switch the PSU on
Note
1 Boot source selection via DIP switches will not be implemented on Mass
Production (MP) variants.
2 To enable serial downloader mode, set jumper X45 to position 2-3. Fastboot is
currently not supported.
3 An AT PSU is recommended.
4 If an ATX PSU is used in combination with a modified U-Boot, it may be
necessary to push the reset button several times to start the system.
Copyright © 2019 congatec AG
M17 Selected
Boot Source
1,2
#1
OFF SPI flash (default)
ON SD card
DIP switch M12 #1 to OFF (Audio: I²S)
3 to the carrier board.
.
4
1,2 :
