Congatec conga-SKIT/APL Quick Start Manual

Starter kit for congatec smarc 2.0 development
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
conga-SKIT/APL
Starter Kit for congatec SMARC 2.0 Development
Quick Start Guide
Revision 1.5
Copyright © 2017 congatec AG
SKIT_q15
1/8

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the conga-SKIT/APL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Congatec conga-SKIT/APL

Summary of Contents for Congatec conga-SKIT/APL

  • Page 1 Starter Kit for congatec SMARC 2.0 Development Quick Start Guide Revision 1.5 Copyright © 2017 congatec AG SKIT_q15...

  • Page 2: Intended Audience

    In no event shall congatec AG be liable for any Copyright © 2017, congatec AG. All rights reserved. All text, pictures and incidental, consequential, special, or exemplary damages, whether based graphics are protected by copyrights.

  • Page 3: Warranty

    (c) arising from course of performance, course of dealing, or usage of trade. congatec AG shall in no event be liable to the end user for collateral or consequential damages of any kind. congatec shall not otherwise be liable for loss, damage or expense directly or indirectly arising from the use of the product or from any other cause.

  • Page 4: Kit Contents

    LVDS, eDP, DP and HDMI. Additional storage media are available via a SD/MMC socket and 1x SATA 6G. The conga-SKIT/APL also includes an ATX power supply, WiFi antenna with pigtail cable, LVDS adapter, SATA, USB cables, as well as a heatspreader and cooling solution for the module.

  • Page 5: Connecting The Hardware

    ATX power supply PN: 500016 SATA power cable PN: 14000202 conga-SEVAL PN: 007010 conga-SA5 PN: 050031 conga-SA5/i-CSP-B PN: 050051 conga-SA5/i-HSP-B PN: 050053 SATA III cable PN: 48000029 cab-RS232-EVAL PN: 14000200 USB Type-C to Type-A PN: 14000199 Copyright © 2017 congatec AG SKIT_q15...
  • Page 6 Interfaces eDP1 eDP0 SD/MMC PWR_LCD1 PWR_LCD0 LVDS/DSI HDD Power Battery Support CAN1 CAN0 SPIO USB1 + USB0 GbE0 GbE1 USB2 (OTG) DP0 / SPDIF RS232 COM0 SPKR HDMI0 Type Copyright © 2017 congatec AG SKIT_q15...

  • Page 7: Dip Switch Settings

    Carrier eSPI Carrier SPI Module device Remote boot Module eMMC Module SPI SW1 - DIP Selected I2C Address Switch 1 Switch 2 Switch 3 Switch 4 M12 M18 M17 M11 1 2 3 4 Copyright © 2017 congatec AG SKIT_q15...

  • Page 8: Jumper Settings

    X45 - FORCE_RECOV# X56 - Postcode For more information, refer Configuration Configuration Configuration to the conga-SA5 and conga- 12 V Normal operation Enabled SEVAL User's Guide or contact Force recovery mode Disabled congatec technical support. Copyright © 2017 congatec AG SKIT_q15...
