1 Hardware
1.1 Sample Distribution Set Contents
The contents of the conga-SMX8-X (Prototype Revision Y.1) sample
distribution set are listed below:
Part # Rev. Name
007010 C.0 conga-SEVAL
051100 Y.1 conga-SMX8-X/QXP-4G
or eMMC16 (Prototype)
051103 or
conga-SMX8-X/QXP-2G
eMMC16 (Prototype)
051050 X.0 conga-SMX8/i-CSP-B
011115 B.0 conga-LDVI/EPI
033331 A cab-LVDV-DAT-34-15
052147 A cab-LVDV-PWR-10-15
48000023 A RS232 adapter cable
10000285 A MicroSDHC-Card UHS-I
N/A 1.1 Quick Start Guide
1.2 conga-SMX8-X
The conga-SMX8-X (Prototype Revision Y.1) included in this sample
distribution set is a SMARC 2.0 prototype module featuring the NXP
i.MX 8QuadXPlus applications processor, 16 GB HS400 onboard eMMC,
and 4 GB or 2 GB LPDDR4 onboard memory.
For information about the Mass Production (MP) variants, refer to the
datasheet available at www.congatec.com.
Copyright © 2019 congatec AG
Description Qty
Evaluation carrier board for standard 1
SMARC modules based on SMARC
Specification 2.0
SMARC 2.0 prototype module with 1
NXP i.MX 8QuadXPlus applications
processor, 16 GB onboard HS400
eMMC, and 4 GB or 2 GB LPDDR4
onboard memory.
Passive cooling for SMARC 2.0 module 1
conga-SMX8. All stand-offs are bore
hole 2.7 mm.
LVDS to DVI converter board for digital 1
flat panels with onboard EEPROM.
15 cm data cable LVDS to DVI adapter 1
15 cm power cable LVDS to DVI adapter 1
MOLEX 6-pin PicoBlade to 2x D-SUB 9 1
adapter
Kingston industrial SDCIT/EU Class 10 1
8 GB microSD card with SD card adapter
and preinstalled image.
conga-SMX8-X Sample Distribution Set 1
Quick Start Guide
1.2.1

Pinout Description

The conga-SMX8-X (Prototype Revision Y.1) pinout description is available
at the link below. The pinout description lists which signals of the NXP i.MX
8QuadXPlus applications processor are routed to the SMARC connector.
https://git.congatec.com/imx8x_early_access/imx8x_sx8x_pinlist
Note
Contact congatec technical support to get access to this folder.
1.3 conga-SEVAL
The conga-SEVAL (Revision C.0) included in this sample distribution set is
an evaluation carrier board based on the SMARC Specification 2.0.
For information about the conga-SEVAL, refer to the User's Guide available
at www.congatec.com.
