1
Hardware
1.1
Sample Distribution Set Contents
The contents of the conga-SMX8-Mini (Prototype Revision X.2) sample
distribution set are listed below:
Part #
Rev. Name
007010
C.0
conga-SEVAL
051203
X.2
conga-SMX8-Mini/
QC-2G eMMC16
(Prototype)
051250
X.0
conga-SX8M/CSP-B
011115
B.0
conga-LDVI/EPI
033331
A
cab-LVDV-DAT-34-15
052147
A
cab-LVDV-PWR-10-15
48000023
A
RS232 adapter cable
10000355
A
SDHC UHS-I 16 GB
N/A
1.0
Quick Start Guide
1.2
conga-SMX8-Mini
The conga-SMX8-Mini (Prototype Revision X.2) included in this sample
distribution set is a SMARC 2.0 prototype module featuring the NXP i.MX
8M Mini Quad applications processor, 2 GB LPDDR4 onboard memory and
8 GB HS400 onboard eMMC.
For information about the Mass Production (MP) variants, refer to the
datasheet available at www.congatec.com.
Copyright © 2019 congatec AG
Description
Qty
Evaluation carrier board for standard SMARC
1
modules based on SMARC Specification 2.0
SMARC 2.0 prototype module with NXP
1
i.MX 8M Mini Quad applications processor,
2 GB LPDDR4 onboard memory and 16 GB
onboard HS400 eMMC.
Passive cooling for SMARC 2.0 module
1
conga-SMX8. All stand-offs are bore hole
2.7 mm.
LVDS to DVI converter board for digital flat
1
panels with onboard EEPROM.
15 cm data cable LVDS to DVI adapter
1
15 cm power cable LVDS to DVI adapter
1
MOLEX 6-pin PicoBlade to 2x D-SUB 9
1
adapter
Sandisk Extreme 16 GB SD card with
1
preinstalled image.
conga-SMX8-Mini Sample Distribution Set
1
Quick Start Guide
1.2.1
Pinout Description
The conga-SMX8-Mini (Prototype Revision X.2) pinout description is
available under the link below. The pinout description lists which signals
of the NXP i.MX 8M Mini applications processor are routed to the SMARC
connector.
https://git.congatec.com/imx8m_early_access/imx8m_sx8m_pinlist
Note
Contact congatec technical support to get access to the pinout description.
1.3
conga-SEVAL
The conga-SEVAL (Revision C.0) included in this sample distribution set is
an evaluation carrier board based on the SMARC Specification 2.0.
For information about the conga-SEVAL, refer to the User's Guide available
at www.congatec.com.
SX8M_SDS_q12
4/7
