Contents Safety Precautions ........1-2 Settings ............14 General ..........14 Produc overview ........... 3 Audio ............14 Time ............14 Remote cotrol ..........3 Language ..........15 Basic Operations .......... 4 Video ............15 Detect parking brake........ 4 Volume ............ 15 Mute ............ -
Page 3: Safety Precautions
Safety Precautions Thank you for purchasing this product. Please Please don't change the fuse on the power read through these operating instructions cord without professional guidance, using so you will know how to operate your model improper fuse may cause damage to this unit properly. - Page 4 Safety Precautions 1. Never disassemble or adjust the unit without any professional guidance. For details, please consult any professional car shop / dealer for inquiry. 2. If the front panel or TFT monitor is dirty, please use a clean silicone cloth and neutral detergent to wipe off the spot.
-
Page 5: Produc Overview
Product overview Front Panel Notice: The graphic in this manual is for reference only, and may be different from the actual unit. 1. Disc slot 5. Rotary/pushbutton 2. [ ] Button Rotate to adjust volume. Press to eject a disc. Press briefly to activate the MUTE function. -
Page 6: Remote Cotrol
Remote overview Remote control 1. Power & Mute On/Off 2. Fast forward / Station up 3. - 4. Previous / Seek down 5. Play / Pause 6. Stop 7. Fast backward / Station down 8. Preset station (1) 9. Repeat play / Preset station (2) 10. -
Page 7: Basic Operations
Basic Operations Detect parking brake • Connect the cable "BRAKE" to the parking brake switch to view video files on the TFT monitor. Engage the parking brake for viewing videos. • When the parking brake is not engaged, the monitor displays "Warning!!!, Video playback is disabled for your safety. -
Page 8: Eq Menu
Basic Operations EQ Menu The Audio Control feature allows you to easily adjust your audio system to meet the acoustical characteristics of your vehicle, which vary depending on the type of vehicle and its measurements. Proper setting of the Fader and Balance boosts the effects of the cabin equalizer. Select Preset Equalizer 1. -
Page 9: Radio Mode
Radio Mode Tuner TFT Display 1. Current radio band indicator. 2. Return to home menu. 3. Current station frequency. 4. Preset stations list. 5. Shortcut. 6. Band switch. 7. Seek backward Tune backward(long press) 8. Enter frequency directly. 9. Seek forward Tune forward(long press) 10. -
Page 10: Preset Station
Radio Mode Preset Station The unit has 5 bands, such as FM1, FM2, FM3, AM1, AM2, and each band can store 6 stations; the unit can store 30 stations in total. Search Stations Automatically Touch [ ] to search station and store 6 strongest stations in current band automatically. Manual Store 1. -
Page 11: Playback Mode
Playback Mode Load a Disc You can play video, audio or images stored on the following discs: • DVD Video, DVD-R, DVD-RW • VCD • Audio CD, CD-R, CD-RW Note:Ensure that the disc contains playable content. Eject a Disc Press the [ ] key on the front panel to eject the disc. -
Page 12: Dvd Movie Playback
Playback Mode DVD movie playback The car sound system can play video DVDs and VCDs. After inserting the DVD, the playback starts automatically. The DVD menu is displayed. You can navigate in the DVD menu by touching the corresponding buttons in the DVD menu on the screen. After starting the movie via the menu of the DVD, the movie is displayed. - Page 13 Playback Mode Audio playback from DVD/CD, USB or SD After starting a title, the playback menu is displayed. 1. Shortcut. 2. Display the folder/file list. 3. Short press: Previous track. Long press: Fast backward. 4. Pause playback and continue playback. 5.
- Page 14 Playback Mode Video playback from DVD/CD, USB or SD Tap on [ ] to display additional operating options of the playback menu. 6. Select playback language. 7. Display equalizer. 8. Start and end REPEAT function. Repeat mode: Repeat One > Repeat Folder > Repeat All >Repeat Off 9.
-
Page 15: Bluetooth Mode
2. Touch [ ] to search for Bluetooth device with the unit. 3. Start scanning on the Bluetooth device and select the unit “M-DVD4000” 4. Enter default password “0000”. Tip: • The operational range between this unit and a Bluetooth device is approximately 5 meters . -
Page 16: Receive A Call
Bluetooth Mode Receive a Call By default, all incoming calls are received automaticaly. 1. If there is an incoming call, the screen will display incoming call number. 2. Touch the screen to select [ ] or [ Speak into the Bluetooth microphone. NOTE: •... -
Page 17: Settings
Settings General Settings 1. Touch [ ], if necessary. 2. Touch to highlight a setting to display/select an option. General Settings Options Description USA/Asia/Japan/Europe/Europe Radio Region Select one that matches your location. LW/Oirt Distance Select Local to receive only stations with extremely Radio Range strong signal. -
Page 18: Language
Settings Language Settings 1. Touch [ 2. Touch an option repeatedly to select. Language Settings Description OSD Language Select on-screen display language. DVD Audio Select DVD audio language. Options available depending on DVD disc. DVD Subtitle Select DVD subtitle language. Options available depending on DVD disc. DVD Menu Select DVD menu language. -
Page 19: Volume
Settings Calibration When the touch operation is not sensitive or valid, you should calibrate the touch screen using the calibration setting function. Adjust the response positions of the touch panel as followings: 1. Touch [ Start ] to enter. 2. Touch [ Cancel ] to exit. 3. -
Page 20: Other Modes
Other Modes Auxiliary inputs Aux 1 Aux 1 is used for playback of audio/video from an external device connected to the unit through a 3.5mm jack located on the front panel. Aux 2 Aux 2 is used for playback of audio/video from an external device connected through RCA connectors located on the back of the unit. -
Page 21: Specifications
Specifications General Reference Supply Voltage ......................12V Operating Voltage Range ..................... 10.5 - 15.8V Max Operating Current ........................15A Grounding System ..................Car Battery Negative Pole Dimensions(WXHXD) ..................178.5X101.5X166mm Weight(main unit) ........................1.8kg Signal Noise Ratio ........................≥55dB Residual Noise Sensitivity (S/N=30dB) ..................18dBμV Frequency Response (±3dB) .................. -
Page 22: Region Code
Specifications Supported Formats: • USB or memory file format: FAT16,FAT32 • Mp3 bit rate(date rate): 32-320 Kbps and variable bit rate • Directory nesting up to a maximum of 8 levels • Number of albums/folders: maximum 99 • Number of tracks/titles: maximum 999 •... -
Page 23: Troubleshooting
Troubleshooting What appears to be trouble is not always serious. Please check the following points before calling a service center. Problem Cause Corrective action General Unit fuse blown. Install new fuse with correct rating. Unit can not power on Car battery fuse blown. Install new fuse with correct rating. -
Page 24: Wire Connections
Wire Connections Microphone input Radio Antenna CAMERA IN BRAKE AV-Input Left REVERSE AV-Input Rght VIDEO Input LINE Output RL VIDEO OUT SWC 1 SWC 2 SUB Output 2 LINE Output RR SUB Output 1 LINE Output FR P.ANT LINE Output FL ACC (Ignition) Illumination GND (Ground) - Page 25 The manufacturer Aldinet S.p.A declares that the type of radio equipment - Multimedia Navigation Receiver, model M-DVD4000, brand Macrom - complies with the 2014/53 / EU Directive. The full text of the EU Declaration of conformity is available at the following internet address: www.macrom.it or at...
