Washing Machine
We hope it will successfully serve its purpose for many years.
This washing machine was designed for home
use.
It meets all the requirements of modern washing:
it is economical, it uses less water, less energy
and washing agent.
Before Use ...................................................... 19
Tips for Energy Savings
Important....................................................... 20
Removing the Transport Brackets .............. 21
Placing and Installation................................ 21
Connection to the Water Supply
Water Outlet
Connection to Power Supply
The Door ........................................................ 23
Direction of Opening the Door
Preparing the Laundry................................. 24
Type of Fabrics
Colour Fastness
Degree of Soil
Loading
Washing Agents and How Much to Use...... 25
Dispenser
Fabric Conditioner and Starching Agent
Liquid Washing Agents
Washing ......................................................... 27
Control Light
Programme Selection Knob
18
Thank you for your trust and for buying this appliance.
Temperature Selection Knob
Spinning Speed Selection Knob
Timer
Spinning-OFF Knob
Pump Stop Pushbutton
Extra Rinsing Switch
Higher water level Switch
Lower RPM
Half Programme Switch
Cold Wash - Switch
ON/OFF switch
Prepare your machine for washing
After Washing
Table of Washing Programmes.................... 31
Cleaning and Maintenance........................... 31
Housing
Drum Interior
Dispenser
Wire Net in the Inlet Hose
Door Gasket
Filter
Trouble-Shooting Guide ............................... 33
Instructions for Use

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WA1022 and is the answer not in the manual?

Questions and answers

Summary of Contents for Gorenje WA1022

  • Page 1 Washing Machine Thank you for your trust and for buying this appliance. We hope it will successfully serve its purpose for many years. This washing machine was designed for home use. It meets all the requirements of modern washing: it is economical, it uses less water, less energy and washing agent.
  • Page 2: Before Use

    Before Use This instruction manual was prepared for the user of the washing machine. Read the manual carefully and get to know your washing machine so that you will know how to use it safely and correctly. This instruction manual was prepared for various models of washing machine, and they vary in function and design.
  • Page 3 Important toxic gases may be produced. There is also a Before putting the machine into use, don't risk of ignition or explosion. forget to remove the transport brackets. • When washing is finished, remember to close Switching on a blocked machine may damage the tap.
  • Page 4: Removing The Transport Brackets

    Removing the Transport Brackets The washing assembly is blocked with two metal rods which protect the machine during transport (fig.1). • Undo the screws on the rear wall (fig. 2). • Remove the squares, rotate them 180° and use them to pull out the rods (fig. 3). •...
  • Page 5: Water Outlet

    Water Outlet Hook the outlet hose securely over the edge of the washbasin or bath tub. The outlet hose can also be connected directly to the plumbing outlet, the diameter of which should be not less than 4 cm (fig. 7). Wall siphon drain must be correctly fitted in such manner to enable cleaning.
  • Page 6 The Door The door can only be opened two minutes after the washing programme has finished. Open the door by pulling the door handle (fig. 9). When closing the door, push it towards the machine until it locks (fig. 10). If the door is not correctly closed, the machine will not operate.
  • Page 7: Preparing The Laundry

    Preparing the Laundry Sort the laundry before washing according to the Always check the pockets before loading the type, quality, colour and soil degree of the laundry. Remove keys, coins, hair-pins and laundry. similar objects that may clog the water outlet hose.
  • Page 8: Washing Agents And How Much To Use

    Washing Agents and How Much to Use Use only washing powder for machine washing. Too much washing powder causes Use special washing agents for delicate and − bubbling, woollen fabrics. − reduced agitation and washing effect, This washing machine was designed for washing −...
  • Page 9 Liquid Washing Agents (for some models only) If the washing machine is equipped with partition plate, the middle section may also be used for liquid washing agents. Lift the partition plate when using washing powders and push it in when using liquid detergent.
  • Page 10 Washing Before washing, select the washing programme Temperature Selection Knob and prepare the machine for washing. The control panel incorporates various switches Turn the knob clockwise (B knob). pushbuttons selecting washing Washing temperature may be optionally selected programmes, a control light, and a dispenser. up to 95°.
  • Page 11 water is automatically adjusted to the amount of Timer laundry. This guarantees successful (some models only) economic washing, regardless of the amount of Timer is used to preset the time when you want laundry. the machine to start washing. This is specially When washing heavily soiled laundry the convenient for the period when electricity is water level can be increased by pressing this...
  • Page 12: After Washing

    − If your machine is equipped with switches, use them, as appropriate. − Select the washing temperature and spinning speed, if your washing machine is equipped with this option. − Switch the machine on. After Washing − Switch off the machine (the control lamp turns off).
  • Page 14: Cleaning And Maintenance

    Cleaning and Maintenance Wire Net in the Inlet Hose Warning: The wire net in the inlet hose should be frequently - Before cleaning disconnect the machine from cleaned. mains supply. Shut off the water supply and remove the inlet - There is a danger of burning when hot water is hose.
  • Page 15 Filter Filter is located under the cap at the bottom of the machine. If you use the machine correctly, there is no need to clean the filter. You have to open and clean the filter when solid objects trap in it and obstruct the outlet. (The laundry is not rinsed enough, still wet, water is not pumped out of the machine).
  • Page 16: Troubleshooting Guide

    Trouble-Shooting Guide The user can come across troubles appearing result from improper handling of the appliance during the operation of the appliance. We are and can be eliminated by yourself. listing some of troubles, which in most cases Problem: Check the following: −...
  • Page 17 Instructions for Use...
