Gorenje WS53101 Instructions For Use Manual

Hide thumbs

Advertisement

Quick Links

Instructions for Use
Washing machine

Advertisement

loading
Need help?

Need help?

Do you have a question about the WS53101 and is the answer not in the manual?

Questions and answers

Related Manuals for Gorenje WS53101

Summary of Contents for Gorenje WS53101

  • Page 1 Instructions for Use Washing machine...

  • Page 2: Table Of Contents

    Thank you for your confi dence in purchasing our washing machine, and congratulations on the excellent choice. Your new washing machine meets the requirements of modern treatment of laundry. It is rational in the consumption of energy, water and washing agents. Our appliances are friendly to the environment.

  • Page 3: Description Of Washing Machine

    Description of washing machine 1. Front panel 5. Adjustable legs 2. Detergent dispenser 6. Water outlet hose 3. Door (depending on the model) 7. Water inlet hose 4. Filter lid 8. Mains power cable Technical information (depending on the model) •...

  • Page 4: Cautions

    Cautions • Be sure to remove transport brackets prior fi rst use of the appliance. Attempted operation of the blocked machine may result in irreparable damage which is not covered by the manufacturer’s warranty! • When connecting your washing machine to water supply, be sure to use brand new water inlet hose and appropriate sealing gaskets (attached).

  • Page 5: Installation And Connection

    Installation and connection Package removal In removing the wrapping be careful not to damage the appliance with a sharp object. Before connecting the appliance, let it warm up to room temperature (wait for two hours). • Our appliances are packed in environmentally friendly materials which may be recycled, deposited or decomposed without any threat to the environment.
  • Page 6 • If you have a tumble dryer of the same dimensions, you can place it on top of the washing machine. Water inlet connection To ensure correct operation of the appliance, water pressure inlet must be between 0,05 and 0,8 MPa. Minimum water pressure can be established by measuring the quantity of poured out water.
  • Page 7 Water outlet connection • Fix the outlet hose to run into the sink or the bathtub, or connect it directly to the wall drain outlet (diameter min. 4 cm). • Wall drain must be installed properly and must enable occasional cleaning. •...

  • Page 8: Operation

    Operation A - program selector E - easy ironing knob B - MENU knob F - START/PAUSE knob C - SELECTION knob G - door knob (depending on the model) D - quick program knob H - display Program selector Basic programs Partial programs Cotton...
  • Page 9 Before fi rst use - Selecting language To change the language in which the information appear on the display, press simultaneously the key MENU (B) and SELECTION(C), and turn the program selector (A) from position “0” to the fi rst program in clockwise direction (Cotton 95°C).
  • Page 10 Washing machine operation 1. Name of the program, 2. Duration or time of day, 3. Symbols for activation of additional functions, 4. Water quantity in liters, 5. Spin RPM Program is selected by turning the program selector from the “0” position to the desired washing program.
  • Page 11 Synthetics Normally stained shirts, blouses and other polyester and polyamide garments, or a mixture of these fabrics with cotton. For heavily stained resistant color laundry, use program with pre-wash. Delicate This is a program for delicate fabrics (dresses, skirts, blouses) and curtains.
  • Page 12 Easy ironing (selection by separate knob (E)) Gentle tumbling and fi nal spin prevent excessive creasing of laundry. Follow the determined maximum load for particular programs. Suggested reduced load (cotton 3 kg, synthetics 2 kg). Auto-clean (SterilTub) program Run this program to eliminate any impurities, bacteria, and odor from the washing machine.
  • Page 13 Extra rinse/ Clean water sensor This function is for persons, especially sensitive to detergents. Using the SELECTION knob (C) you may select one or two extra rinses, or activate the Clean water sensor (S) - certain models only. By activating extra rinse the display indicates adequately increased quantity of water.
  • Page 14 In case you wish to change or suspend the delayed start after starting the machine with the START knob (F), you may do so by pressing the MENU knob (B). The delayed start appears; using the SELECTION button (C) reset the delay period. Setting the end of program (certain models only) Caution: prior this setting check whether the current time of day...
  • Page 15 - Change settings. - Press the START/PAUSE button (F) and reactivate the child lock. In case you fail press any knob within 15 seconds, the protection is automatically reactivated. Permanent disengagement of the function: a.) During the operation: - Keep the MENU knob (B) pressed for 4 seconds. - Stop the program by pressing the START/PAUSE knob (F).
  • Page 16 - Adding washing and softening agents (see tips for washing and energy saving) • pre-wash compartment • main wash compartment • softener compartment If you do not apply the program which includes the pre-wash feature, you may add washing detergent directly into the drum, using the measuring vessel.
  • Page 17 Low water temperature, low network voltage, and smaller loads of laundry may extend the washing time; the time indicated on the display is constantly adjusted to account for such conditions. - End of operation • Sound signal indicates that you may now open the door of the machine.
  • Page 18 After certain time you may open the door if the water level in the drum is low enough, otherwise you must fi st empty the water (use additional program Pumping water out or Spin MA (models with the door opening by pressing the G knob feature the function which enables you to open the door of the appliance during power failure using special lever, located adjacent to the fi...

  • Page 19: Tips For Washing And Energy Saving

    Tips for washing and energy saving • Before washing sort out the laundry according to the type, degree of dirtiness and color resistance. • Prior selecting the washing program consult the sewn tab with information on a particular piece of laundry (see Maintenance chart on the last page). •...

  • Page 20: Cleaning And Maintenance

    • Insert particularly delicate linen (stockings, delicate female underwear, etc.) into the special bag. • High spin RPM leave less moisture in laundry which dries out much quicker in the tumble dryer, thereby saving energy. Do not put clods of detergent into the soap dispenser as the tube in the washing machine may clog.
  • Page 21 • Wash it under running water using a brush, and dry it. Remove any leftover dried detergent from the bottom of the casing. • Clean the entire rinsing area of the washing machine with a brush, especially the nozzles on the upper side of the rinsing chamber.

  • Page 22: Failures

    • Insert the fi lter back as shown on the picture ( : arrow Fig. and pointer - certain models only), and tighten by turning it in clockwise direction. To ensure good sealing the gasket surface (A) must be dirt free. (depending on the model) Failures If the washing machine identifi...
  • Page 23 Failure Possible cause Remedy The machine does not work Machine is not powered. Check if: (display is not illuminated). • plug is in the socket, • there is power in the socket, • the fuse is OK. ERROR 2 Washing program does not Door is not properly closed.
  • Page 24 Failure Possible cause Remedy Laundry is stained after You used liquid detergent or Use the detergent containing washing. detergent for colored laundry whitener. which does not contain Select the heavily soiled laundry whitener. You selected program, or activate soaking inappropriate program. function.
  • Page 25 Failure Possible cause Remedy ERROR 4 Spinning rpm not reached • rpm sensor disconnected • Turn off the appliance and wait for in the selected program (the • Motor overload due to too a few seconds; machine reports a failure high water level (manual •...

  • Page 26: Tables

    Tables Program chart - 7 kg o WA 73xxx,... (depending on the model) Water cons. Energy cons. Basic programs Type of laundry Cotton 2,31/2,19** Cotton 1,31/1,17** Cotton heavy * 1700 1,33/1,19** Cotton * 0,67 Cotton 0,35 Cotton - quick 17’ 1000 0,17 Synthetics...
  • Page 27 Program chart - 6 kg o WA 63xxx,... (depending on the model) Water cons. Energy cons. Basic programs Type of laundry Cotton 2,10/2,05** Cotton 1,12/1,00** Cotton heavy * 1700 1,14/1,02** Cotton * 0,66/0,64** Cotton 0,27 Cotton - quick 17’ 1000 0,17 Synthetics 0,93/0,91**...
  • Page 28 Program chart WA 63xxx, WA 73xxx,... - 6/7 kg n (depending on the model) Water Energy cons. cons. Basic programs [kWh] Type of laundry Cotton 2,05 2,31 Cotton 1,12 1,12 Cotton heavy * 6/3** 7/3,5** 60 1700 1,14/1,01** 1,33/1,09** Cotton * 6/3** 7/3,5** 40 0,66/0,63** 0,67/0,64** Cotton...
  • Page 29 Program chart WA 64xxx, WA 74xxx,... - 6/7 kg (A-10%) n (depending on the model) Water Energy cons. cons. Basic programs [kWh] Type of laundry Cotton 2,05 2,31 Cotton 1,12 1,12 Cotton heavy * 6/3** 7/3,5** 60 1700 1,02/0,85** 1,19/0,97** Cotton * 6/3** 7/3,5** 40 0,66/0,62** 0,67/0,64**...
  • Page 30 Program chart WA 64xxx, WA 74xxx,... - 6/7 kg o (depending on the model) Water Energy cons. cons. Basic programs [kWh] Type of laundry Cotton 2,10/2,05** 2,19 Cotton 1,12/1,00/** 1,17 Cotton heavy * 1800 1,14/1,02** 1,19 Cotton * 0,64 0,67 Cotton 0,27 0,35...
  • Page 31 Program chart WA 64xxx, WA 74xxx,... - 6/7 kg (A-10%) n (depending on the model) Water cons. Energy cons. Basic programs Type of laundry Cotton 2,05 2,31 Cotton 1,12 1,17 Cotton heavy * 6/3** 7/3,5** 60 1800 1,02/0,85** 1,19/0,97** Cotton * 6/3** 7/3,5** 40 0,66/0,63** 0,67/0,64**...
  • Page 32 Program chart - 5,5 kg / 5 kg / 4,5 kg (slim) o Water cons. Basic programs Type of laundry 5,5/5kg 4,5kg 5,5/5kg 4,5kg 5,5/5kg 4,5kg Cotton 5,5/5 1,95 1,80 Cotton 5,5/5 0,92 0,82 Cotton heavy * 5,5/5 1400 0,95 0,85 Cotton * 5,5/5...
  • Page 33 Program chart - 5,5 kg / 5 kg / 4,5 kg (slim) n Water cons. Energy cons. [kWh] Basic programs 5,5/5kg 4,5kg Type of laundry Cotton 5,5/5 1,95 1,80 Cotton 5,5/5 0,92 0,82 Cotton heavy * 5,5/2,75** 4,5/2,25** 0,95/0,78** 0,85/0,74** 5/2,5** 1400 Cotton *...
  • Page 34 Program chart - 5,5 kg / 5 kg / 4,5 kg (slim) (A-10%) n Water cons. Energy cons. [kWh] Basic programs 5,5/5kg 4,5kg Type of laundry Cotton 5,5/5 1,95 1,80 Cotton 5,5/5 0,92 0,82 Cotton heavy * 5,5/2,75** 4,5/2,25** 0,87/0,72** 0,80/0,64** 5/2,5** 1400...
  • Page 35 Program chart / Additional functions Program Basic programs Cotton   / /     Cotton heavy / /    Cotton - quick 17’  / /   Synthetics   / /   ...
  • Page 36 Maintenance chart Normal wash Max. Max. Max. Max. washing washing washing washing temp. temp. temp. Washing temp. 95°C Manual 60°C 40°C 30°C Delicate wash washing allowed Whitening Whitening in cold water Whitening not allowed Ironing Hot iron max. Hot iron max. Hot iron max.
