Gorenje WA71141 Instructions For Use Manual

Gorenje WA71141 Instructions For Use Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Instructions for Use
Washing machine

Advertisement

loading
Need help?

Need help?

Do you have a question about the WA71141 and is the answer not in the manual?

Questions and answers

Related Manuals for Gorenje WA71141

Summary of Contents for Gorenje WA71141

  • Page 1 Instructions for Use Washing machine...

  • Page 2: Table Of Contents

    Thank you for your confi dence in purchasing our washing machine, and congratulations on the excellent choice. Your new washing machine meets the requirements of modern treatment of laundry. It is rational in the consumption of energy, water and washing agents. Our appliances are friendly to the environment.

  • Page 3: Description Of Washing Machine

    Description of washing machine 1. Front panel 5. Adjustable legs 2. Detergent dispenser 6. Water outlet hose 3. Door 7. Water inlet hose 4. Filter lid 8. Mains power cable Technical information (depending on model) • Max. load: 7 kg / 6 kg •...

  • Page 4: Cautions

    Cautions • Be sure to remove transport brackets prior fi rst use of the appliance. Attempted operation of the blocked machine may result in irreparable damage which is not covered by the manufacturer’s warranty! • When connecting your washing machine to water supply, be sure to use brand new water inlet hose and appropriate sealing gaskets (attached).

  • Page 5: Installation And Connection

    Installation and connection Package removal In removing the wrapping be careful not to damage the appliance with a sharp object. Before connecting the appliance, let it warm up to room temperature (wait for two hours). • Our appliances are packed in environmentally friendly materials which may be recycled, deposited or decomposed without any threat to the environment.
  • Page 6 • If you have a tumble dryer of the same dimensions, you can place it on top of the washing machine. Water inlet connection To ensure correct operation of the appliance, water pressure inlet must be between 0,05 and 0,8 MPa. Minimum water pressure can be established by measuring the quantity of poured out water.
  • Page 7 Connect the appliance to • Plug the mains power cable to the wall mains socket. the mains supply • Required voltage and other information are written on the rating plate above the door opening of the machine. The wall socket must be accessible at all times and must be equipped with an earth lead (in accordance with the local safety regulations).
  • Page 8 This appliance must be earthed! Connect the appliance with the cable and plug to a suitable 13 amp socket which is properly earthed. Required nominal voltage and frequency are indicated on the rating plate. The connection to the mains supply and earthing have to be made according to current standards and regulations.

  • Page 9: Operation

    Operation A - program selector Signal LED’s: B - pump stop knob - ON/OFF (orange) C - START/PAUSE knob - pump stop/failure (green) Program selector Basic programs Partial programs Cotton Pre-wash Rinse Quick program Quick program Synthetics Softening Quick program Delicate Pumping water Wool...
  • Page 10 - Open the door of the machine. Door is opened by pulling the handle (lever) on the right hand side of the door towards you. - Sort the laundry by the type of fabrics. Do the buttons and zippers, tie the strings and pull out the pockets.
  • Page 11 the use of the quick program. This way, you will save both energy and time. Synthetics Normally stained shirts, blouses and other polyester and polyamide garments, or a mixture of these fabrics with cotton. For less stained laundry of this type, use short program. It saves energy and washing time.
  • Page 12 To run the auto-clean program, rotate the program selector knob (A) to the position “Cotton 95°C”, then pressing the (B) (pump stop) key and hold it for three seconds. If you do not regularly use washing program with temperatures over 60°C, it is recommended to run the auto-clean program at least once per month.
  • Page 13 Start the operation • Push the START button (C). The ON/OFF LED stops fl ashing, the machine starts operating after a few seconds. If the door is not properly closed after starting the operation, the ON/OFF LED starts fl ashing again after a few seconds. When you close the door, the machine initiates the selected program.

  • Page 14: Tips For Washing And Energy Saving

    • Failures Program is suspended in case a failure occurs. Signal LED’s are fl ashing (see cf. Troubleshooting). • Power failure At electric cutout the program is interrupted, however, after the power supply has been re-established, the program operation automatically proceeds. If a power failure occurs when the drum is still full of water, be careful not to open the door before you pump the water out.
  • Page 15 Degree of hardness Hardness °dH(°N) m mol/l °fH(°F) p.p.m. scale 1 - Soft < 8,4 < 1,5 < 15 < 150 2 - Medium 8,4 - 14 1,5 - 2,5 15 - 25 150 - 250 3 - Hard > 14 >...

  • Page 16: Cleaning And Maintenance

    Cleaning and maintenance Disconnect the washing machine from the mains before cleaning! • The casing should be cleaned with soft cloth and mild detergent. • The interior of the drum and the door gasket is cleaned by washing at 60°C without laundry and adding half quantity of detergent.
  • Page 17 • Clean the entire rinsing area of the washing machine with a brush, especially the nozzles on the upper side of the rinsing chamber. • Clean frequently the water inlet hose screen under running water. • After each wash wipe the door rubber gasket. This will prolong its useful life.

  • Page 18: Failures

    • Turn it anti-clockwise, pull it out and clean under running water. • Insert the fi lter back as shown on the picture, and tighten by turning it in clockwise direction. To ensure good sealing the gasket surface (A) must be dirt free. Failures The washing machine automatically monitors the execution of particular functions during the operation, and reports any detected failures.
  • Page 19 Interferences from the ambient (for example electrical wiring) could induce signalization of different faults. In such cases: - switch the appliance off, and wait for a few seconds; - switch the appliance back on and repeat the washing program. If the fault repeats, call authorized service shop. Warranty shall not apply in case of failures due to interferences from the environment (lightning stroke, power supply circuit faults, natural disasters).
  • Page 20 Failure Possible cause Remedy FAILURE 7 Water is poorly pumped Water outlet is clogged Check if: out or not at all (machine • the fi lter is clean, reports failure - the LEDs • outlet pipe is not jammed, periodically fl ash seven •...
  • Page 21 Failure Possible cause Remedy FAILURE 1 Program temperature not Temperature sensor • Turn off the appliance and wait for reached (the machine disconnected from the electronic a few seconds; reports a failure - the circuit. • turn the appliance back on and LEDs periodically fl...

  • Page 22: Tables

    Tables Program chart - 7 kg o Water cons. Energy cons. [kWh] Basic program Cotton - white 2,31/2,19**  Cotton - color *  1,33/1,19** Cotton + prewash 1300 1,45/1,32**  Cotton 0,67  Cotton - quick 0,58  Cotton - quick 17’ 1000 0,17 ...
  • Page 23 Program chart - 7 kg n Water cons. Energy cons. [kWh] Basic program Cotton - white 2,31  Cotton - color * 7/3,5**  1,33/1,09** Cotton + prewash 1400 1,32  Cotton* 7/3,5** 0,67/0,64  Cotton - quick 0,58  Cotton - quick 17’...
  • Page 24 Program chart - 7 kg (A-10%)n Water cons. Energy cons. [kWh] Basic program Cotton - white 2,31  Cotton - color * 7/3,5**  1,19/0,97** Cotton + prewash 1400 1,32  Cotton* 7/3,5** 0,67/0,63**  Cotton - quick 0,58  Cotton - quick 17’...
  • Page 25 Program chart - 6 kg o Water cons. Energy cons. [kWh] Basic program Cotton - white 58 2,30/2,10** 2,10/2,05**  Cotton - color * 140/150 52 1,30/1,14** 1,14/1,02**  Cotton + prewash 1300 60 1,50/1,34** 1,34/1,22**  Cotton 52 0,70/0,66** 0,66 ...
  • Page 26 Program chart - 6 kg n Water cons. Energy cons. [kWh] Basic program Cotton - white 2,05  Cotton - color * 6/3**  1,14/1,01** Cotton + prewash 1400 1,22  Cotton* 6/3** 0,66/0,63**  Cotton - quick 0,55  Cotton - quick 17’...
  • Page 27 Program chart - 6 kg (A-10%)n Water cons. Energy cons. [kWh] Basic program Cotton - white 2,05  Cotton - color * 6/3**  1,02/0,87** Cotton + prewash 1400 1,22  Cotton* 6/3** 0,66/0,62**  Cotton - quick 0,55  Cotton - quick 17’...
  • Page 28 Program chart - 5 kg/ 4,5 kg o Basic program 4,5kg 4,5kg 4,5kg 5kg 4,5kg Cotton - white 1,95 1,80  Cotton - color * 0,95 0,85  Cotton + prewash 1400 1,12 0,99  Cotton 0,55 0,51  Cotton - short 0,50 0,46 ...
  • Page 29 Program chart - 5 kg/ 4,5 kg n Basic program 4,5kg 5kg 4,5kg 5kg 4,5kg 4,5kg Cotton - white 152 152 1,95 1,80  Cotton - color* 5/2,5** 4,5/2,25** 60 151 151 0,95/0,78** 0,85/0,74**  Cotton + 1400 181 181 1,12 0,99 ...
  • Page 30 Program chart - 5 kg/ 4,5 kg (A-10%)n Basic program 4,5kg 5kg 4,5kg 5kg 4,5kg 4,5kg Cotton - white 152 152 1,95 1,80  Cotton - color* 5/2,5** 4,5/2,25** 60 151 151 0,87/0,72** 0,81/0,65**  Cotton + 1400 181 181 1,12 0,99 ...
  • Page 32 Maintenance chart Normal wash Max. Max. Max. Max. washing washing washing washing temp. temp. temp. Washing temp. 95°C Manual 60°C 40°C 30°C Delicate wash washing allowed Whitening Whitening in cold water Whitening not allowed Ironing Hot iron max. Hot iron max. Hot iron max.
