Outdoor Tabletop Heater
Model No. GM120-001 and GM120-002
FOR YOUR SAFETY
If you smell gas:
1. Shut off the gas to the
appliance.
2. Extinguish any open
flame.
3. If odour continues,
immediately call your
gas supplier.
Do not store or use gasoline
or other flammable vapour
and liquids in the vicinity of
this or any other appliance.
Important: The installer or seller must leave these instructions with the consumer.
3478-06/13
FOR OUTDOOR USE ONLY
Retain these instructions for future use.
WARNING:
Improper installation,
adjustment, alteration, service
or maintenance can cause
injury or property damage.
Read the instructions
thoroughly before installing or
servicing this appliance.
OPERATES ON LPG
CARBON MONOXIDE HAZARD
This appliance can
produce carbon
monoxide which has
no odour.
Using it in an enclosed
space, eg. boat,
caravan, tent, car,
campervan or house,
may cause death.
CARBON MONOXIDE H
This appliance can produce car
monoxide which has no odour.
Using it in an enclosed space,
caravan, tent, car, campervan
house, may cause death.
Advertisement
Table of Contents
Related Manuals for Gasmate GM120-001
Summary of Contents for Gasmate GM120-001
- Page 1 Outdoor Tabletop Heater Model No. GM120-001 and GM120-002 WARNING: FOR YOUR SAFETY If you smell gas: Improper installation, adjustment, alteration, service 1. Shut off the gas to the or maintenance can cause appliance. injury or property damage. 2. Extinguish any open Read the instructions flame.
-
Page 2: Installation
Installation, Operation and Maintenance Instructions INSTALLATION Combustible materials are considered to be wood, compressed paper, plant fibres, plastic, plexiglas or other Important Safety Rules: materials capable of being ignited and burned. Such materials shall be considered combustible even This appliance must only be used in a well ventilated though flame proofed, fire-retardant treated or plastered. area. Additional clearance may be required for glass, painted 1. This appliance shall not be installed or used indoors, surfaces and other materials which may be damaged by in buildings, garages or any other enclosed area. radiant or convection heat. 2. DO NOT place articles on or against this appliance. 4. The appliance must be located on a solid table which 3. DO NOT use or store flammable materials near this should be situated on a level and adequate footing. appliance. Timber tables are recommended. 4. Children and adults should be alerted to the hazards 5. The gas manifold supply pressure must be regulated of high surface temperatures, burns and clothing... -
Page 3: Safety Features
8. DO NOT use any pressure regulator or hose assembly (2) DO NOT operate appliance without the guards or other than those supplied with the appliance. reflector; Replacement pressure regulator and hose assembly (3) DO NOT shorten post length; must be those specified. Replacement parts may be Clothing or other flammable materials should not be hung obtained from the distributor. from the appliance, or placed on or near the appliance. 9. Installation and use of this appliance must conform with The area above the post may be extremely hot. New Zealand Standard 5601 “Gas Installations”. Direct contact with these metal surfaces should be avoided 10. This appliance is designed to operate with a standard in order to prevent burns or clothing ignition. 9Kg LPG cylinder with Approved Cylinder Connection. Q.C.C. Cylinder Connection Device 11. The valve outlet must be maintained in good condition. When the cylinder is not in use, be sure to cover it with a dust cap. A leak test should be performed with soapy water whenever connecting a new cylinder. NEVER use a flame to test for leaks. -
Page 4: General Assembly
GENERAL ASSEMBLY ASSEMBLY INSTRUCTIONS Connecting & Disconnecting to Gas Source Note: Remove any transit protection material. Tools Required: Phillips head screwdriver IMPORTANT: Before connecting and 2 adjustable spanners disconnecting appliance to gas source, make sure control knob is in ‘OFF’ position. PARTS LIST CAUTION: When the appliance is not in use, the gas must be turned off at the cylinder. Item Description Familiarise yourself with the general information and safety Reflector - M6 Castle Nuts guidelines located at the front of this manual. Reflector Check: Reflector - Washers (6mm Ø) - Page 5 ASSEMBLY INSTRUCTIONS STEP 1 STEP 2 STEP 3 Attach the control housing and base Attach flame screen to the base of Fix the safety guard by inserting the with 4 pcs M5x12 bolts. burner using 3/16” bolts and washers. shanks to the notches on the burner base. STEP 4 STEP 5 Secure the reflector with 3 pcs washers & 3 pcs castle nuts. Connect the gas hose to the heater - see instructions on the next page.
- Page 6 ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS STEP 7 STEP 6 Ensure cylinder valve is in its full off position. Check Turn on the gas cylinder ensuring that the control knob on the outdoor heater is turned OFF at this point. for any damage to either the cylinder connection or the hose.
-
Page 7: Troubleshooting
TEST FIRING THE APPLIANCE Test fire appliance, following the lighting instructions WARNING: White smoke may appear around below. Leak test all gas connections with soapy water. Soap the emitter grid during the first minute of the bubbles indicate gas leakage. DO NOT use a match to test initial firing. for gas leaks. TROUBLE SHOOTING PROBLEM CAUSES REMEDY Burner will not light (a) Air in gas line Purge gas line (b) Blockage in gas line Trace back and clear (c) Igniter not sparking Repair or replace lead, electrode, or piezo button (d) Cylinder turned off Turn on (e) Cylinder empty Install full cylinder (f) Suspect thermocouple Replace (g) Excess flow device activated Ensure control knob is off, close cylinder valve, re-try ignition procedure... - Page 8 – the same principles apply to any other shaped area. Gasmate is a registered trademark of: Sitro Group Australia Pty Ltd www.sitro.com.au ® Gasmate ® is a registered trademark of: Sitro Group Australia Pty Ltd www.gasmate.com.au Aber, Hamilton, N.Z. www.gasmate.co.nz Aber, Hamilton, N.Z. www.gasmate.co.nz...
