- Page 1 Toll Free: 1-888-865-6888 Tel: 510-226-8368 Fax: 510-226-8968 Email: sales@RackmountMart.com...
-
Page 2: Dvi-D Kvm
User Manual LCDK 1070 DVI-D KVM www.rackmountmart.com... - Page 3 Legal Information First English printing, October 2002 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. We are not liable for any injury or loss that results from the use of this equipment.
-
Page 4: Table Of Contents
Contents < Part 1 > LCDK 1070 DVI-D K VM Package contents KVM port connection Specifi cations < Part 2 > Usage KVM Button KVM Hotkey DC power 12V, 24V, 48V Input www.rackmountmart.com... - Page 5 Before Installation ■ It is very important to mount the equipment in a suitable cabinet or on a stable surface. ■ Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive dust, dirt, heat, water, moisture and vibration. Unpacking The equipment comes with the standard parts shown in package content.
-
Page 6: Package Contents
• Mounting set w/ bracket & screws x 1 • Power adapter w/ power cord ( for KVM ) x 1 LCDK 1070 Audio 12VDC Console IP console, remote console, daisy-chain and OSD menu are NOT available for this model. -
Page 7: Kvm Port Connection
< 1.2 > KVM port connection DVI-D KVM USB Servers DVI-D KVM port USB Servers DVI KVM Cable LCD-A3005 : 6 feet DVI KVM cable LCD-A3006 : 15 feet DVI KVM cable ( Server end : DVI-D + USB + Audio ) ( KVM port : DVI-D + USB3.0 ) www.rackmountmart.com... -
Page 8: Specifi Cations
< 1.3 > Specifi cations DVI-D KVM LCDK 1070 KVM Port ▀ Number of ports: Connector: DVI-D connector USB 3.0 connector ( combined for keyboard, mouse & audio ) Connectivity: Combo 4-in-1 KVM cable, 6 or 15 feet Local Console ▀... -
Page 9: Part 2. Usage
Part 2. Usage DVI-D KVM Usage 2.1 KVM Button Power ON ■ Turn off all servers and KVM switches ■ Make sure all cables / connectors are properly connected ■ Recommend Power ON sequence is monitor, KVM switch fi nally computer Front Panel - Port LED Indications DVI-D KVM 12 ports PC port LEDs... -
Page 10: Kvm Hotkey
2.2 KVM Hotkey DVI-D KVM Usage Hotkey Function Scroll Lock + Scroll Lock + Switch to previous port Scroll Lock + Scroll Lock + Switch to next port Scroll Lock + Scroll Lock + Port no. Switch to specifi c port Scroll Lock + Scroll Lock + Auto scan for powered on PC Scroll Lock + Scroll Lock +... -
Page 11: Dc Power 12V, 24V, 48V Input
The company reserves the right to modify product specifi cations without prior notice and assumes no responsibility for any error which may appear in this publication. All brand names, logo and registered trademarks are properties of their respective owners. Copyright 2012 Synergy Global Technology Inc. All rights reserved. www.rackmountmart.com...
