Owner's Manual & Assembly Instructions
WO01
Model No.
715490217
Storage Area: 92 Sq. Ft. 545 Cu. Ft.
8,5 m
2
BUILDING DIMENSIONS * Size rounded o to the nearest foot
*Approx.
Base
Size
Size
10' x 10'
121" x 114 1/2"
3,0 m x 2,8 m 307,3 cm x 290,8 cm
697.68220
Missing Parts, Questions on Assembly?
Call: 1-800-851-1085 or
assist@arrowsheds.com
Do not return to dealer, they are not
equipped to handle your requests.
15,4 m
3
Exterior Dimensions
(Roof Edge to Roof Edge)
Width
Depth
Height
123 1/4"
117"
81 3/8"
313,1 cm
297,2 cm
CAUTION: SOME PARTS HAVE SHARP EDGES. CARE
MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES
TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ
SAFETY INFORMATION PROVIDED IN THIS MANUAL
BEFORE BEGINNING CONSTRUCTION. WEAR GLOVES
WHEN HANDLING METAL PARTS.
Interior Dimensions
(Wall to Wall)
Width
Depth
Height
118 1/4" 111 3/4"
206,7 cm
300,4 cm
283,8 cm
DW1010HG
Door
Opening
Width
Height
80 1/8"
55 1/2"
60"
203,5 cm
141,0 cm 152,4 cm
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Arrow Storage Products DW1010HG
Summary of Contents for Arrow Storage Products DW1010HG
- Page 1 Owner's Manual & Assembly Instructions WO01 Model No. 697.68220 DW1010HG Missing Parts, Questions on Assembly? Call: 1-800-851-1085 or assist@arrowsheds.com Do not return to dealer, they are not equipped to handle your requests. 715490217 CAUTION: SOME PARTS HAVE SHARP EDGES. CARE MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES Storage Area: 92 Sq.
- Page 3 BEFORE YOU BEGIN..Owner's Manual Before beginning construction, check local building codes regarding footings, location and other requirements. Study and understand this owner's manual. Important information and helpful tips will make your construction easier and more enjoyable. Assembly Instructions: Instructions are supplied in this manual and contain all appropriate information for your building model.
- Page 4 PLAN AHEAD..Watch the Weather: Be sure the day you select to install your building is dry and calm. Do not attempt to assemble your building on a windy day. Be careful on wet or muddy ground. Teamwork: Whenever possible, two or more people should work together to assemble your building.
- Page 5 SAFETY FIRST..Safety precautions are important to follow throughout the construction of your building. •Care must be taken when handling various •Practice caution with the tools being used in pieces of your building since some contain the assembly of this building. Be familiar with sharp edges.
- Page 6 CARE & MAINTENANCE..Finish: For long lasting nish, periodically clean and wax the exterior surface. Touch-up scratches as soon as you notice them on your unit. Immediately clean the area with a wire brush; wash it and apply touch-up paint per manufacturer's recommendation. Roof: Keep roof clear of leaves and snow with long handled, soft-bristled broom.
- Page 7 ACCESSORIES..FLOOR FRAME KITS ROOF STRENGTHENING (heavy snow load) KITS Extra roof beams and gable braces designed for added protection against heavy snow accumulation. Increases the strength of your roof. BEFORE AFTER ANCHOR KITS Model No. AK4 MODELS FB47410, FB5465, FB106-A Anchor Kit contains heavy-duty steel FB109-A and FB1014-A augers, 60' (18 m) of steel cable and...
- Page 8 ORDERING ACCESSORIES..02/13 We recommend that you purchase accessory items from your local storage building dealer whenever possible; however, because the full line of accessories is not always available from all dealers, Arrow is o ering them to you on a direct basis. There are two ways to order Arrow Storage Building Accessories: Option 1 Option 2...
- Page 9 Base The Base For Your Building No matter which of the options below you choose for a base, an ARROW ANCHORING KIT is recommended as an e ective method of properly securing your building after assembly is complete. OPTION 1: Directly on ground (earth) Assemble your building directly on level ground (grass, dirt, rock, sand, etc.).
- Page 10 Anchoring Anchoring Down The Building It is important that the entire oor frame be anchored after the building is erected. Below are recommended ways of anchoring. Anchoring into Wood/Post: Arrow Anchoring Kit: (Model No. AK4 or 60298) Use 1/4" (6 mm) Wood Screws. There are 1/4" (6 mm) Recommended for use with any suggested base.
- Page 11 Hardware WO11 ctr Remove from bag of screws and save for the last step 65900A 65004 65923 #10Bx1/2" (13 mm) #8Ax5/16" (8 mm) #8-32x3/8" (10 mm) 65103 Black Screw (8) Screw (356) #8-32 Hex Nut (165) Bolt (165) (Packed with Screws) 65109 67468 66646...
- Page 12 Parts List WO12 ctr Assembly Part Part Quantity Check Key No. Number Description in Carton List 3719 Door Handle Brace 5986 Rear Wall Angle 8576 Right Gable 8577 Left Gable 6015 Side Roof Trim 10497 Horizontal Door Brace 6278 Vertical Door Brace 6403 Door Track Splice 6514...
- Page 13 Assembly by Key No. WO13 ctr 21 21 21 21...
- Page 14 8934 Ramp (1) Step 1 Parts Needed For 9367 Front Floor Frame (2) Floor Frame Assemblies 8936 Rear Floor Frame (2) S14 ctr 9299 Side Floor Frame (4) (15) 9367 The front oor frame is made up of 8934 three pieces. The side floor frames and the rear floor frame are made 9367 up of two pieces.
- Page 15 5986 Rear Wall Angle (2) Step 2 Parts Needed For 9917 Rear Wall Channel (2) Frame Assemblies 9923 Side Wall Channel (4) WO15 ctr 10521 Side Wall Angle (4) 9917 9917 Rear Wall Channel 118 1/8" 300,0 cm The main frame pieces reinforce the walls.
- Page 16 Step 3 Parts Needed For 10518 Roof Beam (8) Roof Beam Assemblies S16 ctr (30) 10518 The roof beams join the two gables and support the roof panels. The main roof beam is made up of four pieces overlapped back to back at 10518 the center.
- Page 17 Step 4 Parts Needed For 6403 Door Track Splice (1) Door Track Assembly 9366 Door Track (2) A17 ctr NOTE: Door Track Splice (painted part) 6403 The door track assembly supports the sliding doors and reinforces the front wall. It is made up of three pieces. Using the door track splice, (painted), join the door track (galvanized) pieces end-to-end as...
- Page 18 Step 5 Front Floor Assembly (1) Parts Needed For Side Floor Assembly (2) Floor Frame Rear Floor Assembly (1) S18 ctr RIGHT REAR 9299 Assemble the four corners of the oor frame using two screws at each corner as shown. At the front corners fasten bolts through from STEP 8936...
- Page 19 Step 6 Parts Needed For 6515 Wall Panel (2) 9373 Front Wall Panel (2) Corners 6514 Corner Panel (4) S19 ctr Narrow Side (38) 6514 Wide Side NOTE The remainder of the building assembly REAR requires many hours and more than one person.
- Page 20 Door Track Assembly (1) Step 7 Rear Wall Angle Assembly (1) Parts Needed For Side Wall Angle Assemblies (2) Frames Rear Wall Channel Assembly (1) WO20 ctr Side Wall Channel Assemblies (2) (54) The main frame pieces give rigidity to the side walls and provide a surface for attaching the gables which sup- port the roof.
- Page 21 Step 8 Parts Needed For 6515 Wall Panel (6) Wall Panels S21 ctr STEP 6515 6515 (84) (15) Each wall panel has a crimped rib 6515 STEP 6515 on one side. The crimped rib should go under the rib of the panel that follows it.
- Page 22 Step 9 Parts Needed For 9369 Door Jamb (2) Front Channel/Door Jamb 9365 Front Wall Channel (2) D22ctr 9365 (18) The door jambs reinforce the door STEP opening and provide an attractive trim. Follow these steps for both INSIDE OF door jambs.
- Page 23 Step 10 Parts Needed For 8576 Right Gable (2) 8577 Left Gable (2) Gable Assemblies 6635 Roof Beam Bracket (4) WO23 ctr Edge Trim (plastic piece) The gables go on top of the front and rear walls to support the roof beams. NOTE The gables are packed nested together and might be mistaken...
- Page 24 Step 11 Parts Needed For Left Gable Assemblies (2) Right Gable Assemblies (2) Gables/Braces 9009 Gable Brace (2) N24ctr (32) Lift and fasten a right and left gable, under angle at corner, to the door track with screws. Hint: On the rear gable, use a bolt and nut at the overlapping rear wall angle.
- Page 25 Step 12 Main Roof Beam (1) Parts Needed For Single Roof Beam (2) Roof Beam/Braces 9204 Roof Beam Brace (2) N25ctr (16) Wrap the weather stripping tape around the two joined edges of the left and right gables. See diagram. Cut the weather stripping to length.
- Page 26 Step 13 Parts Needed For 9086 Right Roof Panel (1) Right Roof Panel WO26 ctr STEP 9087 9086 Installing the roof panels is best done with a step ladder. Begin installing roof panels at the back right corner 7743 7743 of the building.
- Page 27 Step 14 Parts Needed For 9087 Left Roof Panel (1) Roof Assembly 7743 Roof Panel (4) WO27ctr 9087 9086 (10) (40) 7743 7743 Install a left roof panel at the left rear corner of the roof. 7743 7743 Install 4 roof panels in the se- quence and positions shown.
- Page 28 Step 15 Parts Needed For 6869 Ridge Cap (2) 9087 Left Roof Panel (1) Ridge Caps & Panels 9086 Right Roof Panel (1) WO28 ctr STEP Peak Cap (28) (44) 6869 Install 1 ridge cap on the com- pleted roof section using bolts and nuts.
- Page 29 Step 16 Parts Needed For 6015 Side Roof Trim (4) Roof Trim S29 ctr Attach the side roof trim to the lower end of the roof panels on each STEP side of the building using screws at each panel overlap. Side Trim Cap 6015 NOTE...
- Page 30 3719 Door Handle Brace (2) Step 17 Parts Needed For 10475 Right and Left Doors (2) Door Assembly 10497 Horizontal Door Brace (4) D30ctr 6278 Vertical Door Brace (2) (12) The steps on this page tell how to assemble the right door. You will per- form exactly the same procedures for the left door.
- Page 31 Step 18 Parts Needed For Right Door Assembly (1) Door Installation & Adjustment Left Door Assembly (1) A31ctr Horizontal Door Brace Gable Door Track Door Slide From inside the building, put the bottom of the right door assembly (on your left when you are inside the building) behind door jamb into the front frame track.
- Page 32 697.68220 DW1010HG WO32 Anchoring and Floor Frame Anchoring Anchor your building at this time. Floor Frame If you have purchased a Floor Frame Kit you need to install it at this time. SOME FACTS ABOUT RUST 1. Avoid nicking or scraping the coating surface, Rusting is a natural oxidizing process that occurs inside and out.
