22LS660V
®
Guest Interactive Pro:Centric 
TVs
Commercial Mode Setup Guide
Note: Selected features shown in this guide may not be available on all models.
EXPERIENCED INSTALLER
First Use Wizard
pages 16 – 17
Custom Master TV Setup
pages 49 – 51
Cloning Procedures
pages 52 – 58
P/N: 206-4354 (Rev A)
© Copyright 2020 LG Electronics U.S.A., Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pro:Centric 22LS660V and is the answer not in the manual?

Questions and answers

Related Manuals for LG Pro:Centric 22LS660V

Summary of Contents for LG Pro:Centric 22LS660V

  • Page 1 Note: Selected features shown in this guide may not be available on all models. EXPERIENCED INSTALLER First Use Wizard pages 16 – 17 Custom Master TV Setup pages 49 – 51 Cloning Procedures pages 52 – 58 P/N: 206-4354 (Rev A) © Copyright 2020 LG Electronics U.S.A., Inc.

  • Page 2: Safety Warnings

    • Consult the dealer or an experienced radio/TV technician for help. CAUTION: Do not attempt to modify this product in any way without written authorization from LG Electronics U.S.A., Inc. Unauthorized modification could void the user’s authority to operate this product.

  • Page 3: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS Read these instructions. 16. Power Cord Caution: Check the TV specifications in the Owner’s Keep these instructions. Manual to determine power requirements. Heed all warnings. Periodically examine the cord of your appliance, and if its Follow all instructions. appearance indicates damage or deterioration, unplug it, discontinue use of the appliance, and have the cord replaced Do not use this apparatus near water.
  • Page 4 IMPORTANT SAFETY INSTRUCTIONS 26. Keep the product away from direct sunlight. (Continued from previous page) 27. When mounting a TV on the wall, make sure that none of the 21. Outdoor Antenna Grounding electrical cabling bears any of the weight of the TV. Install in If an outside antenna or cable system is connected to the accordance with the manufacturer’s instructions.

  • Page 5: Table Of Contents

    Table of Contents Safety Warnings ........2 Cloning Procedures .

  • Page 6: Commercial Mode Overview

    TV’s CPU or Protocol Translation Controller (PTC), or it resides in a Pro:Centric application or an external device from the solution provider. These TV models support several different operational modes: LG’s Free-To-Guest (FTG) Mode via the TV CPU, Application Tuning Mode (ATM) with Pro:Centric application, or Pass-through Mode (default).

  • Page 7: Ftg Mode

    Commercial Mode Overview (Cont.) Installer Menu To create a Master TV Setup, you will need to know how to access PTC INSTALLER MENU the commercial controller (PTC) Installer Menu and make changes to xxLS660V the default values as required. If necessary, familiarize yourself with CPU - CTV the Installer Menu and how to make and save changes.
  • Page 8 • TV Zoning (including channel restrictions by Zone) and Wi-Fi Zoning options for location-specific configurations. LG’s Cloud Configuration Tool enables you to create an FTG Configuration (.tlx) file, which may be used to configure the CPU for FTG Mode. Configuration utilities enable you to create/edit an FTG Channel Map and configure FTG Installer Menu settings.

  • Page 9: Application Tuning Mode / Pro:centric Direct

    While the TV is in Application Tuning Mode: • Users can still access the Installer Menu using an LG Installer Remote; however, all Installer Menu items will be read-only. • While it is possible to update a TV’s Installer Menu and/or Setup Menu settings locally using a USB memory device / Clone (.tlx) file, any Pro:Centric Direct configuration changes are typically made...
  • Page 10 Commercial Mode Overview (Cont.) ASPECT RATIO Aspect Ratio Function Menu TV Setup Menus Indicates the TV is not in Shows that the TV is in Sound Out Aspect Ratio Pass-through Mode . While Pass-through Mode . 16:9 the TV is in this mode, Audio Mode Just Scan Installer Menu settings can...

  • Page 11: Pro:centric Operation

    Pro:Centric Operation These TV models support LG’s Pro:Centric Java application, as well as the Pro:Centric Direct HTML application. Only one application may be implemented at a time. The following sections provide an overview of the application features and functionality. Interactive Menu Features Both the Pro:Centric Java (GEM) application and the Pro:Centric Direct HTML application enable guests to locate and select television entertainment, check the daily weather, view amenities, etc.
  • Page 12 Pro:Centric Operation (Cont.) Example: Pro:Centric Java (GEM) Application Portal Example: Pro:Centric Direct HTML Application Portal 206-4354...

  • Page 13: Pro:centric Java Application Setup

    TV in Factory Default State When the TV is in a factory default state, LG’s First Use Wizard provides automated or manual options for configuring the TV’s Pro:Centric server settings. See “First Use Wizard” on pages 16 to 17 for further information.

  • Page 14: Pro:centric Direct Html Application Setup

    TV in Factory Default State When the TV is in a factory default state, LG’s First Use Wizard provides automated or manual options for configuring the TV’s Pro:Centric server settings. See “First Use Wizard” on pages 16 to 17 for further information.
  • Page 15 Pro:Centric Operation (Cont.) TV in Application Tuning Mode If the TV is already in Application Tuning Mode, use a Master TV of the same model to create and export a Clone (.tlx) file with the desired settings for Installer Menu items 098 PRO:CENTRIC and 119 DATA CHANNEL.

  • Page 16: First Use Wizard

    • If you plan to create a customized Master TV Setup using the procedure described on pages 49 to 51, be sure to exit the LG First Use Wizard in order to avoid setup conflicts or setting modes that may cause unintended behavior or restrict the custom setup procedure. See also “Initiate Configuration or Exit the First Use Wizard”...

  • Page 17: Initiate Configuration Or Exit The First Use Wizard

    TV Zone, Wi-Fi Zone, Label, and/or Room Number settings, from this point, the EZ-Manager Wizard can proceed through each of the configuration steps with no further user interaction. WELCOME TO LG’S FIRST USE WIZARD Select the desired option, and then select START to continue. Basic Settings Quick settings for basic use (language, network, portal, voice service,...

  • Page 18: Basic Settings Wizard

    Basic Settings Wizard This section describes the configuration options available when you select “Basic Settings” from the First Use Wizard / Welcome screen. You can select the “BACK” button, where available, to check previous settings, as necessary. Note: Each Basic Settings Wizard step is allotted a 10-second time frame after which the wizard proceeds without user interaction.
  • Page 19 Basic Settings Wizard (Cont.) (Continued from previous page) Note: If a cable is not currently connected between the TV and the network and you do not want to configure/complete configuration of network settings at this time, you can select/highlight SKIP, and press OK on the Installer Remote to continue to the next step. Configure a Wired Network Connection NETWORK SETTINGS Configure network settings.
  • Page 20 Basic Settings Wizard (Cont.) (Continued from previous page) Configure a Wireless (Wi-Fi) Network Connection NETWORK SETTINGS Configure network settings. Network Connection Type Wireless (Wi-Fi) Wireless (Wi-Fi) Network Network A Advanced Options Automatically Assign IP Address IP Address 10.1.2.4 BACK NEXT a.
  • Page 21 4. In the Voice Service Coverage screen, use the arrow keys on the Installer Remote to select/ highlight each appropriate field in turn—LG Service Country or Service Area Zip Code—and then press OK. Then, use the up/down arrow keys to select the applicable value from the drop- down list of options for the selected field.
  • Page 22 Basic Settings Wizard (Cont.) (Continued from previous page) 5. The Channel Tuning screen is the final step of the Basic Settings Wizard. CHANNEL TUNING If you intend to run Channel Tuning, first select the tuning band you would like to use. Select the tuning band you would like to use Cable Standard BACK...

  • Page 23: Solution Settings / Ez-Manager Wizard

    Solution Settings / EZ-Manager Wizard This section describes the EZ-Manager Wizard that is initiated when you select “Solution Settings” from the First Use Wizard / Welcome screen. Note: If the Pro:Centric server is configured on the system/network and if no location-specific settings are required in the TV, for example, TV Zone, Wi-Fi Zone, Label, and/or Room Number settings, you can simply turn ON the TV, and once initiated, the wizard will proceed through each of the configuration steps with no further user interaction.

  • Page 24: Zones And Room Number Assignments

    Solution Settings / EZ-Manager Wizard (Cont.) (Continued from previous page) Use the Up/Down arrow keys on the Installer Remote to navigate between options on this screen. • If you do not intend to install a Pro:Centric server on this system and you do not wish to use the wizard’s Zoning, network settings, or USB configuration options, exit the wizard as follows: Select NO PRO:CENTRIC, and then press OK.

  • Page 25: Network Settings

    Solution Settings / EZ-Manager Wizard (Cont.) (Continued from previous page) 1. Complete the appropriate field(s) as described below. Use the Up/Down arrow keys on the Installer Remote to navigate between each of the fields. • Wi-Fi Zone: Enables you to set a Wi-Fi Zone # so that the TV can be configured with a particular access point’s login data for wireless networking.
  • Page 26 Solution Settings / EZ-Manager Wizard (Cont.) (Continued from previous page) 1. Refer to the appropriate subsection(s) below for information on configuring the wired and/or wireless connection(s) between the TV and the network. Configure a Wired Network Connection NETWORK SETTINGS Configure network settings. Network Connection Type Wired (Ethernet) Advanced Options...
  • Page 27 Solution Settings / EZ-Manager Wizard (Cont.) (Continued from previous page) Configure a Wireless (Wi-Fi) Network Connection NETWORK SETTINGS Configure network settings. Network Connection Type Wireless (Wi-Fi) Wireless (Wi-Fi) Network Network A Advanced Options Automatically Assign IP Address IP Address 10.1.2.4 BACK CONNECT a.

  • Page 28: Configure Pro:centric Settings

    Solution Settings / EZ-Manager Wizard (Cont.) Configure Pro:Centric Settings Once you select “NEXT” from the TV Configuration Options screen, the Searching for Pro:Centric Server screen is displayed, and you have the following options: • You can allow the EZ-Manager Wizard to proceed with a series of automated steps to configure the TV for Pro:Centric operation and then to look for the Pro:Centric application and maintenance (E-Z Installation) files to download.
  • Page 29 Solution Settings / EZ-Manager Wizard (Cont.) (Continued from previous page) If the process is successful, no further user interaction is required, though, in some instances, where the option (for example, “NEXT”) is available, you may manually move forward to subsequent steps within the wizard to speed up the process.
  • Page 30 Solution Settings / EZ-Manager Wizard (Cont.) (Continued from previous page) Manual Pro:Centric Configuration 1. With the Searching for Pro:Centric Server screen on display, use the Left/Right arrow keys on the Installer Remote to select MANUAL PRO:CENTRIC at the bottom of the screen, and then press OK.
  • Page 31 Solution Settings / EZ-Manager Wizard (Cont.) (Continued from previous page) 3. Refer to the appropriate subsection below, depending on the Pro:Centric server configuration, to complete the remaining fields. RF Configuration a) In the Media Type field, use the Left/Right arrow keys to select RF. b) In the Data Channel field, use the Left/Right arrow keys to select the RF channel number that will be used by the Pro:Centric server as its data channel.

  • Page 32: Usb Configuration

    Solution Settings / EZ-Manager Wizard (Cont.) (Continued from previous page) Note: With RF configuration, Pro:Centric server data must be present on the RF channel selected as the TV’s Data Channel in order for you to select “NEXT” (you will see a “Data Channel Found”...
  • Page 33 Solution Settings / EZ-Manager Wizard (Cont.) USB Configuration via EZ-Manager Wizard With either the TV Configuration Options or the Zones, Label, and Room Number screen on display, proceed as follows to configure the TV using the USB memory device. 1. Insert the USB memory device with the appropriate file(s) into either of the TV’s USB ports. 2.

  • Page 34: Ez Download Utility

    Ez Download Utility The Ez Download utility, available from the TV Manager, enables you to select multiple files at one time from the files loaded on a USB memory device. You may use this utility to download any one or all of the following to a TV: •...
  • Page 35 Ez Download Utility (Cont.) (Continued from previous page) • If the wizard is displayed, you can access the Ez Download utility via the EZ-Manager Wizard, as indicated above (see “Before You Begin”). However, to continue with this procedure and access the Ez Download utility from the TV menus, exit the First Use Wizard. Then, continue with step 3.
  • Page 36 Ez Download Utility (Cont.) (Continued from previous page) 6. If more than one USB memory device is currently connected to the TV, be sure to select the USB device that contains the file(s) you wish to use. If necessary, use the arrow keys on the Installer Remote to select/highlight the USB DEVICE button at the top right of the screen and press OK.
  • Page 37 Ez Download Utility (Cont.) (Continued from previous page) A list of available files is displayed to the right of the file type fields. In the case of image/ icon files, once you select the initial “Download Image File(s)” or “Download Icon File(s)” option, you will need to also select the appropriate type of image/icon (boot logo image, background image, etc.) before selecting the image/icon file(s) itself/themselves.

  • Page 38: Installer Menu

    Installer Menu descriptions in this document if you are configuring the TV CPU using an FTG Configuration (.tlx) file created using LG’s Cloud Configuration Tool. Refer to the table on pages 40 and 41 for brief descriptions of Installer Menu items. More detailed descriptions follow the table listing.

  • Page 39: Navigating Within The Installer Menu

    Installer Menu (Cont.) As part of the Installer Menu header (in all modes), two 3-character acronyms are displayed to indicate the TV’s current configuration mode. The table below lists all possible mode identifiers for these TV models. Acronym Description CPU-CTV Pass-through Mode with Channel Lineup in CPU CPU-FTG FTG Mode via CPU...
  • Page 40 Installer Menu (Cont.) Installer Menu Items 000 through 069 Item Function Value Range Default Value Brief Description of Function INSTALLER SEQ 0 – 3 Leave default set to 0. Selects the number of hours of inactivity allowed before the TV automatically POWER MANAGE 0 –...
  • Page 41 Installer Menu (Cont.) Installer Menu Items 070 through 122 Item Function Value Range Default Value Brief Description of Function FOR. CH-TIME 0 – 7 Chooses custom foreground color for MPI display characters. BCK. CH-TIME 0 – 7 Chooses custom background color for MPI display characters. If set to 1 and item 028 CH.

  • Page 42: Detailed Descriptions Of Installer Menu Items

    Installer Menu (Cont.) Detailed Descriptions of Installer Menu Items • 000 - INSTALLER SEQUENCE Instant ON without reboot: The TV will not reboot to check for and Specifies entry sequence to the Installer Menu. download updates at turn OFF, with the following exception: the first time the TV is turned OFF after this item is set to 3 or 19, the 0 = 9876 1 = 4321...
  • Page 43 Installer Menu (Cont.) CPUs for FTG Mode. The same applies for the additional Major 008 - MIN VOLUME (Minimum Volume) Channel number range of 128 – 135 in Physical tuning and This function determines the minimum volume level allowable 128 – 999 in Virtual tuning mode. When the TV is in FTG Mode, with the Volume (VOL) Up/Down control.
  • Page 44 Installer Menu (Cont.) 021 - V-CHIP (Parental Control) 035 - HDMI1 ENABLE Set to 1 to activate V-Chip (Parental Control) and have it available Set to 1 to enable HDMI 1 input in DTV Mode. Set to 2 to enable to the end user to filter and control or otherwise restrict program- HDMI 1 input in PC Mode.
  • Page 45 External Speaker (Optical) Disabled direct tune a channel that is not included in the channel lineup. Enabled LG Sound Sync (Optical) Note: This item is not available in the Installer Menu when item Disabled LG Sound Sync (Optical) 028 CH. OVERIDE is set to 1.
  • Page 46 096) is not available in the Installer Menu when item 106 is set to 1. If set to 0 (default), the TV’s MMR (Magic Motion Remote) feature is enabled, and a compatible LG MMR (not supplied) may be used 097 - AUDIO OUTPUT with the TV.
  • Page 47 Installer Menu (Cont.) 107 - BANNER SELECT Note: The Data Channel value also is automatically set to “253” Selects the type of banner to display during channel change. if Media Type is set to “IP” either in the Solution Settings / EZ- Set to 1 for channel label display, plus channel information (full Manager Wizard (see “Solution Settings / EZ-Manager Wizard”...
  • Page 48 Installer Menu (Cont.) Note: This item is not available in the Installer Menu when item 119 DATA CHANNEL is set to 0, except when item 002 AC ON is set to 2, 3, 18, or 19 for Instant ON. Note: The TV clock must be set in order for a Wake For Update event to occur at the precise time of day in accordance with item 121 and item 122 settings.

  • Page 49: Custom Master Tv Setup

    Custom Master TV Setup This section describes how to create a customized Master TV Setup for cloning purposes when the TV is in Pass-through Mode. All cloning (export and import) processes on the TV are performed via USB memory device / “.tlx” file. The Master TV Setup may be exported to a Clone (.tlx) file, which can then be used (i.e., imported) to configure either TVs that are to remain in Pass-through Mode or TVs that are to be configured for FTG Mode.

  • Page 50: Custom Master Tv Setup Procedure

    Custom Master TV Setup (Cont.) Custom Master TV Setup Procedure 1. Turn ON the TV. The next step depends on whether the First Use Wizard appears on the screen when you turn ON the TV: • If the wizard is displayed, the TV is in the required factory default state. Exit the wizard, and then continue with step 2.
  • Page 51 Custom Master TV Setup (Cont.) (Continued from previous page) 4. Set up TV features. On-screen setup menus control the features of the TV. Press MENU PICTURE SETTINGS on the Installer Remote, and select the All Settings Picture menu icon from the Quick Settings Menu to access the advanced TV setup menus.

  • Page 52: Cloning Procedures

    Cloning Procedures Cloning typically refers to the process of using a Master TV Setup to configure a Target TV. This section describes how to save (export) a Master TV Setup and then transfer (import) it to a Target TV using a USB memory device / Clone (.tlx) file. You can also create an FTG Configuration (.tlx) file using the Cloud Configuration Tool and then use the Import Clone File procedure to transfer the configuration to Target TVs.
  • Page 53 Cloning Procedures (Cont.) (Continued from previous page) Note: Ez Download is always selected by default when you initially access the TV Manager. Also, note that Diagnostics is for service use only. TV MANAGER USB 1: Device Name DIAGNOSTICS: ON USB DEVICE Select the desired option below.

  • Page 54: Importing A Clone File

    Cloning Procedures (Cont.) (Continued from previous page) DATA CLONING < 01 USB 1: Device Name EXPORT Select the filename, and then select EXPORT. Import Clone File Export Clone File xxLS660V0UD_.TLX Export progress will be displayed on the screen. This process may take a few minutes. Do NOT remove the USB device while exporting is in progress.
  • Page 55 Cloning Procedures (Cont.) (Continued from previous page) • If you have initiated the EZ-Manager Wizard, you can use the wizard’s “USB Configuration” option to access the TV Manager and complete the import procedure (see “TV Configuration Options” and/or “USB Configuration” on pages 23 and 32, respectively, as necessary). •...
  • Page 56 Cloning Procedures (Cont.) (Continued from previous page) • If the wizard is displayed, you can complete the import procedure via the EZ-Manager Wizard, as indicated above (see “Before You Begin”). However, to continue with this procedure and access the “Import Clone File” option from the TV menus, exit the First Use Wizard. Then, continue with step 3.
  • Page 57 Cloning Procedures (Cont.) (Continued from previous page) 8. If more than one USB memory device is currently connected to the TV, be sure to select the USB device that contains the “.tlx” file you wish to use. If necessary, use the arrow keys on the Installer Remote to select/highlight the USB DEVICE button in the top right corner of the screen and press OK.
  • Page 58 Cloning Procedures (Cont.) (Continued from previous page) 12. When you are ready to continue, select UPDATE on the screen and then press OK on the Installer Remote. Import progress will be displayed on the screen. This process may take a few minutes. Do NOT remove the USB device while importing is in progress.

  • Page 59: Cloud Configuration Tool Overview

    Cloud Configuration Tool Overview This section provides an overview of LG’s Cloud Configuration Tool web application, which is used for FTG Mode configuration. For best results, it is recommended that you access the Cloud Configuration ® Tool using one of the following web browsers: Google Chrome™ 51 or later or Mozilla Firefox ...
  • Page 60 Cloud Configuration Tool Overview (Cont.) (Continued from previous page) • If you are creating an FTG Configuration file from scratch and this is your first time using the Cloud Configuration Tool, you may wish to select the Wizard Setup, which will guide you through the essential steps of creating the file, i.e., creating the FTG Channel Map and/or the Installer Menu profile(s).
  • Page 61 Cloud Configuration Tool Overview (Cont.) (Continued from previous page) 3. If you need to edit the FTG Channel Map from an existing file (see previous step) or create a new FTG Channel Map, click on CHANNEL MAP in the menu options bar at the top left of the page to access the Channel Map web page (see example on page 63), and edit/create the FTG Channel Map.

  • Page 62: File Manager Web Page Overview

    Cloud Configuration Tool Overview (Cont.) File Manager Web Page Overview The File Manager page (displayed after you select ADVANCED SETUP from the Welcome page) enables you to compile, modify, and save (export) FTG Configuration (.tlx) files. The following example provides an overview reference of the functions available on the File Manager page. Data contained in uploaded FTG Data to be saved in the FTG Configuration (.tlx) file.

  • Page 63: Channel Map Web Page Overview

    Cloud Configuration Tool Overview (Cont.) Channel Map Web Page Overview On the Channel Map page, you can create, view, and edit a Logical Channel Map. Click the appropriate button to Search for existing channels or add a new RF or IP channel to clear the FTG Channel Map.

  • Page 64: Installer Menu Web Page Overview

    Cloud Configuration Tool Overview (Cont.) Installer Menu Web Page Overview Load default Installer Menu for selected model. Assign Zone as applicable. Once you click on CREATE (Advanced Setup only) Cloud PROFILE, this Installer Menu profile will be listed under Configuration Tool menu bar the Installer Menu Profile List, and Installer Menu items provides access to all utilities.

  • Page 65: Ip Environment Setup

    Master TV Setup for cloning purposes (see Master TV Setup procedure on pages 49 to 51), all IP Environment settings, with the exception of wired network (Ethernet) settings, LG Connect settings, the TV name (editable in the Media Share Menu), and SoftAP settings, may be cloned.
  • Page 66 IP Environment Setup (Cont.) Configuring a Wired Network Connection Note: If desired, you can configure both wired and wireless NETWORK SETT... connections. However, note that a wired connection is always Network prioritized over a wireless connection. That is, when the TV is turned Network / OFF and then back ON, if a Local Area Network (LAN) is detected Pro:Centric...
  • Page 67 IP Environment Setup (Cont.) (Continued from previous page) • When all Edit fields are set as required, use the arrow keys on the Installer Remote to select Connect and press OK. At the top of the screen, you will see a progress display that indicates status as each network element is confirmed (see example on previous page).
  • Page 68 LG Connect requires that both the TV and the mobile device be on the same Wi-Fi network. This menu option enables you to turn LG Connect either on or off. It also allows you to delete all existing stored device pairings.
  • Page 69 IP Environment Setup (Cont.) IP Stream Control If necessary, due to an audio and/or video stream delay, IP Stream Control options enable you to compensate for synchronization irregularities by allowing audio PTS and video PTS offset modifications. This menu also enables you to specify the IGMP version (2 or 3). Note that any modifications to these settings should be performed by qualified personnel only.

  • Page 70: Pro:centric Setup

    IP Environment Setup (Cont.) VLAN ID Setup The VLAN ID option enables you to turn VLAN ID either on or off. It also allows you to specify a VLAN ID for the LAN and Aux LAN ports. 1. With the Network Menu on display, use the arrow keys on the Installer Remote to select VLAN ID.
  • Page 71 IP Environment Setup (Cont.) (Continued from previous page) While the Pro:Centric application itself is an additional feature (see step 4), the appropriate Pro:Centric server configuration must be completed to enable TV E-Z Installation (boot logo, configuration, and software) data downloads and, if configured, the Pro:Centric application download.

  • Page 72: Portal Settings

    IP Environment Setup (Cont.) (Continued from previous page) For each data entry field: Use the arrow keys to select the field and press OK. Then, you can either use the number keys on the Installer Remote to direct enter data values, or you can use the arrow keys to select the appropriate number(s)/alphanumeric character(s) from the pop-up virtual keyboard displayed at the bottom of the screen.
  • Page 73 Follow on-screen instructions to complete the setup. Note: For further information on the portal settings and options, please contact your LG representative. Pre-loaded Applications This option allows you to select which of the pre-loaded application icons to display in the TV’s Smart Launcher, which appears along the...

  • Page 74: Media Share Setup

    : Allows guests to use the TV to access and view ® data shared by DLNA Certified devices connected to the same LAN as the TV or by wireless LG devices using LG’s Smart Share ® application with Wi-Fi Direct ®...
  • Page 75 IP Environment Setup (Cont.) (Continued from previous page) • DIAL (Discovery and Launch): Allows guests to play selected application media on the TV from a device with DIAL capability. The device may be used to cast any application for which a TV-compatible application has been created/selected for inclusion in the Pre-loaded Apps Menu (e.g., YouTube—see also “Pre-loaded Applications”...
  • Page 76 IP Environment Setup (Cont.) (Continued from previous page) Note: Depending on your Security Type selection, additional fields will be displayed, for example VLAN ID for WPA2-PSK and Open security and Radius Server IP, Radius Server Port, and Radius Server Key for WPA2-Enterprise security. Direct enter the appropriate value(s), as required.
  • Page 77 IP Environment Setup (Cont.) (Continued from previous page) • the arrow keys to select the appropriate alphanumeric characters from the pop-up virtual keyboard displayed at the bottom of the screen. When you are done, select Enter from the virtual keyboard, and then press OK on the Installer Remote. •...

  • Page 78: Device

    Reference: Updating TV/PTC Software using a USB Memory Device This section describes how to update TV (CPU) and/or PTC software using the TV Manager “Update TV Software” and/or “Update PTC Software” option(s), respectively, though you may also use the Ez Download utility to update software, if desired. See “Ez Download Utility” on pages 34 to 37 for further information.
  • Page 79 Reference: Updating TV/PTC Software using a USB Memory Device (Cont.) (Continued from previous page) TV MANAGER USB 1: Device Name DIAGNOSTICS: ON USB DEVICE Select the desired option below. Ez Download Data Cloning Image Download Icon Download Software Update 6. Use the arrow keys to select Software Update, and then press OK. 7.
  • Page 80 Reference: Downloading Images or Icons using a USB Memory Device This section describes how to download the image types listed below using the TV Manager “Image Download” or “Icon Download” options, though you may also use the Ez Download utility to download the image(s), if desired.
  • Page 81 Reference: Downloading Images or Icons using a USB Memory Device (Cont.) Before You Begin • The image file(s) must be stored in a folder named “LG_DTV” in the root directory of the USB memory device. • Ensure the USB device has been formatted with FAT format. Download the Image(s) 1.
  • Page 82 Reference: Downloading Images or Icons using a USB Memory Device (Cont.) (Continued from previous page) 6. Use the arrow keys to select Image Download or Icon Download, as applicable, and then press OK. Depending on your selection in the previous step, either the Image Download or Icon Download screen will be displayed.

  • Page 83: Power Consumption Settings

    Reference: Power Consumption Settings The following tables assume that Installer Menu item 099 BACK LIGHTING is set as shown below (default value is 255). 22LS660V Item 099 Power Percent Back Lighting (Static) Consumption (Watts) Savings 28.0 27.1 26.3 25.2 24.3 23.2 22.1 21.2...

  • Page 84: Tv Aux Input Configuration

    Reference: TV Aux Input Configuration ENABLE MPI DATA MPI DATA DATA STATUS DATA STATUS DIRECT ACCESS STATUS TYPE TYPE 0xD2 TYPE 0x0D Tuning Installer Installer Menu 0x41 SOURCES CURRENT AV Menu Item ENABLED (R/W) SOURCE (R) SOURCE (R) 046 START AUX SRCE Installer Installer...

  • Page 85: Auto Input(S) Sensing Feature

    Reference: Auto Input(s) Sensing Feature This section provides detailed settings information for Installer Menu item 042 AUTO INPUTS. To disable auto-sensing for all available Aux inputs, set item 042 to 0. To enable auto-sensing for all available Aux inputs, set item 042 to 255. For specifications on all other available settings (i.e., settings for individual inputs), refer to the Aux Inputs Values table on the following page.
  • Page 86 Reference: Auto Input(s) Sensing Feature (Cont.) The following table shows all available Aux inputs as if each is enabled in the Installer Menu. The Installer Menu text codes for item 042 will be altered accordingly if any of the available Aux inputs are disabled in the Installer Menu.

  • Page 87: Restoring Factory Defaults On The Tv(S)

    This section describes how to restore a single TV, regardless of its mode, to a factory default condition. The following procedure requires that you contact LG technical support to obtain a predefined value/ password for Installer Menu item 117 FACT DEFAULT that enables access to initiate a factory “IN-STOP”...

  • Page 88: Using The Tv's Zoning Features

    Reference: Using the TV’s Zoning Features This section describes the TV Zoning and Wi-Fi Zoning features available with the LS660V model TVs. These features are primarily intended for use when the TV is configured for FTG Mode operation; however, Wi-Fi Zoning, along with selected elements of TV Zoning (Installer Menu and Setup Menu profile Zone assignments), may also be used with TV cloning processes using a Clone (.tlx) file.
  • Page 89 Reference: Using the TV’s Zoning Features (Cont.) Note: While a channel can be restricted from up to eight Zones, a TV can only ever be in (set for) one Zone. See also the Channel Map web page overview on page 63. At the same time, keep in mind that the TV Zone designations are not mutually exclusive.
  • Page 90 Reference: Using the TV’s Zoning Features (Cont.) Using the Wi-Fi Zoning Feature with Cloning Configuration A location-specific Wi-Fi configuration / Clone (.tlx) file may be saved (exported) from a Master TV and then be used to configure Target TVs. First, the wireless network (i.e., the access point login data) must be configured in the Master TV’s IP Environment Menu (see “Configuring a Wi-Fi Network Connection”...
  • Page 91 Reference: Using the TV’s Zoning Features (Cont.) (Continued from previous page) • Label: Allows you to select a North, South, East, or West text label for this TV. Select/highlight the Label field and press OK. Then, use the Up/Down arrow keys to select the applicable label. Press OK when you are finished.

  • Page 92: Using Media Share Features

    Smart Share with Wi-Fi Direct The following steps describe how to access and use Wi-Fi Direct (i.e., to connect to a wireless LG device). Remember that you must also turn on Wi-Fi Direct and launch the Smart Share application on the LG device.
  • Page 93 GENERAL WI-FI DIRECT Picture Picture General / REFRESH LIST Sound Sound Language [TV]LG Smart TV Note: The example at left Location shows the General Menu when Channels Channels Room Info the TV is in Pass-through Mode. Time & Date The Wi-Fi Direct screen is the...
  • Page 94 Reference: Using Media Share Features (Cont.) Screen Share (Miracast / WiDi) The following steps describe how to access and use the Miracast / WiDi features. Note: This procedure describes how to access Screen Share from the TV’s Smart Launcher. If the TV is not in Pass-through Mode, it is also possible to access Screen Share from the TV’s General Menu.
  • Page 95 Reference: Using Media Share Features (Cont.) (Continued from previous page) 3. When you initially access the Wi-Fi Service screen, the Off/On toggle button at the top right of the screen is selected/highlighted by default. If Wi-Fi Service is currently off, press OK on the Installer Remote to turn on Wi-Fi Service.

  • Page 96: Ls660V Rear And Side Jack Panels

    Reference: LS660V Rear and Side Jack Panels AUX LAN & LAN OPTICAL DIGITAL AUDIO OUT Use for video IP and/or network Use for amps and home theater connections. systems. Note: When the TV is OFF, this port is not enabled. HDMI IN 1 Connection for HDMI output from RS-232C IN (CONTROL &...

  • Page 97: External Stereo Speaker Specifications

    Reference: External Stereo Speaker Specifications The SPEAKER OUT / LINE OUT 3.5 mm stereo jack on the LS660V rear panel provides stereo speaker signal outputs (fixed speaker, variable speaker, or fixed line level [amplifier]) for external audio equipment. Set Installer Menu item 097 AUDIO OUTPUT as required in accordance with external audio equipment connected to the TV.

  • Page 98: Installer Remote Control Typical Key Functions

    Reference: Installer Remote Control Typical Key Functions The LG Installer Remote is supplied with and dedicated to operate the TV. The LG Installer Remote illustrated below shows typical remote control functions and is provided for reference only. This Installer Remote may vary from the Installer Remote supplied with the TV.

  • Page 99: Tlt Communication Parameters

    Reference: TLT Communication Parameters RS-232C Configuration RS-232C IN (CONTROL) Port Pin Configuration RS-232C IN (CONTROL) Pin Number Description DB9-Male Serial Port on TV 3.5 V IR Data Pass-through * No Connection No Connection No Connection No Connection * Normally low signal with logic high pulses. If your configuring device has a DB9-Male serial port, use a DB9-Female to DB9-Female null-modem (crossover) cable to connect the device to the TV.
  • Page 100 Reference: TLT Communication Parameters (Cont.) Transmitting / Receiving Protocol This communication protocol transmits and receives 1-byte ASCII data representation for each Command, Set ID, and Data character. Therefore, a standard ASCII terminal program can be used to send and receive the protocol.
  • Page 101 Reference: TLT Communication Parameters (Cont.) Data Conversion (Hexadecimal : Decimal) In cases where decimal values are shown in commands, refer to following conversion examples to enter the [Data] value in the terminal program as hexadecimal. Note: The Channel Tune (ma) Command uses two-byte hexadecimal values ([Data]) to represent the channel number.
  • Page 102 Reference: TLT Communication Parameters (Cont.) Acknowledgment Acknowledgment [e][ ][Set ID][ ][OK/NG][Data][x] [j][ ][Set ID][ ][OK/NG][Data][x] 10. Sharpness (Command: k k) 05. Volume Control (Command: k f) To adjust the screen sharpness. To adjust volume. Command Structure Command Structure [k][k][ ][Set ID][ ][Data][CR] [k][f][ ][Set ID][ ][Data][CR] Data Min: 00 to Max: 32 Data Min: 00 to Max: 64...
  • Page 103 Reference: TLT Communication Parameters (Cont.) 14. Color Temperature (Command: x u) [Data1  –   4 ]: Major/Minor Channel number − Data1 & Data2: xx (Don’t care) To adjust color temperature. − Data3 & Data4: xx (Don’t care) Command Structure [Data5]: Input Source (Analog) −...
  • Page 104 Reference: TLT Communication Parameters (Cont.) 20. Input select (Command: x b) Acknowledgment To select input source for main picture.  * [a][ ][Set ID][ ][OK][Data 0][Data1] Command Structure [Data2][Data3][Data4][Data5] [x][b][ ][Set ID][ ][Data][CR] [x][a][ ][Set ID][ ][NG][Data0][x] Data 00: DTV 01: CADTV 17.
  • Page 105 Reference: TLT Communication Parameters (Cont.) Key Codes The following table provides key codes for a typical LG Installer Remote. Note: Some keys are not applicable to all models. Code Function Code Function (Hexa) (Hexa) PAGE (Green) PAGE (Red) (Yellow) (Blue)

  • Page 106: Troubleshooting

    If applicable, connect MPI cable to MPI device. Weak batteries. Replace batteries. Wrong battery polarity. Check that “+” and “-” match in battery compartment. Too much light in room. Dim room light. Wrong Installer Remote. Requires compatible LG Installer Remote. Contact your LG representative. 206-4354...

  • Page 107: Commercial Mode Check

    Troubleshooting (Cont.) Commercial Mode Check Use this flowchart to determine whether the TV is currently in Commercial Mode. Press POWER on Installer Remote. connected Plug into AC TV turned to AC Power outlet. Power? Leave the TV set ON, and press MENU SETTINGS on the Installer Remote.

  • Page 108: Glossary Of Terms

    HTML) application. Refers to a particular commercial mode of of physical channels (for example, an FTG Pro:Idiom operation within an LG TV. See also FTG Channel Map). This allows digital channels, Zenith proprietary security software that Mode. like analog channels, to be tuned without re- unlocks access to premium content to help quiring the dash key.

  • Page 109: Notice

    In addition to the source code, all referenced license terms, warranty disclaimers and copyright notices are available for download. LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping and handling) upon e-mail request to opensource@ lge.com.

  • Page 110: Back Cover

    Pro:Idiom is a registered trademark of Zenith Electronics LLC. Pro:Centric, Smart Share, and the “LG” logo are registered trademarks of LG Electronics Inc. DLNA Certified is a registered trademark of Digital Living Network Alliance. Intel is a registered trademark of Intel Corporation in the U.S.
